Analysis of high-position landslide characteristics based on multi-source remote sensing data：A case study of the Yanwo Village landslide in Rongshan Town, Lizhou District, Guangyuan City
-
摘要:
2021年10月6日13时许，四川省广元市利州区荣山镇岩窝村三组发生高位滑坡灾害。滑坡造成4处民房、3条电力线路被毁，掩埋170 m长的乡村公路，堵塞河道350 m。利用高位滑坡滑前多期卫星数据、滑坡滑后高精度无人机航空影像以及机载LiDAR数据等多源遥感信息源，采用三维立体+时间的四维分析方法，研究高位滑坡特征及其滑动模式。从高位滑坡发育背景入手，通过高位滑坡滑前变形特征以及高位滑动过程动态分析，总结高位滑坡变形破坏特征及滑动模式。根据滑坡已经发生过程推演及后部残留滑坡体稳定性分析结果，预测分析高位滑坡未来滑动的三种滑动模式：一是滑坡后缘继续错落和活动，挤压前部滑坡体直接剪出；二是滑坡后缘继续错落和活动，沿着已有滑坡通道发生推移式滑坡；三是前部滑坡体启动，引发中后部滑坡体发生牵引式滑坡。高位滑坡在西南山区屡见不鲜，在早期地质灾害隐患调查中应有效识别、加强防灾减灾措施。
Abstract:On October 6, 2021, a high-position landslide disaster occurred in Yanwo Village, Rongshan Town, Lizhou District, Guangyuan City,Sichuan Province, around 13: 00. The landslide resulted in the destruction of 4 houses, 3 power lines, the burial of a 170-meter-long rural road, and the blockage of a 350-meter-long river channel. By utilizing a variety of remote sensing information sources, including multi-period satellite data before and after landslide, high-precision UAV aerial images, and airborne LiDAR data, the characteristics of high landslide and its sliding mode are studied by using a four-dimensional analysis approach combining three-dimensional space with time. Starting from the development background of high landslide, the deformation and failure characteristics and sliding mode of high landslide are summarized by analyzing the deformation characteristics before sliding and the dynamic procession of the high landslide. Based on the deduced landslide progression and the stability evaluation of the residual landslide at the rear, three sliding modes for future high-position landslide events are predicted and analyzed: Firstly, the back edge of landslide continues to be disjointed and move, causing a direct shear failure of the front part of the landslide by squeezing. Secondly, the trailing edge of the landslide continues to be disjointed and move, resulting in the sliding landslide occurs along the existing landslide channel. Thirdly, the initiation of the front part of the landslide trigger a tractional landslide in the middle and rear parts of the landslide. High-position landslides are common in the southwest mountainous areas, and during early geological hazard investigations, they should be effectively identified, and disaster prevention and mitigation measures should be strengthened.
-
-
表 1 岩窝村滑坡多源遥感数据列表
Table 1. List of multi-source remote sensing data for the Yanwo Village landslide
序号 数据日期 数据类型 分辨率/m 数据来源 1 2013-02-12 光学卫星 0.5 Google地球 2 2013-03-05 光学卫星 0.5 Google地球 3 2013-04-01 光学卫星 0.5 Google地球 4 2014-10-05 光学卫星 0.5 Google地球 5 2014-11-30 光学卫星 0.5 Google地球 6 2015-05-29 光学卫星 0.5 Google地球 7 2016-06-07 光学卫星 0.5 Google地球 8 2018-01-17 光学卫星 0.5 Google地球 9 2019-06-03 光学卫星 0.5 Google地球 10 2019-09-22 光学卫星 0.5 Google地球 11 2020-03-17 光学卫星 0.8 高分二号卫星 12 2020-04-30 光学卫星 0.8 高分二号卫星 13 2020-05-05 光学卫星 0.8 高分二号卫星 14 2020-07-13 光学卫星 0.8 高分二号卫星 15 2021-01-21 光学卫星 0.8 高分二号卫星 16 2021-02-05 光学卫星 0.8 高分二号卫星 17 2021-02-20 光学卫星 0.8 高分二号卫星 18 2021-03-01 光学卫星 0.8 高分七号卫星 19 2021-09-19 光学卫星 0.8 高分七号卫星 20 2021-09-20 光学卫星 0.8 高分二号卫星 21 2021-10-17 无人机航空影像 0.2 深圳飞马机器人
科技有限公司22 2021-10-26 激光雷达数据 0.05 深圳飞马机器人
科技有限公司23 2021-10-26 无人机航空影像 0.2 深圳飞马机器人
科技有限公司24 2021-11-28 无人机航空影像 0.2 深圳飞马机器人
科技有限公司
下载: 导出CSV
表 2 岩土体主要物理力学性质指标
Table 2. Key physical and mechanical properties of rock and soil mass
岩土名称 天然重度
/（kN·m−3）饱和重度
/（kN·m−3）天然抗剪强度指标 黏聚力/kPa 内摩擦角/（°） 滑体 17.0 17.6 16.0 15.0 粉质黏土（硬塑） 18.0 18.2 18.0 23.0 基岩 20.0 20.4 30.0 15.0
下载: 导出CSV
-
[1] WEIDINGER J T. Landslide damsinthe high mountains of India,Nepaland China-stability and life spanoftheirdammed lakes[J]. Italian Journal of Engineering Geology and Environment,2006,(1):67 − 80.
