Evaluation on landslide susceptibility based on self-organizing feature map network and random forest model：A case study of Dayu County of Jiangxi Province
-
摘要:
为深入探讨评价单元和非滑坡样本选取对滑坡易发性预测的影响，构建了一种基于自组织特征映射网络-随机森林模型的滑坡易发性评价模型。该模型针对栅格单元和斜坡单元在滑坡易发性评价中的不足，结合栅格单元和斜坡单元的相互关系，提出了滑坡易发性指数的优化计算方法。在此基础上，基于随机森林Tree Bagger分类器构建滑坡易发性评价模型，通过对比分析自组织特征映射网络和随机方法选取非滑坡样本对评价结果的影响，探讨自组织特征映射网络、随机森林和自组织特征映射网络-随机森林三种评价模型的有效性；将评价模型应用于大余县滑坡易发性评价。结果显示，随机森林模型和自组织特征映射网络-随机森林模型的预测精度较高，分别达到91.19%和94.94%，成功率曲线的AUC值分别为0.822和0.849，表明自组织特征映射网络-随机森林模型具有更高的预测率和成功率, 自组织特征映射网络聚类的预测精度虽然有限，但作为非滑坡样本的选择方法，能够有效提高随机森林模型的评价精度。
Abstract:In order to further explore the influence of evaluation units and non-landslide sample selection methods on landslide susceptibility prediction, a landslide susceptibility evaluation model is established based on self-organizing feature map network and random forest model in this paper. According to the relationship between grid units and slope units, an optimized calculation method of landslide susceptibility index is proposed. Aiming at the deficiencies of grid units and slope units in the evaluation of landslide susceptibility, this model proposes an optimized calculation method for landslide susceptibility index based on the relationship between grid cells and slope cells. On this basis, a landslide susceptibility evaluation model was established based on the random forest Tree Bagger classifier. By comparing and analyzing the influence of self-organizing feature map network and random non-landslide sample selection methods on the evaluation results, the effectiveness of the three evaluation models of self-organizing feature map network, random forest and self-organizing feature map network -random forest were discussed. The evaluation model has been applied to the landslide susceptibility evaluation in Dayu County. The results show that the prediction accuracy of random forest and self-organizing feature map network-random forest is higher, reaching 91.19% and 94.94% respectively, and the AUC of success rate curve was 0.822 and 0.849 respectively. It shows that self-organizing feature map network-random forest has higher prediction rate and success rate, although the prediction accuracy of self-organizing feature map network clustering is limited, it can effectively improve the evaluation accuracy of random forest model as the basis for selecting non landslide samples.
-
-
表 1 评价指标体系
Table 1. Evaluation index system
滑坡影响因素 分类及分级 高程 （1）[130,200)；（2）[200,300）；（3）[300,400)；（4）[400,500)；（5）[500,600)；（6）[600,700)；（7）[700,800)；（8）[800,900)；（9）[900,1346)； 植被归一化指数 （1）[−1,0.2)；（2）[0.2,0.4）；（3）[0.4,0.6)；（4）[0.6,0.8)；（5）[0.8,1.0) 土地利用类型 （1）矿山工程用地；（2）乔木；（3）耕地和荒地；（4）城镇用地 坡度/(◦) （1）[0,10)；（2）[10,20）；（3）[20,30)；（4）[30,40)；（5）[40,54.6) 总曲率 （1）[−6.3,−0.82)；（2）[−0.82,−0.27）；（3）[−0.27,−0.18)；（4）[−0.18,0.88)；（5）[0.88,6.44) 岩土类型 （1）C:白云质灰岩类；（2）D:砂岩类；（3）Q:松散沉积物；（4）H:变余砂岩类；
（5)K:红色砂砾岩类；（6）R:岩浆岩类；（7）Z:板岩千枚岩道路密度/(km∙km-2) （1）[0,0.393)；（2）[0.393,0.786）；（3）[0.786,1.178)；（4）[1.178,1.571)；（5）[1.571,1.964) 距道路的距离/m （1）[0,50)；（2）[50,100）；（3）[100,150)；（4）[150,200)；（5）≥200 距水系的距离/m （1）[0,50)；（2）[50,100）；（3）[100,150)；（4）[150,200)；（5）≥200 距断层的距离/m （1）[0,200)；（2）[200,400）；（3）[400,600)；（4）[600,800)；（5）≥800
