Experimental analysis of failure process in soft-hard combined rock masses at different inclination angles
-
摘要:
为探究软岩倾角对组合岩体破裂演化过程的影响，论文通过对不同软岩倾角组合岩体进行单轴压缩试验，采用数字散斑和声发射方法作为观测手段，探究含不同软岩倾角组合岩体的破裂演化过程，分析组合岩体力学性能随角度的变化规律，得出含不同倾角软硬组合岩体的破裂模式。结果表明：（1）软硬组合岩体破坏是岩体内部发生损伤，在软岩周围开始出现裂纹，并沿着软岩层及周围扩展、贯通破裂的动态演化过程。（2）组合岩体的变形破坏过程仍表现为原始裂隙压密、弹性变形、塑性变形及破坏四个阶段。（3）随着软岩倾角的增大，岩体的压密阶段逐渐增大，弹性模量逐渐减小，抗压强度越来越小；当软岩倾角θ=0°、15°时，岩体破裂表现为软硬组合岩体组合破裂；当软岩倾角θ=30°、45°时，岩体破裂主要发生在软岩区域，岩体的破坏形式由贯穿软岩层剪切破坏转变为沿软岩层滑移剪切破坏。可见软岩层倾角越大，岩体越容易发生失稳破坏。论文可为含软硬组合岩体工程的长期稳定性分析及复杂层状组合岩体的力学行为研究提供参考。
Abstract:In order to investigate the influence of the inclination angle of soft rocks on the evolution process of composite rock mass rupture, this paper conducted uniaxial compression experiments on composite rock masses with different inclination angles of soft rock. Digital speckle and acoustic emission methods were used as observation tools to explore the combined effects of different soft rock dip angles. The fracture evolution process of the rock mass was analyzed, and the change in mechanical properties of the composite rock mass with angle was studied. The fracture mode of the soft and hard composite rock mass with different inclination angles was obtained. The results show that the deformation and failure of the composite rock mass is a dynamic evolution process in which damage occurs inside the rock mass, with cracks appearing around the soft rock, and extend along and around the soft rock layer, eventually penetrating through the fracture. The deformation and failure process of the combined rock mass is manifested in four stages: original fissure compaction, elastic deformation, plastic deformation and failure. With an increase of the inclination angle of soft rocks, the compaction stage of the rock mass gradually increased, and the elastic modulus gradually decreased. When the inclination angle of soft rock is θ=0° or 15°, the rock mass rupture appears as a combination of soft and hard rock mass failure. When the inclination angle of soft rock is θ=30° or 45°, the rock mass failure mainly occurs in the soft rock area, and the form of rock mass changes from shear failure penetrating the soft rock layer to sliding shear failure along the soft rock layer. The greater the inclination angle of the soft rock layer, the more likely the rock mass is to undergo unstable failure. This study provides a reference for the long-term stability analysis of rock mass engineering containing soft and hard composites and the mechanical behavior of complex layered composite rock mass.