[2] YIN Yueping,WANG Wenpei,ZHANG Nan,et al. The June 2017 Maoxian landslide:Geological disaster in an earthquake area after the Wenchuan Ms 8.0 earthquake[J]. Science China Technological Sciences,2017,60(11):1762 − 1766. doi: 10.1007/s11431-017-9148-2
[3] 刘传正,郭强,陈红旗. 贵州省纳雍县岩脚寨危岩崩塌灾害成因初步分析[J]. 中国地质灾害与防治学报,2004,15(4):120 − 121. [LIU Chuanzheng,GUO Qiang,CHEN Hongqi. Preliminary analysis on the causes of dangerous rock collapse in Yanjiaozhai,Nayong County,Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2004,15(4):120 − 121. (in Chinese with English abstract)
LIU Chuanzheng, GUO Qiang, CHEN Hongqi . Preliminary analysis on the causes of dangerous rock collapse in Yanjiaozhai, Nayong County, Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2004 ,15 （4 ）:120 −121 . （in Chinese with English abstract）[4] 许强,黄润秋,殷跃平,等. 2009年6·5重庆武隆鸡尾山崩滑灾害基本特征与成因机理初步研究[J]. 工程地质学报,2009,17(4):433 − 444. [XU Qiang,HUANG Runqiu,YIN Yueping,et al. The jiweishan landslide of June 5,2009 in Wulong,Chongqing:Characteristics and failure mechanism[J]. Journal of Engineering Geology,2009,17(4):433 − 444. (in Chinese with English abstract)
XU Qiang, HUANG Runqiu, YIN Yueping, et al . The jiweishan landslide of June 5, 2009 in Wulong, Chongqing: Characteristics and failure mechanism[J]. Journal of Engineering Geology,2009 ,17 （4 ）:433 −444 . （in Chinese with English abstract）[5] 殷跃平. 斜倾厚层山体滑坡视向滑动机制研究——以重庆武隆鸡尾山滑坡为例[J]. 岩石力学与工程学报,2010,29(2):217 − 226. [YIN Yueping. Mechanism of apparent dip slide of inclined bedding rockslide:A case study of Jiweishan rockslide in Wulong,Chongqing[J]. Chinese Journal of Rock Mechanics and Engineering,2010,29(2):217 − 226. (in Chinese with English abstract)
YIN Yueping . Mechanism of apparent dip slide of inclined bedding rockslide: A case study of Jiweishan rockslide in Wulong, Chongqing[J]. Chinese Journal of Rock Mechanics and Engineering,2010 ,29 （2 ）:217 −226 . （in Chinese with English abstract）[6] 梁京涛,成余粮,王军,等. 2013年7月10日四川省都江堰三溪村五里坡特大滑坡灾害遥感调查及成因机制浅析[J]. 工程地质学报,2014,22(6):1194 − 1203. [LIANG Jingtao,CHENG Yuliang,WANG Jun,et al. Remote sensing investigation and formation mechanism on Wulipo landslide of July 10,2013 in Sanxi Village,Dujiangyan,Sichuan Province[J]. Journal of Engineering Geology,2014,22(6):1194 − 1203. (in Chinese with English abstract)
LIANG Jingtao, CHENG Yuliang, WANG Jun, et al . Remote sensing investigation and formation mechanism on Wulipo landslide of July 10, 2013 in Sanxi Village, Dujiangyan, Sichuan Province[J]. Journal of Engineering Geology,2014 ,22 （6 ）:1194 −1203 . （in Chinese with English abstract）[7] 张涛,杨志华,张永双,等. 四川茂县新磨村高位滑坡铲刮作用分析[J]. 水文地质工程地质,2019,46(3):138 − 145. [ZHANG Tao,YANG Zhihua,ZHANG Yongshuang,et al. An analysis of the entrainment of the Xinmo high-position landslide in Maoxian County,Sichuan[J]. Hydrogeology & Engineering Geology,2019,46(3):138 − 145. (in Chinese with English abstract)