下载: 导出CSV
表 2 不同滑坡易发性分区的滑坡频率
Table 2. Landslide frequency in different landslide susceptibility zones
序号 滑坡
易发性
等级SOM 随机森林 SOM-随机森林 分区面积/km2 滑坡频率
/（个·km−2）比例/% 分区面积/km2 滑坡频率
/（个·km-2）比例/% 分区面积/km2 滑坡频率
/（个·km−2）比例/% 1 低 372.45 0.0081 1 561.52 0 0 545.46 0.0000 0 2 较低 495.01 0.0626 7.76 113.70 0.0176 3.94 122.06 0.0082 1.84 3 中等 288.02 0.1805 22.37 137.65 0.0218 4.88 139.19 0.0144 3.22 4 较高 61.03 0.2785 34.5 152.83 0.0916 20.49 152.12 0.1183 26.53 5 高 122.53 0.2775 34.37 373.34 0.3161 70.70 380.21 0.3051 68.41
下载: 导出CSV
-
[1] 黄发明, 叶舟, 姚池, 等. 滑坡易发性预测不确定性: 环境因子不同属性区间划分和不同数据驱动模型的影响[J]. 地球科学,2020,45(12):4535 − 4549. [HUANG Faming, YE Zhou, YAO Chi, et al. Uncertainties of landslide susceptibility prediction: different attribute interval divisions of environmental factors and different data-based models[J]. Earth Science,2020,45(12):4535 − 4549. (in Chinese with English abstract)
[2] PEETHAMBARAN B, ANBALAGAN R, KANUNGO D P, et al. A comparative evaluation of supervised machine learning algorithms for township level landslide susceptibility zonation in parts of Indian Himalayas[J]. Catena,2020,195:104751. doi: 10.1016/j.catena.2020.104751
[3] 周超, 殷坤龙, 曹颖, 等. 基于集成学习与径向基神经网络耦合模型的三峡库区滑坡易发性评价[J]. 地球科学,2020,45(6):1865 − 1876. [ZHOU Chao, YIN Kunlong, CAO Ying, et al. Landslide susceptibility assessment by applying the coupling method of radial basis neural network and adaboost: A case study from the Three Gorges Reservoir area[J]. Earth Science,2020,45(6):1865 − 1876. (in Chinese with English abstract)
[4] BAHARVAND S, RAHNAMARAD J, SOORI S, et al. Landslide susceptibility zoning in a catchment of Zagros mountains using fuzzy logic and GIS[J]. Environmental Earth Sciences,2020,79(10):1 − 10.
[5] 杨永刚, 殷坤龙, 赵海燕, 等. 基于C5.0决策树-快速聚类模型的万州区库岸段乡镇滑坡易发性区划[J]. 地质科技情报,2019,38(6):189 − 197. [YANG Yonggang, YIN Kunlong, ZHAO Haiyan, et al. Landslide susceptibility evaluation for township units of bank section in Wanzhou district based on C5.0 decision tree and K-means cluster model[J]. Geological Science and Technology Information,2019,38(6):189 − 197. (in Chinese with English abstract)
[6] 武雪玲, 沈少青, 牛瑞卿. GIS支持下应用PSO-SVM模型预测滑坡易发性[J]. 武汉大学学报(信息科学版),2016,41(5):665 − 671. [WU Xueling, SHEN Shaoqing, NIU Ruiqing. Landslide susceptibility prediction using GIS and PSO-SVM[J]. Geomatics and Information Science of Wuhan University,2016,41(5):665 − 671. (in Chinese with English abstract)
[7] 夏辉, 殷坤龙, 梁鑫, 等. 基于SVM-ANN模型的滑坡易发性评价: 以三峡库区巫山县为例[J]. 中国地质灾害与防治学报,2018,29(5):13 − 19. [XIA Hui, YIN Kunlong, LIANG Xin, et al. Landslide susceptibility assessment based on SVM-ANN Models: A case stualy for Wushan County in the Three Gorges Reservoir[J]. The Chinese Journal of Geological Hazard and Control,2018,29(5):13 − 19. (in Chinese with English abstract)
[8] 刘坚, 李树林, 陈涛. 基于优化随机森林模型的滑坡易发性评价[J]. 武汉大学学报(信息科学版),2018,43(7):1085 − 1091. [LIU Jian, LI Shulin, CHEN Tao. Landslide susceptibility assesment based on optimized random forest model[J]. Geomatics and Information Science of Wuhan University,2018,43(7):1085 − 1091. (in Chinese with English abstract)
[9] 杜国梁,杨志华,袁颖,等. 基于逻辑回归-信息量的川藏交通廊道滑坡易发性评价[J].水文地质工程地质,2021,48(5):102-111.
