摘要:
桩板拦石墙是一种拦截落石的新型被动防护结构，由悬臂桩、桩间板和缓冲垫层组成。这种结构具有地形适应性强、占地面积小、拦截高度大等优点，在落石高发区得到了应用。然而，由于悬臂桩的极限承载力缺乏详细的报道，因此无法为工程实践提供指导。文章首先根据落石冲击力传播特征，提出缓冲垫层的合理厚度；然后根据桩身的受力和变形特性，采用弹性固支悬臂梁模型和Winkler弹性地基梁模型推导了桩身内力、位移的理论计算方法，实现了落石冲击作用下悬臂桩设计参数的自动求解。结果表明：当落石直径为2 m、冲击高度为7.0 m，冲击速度为10 m/s，且砂土垫层厚度为落石直径的1.5倍时，双排三肢钢筋1.5 m×1.2 m悬臂桩可承受冲击力为2.51×106 N且冲击能量为565 kJ的落石冲击。对于冲击能量更高的情况，建议优先提高拦石桩的抗弯能力。研究可为西部山区岩崩防灾减灾提供科学依据。
Abstract:Pile-slab rockfall retaining wall is a novel passive protective structure designed to intercept falling rocks. It is made up of cantilever piles, pile-intermediate slabs, and cushion layers. This structure features strong terrain adaptability , small footprint, and high interception height, making it applicable in high-risk rockfall areas. However, due to the lack of detailed reports on the ultimate bearing capacity of cantilever piles, guidance for engineering practice is unavailable. This paper first proposes a reasonable thickness for the cushion layer based on the characteristics of the propagation of falling rock impact forces. Then, according to the stress and deformation characteristics of the pile body, theoretical calculation methods of the internal forces and displacements of the pile body are derived using the elastic support cantilever beam model and the Winkler elastic foundation beam model, enabling the automatic determination of design parameters for cantilever pile under falling rock impact. The results indicate that for a rockfall with a diameter of 2 m, impact height of 7.0 m, impact velocity of 10 m/s, and a cushion layer thickness of 1.5 times the rockfall diameter, a double-row triple-limb steel-reinforced 1.5 m × 1.2 m cantilever pile can withstand an impact force of 2.51 × 106 N and impact energy of 565 kJ. For cases with higher falling rock impact energy, it is recommended to prioritize enhancing the bending resistance of the retaining wall. This research provides a scientific basis for disaster prevention and reduction in rockfall-prone areas in the western mountainous regions of China.
-
Key words:
- rockfall /
- cushion /
- rockfall retaining pile /
- internal force of pile /
- optimal design
-
-
表 1 落石冲击力计算结果
Table 1. Calculation results of rockfall impact force
参数 落石
半径
/m落石
质量
/kg冲击
速度
/（m·s−1）垫层
厚度
/m垫层变形
模量
/kPa垫层
内摩擦角
/（°）落石
冲击力
/MN取值 1 11309.7 5 3 35 000 39.0 1.09 1 11309.7 10 3 35 000 39.0 2.51 1 11309.7 15 3 35 000 39.0 4.08 1 11309.7 20 3 35 000 39.0 5.76
下载: 导出CSV
表 2 悬臂桩结构和材料参数
Table 2. Cantilever pile structure and material parameters
参数 悬臂段
长度
/m嵌固段
长度
/m冲击力
作用点距离
/m截面
宽度/m截面
高度/m地基抗力的
比例系数
/（kN·m−4）取值 9.5 9.5 7.0 1.2 1.5 10000
下载: 导出CSV
表 3 混凝土物理力学参数
Table 3. Concrete physical mechanical parameters
材料
类型弹性
模量
/MPa泊松比 抗压强度
标准值
/MPa轴心抗压
强度设计值
/MPa轴心抗拉
强度设计值
/MPaC50混凝土 34500 0.20 32.4 23.1 1.89
下载: 导出CSV
表 4 钢筋材料参数
Table 4. Reinforcement material parameters
型号 弹性
模量
/MPa泊松比 抗拉强度
设计值
/MPa钢筋抗压
强度设计值
/MPa极限
拉应变HRB400（纵筋） 2.0 × 105 0.27 360 360 0.0305 HRB335（箍筋） 2.0 × 105 0.27 300 300 0.0305
下载: 导出CSV
表 5 桩身内力计算结果（h2=9.5 m）
Table 5. Calculation results of pile body internal forces (h2=9.5 m)
参数 冲击能量/kJ 横向荷载/MN 桩身最大弯矩/（MN·m） 允许弯矩/（MN·m） 桩身最大剪力/MN 允许剪力/MN 桩顶扰度/m 允许扰度/m 取值 141 0.286 3.34 6.57 0.578 3.06 0.031 0.3558 565 0.656 6.54 6.57 1.125 3.06 0.063 0.3558 1272 1.07 10.09 6.57 1.75 3.06 0.097 0.3558 2261 1.51 13.91 6.57 2.41 3.06 0.136 0.3558
