SBAS-InSAR技术在西藏江达县金沙江流域典型巨型滑坡变形监测中的应用

杨成业; 张涛; 高贵; 卜崇阳; 吴华

doi:10.16031/j.cnki.issn.1003-8035.2022.03-11

SBAS-InSAR技术在西藏江达县金沙江流域典型巨型滑坡变形监测中的应用

1.
西藏大学工学院, 西藏拉萨　850000

2.
西南交通大学地球科学与环境工程学院, 四川成都　611756

基金项目: 西藏大学培育基金项目（ZDCZJH19-05）；西藏自治区自然科学基金项目（XZ2019ZRG-11（Z））；西藏自治区自然科学基金项目（XZ202001ZR0062G）；湖南省重点领域研发技术−社会发展领域重点项目（2019SK2173）；中央引导地方项目（XZ202001YD0004C）；中央支持地方高校改革发展资金项目（20201号）；武汉理工大学−西藏大学创新基金项目（LZT2022003）

详细信息

作者简介: 杨成业（1990-），男，河南镇平人，硕士研究生，主要从事地质资源与地质工程方向的研究。E-mail：1209097754@qq.com

通讯作者: 张　涛（1995-），男，河南台前人，硕士研究生，主要从事SAR目标监测研究。E-mail：ZTSWJTU@outlook.com

中图分类号: P642.22

收稿日期: 2021-12-09

修回日期: 2022-04-06

刊出日期: 2022-06-25

Application of SBAS-InSAR technology in monitoring of ground deformation of representative giant landslides in Jinsha river basin, Jiangda County, Tibet

1.
College of Engineering, Tibet University, Lhasa, Tibet　850000, China

2.
Faculty of Geosciences and Environmental Engineering, Southwest Jiaotong University, Chengdu, Sichuan　611756, China

More Information

Corresponding author: ZHANG Tao, ZTSWJTU@outlook.com

Received Date: 09 December 2021

Revised Date: 06 April 2022

Publish Date: 25 June 2022

摘要

摘要:
滑坡是一种破坏力极强的地质灾害，对滑坡易发区域进行长期有效的时序形变监测是研究机理和防灾减灾的重要途径，小基线雷达干涉测量技术（SBAS-InSAR）在滑坡等地质灾害形变监测中的应用为当前地灾防治提供了新的手段。文章使用SBAS-InSAR技术对西藏江达县金沙江流域发生的典型滑坡灾害进行了时序形变特征分析。首先，基于2017年7月—2018年12月的23景Sentinel-1A影像数据，获取了江达县东部及其周边区域在时间跨度内的形变分布图以及时序形变特征；在此基础上，结合区域内沃达和白格2处滑坡的实地勘探资料和现有研究成果验证了形变探测结果的准确性；另监测数据显示沃达滑坡中部及前缘位置存在明显形变，且部分位置的形变量超过100 mm，白格滑坡的残留体同样存在较大的形变，尤其是边界区域存在明显的形变漏斗，最大形变量超过110 mm。同时在金沙江流域西岸存在2处滑坡隐患区域，累计沉降量均超过45 mm，最大形变速率分别为−53 mm/a和−45 mm/a。基于数据分析和现场勘查，表明SBAS-InSAR技术在滑坡灾害的形变监测方面是一种有效手段，另江达县金沙江多处岸坡在不断发生形变，应进一步加强该区域地质灾害形变监测，必要时提前开展防治工作。
- 滑坡 /
- SBAS-InSAR /
- 形变监测
Abstract:
Landslide is a kind of natural geological disaster with strong destructive power, long-term effective time-series deformation monitoring of landslide prone areas is an important way to prevent and mitigate disasters, and the application of time-series radar interferometry technology in geological disaster deformation monitoring such as landslide provides a new effective means for current geological disaster prevention and control. This paper uses SBAS-InSAR technology to analyze the time-series deformation characteristics of the representative giant landslides in the areas of Jinsha river basin in Jiangda country, Tibet. Firstly, based on the 23 sentinel-1A images from July 2017 to December 2018, the deformation distribution map and temporal deformation characteristics of eastern Jiangda County and its surrounding areas in the time span were obtained; on this basis, the accuracy of the deformation detection results of this paper were verified by combining the field exploration data of two paleolandslide in the region and the existing research results; finally, the deformation detection results of two landslides show that there were resurrection areas in the middle and front edge of the Woda landslide, and the deformation in some locations exceeded 100 mm, and the residual bodies in the Baige landslide also had large deformation, especially there was an obvious deformation funnel in the boundary area, and the maximum deformation exceeded 110 mm. Meanwhile, there are two potential landslide areas on the west bank of the Jinsha river basin, the cumulative settlement exceeds 45 mm, and the maximum deformation rates are −53 mm/a and −45 mm/a, respectively.Based on data analysis and field investigation, SBAS-InSAR technology provide an effective mean for monitoring and preventing the deformation of landslides geological hazards. In addition, many bank slopes of Jinsha river in Jiangda County are constantly deformed. It is necessary to strengthen the monitoring of local disaster and carry out prevention and control work in advance.
- landslide /
- SBAS-InSAR /
- deformation monitoring

HTML全文

图 1 SBAS-InSAR技术处理流程

Figure 1.

下载: 全尺寸图片幻灯片

图 2 研究区范围

Figure 2.

下载: 全尺寸图片幻灯片

图 3 干涉对以及基线连接图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 沃达村和白格村滑坡区域的相干点分布

Figure 4.

下载: 全尺寸图片幻灯片

图 5 白格滑坡与沃达滑坡区域地表覆盖特征

Figure 5.

下载: 全尺寸图片幻灯片

图 6 研究区的整体形变分布结果

Figure 6.

下载: 全尺寸图片幻灯片

图 7 沃达滑坡形变速率图及现场照片

Figure 7.

下载: 全尺寸图片幻灯片

图 8 白格滑坡形变速率图及现场照片

Figure 8.

下载: 全尺寸图片幻灯片

图 9 白格与沃达滑坡形变特征和区域内月降水量

Figure 9.

下载: 全尺寸图片幻灯片

图 10 滑坡隐患区域A、B时序形变

Figure 10.

下载: 全尺寸图片幻灯片

表 1 Sentinel-1A数据集

Table 1. Sentinel-1A data set

序号	成像时间	时间基线/d	空间基线/m
1	2017-07-04	−96	−76.3019
2	2017-07-28	−72	−14.389
3	2017-08-21	−48	−40.7962
4	2017-09-14	−24	−6.9448
5	2017-10-08	0	0
6	2017-11-01	24	24.3437
7	2017-11-25	48	−19.665
8	2017-12-19	72	40.3736
9	2018-01-12	96	−6.72568
10	2018-02-05	120	−8.33992
11	2018-03-01	144	41.6516
12	2018-03-25	168	−122.65
13	2018-04-18	192	−116.634
14	2018-05-12	216	39.3469
15	2018-06-05	240	−128.818
16	2018-06-29	264	−29.1712
17	2018-07-23	288	−39.5201
18	2018-08-16	312	−70.3451
19	2018-09-21	348	−17.7032
20	2018-10-15	372	8.636.3
21	2018-11-08	396	31.0979
22	2018-12-02	420	−9.71988
23	2018-12-26	444	40.6537

下载: 导出CSV
