Analyses on failure modes and effectiveness of the prevention measures of Jianchuandong dangerous rock mass in the Three Gorges Reservoir area
-
摘要:
本文以三峡库区箭穿洞危岩体为例，对涉水厚层危岩体的变形破坏模式和防护措施进行了研究。根据现场调查和长期监测数据可知，干湿循环作用下基座岩体的劣化是加速箭穿洞危岩体变形破坏的主导因素，并判定其破坏模式为基座滑移式崩塌。在此基础上，将危岩体的防护治理定为两部分，分别是基座软弱岩体的补强加固，以及中上部危岩体的锚索加固。通过数值模拟对防护前后危岩体的位移场以及应力场进行了分析，结果表明危岩体上部的锚索加固能够有效控制岩体的变形，基座补强能够有效控制危岩体的最大剪应力，综合防护可以显著提高箭穿洞危岩体的稳定性。该防护措施的理念及方法，可以为库区涉水危岩体的治理提供重要的参考价值。
Abstract:In this paper, the Jianchuandong dangerous rock mass in the Three Gorges Reservoir area is taken as an example to study the failure mode and protection of submerged thick-layer dangerous rock mass. Based on field investigation and the monitoring data, it was found that the degradation of the base rock mass under the dry-wet cycles is the main factor to accelerate the deformation of the dangerous rock mass. Its failure mode is determined as slip collapse. According to the deformation and failure characteristics of the dangerous rock mass, the corresponding treatment measure is divided into two parts, inculding the reinforcement of the weak base rock mass, and anchor cable in the upper part of the dangerous rock mass. By comparing the displacement field and the stress field before and after protection, it is found that the prestressed reinforcement of the upper dangerous rock mass can effectively control the deformation of the rock mass, and the reinforcement of base rock mass can effectively control the maximum shear stress of the dangerous rock mass. The comprehensive protection effect is significant to ensure the stability of dangerous rock mass. The protection method can provide important reference for the treatment of submerged dangerous rock mass in the reservoir area.
-
-
表 1 泥质条带灰岩力学参数
Table 1. Mechanical parameters of marlstone under dry-wet cycles in the Three Gorges Reservoir area
干湿循环次数 单轴抗压强度 抗拉强度 /MPa 抗剪强度 变形参数 天然状态/MPa 饱和状态/MPa 内摩擦角/(°) 黏聚力/MPa 弹性模量/(104 MPa) 泊松比μ 0 19.07 13.24 1.10 32.6 3.36 0.405 0.30 5 18.39 12.25 0.99 32.2 3.16 0.373 0.31 15 16.96 11.10 0.89 31.8 2.91 0.351 0.32 20 16.22 10.44 0.83 30.1 2.83 0.272 0.33 30 14.98 9.67 0.79 28.4 2.76 0.238 0.35
下载: 导出CSV
表 2 有限元数值计算岩体参数
Table 2. Mechanical parameters of the marlstone used in the numerical simulation
岩性 本构模型 弹性模量/MPa 泊松比 容重/(kN·m−3) 黏聚力/MPa 内摩擦角/（°） 灰岩（基岩） 摩尔库伦 47800 0.26 27.20 5.21 44.4 灰岩（消落带） 摩尔库伦 42000 0.24 24.50 4.82 40.2 泥质条带灰岩（消落带） 摩尔库伦 27200 0.33 26.50 1.79 37.6 泥质条带灰岩（水上基岩） 摩尔库伦 40500 0.30 26.60 2.36 37.6 水上灰岩（基岩） 摩尔库伦 50400 0.28 27.10 5.48 44.4 平硐（充填） 摩尔库伦 27000 0.20 24.20 3.18 48.6 砂浆锚杆 弹性 196000 0.28 78.50 − − 预应力锚杆 弹性 196000 0.28 78.50 − − 板肋式锚杆挡墙 弹性 27000 0.25 23.00 − −
下载: 导出CSV
-
[1] HUNGR O, EVANS SG. The occurrence and classification of massive rock slope failure[J]. Felsbau—Rock and Soil Engineering,2004(22):16 − 23.
[2] HUNGR O, LEROUEIL S, PICARELLI L. The Varnes classification of landslide types, an update[J]. Landslides,2014,11(2):167 − 194. doi: 10.1007/s10346-013-0436-y
[3] YIN Y P, SUN P, ZHU J L, et al. Research on catastrophic rock avalanche at Guanling, Guizhou, China[J]. Landslides,2011,8(4):517 − 525. doi: 10.1007/s10346-011-0266-8
[4] XING A G, WANG G H, YIN Y P, et al. Investigation and dynamic analysis of a catastrophic rock avalanche on September 23, 1991, Zhaotong, China[J]. Landslides,2016,13(5):1035 − 1047. doi: 10.1007/s10346-015-0617-y
[5] FENG Z, LI B, HE K. Rock collapse mechanism on high-steep slopefailure in sub-horizontal thick-bedded mountains[J]. Journal of Geomechanics,2014(20):123 − 131.
[6] FENG Z, LI B, YINY P, HE K. Rockslides on limestone cliffs withsubhorizontal bedding in the southwestern calcareous area of China[J]. NatureHazards and Earth System Sciences,2014(14):2627 − 2635.