下载: 导出CSV
表 6 桩身内力计算结果（h2=8.5 m）
Table 6. Calculation results of pile body internal forces (h2=8.5 m)
参数 冲击能量/kJ 横向荷载/MN 桩身最大弯矩/（MN·m） 允许弯矩/（MN·m） 桩身最大剪力/MN 允许剪力/MN 桩顶扰度/m 允许扰度/m 取值 141 0.286 3.37 6.57 0.581 3.06 0.032 0.3558 565 0.656 6.58 6.57 0.952 3.06 0.063 0.3558 1272 1.07 10.15 6.57 1.425 3.06 0.098 0.3558 2261 1.51 13.98 6.57 1.984 3.06 0.136 0.3558
下载: 导出CSV
表 7 桩身内力计算结果（h2=7.5 m）
Table 7. Calculation results of pile body internal forces (h2=7.5 m)
参数 冲击能量/kJ 横向荷载/MN 桩身最大弯矩/（MN·m） 允许弯矩/（MN·m） 桩身最大剪力/MN 允许剪力/MN 桩顶扰度/m 允许扰度/m 取值 141 0.286 3.48 6.57 0.581 3.06 0.031 0.3558 565 0.656 6.71 6.57 0.952 3.06 0.061 0.355 1272 1.07 10.33 6.57 1.363 3.06 0.095 0.3558 2261 1.51 14.21 6.57 1.803 3.06 0.132 0.3558
下载: 导出CSV
表 8 桩身内力计算结果（h2=6.5 m）
Table 8. Calculation results of pile body internal forces (h2=6.5 m)
参数 冲击能量/kJ 横向荷载/MN 桩身最大弯矩/（MN·m） 允许弯矩/（MN·m） 桩身最大剪力/MN 允许剪力/MN 桩顶扰度/m 允许扰度/m 取值 141 0.286 3.88 6.57 0.581 3.06 0.028 0.3558 565 0.656 7.12 6.57 0.952 3.06 0.057 0.3558 1272 1.07 10.84 6.57 1.363 3.06 0.089 0.3558 2261 1.51 14.84 6.57 1.803 3.06 0.122 0.3558
下载: 导出CSV
-
[1] 刘传正,肖锐铧. 湖北远安盐池河1980年“6•3” 山崩灾难成因分析[J]. 灾害学,2021,36(2):130 − 133. [LIU Chuanzheng,XIAO Ruihua. Mechanism analysis on Yanchihe avalanche disaster in Yuan’an,Hubei[J]. Journal of Catastrophology,2021,36(2):130 − 133. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-811X.2021.02.022
LIU Chuanzheng, XIAO Ruihua. Mechanism analysis on Yanchihe avalanche disaster in Yuan’an, Hubei［J］. Journal of Catastrophology, 2021, 36（2）: 130 − 133. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-811X.2021.02.022
[2] 罗刚,程谦恭,沈位刚,等. 高位高能岩崩研究现状与发展趋势[J]. 地球科学,2022,47(3):913 − 934. [LUO Gang,CHENG Qiangong,SHEN Weigang,et al. Research status and development trend of the high-altitude extremely-energetic rockfalls[J]. Earth Science,2022,47(3):913 − 934. (in Chinese with English abstract)] doi: 10.3321/j.issn.1000-2383.2022.3.dqkx202203013
LUO Gang, CHENG Qiangong, SHEN Weigang, et al. Research status and development trend of the high-altitude extremely-energetic rockfalls［J］. Earth Science, 2022, 47（3）: 913 − 934. （in Chinese with English abstract） doi: 10.3321/j.issn.1000-2383.2022.3.dqkx202203013
[3] 黄维,艾东,胡胜华,等. 鄂西山区崩塌落石运动特征及危险性分析——以远安县瓦坡崩塌区为例[J]. 中国地质灾害与防治学报,2022,33(6):37 − 43. [HUANG Wei,AI Dong,HU Shenghua,et al. Characteristics of rockfall trajectory and hazard assessment in western Hubei Province:A case study of the Wapo collapse area in Yuan’an County[J]. The Chinese Journal of Geological Hazard and Control,2022,33(6):37 − 43. (in Chinese with English abstract)]
HUANG Wei, AI Dong, HU Shenghua, et al. Characteristics of rockfall trajectory and hazard assessment in western Hubei Province: A case study of the Wapo collapse area in Yuan’an County［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（6）: 37 − 43. （in Chinese with English abstract）
[4] 尚寒春,刘科,郦亚军,等. 预制拼装式明洞结构在成昆铁路K279崩塌落石治理中的应用[J]. 隧道建设(中英文),2023,43(增刊1):330 − 336. [SHANG Hanchun,LIU Ke,LI Yajun,et al. Application of Precast Assembled Open-cut Tunnel Structure in chengdu-kunming railway K279 Collapse and Rockfall Control[J]. Tunnel Construction,2023,43(Sup 1):330 − 336. (in Chinese)]