ZHANG Tao, YANG Zhihua, ZHANG Yongshuang, et al . An analysis of the entrainment of the Xinmo high-position landslide in Maoxian County, Sichuan[J]. Hydrogeology & Engineering Geology,2019 ,46 （3 ）:138 −145 . （in Chinese with English abstract）[8] 温铭生,方志伟,王阳谷. 都江堰市五里坡特大滑坡灾害特征与致灾成因[J]. 现代地质,2015,29(2):448 − 453. [WEN Mingsheng,FANG Zhiwei,WANG Yanggu. Characteristics and disaster causes of Wulipo landslide in Dujiangyan City[J]. Geoscience,2015,29(2):448 − 453. (in Chinese with English abstract)
WEN Mingsheng, FANG Zhiwei, WANG Yanggu . Characteristics and disaster causes of Wulipo landslide in Dujiangyan City[J]. Geoscience,2015 ,29 （2 ）:448 −453 . （in Chinese with English abstract）[9] 王佳运,张茂省,贾俊,等. 都江堰中兴镇高位滑坡泥石流灾害致灾成因与发展趋势[J]. 西北地质,2014,47(3):157 − 164. [WANG Jiayun,ZHANG Maosheng,JIA Jun,et al. The cause and development tendency of the high-locality landslide and debris flow disaster of Zhongxing Town,Dujiangyan City[J]. Northwestern Geology,2014,47(3):157 − 164. (in Chinese with English abstract)
WANG Jiayun, ZHANG Maosheng, JIA Jun, et al . The cause and development tendency of the high-locality landslide and debris flow disaster of Zhongxing Town, Dujiangyan City[J]. Northwestern Geology,2014 ,47 （3 ）:157 −164 . （in Chinese with English abstract）[10] 王佳运,石小亚,武立,等. “8·12”山阳滑坡视向滑动成因机理[J]. 西北地质,2018,51(3):232 − 239. [WANG Jiayun,SHI Xiaoya,WU Li,et al. Formation mechanism of apparent dip slide in the Shanyang “ 8·12” landslide[J]. Northwestern Geology,2018,51(3):232 − 239. (in Chinese with English abstract)
WANG Jiayun, SHI Xiaoya, WU Li, et al . Formation mechanism of apparent dip slide in the Shanyang “ 8·12” landslide[J]. Northwestern Geology,2018 ,51 （3 ）:232 −239 . （in Chinese with English abstract）[11] 崔芳鹏,李滨,杨忠平,等. 贵州纳雍普洒滑坡动力触发机制离散元模拟分析[J]. 中国岩溶,2020,39(4):524 − 534. [CUI Fangpeng,LI Bin,YANG Zhongping,et al. Discrete element modelling on dynamic triggering mechanism of the Pusa landslide in Nayong County,Guizhou Province[J]. Carsologica Sinica,2020,39(4):524 − 534. (in Chinese with English abstract)
CUI Fangpeng, LI Bin, YANG Zhongping, et al . Discrete element modelling on dynamic triggering mechanism of the Pusa landslide in Nayong County, Guizhou Province[J]. Carsologica Sinica,2020 ,39 （4 ）:524 −534 . （in Chinese with English abstract）[12] 肖锐铧,陈红旗,冷洋洋,等. 贵州纳雍“8·28”崩塌破坏过程与变形破坏机理初探[J]. 中国地质灾害与防治学报,2018,29(1):3 − 9. [XIAO Ruihua,CHEN Hongqi,LENG Yangyang,et al. Preliminary analysis on the failure process and mechanism of the August 28 collapse in Nayong County,Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2018,29(1):3 − 9. (in Chinese with English abstract)
XIAO Ruihua, CHEN Hongqi, LENG Yangyang, et al . Preliminary analysis on the failure process and mechanism of the August 28 collapse in Nayong County, Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2018 ,29 （1 ）:3 −9 . （in Chinese with English abstract）[13] 王立朝,温铭生,冯振,等. 中国西藏金沙江白格滑坡灾害研究[J]. 中国地质灾害与防治学报,2019,30(1):1 − 9. [WANG Lichao,WEN Mingsheng,FENG Zhen,et al. Researches on the baige landslide at Jinshajiang River,Tibet,China[J]. The Chinese Journal of Geological Hazard and Control,2019,30(1):1 − 9. (in Chinese with English abstract)