DU Guoliang, YANG Zhihua, YUAN Ying, et al. Landslide susceptibility mapping in the Sichuan-Tibet traffic corridor using logistic regression-information value method[J]. Hydrogeology & Engineering,2021,48(5):102-111.(in Chinese with English)
[10] 连志鹏, 徐勇, 付圣, 等. 采用多模型融合方法评价滑坡灾害易发性: 以湖北省五峰县为例[J]. 地质科技通报,2020,39(3):178 − 186. [LIAN Zhipeng, XU Yong, FU Sheng, et al. Landslide susceptibility assessment based on multi-model fusion method: A case study in Wufeng County, Hubei Province[J]. Bulletin of Geological Science and Technology,2020,39(3):178 − 186. (in Chinese with English abstract)
[11] 郭子正, 殷坤龙, 付圣, 等. 基于GIS与WOE-BP模型的滑坡易发性评价[J]. 地球科学,2019,44(11):4299 − 4312. [GUO Zizheng, YIN Kunlong, FU Sheng, et al. Evaluation of landslide susceptibility based on GIS and WOE-BP model[J]. Earth Science,2019,44(11):4299 − 4312. (in Chinese with English abstract)
[12] 鲜木斯艳·阿布迪克依木, 何书. 基于MIV-BP神经网络的滑坡易发性空间预测[J]. 人民长江,2019,50(12):140 − 144. [ABUDIKEYIMU XMSY, HE Shu. Spatial prediction on landslide vulnerability based on MIV-BP neural network[J]. Yangtze River,2019,50(12):140 − 144. (in Chinese with English abstract)
[13] 李文娟, 邵海. 基于遥感影像多尺度分割与地质因子评价的滑坡易发性区划[J]. 中国地质灾害与防治学报,2021,32(2):94 − 99. [LI Wenjuan, SHAO Hai. Landslide susceptibility assessment based on multi-scale segmentation of remote sensing and geological factor evaluation[J]. The Chinese Journal of Geological Hazard and Control,2021,32(2):94 − 99. (in Chinese with English abstract)
[14] PARYANI S, NESHAT A, JAVADI S, et al. Comparative performance of new hybrid ANFIS models in landslide susceptibility mapping[J]. Natural Hazards,2020,103(2):1961 − 1988. doi: 10.1007/s11069-020-04067-9
[15] 谈树成, 赵娟娟, 杨林, 等. 基于GIS和信息量-快速聚类模型的滑坡易发性研究: 以云南省福贡县为例[J]. 云南大学学报(自然科学版),2018,40(6):1148 − 1158. [TAN Shucheng, ZHAO Juanjuan, YANG Lin, et al. Evaluation of landslide susceptibility based on GIS and the information value & the K-means cluster model—Take Fugong County as an Example[J]. Journal of Yunnan University (Natural Sciences Edition),2018,40(6):1148 − 1158. (in Chinese with English abstract)
[16] 孙长明, 马润勇, 尚合欣, 等. 基于滑坡分类的西宁市滑坡易发性评价[J]. 水文地质工程地质,2020,47(3):173 − 181. [SUN Changming, MA Runyong, SHANG Hexin, et al. Landslide susceptibility assessment in Xining based on landslide classification[J]. Hydrogeology & Engineering Geology,2020,47(3):173 − 181. (in Chinese with English abstract)
[17] 郭子正, 殷坤龙, 黄发明, 等. 基于滑坡分类和加权频率比模型的滑坡易发性评价[J]. 岩石力学与工程学报,2019,38(2):287 − 300. [GUO Zizheng, YIN Kunlong, HUANG Faming, et al. Evaluation of landslide susceptibility based on landslide classification and weighted frequency ratio model[J]. Chinese Journal of Rock Mechanics and Engineering,2019,38(2):287 − 300. (in Chinese with English abstract)
[18] 黄发明, 殷坤龙, 蒋水华, 等. 基于聚类分析和支持向量机的滑坡易发性评价[J]. 岩石力学与工程学报,2018,37(1):156 − 167. [HUANG Faming, YIN Kunlong, JIANG Shuihua, et al. Landslide susceptibility assessment based on clustering analysis and support vector machine[J]. Chinese Journal of Rock Mechanics and Engineering,2018,37(1):156 − 167. (in Chinese with English abstract)
[19] 李颖, 应保胜, 容芷君, 等. 基于SOM的产品设计结构模块划分及其评价[J]. 武汉科技大学学报,2018,41(4):301 − 306. [LI Ying, YING Baosheng, RONG Zhijun, et al. SOM-based product design structure clustering and its evaluation[J]. Journal of Wuhan University of Science and Technology,2018,41(4):301 − 306. (in Chinese with English abstract)
[20] 王小川, 史峰, 郁磊. MATLAB神经网络43个案例分析[M]. 北京: 北京航空航天大学出版社, 2013.
