Landslide susceptibility assessment based on MaxEnt model of along Sino-Nepal traffic corridor
-
摘要:
中尼交通廊道作为中国近年来建设的重点区域，地质灾害频发，尤其是滑坡灾害层出不穷。文章基于对G216国道沿线地质灾害的实地调查以及遥感解译结果，以最大熵模型为方法，利用169个灾害点数据和8个评价因子图层预测了研究区滑坡灾害的易发性分布。根据占比划分五级风险区。结果表明，滑坡易发概率以G216为中心向外辐射逐渐降低。同时采用刀切法检验评价因子对预测结果的贡献度，确定了滑坡主导因素及其阈值。最后通过ROC曲线验证了模型的可靠性。为中尼边境公路区域建设提供一种地质灾害预测分析模型，也为青藏地区公路边坡防灾减灾提供有效支撑。
Abstract:As a key area of China's construction in recent years, the Sino Nepal traffic corridor has complex geological conditions and frequent geological disasters, especially landslides are the most serious. Through the field survey and remote sensing interpretation along G216 highway, we obtained the data of 169 disaster points. Using the MaxEnt model and 8 evaluation factor layers, we predicted the distribution of landslide susceptibility in the study area. We divided the results into five categories: extremely low, low, medium, high and extremely high prone areas, and their proportions are 11.48%, 41.28%, 25.21%, 10.87%, 11.16%. The probability of landslide occurrence is higher near the road and lower the farther away from the road. In addition, we used the jackknife to test the contribution of evaluation factors to the prediction results, and determine the dominant factors. The study provides a high-accuracy analysis model for the prediction of geological disasters in the China Nepal border highway area, and also provides effective support for highway slope disaster prevention in Qinghai Tibet region.
-
Key words:
- landslide susceptibility /
- MaxEnt model /
- Sino-Nepal traffic corridor /
- GIS /
- ROC
-
-
表 1 评价因子选取及其来源
Table 1. Selection of evaluation factors and sources
评价因子 数据来源 高程 地理空间数据云（ http://www.gscloud.cn ）坡向 ArcGIS 高程提取 坡度 ArcGIS 高程提取 断层密度 西藏自治区吉隆县地质图（全国地质资料馆 http://www.ngac.org.cn/ ）及现场调查河流密度 西藏自治区吉隆县地质图（全国地质资料馆 http://www.ngac.org.cn/ ）及现场调查岩性 西藏自治区吉隆县地质图（全国地质资料馆 http://www.ngac.org.cn/ ）及现场调查地震加速度 中国地震动参数区划图
(http://www.gb18306.net/ )植被覆盖指数 地理空间数据云
（http://www.gscloud.cn ）
下载: 导出CSV
表 2 评价因子相关性检验
Table 2. Correlation test of evaluation factors
高程 坡向 坡度 断层密度 河流密度 岩性 地震峰值加速度 植被覆盖指数 高程 1 坡向 0.056 1 坡度 −0.307 0.388 1 断层密度 0.414 −0.177 −0.104 1 河流密度 0.251 −0.141 −0.124 0.030 1 岩性 0.459 −0.125 −0.098 0.398 0.200 1 地震峰值加速度 0.491 0.322 −0.441 0.446 −0.182 0.442 1 植被覆盖指数 0.406 -0.466 0.468 −0.156 −0.107 −0.163 −0.467 1
下载: 导出CSV
-
[1] LI C, VAN DER HILST R D, MELTZER A S, et al. Subduction of the Indian lithosphere beneath the Tibetan plateau and burma[J]. Earth and Planetary Science Letters,2008,274(1/2):157 − 168.