SHANG Hanchun, LIU Ke, LI Yajun, et al. Application of Precast Assembled Open-cut Tunnel Structure in chengdu-kunming railway K279 Collapse and Rockfall Control［J］. Tunnel Construction, 2023, 43（Sup 1）: 330 − 336. （in Chinese）
[5] 冉龙洲, 袁松, 王希宝, 等. 明棚洞落石冲击荷载计算方法研究[J]. 岩土力学,2023,44(6):1748 − 1760. [RAN Longzhou, YUAN Song, WANG Xibao, et al. A method for calculating rockfall impact load on shed tunnel[J]. Rock and Soil Mechanics,2023,44(6):1748 − 1760. (in Chinese with English abstract)]
RAN Longzhou, YUAN Song, WANG Xibao, et al. A method for calculating rockfall impact load on shed tunnel［J］. Rock and Soil Mechanics, 2023, 44（6）: 1748 − 1760. （in Chinese with English abstract）
[6] 易靖松,王峰,程英建,等. 高山峡谷区地质灾害危险性评价——以四川省阿坝县为例[J]. 中国地质灾害与防治学报,2022,33(3):134 − 142. [YI Jingsong,WANG Feng,CHENG Yingjian,et al. Study on the risk assessment of geological disasters in alpine valley area:A case study in Aba County,Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(3):134 − 142. (in Chinese with English abstract)]
YI Jingsong, WANG Feng, CHENG Yingjian, et al. Study on the risk assessment of geological disasters in alpine valley area: A case study in Aba County, Sichuan Province［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（3）: 134 − 142. （in Chinese with English abstract）
[7] 叶四桥, 陈洪凯, 唐红梅. 落石冲击力计算方法的比较研究[J]. 水文地质工程地质,2010,37(2):59 − 64. [YE Siqiao, CHEN Hongkai, TANG Hongmei. Comparative research on impact force calculation methods for rockfalls[J]. Hydrogeology & Engineering Geology,2010,37(2):59 − 64. (in Chinese with English abstract)]
YE Siqiao, CHEN Hongkai, TANG Hongmei. Comparative research on impact force calculation methods for rockfalls［J］. Hydrogeology & Engineering Geology, 2010, 37（2）: 59 − 64. （in Chinese with English abstract）
[8] 胡卸文,梅雪峰,杨瀛,等. 落石冲击荷载作用下的桩板拦石墙结构动力响应[J]. 工程地质学报,2019,27(1):123 − 133. [HU Xiewen,MEI Xuefeng,YANG Ying,et al. Dynamic response of pile-plate rock retaining wall under impact of rockfall[J]. Journal of Engineering Geology,2019,27(1):123 − 133. (in Chinese with English abstract)]
HU Xiewen, MEI Xuefeng, YANG Ying, et al. Dynamic response of pile-plate rock retaining wall under impact of rockfall［J］. Journal of Engineering Geology, 2019, 27（1）: 123 − 133. （in Chinese with English abstract）
[9] 蔡向阳,铁永波. 崩塌落石运动计算模型综述[J]. 地质灾害与环境保护,2016,27(3):100 − 104. [CAI Xiangyang,TIE Yongbo. Overview of calulation model for collapse and rockfall movement[J]. Journal of Geological Hazards and Environment Preservation,2016,27(3):100 − 104. (in Chinese with English abstract)] doi: 10.3969/j.issn.1006-4362.2016.03.023
CAI Xiangyang, TIE Yongbo. Overview of calulation model for collapse and rockfall movement［J］. Journal of Geological Hazards and Environment Preservation, 2016, 27（3）: 100 − 104. （in Chinese with English abstract） doi: 10.3969/j.issn.1006-4362.2016.03.023
[10] 吴建利, 胡卸文, 梅雪峰, 等. 落石冲击混凝土板与缓冲层组合结构的动力响应[J]. 水文地质工程地质,2021,48(1):78 − 87. [WU Jianli, HU Xiewen, MEI Xuefeng, et al. Dynamic response of RC slab with cushion layer composed of sandy soil to rockfall impact[J]. Hydrogeology & Engineering Geology,2021,48(1):78 − 87. (in Chinese with English abstract)]
WU Jianli, HU Xiewen, MEI Xuefeng, et al. Dynamic response of RC slab with cushion layer composed of sandy soil to rockfall impact［J］. Hydrogeology & Engineering Geology, 2021, 48（1）: 78 − 87. （in Chinese with English abstract）