-
Key words:
- soft-hard combination /
- crack evolution /
- digital speckle /
- acoustic emission /
- uniaxial compression
-
-
表 2 不同倾角组合岩体单轴压缩试验结果
Table 2. Experimental results of uniaxial compression of rock masses with different inclination angles of the weak layers
标号 密度/（g·cm−3） 弹性模量/GPa 峰值应变/% 抗压强度/MPa 单个试样 均值 单个试样 均值 单个试样 均值 单个试样 均值 Q0-1 2.42 2.40 2.96 2.94 1.64 1.46 29.50 27.53 Q0-2 2.41 2.99 1.53 26.50 Q0-3 2.36 2.86 1.21 26.59 Q15-1 2.38 2.38 2.86 2.80 1.54 1.51 25.07 25.62 Q15-2 2.41 3.00 1.69 26.95 Q15-3 2.35 2.55 1.30 24.83 Q30-1 2.42 2.39 2.91 2.76 1.57 1.32 18.75 19.42 Q30-2 2.38 2.84 1.26 19.89 Q30-3 2.37 2.54 1.12 19.62 Q45-1 2.28 2.28 2.40 2.39 0.97 1.00 16.99 16.75 Q45-2 2.27 2.39 1.05 16.07 Q45-3 2.28 2.37 0.99 17.02
下载: 导出CSV
-
[1] 毛正君,毕银丽,李成,等. 渭北石灰岩露天采区高陡边坡破坏模式及形态优化研究[J]. 西北地质,2021,54(4):211 − 226. [MAO Zhengjun,BI Yinli,LI Cheng,et al. Study on failure mode and shape optimization of high and steep slope of open-pit limestone mining area in Weibei[J]. Northwestern Geology,2021,54(4):211 − 226. (in Chinese with English abstract)
[MAO Zhengjun, BI Yinli, LI Cheng, et al. Study on failure mode and shape optimization of high and steep slope of open-pit limestone mining area in Weibei[J]. Northwestern Geology, 2021, 54(4)211-226(in Chinese with English abstract)
[2] 姚闯闯,姚鑫,顾畛逵,等. 基于InSAR识别的黄土高原活动性地质灾害发育规律分析[J]. 地质力学学报,2022,28(2):257 − 267. [YAO Chuangchuang,YAO Xin,GU Zhenkui,et al. Analysis on the development law of active geological hazards in the Loess Plateau based on InSAR identification[J]. Journal of Geomechanics,2022,28(2):257 − 267. (in Chinese with English abstract)
[YAO Chuangchuang, YAO Xin, GU Zhenkui, et al. Analysis on the development law of active geological hazards in the Loess Plateau based on InSAR identification[J]. Journal of Geomechanics, 2022, 28(2)257-267(in Chinese with English abstract)]
[3] 李洪梁,高波,张佳佳,等. 内外动力地质作用耦合的崩塌形成机理研究—以藏东昌都地区上三叠统石灰石矿山采场崩塌为例[J]. 地质力学学报,2022,28(6):995 − 1011. [LI Hongliang,GAO Bo,ZHANG Jiajia,et al. Mechanism of rockfall coupled with endogenic and exogenic geological processes: A case study in the upper Triassic limestone mines in the Qamdo area, eastern Tibet[J]. Journal of Geomechanics,2022,28(6):995 − 1011. (in Chinese with English abstract)
[LI Hongliang, GAO Bo, ZHANG Jiajia, et al. Mechanism of rockfall coupled with endogenic and exogenic geological processes: a case study in the upper Triassic limestone mines in the Qamdo area, eastern Tibet[J]. Journal of Geomechanics, 2022, 28(6): 995-1011.(in Chinese with English abstract)
[4] 王小明,李勇,李刚. 中欧岩土工程勘察分级及岩土分类对比[J]. 长江科学院院报,2013,30(10):72 − 76. [WANG Xiaoming,LI Yong,LI Gang. Comparison of the grading of geotechnical investigation and the classification of rock and soil between Europe and China[J]. Journal of Yangtze River Scientific Research Institute,2013,30(10):72 − 76. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-5485.2013.10.015
WANG Xiaoming, LI Yong, LI Gang. Comparison of the grading of geotechnical investigation and the classification of rock and soil between Europe and China[J]. Journal of Yangtze River Scientific Research Institute, 2013, 30（10）: 72-76. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-5485.2013.10.015
[5] 徐伟,冉涛,田凯. 西南红层地区地质灾害发育规律与成灾模式—以云南彝良县为例[J]. 中国地质灾害与防治学报,2021,32(6):127 − 133. [XU Wei,RAN Tao,TIAN Kai. Developing law and disaster modes of geohazards in red bed region of southwestern China:A case study of Yiliang County of Yunnan Province[J]. The Chinese Journal of Geological Hazard and Control,2021,32(6):127 − 133. (in Chinese with English abstract)
XU Wei, RAN Tao, TIAN Kai. Developing law and disaster modes of geohazards in red bed region of southwestern China: a case study of Yiliang County of Yunnan Province[J]. The Chinese Journal of Geological Hazard and Control, 2021, 32（6）: 127-133. （in Chinese with English abstract）
[6] JAEGER J C. Friction of rocks and stability of rock slopes[J]. Géotechnique,1971,21(2):97 − 134.