[2] PARK N W. Using maximum entropy modeling for landslide susceptibility mapping with multiple geoenvironmental data sets[J]. Environmental Earth Sciences,2015,73(3):937 − 949. doi: 10.1007/s12665-014-3442-z
[3] KORNEJADY A, OWNEGH M, BAHREMAND A. Landslide susceptibility assessment using maximum entropy model with two different data sampling methods[J]. CATENA,2017,152:144 − 162. doi: 10.1016/j.catena.2017.01.010
[4] AKGUN A, DAG S, BULUT F. Landslide susceptibility mapping for a landslide-prone area (Findikli, NE of Turkey) by likelihood-frequency ratio and weighted linear combination models[J]. Environmental Geology,2008,54(6):1127 − 1143. doi: 10.1007/s00254-007-0882-8
[5] CARRARA A, CARDINALI M, DETTI R, et al. GIS techniques and statistical models in evaluating landslide hazard[J]. Earth Surface Processes and Landforms,1991,16(5):427 − 445. doi: 10.1002/esp.3290160505
[6] AYALEW L, YAMAGISHI H, MARUI H, et al. Landslides in Sado Island of Japan: part II. GIS-based susceptibility mapping with comparisons of results from two methods and verifications[J]. Engineering Geology,2005,81(4):432 − 445. doi: 10.1016/j.enggeo.2005.08.004
[7] 刘佳, 赵海军, 马凤山, 等. 基于改进变异系数法的G109拉萨—那曲段泥石流危险性评价[J]. 中国地质灾害与防治学报,2020,31(4):63 − 70. [LIU Jia, ZHAO Haijun, MA Fengshan, et al. Risk assessment of G109 Lhasa-Naqu debris flow based on improved coefficient of variation[J]. The Chinese Journal of Geological Hazard and Control,2020,31(4):63 − 70. (in Chinese with English abstract)
[8] CHANG K T, MERGHADI A, YUNUS A P, et al. Evaluating scale effects of topographic variables in landslide susceptibility models using GIS-based machine learning techniques[J]. Scientific Reports,2019,9:12296. doi: 10.1038/s41598-019-48773-2
[9] 宋盛渊, 潘玉珍, 陈剑平, 等. 基于联系期望的库岸泥石流危险性评价: 以乌东德库区为例[J]. 工程地质学报,2015,23(4):719 − 724. [SONG Shengyuan, PAN Yuzhen, CHEN Jianping, et al. Connectional expectation based evaluation of debris flow risk degree: A case study of Wudongde reservoir[J]. Journal of Engineering Geology,2015,23(4):719 − 724. (in Chinese with English abstract)
[10] CERYAN N, CERYAN S. An application of the interaction matrices method for slope failure susceptibility zoning: Dogankent settlement area (Giresun, NE Turkey)[J]. Bulletin of Engineering Geology and the Environment,2008,67(3):375 − 385. doi: 10.1007/s10064-008-0144-3
[11] 周天伦, 曾超, 范晨, 等. 基于快速聚类-信息量模型的汶川及周边两县滑坡易发性评价[J]. 中国地质灾害与防治学报,2021,32(5):137 − 150. [ZHOU Tianlun, ZENG Chao, FAN Chen, et al. Landslide susceptibility assessment based on K-means cluster information model in Wenchuan and two neighboring counties, China[J]. The Chinese Journal of Geological Hazard and Control,2021,32(5):137 − 150. (in Chinese with English abstract)
[12] 王雷, 吴君平, 赵冰雪, 等. 基于GIS和信息量模型的安徽池州地质灾害易发性评价[J]. 中国地质灾害与防治学报,2020,31(3):96 − 103. [WANG Lei, WU Junping, ZHAO Bingxue, et al. Susceptibility assessment of geohazards in Chizhou City of Anhui Province based on GIS and informative model[J]. The Chinese Journal of Geological Hazard and Control,2020,31(3):96 − 103. (in Chinese with English abstract)
[13] 李航. 统计学习方法[M]. 北京: 清华大学出版社, 2012
LI Hang. Statistical learning methods[M]. Beijing: Tsinghua University Press, 2012. (in Chinese)
[14] 孙莉, 王山, 王正元, 等. 基于最大熵模型的枸杞生态适宜区预测[J]. 宁夏大学学报(自然科学版),2018,39(2):143 − 147. [SUN Li, WANG Shan, WANG Zhengyuan, et al. Ecological suitable prediction of lycium barbarum L. based on maximum entropy model[J]. Journal of Ningxia University (Natural Science Edition),2018,39(2):143 − 147. (in Chinese with English abstract)
[15] FELICÍSIMO Á M, CUARTERO A, REMONDO J, et al. Mapping landslide susceptibility with logistic regression, multiple adaptive regression splines, classification and regression trees, and maximum entropy methods: A comparative study[J]. Landslides,2013,10(2):175 − 189. doi: 10.1007/s10346-012-0320-1
