摘要:
坡面形态对边坡表面应力状态影响显著，而应力状态与边坡稳定性密切相关。以往的降雨入渗模型仅考虑直线形态的边坡，并没有考虑边坡为曲线形态的情况。将Mein-Larson入渗模型与坡形函数相结合，推导降雨作用下凹形边坡的入渗函数，结合极限平衡分析方法，提出一种凹形边坡稳定性计算模型。同时根据坡形拟合与坡形简化的思路，将实际边坡分别当作成凹形边坡和直线边坡进行研究。研究结果表明：湿润锋入渗深度与降雨时间呈线性关系，湿润锋面在不同降雨时刻下均与坡面平行。将实际边坡当作凹形边坡进行分析时，其降雨入渗规律更符合实际情况；当降雨时间为10天时，浅层斜坡模型得到的计算结果为0.95，而本文计算模型与数值模拟得到的稳定性系数分别为1.004和1.003，相对误差不超过1%。因此与以往提出的计算模型相比，该模型不仅考虑了实际边坡的坡面形态，而且具有计算简便、可靠度较高等特点。
Abstract:The slope shape has a significant effect on the surface stress state of slope, and the stress state is closely related to the slope stability. The previous rainfall infiltration model only takes the slope with straight line shape into account, and did not include the slope with curve shape. Combining Mein-Larson infiltration model with slope shape function, the infiltration function of concave slope under rainfall is deduced. Combined with limit equilibrium analysis method, a calculation model of concave slope stability is proposed. At the same time, according to the idea of slope shape fitting and slope shape simplification, the actual slope is studied as concave slope and straight slope respectively. The results show that the infiltration depth of wetting front has a linear relationship with rainfall time, and the wetting front is paralleled to the slope at different rainfall time. When the actual slope is analyzed as a concave slope, the rainfall infiltration law is more in line with the actual situation; when the rainfall time is 10 days, the calculation result of the shallow slope model is 0.95, while the stability coefficients of the calculation model and the numerical simulation are 1.004 and 1.003 respectively, and the relative error is not more than 1%. Therefore, compared with the previous calculation model, this model not only takes the actual slope shape into account, but also has the characteristics of simple calculation and high reliability.
-
Key words:
- rainfall infiltration /
- limit equilibrium method /
- concave slope /
- wetting front /
- slope stability
-
-
表 1 边坡岩土及水文参数表
Table 1. Geotechnical and hydrological parameters of slope
参数 饱和黏聚力
c´/kPa饱和内摩擦角
φ´/(°)天然黏聚力
c/kPa天然内
摩擦角φ/(°)土体天然重度
γt/(kN·m−3)土体饱和重度
γsat/(kN·m−3)饱和渗透系数
Ks/(m·d−1)粉质黏土 15 21 18 24.6 20 22 0.072 变质粉砂岩 − − 4000 35 24 − −
下载: 导出CSV
-
[1] 李媛, 孟晖, 董颖, 等. 中国地质灾害类型及其特征: 基于全国县市地质灾害调查成果分析[J]. 中国地质灾害与防治学报,2004,15(2):29 − 34. [LI Yuan, MENG Hui, DONG Ying, et al. Main types and characterisitics of geo-hazard in China—Based on the results of geo-hazard survey in 290 counties[J]. The Chinese Journal of Geological Hazard and Control,2004,15(2):29 − 34. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-8035.2004.02.005
[2] 张明, 胡瑞林, 谭儒蛟, 等. 降雨型滑坡研究的发展现状与展望[J]. 工程勘察,2009,37(3):11 − 17. [ZHANG Ming, HU Ruilin, TAN Rujiao, et al. State-of-the-art study on landslides due to rainfall and the prospect[J]. Geotechnical Investigation & Surveying,2009,37(3):11 − 17. (in Chinese with English abstract)
[3] GREEN W H, AL E. Studies of soil physics, part I - the flow of air and water through soils[J]. Journal of Agricultual Science,1911,4:1 − 24. doi: 10.1017/S0021859600001441
[4] MEIN R G, LARSON C L. Modeling infiltration during a steady rain[J]. Water Resources Research,1973,9(2):384 − 394. doi: 10.1029/WR009i002p00384
[5] CHU S T. Infiltration during an unsteady rain[J]. Water Resources Research,1978,14(3):461 − 466. doi: 10.1029/WR014i003p00461
[6] PHILIP J R. Hillslope infiltration: planar slopes[J]. Water Resources Research,1991,27(1):109 − 117. doi: 10.1029/90WR01704
[7] MUNTOHAR A S, LIAO H J. Rainfall infiltration: infinite slope model for landslides triggering by rainstorm[J]. Natural Hazards,2010,54(3):967 − 984. doi: 10.1007/s11069-010-9518-5