[7] 李剑光,王永岩. 含水平弱夹层岩体界面应力及破坏形式[J]. 辽宁工程技术大学学报(自然科学版),2015,34(6):710 − 715. [LI Jianguang,WANG Yongyan. Analysis for failure modes and interfacial stress of rock mass with horizontal weak interlayer[J]. Journal of Liaoning Technical University (Natural Science),2015,34(6):710 − 715. (in Chinese with English abstract)
LI Jianguang, WANG Yongyan. Analysis for failure modes and interfacial stress of rock mass with horizontal weak interlayer[J]. Journal of Liaoning Technical University （Natural Science）, 2015, 34（6）: 710-715. （in Chinese with English abstract）
[8] 李剑光. 含倾斜软弱夹层复合岩体强度及蠕变特性研究[D]. 青岛: 青岛科技大学, 2015
LI Jianguang. Study on strength and creep characteristics of composite rock mass with inclined weak interlayer[D]. Qingdao: Qingdao University of Science & Technology, 2015. （in Chinese with English abstract）
[9] SAROGLOU H, TSIAMBAOS G. 2008. A modified Hoek-Brown failure criterionfor anisotropic intact rock[J]. International Journal of Rock Mechanics & Mining Sciences, 45（2） : 223 − 234.
[10] SINGH M,SINGH B. Modified Mohr-Coulomb criterion for non-linear triaxial and polyaxial strength of jointed rocks[J]. International Journal of Rock Mechanics and Mining Sciences,2012,51:43 − 52. doi: 10.1016/j.ijrmms.2011.12.007
[11] 康钦容,张卫中,张电吉. 层状岩体破坏性质试验研究[J]. 科学技术与工程,2017,17(14):273 − 276. [KANG Qinrong,ZHANG Weizhong,ZHANG Dianji. Experimental study on failure property of layered rock mass[J]. Science Technology and Engineering,2017,17(14):273 − 276. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1815.2017.14.043
KANG Qinrong, ZHANG Weizhong, ZHANG Dianji. Experimental study on failure property of layered rock mass[J]. Science Technology and Engineering, 2017, 17（14）: 273-276. （in Chinese with English abstract） doi: 10.3969/j.issn.1671-1815.2017.14.043
[12] 张顶立,王悦汉,曲天智. 夹层对层状岩体稳定性的影响分析[J]. 岩石力学与工程学报,2000,19(2):140 − 144. [ZHANG Dingli,WANG Yuehan,QU Tianzhi. Influence analysis of interband on stability of stratified rockmass[J]. Chinese Journal of Rock Mechanics and Engineering,2000,19(2):140 − 144. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2000.02.003
ZHANG Dingli, WANG Yuehan, QU Tianzhi. Northern Jiaotong University, Beijing China China University of Mining & Technology Xuzhou China Yanzhou Mining group Go. Ltd. , Zoucheng China], WANG Yuehan, QU Tianzhi. Influence analysis of interband on stability of stratified rockmass[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19（2）: 140-144. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-6915.2000.02.003
[13] 鲜学福, 谭学术. 层状岩体破坏机理[M]. 重庆: 重庆大学出版社, 1989
XIAN Xuefu, TAN Xueshu. [M]. Chongqing: Chongqing University Press, 1989. （in Chinese）
[14] 张永泽,刘俊新,冒海军,等. 单轴压缩下页岩力学特性的各向异性试验研究[J]. 金属矿山,2015(12):33 − 37. [ZHANG Yongze,LIU Junxin,MAO Haijun,et al. Anisotropic experimental study on mechanical properties of shale under uniaxial compression[J]. Metal Mine,2015(12):33 − 37. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-1250.2015.12.008
ZHANG Yongze, LIU Junxin, MAO Haijun, et al. Anisotropic experimental study on mechanical properties of shale under uniaxial compression[J]. Metal Mine, 2015（12）: 33-37. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-1250.2015.12.008
[15] 衡帅,杨春和,张保平,等. 页岩各向异性特征的试验研究[J]. 岩土力学,2015,36(3):609 − 616. [HENG Shuai,YANG Chunhe,ZHANG Baoping,et al. Experimental research on anisotropic properties of shale[J]. Rock and Soil Mechanics,2015,36(3):609 − 616. (in Chinese with English abstract) doi: 10.16285/j.rsm.2015.03.001