WANG Lichao, WEN Mingsheng, FENG Zhen, et al . Researches on the baige landslide at Jinshajiang River, Tibet, China[J]. The Chinese Journal of Geological Hazard and Control,2019 ,30 （1 ）:1 −9 . （in Chinese with English abstract）[14] 高杨,贺凯,李壮,等. 西南岩溶山区特大滑坡成灾类型及动力学分析[J]. 水文地质工程地质,2020,47(4):14 − 23. [GAO Yang,HE Kai,LI Zhuang,et al. An analysis of disaster types and dynamics of landslides in the southwest Karst Mountain areas[J]. Hydrogeology & Engineering Geology,2020,47(4):14 − 23. (in Chinese with English abstract)
GAO Yang, HE Kai, LI Zhuang, et al . An analysis of disaster types and dynamics of landslides in the southwest Karst Mountain areas[J]. Hydrogeology & Engineering Geology,2020 ,47 （4 ）:14 −23 . （in Chinese with English abstract）[15] 王得双,梁收运,赵红亮. 高位滑坡特征与防治[J]. 地质灾害与环境保护,2018,29(3):5 − 11. [WANG Deshuang,LIANG Shouyun,ZHAO Hongliang. Characteristic of high-locality landslide and prevention[J]. Journal of Geological Hazards and Environment Preservation,2018,29(3):5 − 11. (in Chinese with English abstract)
WANG Deshuang, LIANG Shouyun, ZHAO Hongliang . Characteristic of high-locality landslide and prevention[J]. Journal of Geological Hazards and Environment Preservation,2018 ,29 （3 ）:5 −11 . （in Chinese with English abstract）[16] 上官力. 高位陡倾崩塌堆积体滑坡形成机理研究[D]. 北京:中国铁道科学研究院,2015. [SHANGGUAN Li. Research on genetic mechanism of the high dipping landslide composed of collapse deposit[D]. Beijing:China Academy of Railway Sciences,2015. (in Chinese with English abstract)
SHANGGUAN Li. Research on genetic mechanism of the high dipping landslide composed of collapse deposit[D]. Beijing: China Academy of Railway Sciences, 2015. （in Chinese with English abstract） [17] 刘雄. 新滩大滑坡机制探讨[J]. 岩土力学,1986,7(2):53 − 60. [LIU Xiong. Discussion of the mechanism for Xintan beach landslide[J]. Rock and Soil Mechanics,1986,7(2):53 − 60. (in Chinese with English abstract)
LIU Xiong . Discussion of the mechanism for Xintan beach landslide[J]. Rock and Soil Mechanics,1986 ,7 （2 ）:53 −60 . （in Chinese with English abstract）[18] 瞿婧晶,陆燕,吴曙亮,等. 基于不同方法的江苏镇江地区下蜀土边坡稳定性分析与评价[J]. 中国地质灾害与防治学报,2021,32(1):35 − 42. [QU Jingjing,LU Yan,WU Shuliang,et al. Evaluation of Xiashu loess slope stability in Zhenjiang area using different methods[J]. The Chinese Journal of Geological Hazard and Control,2021,32(1):35 − 42. (in Chinese with English abstract)
QU Jingjing, LU Yan, WU Shuliang, et al . Evaluation of Xiashu loess slope stability in Zhenjiang area using different methods[J]. The Chinese Journal of Geological Hazard and Control,2021 ,32 （1 ）:35 −42 . （in Chinese with English abstract）[19] 杨学堂,王飞. 边坡稳定性评价方法及发展趋势[J]. 岩土工程技术,2004,18(2):103 − 106. [YANG Xuetang,WANG Fei. Evaluation method of slope stability and its developing trend[J]. Geotechnical Engineering Technique,2004,18(2):103 − 106. (in Chinese with English abstract)