[7] YIN Y P, HUANG B L, LIU G N, et al. Potential risk analysis on a Jianchuandong dangerous rockmass-generated impulse wave in the Three Gorges Reservoir, China[J]. Environmental Earth Sciences,2015,74(3):2595 − 2607. doi: 10.1007/s12665-015-4278-x
[8] YIN Y P, HUANG B L, WANG W P, etal. Reservoir-induced landslides and risk control in Three Gorges Project on Yangtze River, China[J]. Journal of Rock Mechanics and Geotechnical Engineering,2016,8(5):577 − 595. doi: 10.1016/j.jrmge.2016.08.001
[9] 赵海林, 黄波林, 张全, 等. 柱状危岩体崩塌产生涌浪的物理试验与数值模拟分析[J]. 地质力学学报,2020,26(4):500 − 509. [ZHAO Hailin, HUANG Bolin, ZHANG Quan, et al. Physical experiment and numerical model analysis of surge caused by collapse of columnar dangerous rock mass[J]. Journal of Geomechanics,2020,26(4):500 − 509. (in Chinese with English abstract) doi: 10.12090/j.issn.1006-6616.2020.26.04.043
[10] 邓华锋, 肖瑶, 方景成, 等. 干湿循环作用下岸坡消落带土体抗剪强度劣化规律及其对岸坡稳定性影响研究[J]. 岩土力学,2017,38(9):2629 − 2638. [DENG Huafeng, XIAO Yao, FANG Jingcheng, et al. Shear strength degradation and slope stability of soils at hydro-fluctuation belt of river bank slope during drying-wetting cycle[J]. Rock and Soil Mechanics,2017,38(9):2629 − 2638. (in Chinese with English abstract)
[11] WANG X G, WANG J D, GU T F, et al. A modified Hoek-Brown failure criterion considering the damage to reservoir bank slope rocks under water saturation-dehydration circulation[J]. Journal of Mountain Science,2017,14(4):771 − 781. doi: 10.1007/s11629-016-4206-x
[12] 余姝, 张枝华, 黄波林, 等. 三峡库区青石-抱龙段顺层灰岩库岸坡变形破坏机理[J]. 中国地质灾害与防治学报,2019,30(3):18 − 23. [YU Shu, ZHANG Zhihua, HUANG Bolin, et al. Deformation mechanism of bedding limestone bank slope from Qingshi to Baolong, the Three Gorges Area[J]. The Chinese Journal of Geological Hazard and Control,2019,30(3):18 − 23. (in Chinese with English abstract)
[13] 唐红梅. 群发性崩塌灾害形成机制与减灾技术[D]. 重庆: 重庆大学, 2011.
TANG Hongmei. Developing mechanism and mitigation techniques of massive collapse[D]. Chongqing: Chongqing University, 2011. (in Chinese with English abstract)
[14] 张枝华, 杜春兰, 余姝, 等. 三峡库区巫峡箭穿洞危岩体稳定性分析及防治工程设计[J]. 中国地质灾害与防治学报,2018,29(2):48 − 54. [ZHANG Zhihua, DU Chunlan, YU Shu, et al. Stability analysis and design of control works on Jianchuandong dangerous rockmass in Wuxia Gorge, the Three Gorges Reservoir[J]. The Chinese Journal of Geological Hazard and Control,2018,29(2):48 − 54. (in Chinese with English abstract)
[15] 陈小婷, 王健, 黄波林, 等. 库水位变动条件下柱状危岩体变形破坏机理[J]. 中国地质灾害与防治学报,2019,30(2):9 − 18. [CHEN Xiaoting, WANG Jian, HUANG Bolin, et al. Deformation and failure mechanism of pillar-shaped dangerous rock mass under resenoir's water level fluctuation[J]. The Chinese Journal of Geological Hazard and Control,2019,30(2):9 − 18. (in Chinese with English abstract)
[16] 贺凯. 塔柱状岩体崩塌机理研究[D]. 西安: 长安大学, 2015.
HE Kai. Research on collapse mechanism of tower rock[D]. Xi'an: Chang'an University, 2015. (in Chinese with English abstract)
[17] HUANG B L, YIN Y P, ZHANG Z H, etal. A case study of pillar-shaped rock mass failure in the Three Gorges Reservoir Area, China[J]. Quarterly Journal of Engineering Geology and Hydrogeology,2016,49(3):195 − 202. doi: 10.1144/qjegh2015-034
[18] ULUSAY R. The isrm suggested methods for rock characterization, testing and monitoring: 2007-2014 [M]. Switzerland: Springer International Publishing, 2014.
[19] 闫玉平, 肖世国. 双排抗滑桩加固滑坡的前桩后侧推力算法[J]. 水文地质工程地质,2021,48(4):55 − 63. [YAN Yuping, XIAO Shiguo. A calculation method for thrust on the fore piles of double-row stabilizing piles used to reinforce landslides[J]. Hydrogeology & Engineering Geology,2021,48(4):55 − 63. (in Chinese with English abstract)
[20] 三峡库区地质灾害防治工作指挥部. 三峡库区三期地质灾害防治工程地质勘查技术要求[S]. 2012.
Headquarters for Geological Hazard Prevention of the Three Gorges Reservoir Region. The technicalrequirements of the 3rd phase geological exploration inthe Three Gorges Reservoir Region[S]. 2012. (in Chinese)
[21] 闫国强, 黄波林, 代贞伟, 等. 三峡库区巫峡段典型岩体劣化特征研究[J]. 水文地质工程地质,2020,47(4):62 − 72. [YAN Guoqiang, HUANG Bolin, DAI Zhenwei, etal. A study of the deterioration effect of limestone bank slope rock mass at the Wuxia section of the Three Gorges Reservoir area[J]. Hydrogeology & Engineering Geology,2020,47(4):62 − 72. (in Chinese with English abstract)
-