HENG Shuai, YANG Chunhe, ZHANG Baoping, et al. Experimental research on anisotropic properties of shale[J]. Rock and Soil Mechanics, 2015, 36（3）: 609-616. （in Chinese with English abstract） doi: 10.16285/j.rsm.2015.03.001
[16] 王聪聪,李江腾,林杭,等. 板岩单轴压缩各向异性力学特征[J]. 中南大学学报(自然科学版),2016,47(11):3759 − 3764. [WANG Congcong,LI Jiangteng,LIN Hang,et al. Anisotropic mechanical characteristics of slate in uniaxial compression[J]. Journal of Central South University (Science and Technology),2016,47(11):3759 − 3764. (in Chinese with English abstract)
WANG Congcong, LI Jiangteng, LIN Hang, et al. Anisotropic mechanical characteristics of slate in uniaxial compression[J]. Journal of Central South University （Science and Technology）, 2016, 47（11）: 3759-3764. （in Chinese with English abstract）
[17] 丁多文,罗国煜. 链子崖危岩体软弱夹层的力学特性[J]. 水文地质工程地质,1994,21(6):7 − 9. [DING Duowen,LUO Guoyu. Mechanical properties of weak interlayers in Lianziya dangerous rock mass[J]. Hydrogeology & Engineering Geology,1994,21(6):7 − 9. (in Chinese with English abstract)
DING Duowen, LUO Guoyu. Mechanical properties of weak interlayers in Lianziya dangerous rock mass [J]. Hydrogeology & Engineering Geology, 1994, 21（6）: 7-9. （in Chinese with English abstract）
[18] TIEN Y M,KUO M C. A failure criterion for transversely isotropic rocks[J]. International Journal of Rock Mechanics and Mining Sciences,2001,38(3):399 − 412. doi: 10.1016/S1365-1609(01)00007-7
[19] TIEN Y M,TSAO P F. Preparation and mechanical properties of artificial transversely isotropic rock[J]. International Journal of Rock Mechanics and Mining Sciences,2000,37(6):1001 − 1012. doi: 10.1016/S1365-1609(00)00024-1
[20] 张立. 冻融循环条件下含软弱夹层隧道围岩力学性质及破坏特征[J]. 水文地质工程地质,2021,48(5):74 − 80. [ZHANG Li. On mechanical properties and failure characteristics of surrounding rock of tunnel with weak interlayer under freezing-thawing cycles[J]. Hydrogeology & Engineering Geology,2021,48(5):74 − 80. (in Chinese with English abstract)
ZHANG Li. On mechanical properties and failure characteristics of surrounding rock of tunnel with weak interlayer under freezing-thawing cycles[J]. Hydrogeology & Engineering Geology, 2021, 48（5）: 74-80. （in Chinese with English abstract）
[21] 刘伟,曾亚武,夏磊,等. 单轴压缩下层状岩体的各项异性研究[J]. 水利与建筑工程学报,2018,16(1):145 − 149. [LIU Wei,ZENG Yawu,XIA Lei,et al. Anisotropy of layered rock mass under uniaxial compression[J]. Journal of Water Resources and Architectural Engineering,2018,16(1):145 − 149. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-1144.2018.01.026
LIU Wei, ZENG Yawu, XIA Lei, et al. Anisotropy of layered rock mass under uniaxial compression[J]. Journal of Water Resources and Architectural Engineering, 2018, 16（1）: 145-149. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-1144.2018.01.026
[22] 赵永红,杨振涛. 含软弱夹层岩石材料的损伤破坏过程[J]. 岩石力学与工程学报,2005,24(13):2350 − 2356. [ZHAO Yonghong,YANG Zhentao. Research on fracturing around cemented slot in rock specimen[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(13):2350 − 2356. (in Chinese with English abstract)
ZHAO Yonghong, YANG Zhentao. Research on fracturing around cemented slot in rock specimen[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24（13）: 2350-2356. （in Chinese with English abstract）
-