YANG Xuetang, WANG Fei . Evaluation method of slope stability and its developing trend[J]. Geotechnical Engineering Technique,2004 ,18 （2 ）:103 −106 . （in Chinese with English abstract）[20] 周维垣,寇晓东. 无单元法及其在岩土工程中的应用[J]. 岩土工程学报,1998,20(1):5 − 9. [ZHOU Weiyuan,KOU Xiaodong. Element free method and its application in geotechnique engineering[J]. Chinese Journal of Geotechnical Engineering,1998,20(1):5 − 9. (in Chinese with English abstract)
ZHOU Weiyuan, KOU Xiaodong . Element free method and its application in geotechnique engineering[J]. Chinese Journal of Geotechnical Engineering,1998 ,20 （1 ）:5 −9 . （in Chinese with English abstract）[21] 王勖成. 有限单元法[M]. 北京:清华大学出版社,2003. [WANG Xucheng. Finite element method[M]. Beijing:Tsinghua University Press,2003. (in Chinese)
WANG Xucheng. Finite element method[M]. Beijing: Tsinghua University Press, 2003. （in Chinese） [22] GHABOUSSI J,BARBOSA R. Three-dimensional discrete element method for granular materials[J]. International Journal for Numerical and Analytical Methods in Geomechanics,1990,14(7):451 − 472. doi: 10.1002/nag.1610140702
[23] 李元松,高晖,陈峰,等. 乌尉高速公路边坡稳定性综合评价[J]. 水文地质工程地质,2018,45(4):150 − 156. [LI Yuansong,GAO Hui,CHEN Feng,et al. Comprehensive assessment of slope stability in Wu—Yu highway[J]. Hydrogeology & Engineering Geology,2018,45(4):150 − 156. (in Chinese with English abstract)
LI Yuansong, GAO Hui, CHEN Feng, et al . Comprehensive assessment of slope stability in Wu—Yu highway[J]. Hydrogeology & Engineering Geology,2018 ,45 （4 ）:150 −156 . （in Chinese with English abstract）[24] 殷跃平,张作辰,黎志恒,等. 兰州皋兰山黄土滑坡特征及灾度评估研究[J]. 第四纪研究,2004,24(3):302 − 310. [YIN Yueping,ZHANG Zuochen,LI Zhiheng,et al. Occurrence and hazard assessment on loess landslide of Gaolanshan in Lanzhou[J]. Quaternary Sciences,2004,24(3):302 − 310. (in Chinese with English abstract)
YIN Yueping, ZHANG Zuochen, LI Zhiheng, et al . Occurrence and hazard assessment on loess landslide of Gaolanshan in Lanzhou[J]. Quaternary Sciences,2004 ,24 （3 ）:302 −310 . （in Chinese with English abstract）[25] 王述红,朱承金,张紫杉,等. 基于动态强度折减DDA法的边坡多滑面稳定性分析[J]. 煤炭学报,2019,44(4):1084 − 1091. [WANG Shuhong,ZHU Chengjin,ZHANG Zishan,et al. Stability analysis of multi-slip surface of slope based on dynamic strength reduction DDA method[J]. Journal of China Coal Society,2019,44(4):1084 − 1091. (in Chinese with English abstract)
WANG Shuhong, ZHU Chengjin, ZHANG Zishan, et al . Stability analysis of multi-slip surface of slope based on dynamic strength reduction DDA method[J]. Journal of China Coal Society,2019 ,44 （4 ）:1084 −1091 . （in Chinese with English abstract）[26] MATSUI T,SAN K C. Finite element slope stability analysis by shear strength reduction technique[J]. Soils and Foundations,1992,32(1):59 − 70. doi: 10.3208/sandf1972.32.59
-