WANG Xiaochuan, SHI Feng, YU Lei. Analysis of 43 cases of neural network in matlab [M]. Beijing: Beijing University of Aeronautics & Astronautics Press, 2013. (in Chinese)
[21] 林荣福, 刘纪平, 徐胜华, 等. 随机森林赋权信息量的滑坡易发性评价方法[J]. 测绘科学,2020,45(21):131 − 138. [LIN Rongfu, LIU Jiping, XU Shenghua, et al. Evaluation method of landslide susceptibility based on random forest weighted information[J]. Science of Surveying and Mapping,2020,45(21):131 − 138. (in Chinese with English abstract)
[22] 李亭, 田原, 邬伦, 等. 基于随机森林方法的滑坡灾害危险性区划[J]. 地理与地理信息科学,2014,30(6):25 − 30. [LI Ting, TIAN Yuan, WU Lun, et al. Landslide susceptibility mapping using random forest[J]. Geography and Geo-Information Science,2014,30(6):25 − 30. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-0504.2014.06.006
[23] 颜阁, 梁收运, 赵红亮. 基于GIS的斜坡单元划分方法改进与实现[J]. 地理科学,2017,37(11):1764 − 1770. [YAN Ge, LIANG Shouyun, ZHAO Hongliang. An approach to improving slope unit division using GIS technique[J]. Scientia Geographica Sinica,2017,37(11):1764 − 1770. (in Chinese with English abstract)
[24] 罗路广, 裴向军, 黄润秋. 强震山区地震滑坡发生概率研究: 以九寨沟国家地质公园为例[J]. 岩石力学与工程学报,2020,39(10):2079 − 2093. [LUO Luguang, PEI Xiangjun, HUANG Runqiu. Earthquake-triggered landslide occurrence probability in strong seismically mountainous areas: A case study of Jiuzhaigou National Geopark[J]. Chinese Journal of Rock Mechanics and Engineering,2020,39(10):2079 − 2093. (in Chinese with English abstract)
[25] 黄启乐, 陈伟, 唐绪波, 等. 区域地质灾害评价中斜坡单元划分方法研究[J]. 自然灾害学报,2017,26(5):157 − 164. [HUANG Qile, CHEN Wei, TANG Xubo, et al. Study on the method of slope unit zoning in regional geo-hazards risk assessment[J]. Journal of Natural Disasters,2017,26(5):157 − 164. (in Chinese with English abstract)
[26] 程温鸣, 彭令, 牛瑞卿. 基于粗糙集理论的滑坡易发性评价: 以三峡库区秭归县境内为例[J]. 中南大学学报(自然科学版),2013,44(3):1083 − 1090. [CHENG Wenming, PENG Ling, NIU Ruiqing. Landslide susceptibility assessment based on rough set theory: Taking Zigui County territory in Three Gorges Reservoir for example[J]. Journal of Central South University (Science and Technology),2013,44(3):1083 − 1090. (in Chinese with English abstract)
[27] 宫清华, 黄光庆, 张冬良, 等. 基于斜坡单元的浅层滑坡风险区划: 以华南松岗河小流域为例[J]. 安全与环境学报,2017,17(2):615 − 620. [GONG Qinghua, HUANG Guangqing, ZHANG Dongliang, et al. On the application of the slope element unit method to the shallow landslide risk-prevention mapping with a case study sample of Songgang watershed[J]. Journal of Safety and Environment,2017,17(2):615 − 620. (in Chinese with English abstract)
[28] 薛强, 张茂省, 高波. 斜坡单元支持下基于土体含水率的陕西省清涧县城区黄土滑坡危险性评价[J]. 中国地质,2020,47(6):1904 − 1914. [XUE Qiang, ZHANG Maosheng, GAO Bo. Hazard assessment of loess landslide based on soil moisture content and supported by slope unit in Qingjian City, Shaanxi Province[J]. Geology in China,2020,47(6):1904 − 1914. (in Chinese with English abstract) doi: 10.12029/gc20200624
[29] PHAM B T, TIEN BUI D, PRAKASH I, et al. Rotation forest fuzzy rule-based classifier ensemble for spatial prediction of landslides using GIS[J]. Natural Hazards,2016,83(1):97 − 127. doi: 10.1007/s11069-016-2304-2
[30] 武雪玲, 任福, 牛瑞卿. 多源数据支持下的三峡库区滑坡灾害空间智能预测[J]. 武汉大学学报(信息科学版),2013,38(8):963 − 968. [WU Xueling, REN Fu, NIU Ruiqing. Spatial intelligent prediction of landslide hazard based on multi-source data in Three Gorges Reservoir area[J]. Geomatics and Information Science of Wuhan University,2013,38(8):963 − 968. (in Chinese with English abstract)
-