[16] 扈秀宇, 秦胜伍, 窦强, 等. 基于GIS和随机森林模型的泥石流敏感性分析: 以吉林省洮南市北部山区为例[J]. 水土保持通报,2019,39(5):204 − 210. [HU Xiuyu, QIN Shengwu, DOU Qiang, et al. Susceptibility analysis of debris flow based on GIS and random forest—A case study of a mountainous area in northern Taonan City, Jilin Province[J]. Bulletin of Soil and Water Conservation,2019,39(5):204 − 210. (in Chinese with English abstract)
[17] 杨人凡. 西藏吉隆盆地冲锥堆积体的成因研究[D]. 成都: 成都理工大学, 2011
YANG Renfan. Research of Chongzhui accumulation body′s cause of formation in basin Jilong Tibet[D]. Chengdu: Chengdu University of Technology, 2011. (in Chinese with English abstract)
[18] 韩培锋, 王镁河, 姜兆华, 等. 西藏吉隆县地质灾害及其影响因素分析[J]. 中国地质灾害与防治学报,2020,31(2):111 − 118. [HAN Peifeng, WANG Meihe, JIANG Zhaohua, et al. Geological disasters and their influencing factors in Jilong County, Tibet[J]. The Chinese Journal of Geological Hazard and Control,2020,31(2):111 − 118. (in Chinese with English abstract)
[19] 祝建, 吴臻林, 雷曙辉. 西藏吉隆口岸G216国道K81特大型滑坡形成过程和机理分析[J]. 工程勘察,2017,45(7):20 − 24. [ZHU Jian, WU Zhenlin, LEI Shuhui. Formation process and mechanism analysis of the super large-scale landslide at K81km of the national highway G216 in Tibet Jilong Port[J]. Geotechnical Investigation & Surveying,2017,45(7):20 − 24. (in Chinese with English abstract)
[20] 侯轶攀, 杨宜军, 王鹏来. 小流域评价单元在地质灾害详细调查易发性分区中的应用[J]. 资源环境与工程,2019,33(增刊 1):36 − 42. [HOU Yipan, YANG Yijun, WANG Penglai. Application of small watershed evaluation unit in detailed investigation of geological disaster and susceptibility zoning[J]. Resources Environment & Engineering,2019,33(Sup 1):36 − 42. (in Chinese with English abstract)
[21] 邹宇. 川藏交通走廊滑坡灾害内外动力耦合作用机理及空间分布预测[D]. 北京: 中国科学院大学, 2017
ZOU Yu. Coupling between endogenic and exogenic geological mechanisms and spatial distribution prediction model of the traffic corridor in Sichuan-Tibet[D]. Beijing: University of Chinese Academy of Sciences, 2017. (in Chinese with English abstract)
[22] 骆畅. 山地城市绿地生态系统服务价值评估及规划策略研究: 以重庆市主城区为例[D]. 北京: 北京林业大学, 2018
LUO Chang. Ecosystem services value of greenspaces in mountainous urban area—A case study in Chongqing[D]. Beijing: Beijing Forestry University, 2018. (in Chinese with English abstract)
[23] PHILLIPS S J, DUDÍK M, ELITH J, et al. Sample selection bias and presence-only distribution models: implications for background and pseudo-absence data[J]. Ecological Applications:a Publication of the Ecological Society of America,2009,19(1):181 − 197. doi: 10.1890/07-2153.1
[24] RAES N, TER STEEGE H. A null-model for significance testing of presence-only species distribution models[J]. Ecography,2007,30(5):727 − 736. doi: 10.1111/j.2007.0906-7590.05041.x
[25] 邱浩杰, 孙杰杰, 徐达, 等. 基于MaxEnt模型预测鹅掌楸在中国的潜在分布区[J]. 浙江农林大学学报,2020,37(1):1 − 8. [QIU Haojie, SUN Jiejie, XU Da, et al. MaxEnt model-based prediction of potential distribution of Liriodendron chinense in China[J]. Journal of Zhejiang A & F University,2020,37(1):1 − 8. (in Chinese with English abstract) doi: 10.11833/j.issn.2095-0756.2020.01.001
[26] 张宝龙, 范文. 临空条件对边坡稳定性的影响[J]. 公路交通科技,2018,35(7):35 − 41. [ZHANG Baolong, FAN Wen. Influence of free face condition on slope stability[J]. Journal of Highway and Transportation Research and Development,2018,35(7):35 − 41. (in Chinese with English abstract)
[27] 刘道胜. 中尼铁路佩枯措至吉隆段第四纪断裂活动性与工程选线设计[J]. 水文地质工程地质, 10.16030/j.cnki.issn.1000-3665.202109013.
LIU Daosheng. Quaternary fault activity and engineering effects along the Peikucuo-Gilong segment of the China-Nepal railway[J]. Hydrogeology & Engineering Geology, 10.16030/j.cnki.issn.1000-3665.202109013. (in Chinese with English abstract)
[28] 杨志华, 郭长宝, 吴瑞安,等. 青藏高原巴塘断裂带地震滑坡危险性预测研究[J]. 水文地质工程地质,2021,48(5):91 − 101. [YANG Zhihua, GUO Changbao, WU Ruian, et al. Predicting seismic landslide hazard in the Batang fault zone of the Qinghai-Tibet Plateau[J]. Hydrogeology & Engineering Geology,2021,48(5):91 − 101. (in Chinese with English abstract)
-