[11] 姬中民, 张晟, 伍法权, 等. 落石法向恢复系数的多因素联合影响研究[J]. 水文地质工程地质,2022,49(2):164 − 173. [JI Zhongmin, ZHANG Sheng, WU Faquan, et al. Research on the joint influence of multiple factors on the normal coefficient of restitution of rockfall[J]. Hydrogeology & Engineering Geology,2022,49(2):164 − 173. (in Chinese with English abstract)]
JI Zhongmin, ZHANG Sheng, WU Faquan, et al. Research on the joint influence of multiple factors on the normal coefficient of restitution of rockfall［J］. Hydrogeology & Engineering Geology, 2022, 49（2）: 164 − 173. （in Chinese with English abstract）
[12] 叶四桥,陈洪凯,唐红梅. 落石冲击力计算方法[J]. 中国铁道科学,2010,31(6):56 − 62. [YE Siqiao,CHEN Hongkai,TANG Hongmei. The calculation method for the impact force of the rockfall[J]. China Railway Science,2010,31(6):56 − 62. (in Chinese with English abstract)]
YE Siqiao, CHEN Hongkai, TANG Hongmei. The calculation method for the impact force of the rockfall［J］. China Railway Science, 2010, 31（6）: 56 − 62. （in Chinese with English abstract）
[13] 袁进科,黄润秋,裴向军. 滚石冲击力测试研究[J]. 岩土力学,2014,35(1):48 − 54. [YUAN Jinke,HUANG Runqiu,PEI Xiangjun. Test research on rockfall impact force[J]. Rock and Soil Mechanics,2014,35(1):48 − 54. (in Chinese with English abstract)]
YUAN Jinke, HUANG Runqiu, PEI Xiangjun. Test research on rockfall impact force［J］. Rock and Soil Mechanics, 2014, 35（1）: 48 − 54. （in Chinese with English abstract）
[14] PERERA J S,LAM N,DISFANI M M,et al. Experimental and analytical investigation of a RC wall with a gabion cushion subjected to boulder impact[J]. International Journal of Impact Engineering,2021,151:103823. doi: 10.1016/j.ijimpeng.2021.103823
[15] 杨其新,关宝树. 落石冲击力计算方法的试验研究[J]. 铁道学报,1996,18(1):101 − 106. [YANG Qixin,GUAN Baoshu. Experimental study on calculation method of rockfall impact force[J]. Journal of the China Railway Society,1996,18(1):101 − 106. (in Chinese)] doi: 10.3321/j.issn:1001-8360.1996.01.017
YANG Qixin, GUAN Baoshu. Experimental study on calculation method of rockfall impact force［J］. Journal of the China Railway Society, 1996, 18（1）: 101 − 106. （in Chinese） doi: 10.3321/j.issn:1001-8360.1996.01.017
[16] SU Y,CHOI C E,LYU Y R,et al. Towards realistic simulations of the impact dynamics of boulders on rock-filled gabion:Combined effects of rock shapes and their crushing strength[J]. Engineering Geology,2021,283:106026. doi: 10.1016/j.enggeo.2021.106026
[17] 裴向军,刘洋,王东坡. 滚石冲击棚洞砂土垫层耗能缓冲机理研究[J]. 四川大学学报(工程科学版),2016,48(1):15 − 22. [PEI Xiangjun,LIU Yang,WANG Dongpo. Study on the energy dissipation of sandy soil cushions on the rock-shed under rockfall impact load[J]. Journal of Sichuan University (Engineering Science Edition),2016,48(1):15 − 22. (in Chinese with English abstract)]
PEI Xiangjun, LIU Yang, WANG Dongpo. Study on the energy dissipation of sandy soil cushions on the rock-shed under rockfall impact load［J］. Journal of Sichuan University （Engineering Science Edition）, 2016, 48（1）: 15 − 22. （in Chinese with English abstract）
[18] ZHU Chun,WANG Dongsheng,XIA Xing,et al. The effects of gravel cushion particle size and thickness on the coefficient of restitution in rockfall impacts[J]. Natural Hazards and Earth System Sciences,2018,18(6):1811 − 1823. doi: 10.5194/nhess-18-1811-2018
[19] SCHELLENBERG K. On the design of rockfall protection galleries[M]. Südwestdeutscher Verlag für Hochschulschriften, 2008.