[8] 饶鸿, 王金淑, 赵志明, 等. 基于有限元软件自定义本构模型的膨胀土边坡降雨入渗分析[J]. 水文地质工程地质,2021,48(1):154 − 162. [RAO Hong, WANG Jinshu, ZHAO Zhiming, et al. An analysis of rainfall infiltration of expansive soil slope based on the finite element software custom constitutive model[J]. Hydrogeology & Engineering Geology,2021,48(1):154 − 162. (in Chinese with English abstract)
[9] 常金源, 包含, 伍法权, 等. 降雨条件下浅层滑坡稳定性探讨[J]. 岩土力学,2015,36(4):995 − 1001. [CHANG Jinyuan, BAO Han, WU Faquan, et al. Discussion on stability of shallow landslide under rainfall[J]. Rock and Soil Mechanics,2015,36(4):995 − 1001. (in Chinese with English abstract)
[10] 李秀珍, 何思明. 基于Mein-Larson入渗模型的浅层降雨滑坡稳定性研究[J]. 灾害学,2015,30(2):16 − 20. [LI Xiuzhen, HE Siming. A study on stability of shallow rainfall-induced landslide based on Mein-Larson infiltration model[J]. Journal of Catastrophology,2015,30(2):16 − 20. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-811X.2015.02.004
[11] 李秀珍, 张小红. 基于Mein-Larson入渗模型的降雨滑坡失稳破坏概率研究[J]. 水土保持通报,2017,37(1):219 − 223. [LI Xiuzhen, ZHANG Xiaohong. A study of instability probability of rainfall-induced landslides based on Mein-Larson infiltration model[J]. Bulletin of Soil and Water Conservation,2017,37(1):219 − 223. (in Chinese with English abstract)
[12] 孟庆成, 王明, 齐欣, 等. 水力滞回性对降雨入渗边坡稳定性的影响[J]. 中国地质灾害与防治学报,2018,29(4):23 − 29. [MENG Qingcheng, WANG Ming, QI Xin, et al. Influence of hydraulic hysteresis on the slope stability under rainfall infiltration condition[J]. The Chinese Journal of Geological Hazard and Control,2018,29(4):23 − 29. (in Chinese with English abstract)
[13] 王进, 冷先伦, 阮航, 等. 强降雨作用下浅层滑坡的入渗及稳定性[J]. 东南大学学报(自然科学版), 2016, 46(增刊1): 153−158.
WANG Jin, LENG Xianlun, RUAN Hang, et al. Infiltration and stability of shallow landslide under intensive rainfall conditions[J]. Journal of Southeast University (Natural Science Edition), 2016, 46(Sup 1): 153−158. (in Chinese with English abstract)
[14] 唐扬, 殷坤龙, 汪洋, 等. 斜坡降雨入渗的改进Mein-Larson模型[J]. 地球科学,2017,42(4):634 − 640. [TANG Yang, YIN Kunlong, WANG Yang, et al. The landslide rain infiltration based on the improved Mein-Larson model[J]. Earth Science,2017,42(4):634 − 640. (in Chinese with English abstract)
[15] 匡野. 降雨诱发堆积体滑坡预警模型研究[D]. 成都: 成都理工大学, 2014.
KUANG Ye. Early warning model of rainfall-induced colluviums landslides[D]. Chengdu: Chengdu University of Technology, 2014. (in Chinese with English abstract)
[16] 乔建平, 吴彩燕, 田宏岭. 三峡库区云阳-巫山段坡形因素对滑坡发育的贡献率研究[J]. 工程地质学报,2006,14(1):18 − 22. [QIAO Jianping, WU Caiyan, TIAN Hongling. Contributing ratios of the slope shape toward the landslide development from Yunyang to Wushan in Three Gorges Reservoir area[J]. Journal of Engineering Geology,2006,14(1):18 − 22. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2006.01.004
[17] PUZRIN A M, GRAY T E, HILL A J. Significance of the actual nonlinear slope geometry for catastrophic failure in submarine landslides[J]. Proc Math Phys Eng Sci,2015,471(2175):20140772.
[18] 毕仲辉, 翟亚飞, 唐彧杰, 等. 基于有限元强度折减法的降雨入渗基岩型边坡可靠度分析[J]. 水利水电技术,2020,51(9):187 − 192. [BI Zhonghui, ZHAI Yafei, TANG Yujie, et al. Finite element strength reduction method-based reliability analysis on rainfall-infiltrated bedrock-typed slope[J]. Water Resources and Hydropower Engineering,2020,51(9):187 − 192. (in Chinese with English abstract)
[19] 李全文, 常金源, 徐文刚, 等. Geostudio软件模拟降雨入渗过程中边界条件的探讨[J]. 水利规划与设计,2019(2):54 − 57. [LI Quanwen, CHANG Jinyuan, XU Wengang et al. Discussion on boundary conditions of simulating rainfall infiltration process by Geostudio software[J]. Water Resources Planning and Design,2019(2):54 − 57. (in Chinese) doi: 10.3969/j.issn.1672-2469.2019.02.017
[20] 高博. 大戛高速公路水敏性软岩高填方路基稳定性及其控制研究[D]. 北京: 北京交通大学, 2019.
GAO Bo. Study on stability and control of water-sensitive soft rock high fill subgrade in daga highway[D]. Beijing: Beijing Jiaotong University, 2019. (in Chinese with English abstract)
-