[20] SU Y,CUI Y,NG C W W,et al. Effects of particle size and cushioning thickness on the performance of rock-filled gabions used in protection against boulder impact[J]. Canadian Geotechnical Journal,2019,56(2):198 − 207. doi: 10.1139/cgj-2017-0370
[21] 王爽,周晓军,姜波,等. 落石冲击下隧道大跨度棚洞的动力响应数值分析与抗冲击研究[J]. 爆炸与冲击,2016,36(4):548 − 556. [WANG Shuang,ZHOU Xiaojun,JIANG Bo,et al. Numerical analysis of dynamic response and impact resistance of a large-span rock shed in a tunnel under rockfall impact[J]. Explosion and Shock Waves,2016,36(4):548 − 556. (in Chinese with English abstract)] doi: 10.11883/1001-1455(2016)04-0548-09
WANG Shuang, ZHOU Xiaojun, JIANG Bo, et al. Numerical analysis of dynamic response and impact resistance of a large-span rock shed in a tunnel under rockfall impact［J］. Explosion and Shock Waves, 2016, 36（4）: 548 − 556. （in Chinese with English abstract） doi: 10.11883/1001-1455(2016)04-0548-09
[22] 温宇轩,贺九平. 水泥搅拌桩在软土路基施工中的应用研究[J]. 灾害学,2019,34(增刊1):236 − 242. [WEN Yuxuan,HE Jiuping. Study on application of cement mixing pile in soft soil subgrade construction[J]. Journal of Catastrophology,2019,34(Sup 1):236 − 242. (in Chinese)]
WEN Yuxuan, HE Jiuping. Study on application of cement mixing pile in soft soil subgrade construction［J］. Journal of Catastrophology, 2019, 34（Sup 1）: 236 − 242. （in Chinese）
[23] 中华人民共和国国土资源部. 滑坡防治工程设计与施工技术规范:DZ/T 0219—2006. 北京:中国标准出版社,2006. [Ministry of Land and Resources of the People’s Republic of China. Specification of design and construction for landslide stabilization:DZ/T 0219—2006. Beijing:Standards Press of China,2006. (in Chinese)]
Ministry of Land and Resources of the People’s Republic of China. Specification of design and construction for landslide stabilization: DZ/T 0219—2006. Beijing: Standards Press of China, 2006. （in Chinese）
[24] 地质灾害拦石墙工程设计规范(试行):T/CAGHP 060-2019[S]. 武汉:中国地质大学出版社,2019. [Code for design of geological hazard retaining wall engineering:T/CAGHP 060-2019[S]. Wuhan:Press of China University of Geosciences,2019. (in Chinese)]
Code for design of geological hazard retaining wall engineering: T/CAGHP 060-2019［S］. Wuhan: Press of China University of Geosciences, 2019. （in Chinese）
[25] 李海光. 新型支挡结构设计与工程实例[M]. 北京:人民交通出版社,2004. [LI Haiguang. Design and engineering example of new retaining structure[M]. Beijing:China Communications Press,2004. (in Chinese)]
LI Haiguang. Design and engineering example of new retaining structure［M］. Beijing: China Communications Press, 2004. （in Chinese）
-
