Analysis of typical cases of groundwater in high fill landslide with combined well-hole drainage
-
摘要:
以攀枝花机场13#滑坡治理工程为例，在简述滑坡基本概况的基础上，着重论述了研究区水文地质条件。研究区雨季降水量占全年降水量的95%，中−大暴雨、3 d及以上降雨天数出现次数集中于7—9月，占总数的95%以上。研究区降雨具有雨季降水量强度大且集中的特点。物探及钻探揭示，滑坡后缘场坪填方区地下水丰富，具有“窝”状不连续分布特征，有明显的成层性；含水层具有黏土含量高、赋水性较好、孔隙连通性差、径流不畅，坡内地下水难以快速消散等特点。基于该滑坡地下水丰富的突出特点，提出了抗滑桩支挡与集水井联合井内仰斜排水孔疏排地下水并重的治理方案。治理工程竣工后，评估了井孔联合疏排地下水措施的排水效果，证明排水效果良好。
Abstract:Taking the landslide control project of landslide No.13 at Panzhihua airport as an example, this paper briefly describes the basic situation of the landslide and focuses on the hydrogeological conditions of the study area. The rainy season rainfall accounts for 95% of the annual rainfall in the study area, and the occurrence times of moderate to heavy rain and rainfall days of 3 days or more are concentrated in the rainy season from July to September, accounting for more than 95% of the total. The rainfall in the study area is characterized by high intensity and concentration during the rainy season. Geophysical exploration and drilling revealed that the ground water in the field filling area at the rear edge of the landslide was abundant, with a "nest" -shaped discontinuous distribution and obvious stratification. Aquifers are characterized by high clay content, good water-bearing properties, poor pore connectivity, and poor drainage, making it difficult to dissipate quickly. Based on the prominent feature of abundant groundwater in the landslide area, a remediation scheme combining anti-slide piles and joint drainage by well and inclined drainage holes is proposed. After the completion of the treatment project, the drainage effect of the joint drainage measures by well and drainage hole was evaluated, and the practical results demonstrated excellent drainage effectiveness.
-
Key words:
- high fill landslide /
- landslide /
- ground water /
- water collecting well /
- oblique drainage hole
-
-
表 1 治理前后稳定性评估结果
Table 1. Stability assessment results before and after treatment
序号 断面
编号治理前稳定系数 应急刷
体积/m3设支挡结构后增加
抗滑力/（kN·m−1）设集水井后地下水
降低高度/m治理后稳定系数 自然工况 暴雨工况 地震工况 自然工况 暴雨工况 地震工况 1 1-1' 1.03 1.00 0.86 23516 1740 5.8 1.35 1.31 1.25 2 2-2' 1.03 1.00 0.85 2730 6.5 1.34 1.33 1.26 3 3-3' 1.02 0.99 0.82 2609 7.2 1.35 1.32 1.26
下载: 导出CSV
-
[1] 张作辰. 滑坡地下水作用研究与防治工程实践[J]. 工程地质学报,1996,4(4):80 − 85. [ZHANG Zuochen. Study on groundwater action of landslide and its prevention engineering practice[J]. Journal of Engineering Geology,1996,4(4):80 − 85. (in Chinese with English abstract)]
ZHANG Zuochen. Study on groundwater action of landslide and its prevention engineering practice［J］. Journal of Engineering Geology, 1996, 4（4）: 80 − 85. （in Chinese with English abstract）
[2] 魏丽敏,何群,林镇洪. 考虑地下水影响的滑坡稳定性分析[J]. 岩土力学,2004,25(3):422 − 426. [WEI Limin,HE Qun,LIN Zhenhong. Stability analysis of landslide under influence of groundwater[J]. Rock and Soil Mechanics,2004,25(3):422 − 426. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-7598.2004.03.019
WEI Limin, HE Qun, LIN Zhenhong. Stability analysis of landslide under influence of groundwater［J］. Rock and Soil Mechanics, 2004, 25（3）: 422 − 426. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-7598.2004.03.019
[3] 王文沛,殷跃平,王立朝,等. 排水抗滑桩技术研究现状及展望[J]. 水文地质工程地质,2023,50(2):73 − 83. [WANG Wenpei,YIN Yueping,WANG Lichao,et al. Studies on status and prospects of anti-slide shaft technology[J]. Hydrogeology & Engineering Geology,2023,50(2):73 − 83. (in Chinese with English abstract)]
WANG Wenpei, YIN Yueping, WANG Lichao, et al. Studies on status and prospects of anti-slide shaft technology［J］. Hydrogeology & Engineering Geology, 2023, 50（2）: 73 − 83. （in Chinese with English abstract）
[4] 瞿生军,赵建军,丁秀美,等. 降雨诱发缓倾顺层滑坡机制离散元模拟[J]. 水文地质工程地质,2016,43(6):120 − 126. [QU Shengjun,ZHAO Jianjun,DING Xiumei,et al. Discrete element simulation of rainfall induced shelving bedding landslides[J]. Hydrogeology & Engineering Geology,2016,43(6):120 − 126. (in Chinese with English abstract)]
QU Shengjun, ZHAO Jianjun, DING Xiumei, et al. Discrete element simulation of rainfall induced shelving bedding landslides［J］. Hydrogeology & Engineering Geology, 2016, 43（6）: 120 − 126. （in Chinese with English abstract）
[5] 刘礼领,殷坤龙. 暴雨型滑坡降水入渗机理分析[J]. 岩土力学,2008,29(4):1061 − 1066. [LIU Liling,YIN Kunlong. Analysis of rainfall infiltration mechanism of rainstorm landslide[J]. Rock and Soil Mechanics,2008,29(4):1061 − 1066. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-7598.2008.04.039
LIU Liling, YIN Kunlong. Analysis of rainfall infiltration mechanism of rainstorm landslide［J］. Rock and Soil Mechanics, 2008, 29（4）: 1061 − 1066. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-7598.2008.04.039
[6] 徐邦栋. 高堑坡设计及病害分析与防治[M]. 北京:中国铁道出版社,2011. [XU Bangdong. Design of high cutting slope,disease analysis and prevention[M]. Beijing:China Railway Publishing House,2011. (in Chinese)]
XU Bangdong. Design of high cutting slope, disease analysis and prevention［M］. Beijing: China Railway Publishing House, 2011. （in Chinese）
[7] 国家市场监督管理总局,国家标准化管理委员会. 滑坡防治设计规范:GB/T 38509—2020[S]. 北京:中国标准出版社,2020. [State Administration for Market Regulation, National Standardization Administration,Standardization Administration of the People’s Republic of China. Code for the design of landslide stabilization:GB/T 38509—2020[S]. Beijing:Standards Press of China,2020. (in Chinese)]
State Administration for Market Regulation, National Standardization Administration, Standardization Administration of the People’s Republic of China. Code for the design of landslide stabilization: GB/T 38509—2020［S］. Beijing: Standards Press of China, 2020. （in Chinese）
[8] 孙红月,尚岳全. 浙江上三公路6#滑坡的地下水作用与控制[J]. 岩石力学与工程学报,2006,25(3):505 − 510. [SUN Hongyue,SHANG Yuequan. Groundwater effect on landslide and its control along Shangyu-Sanmen highway in Zhejiang Province[J]. Chinese Journal of Rock Mechanics and Engineering,2006,25(3):505 − 510. (in Chinese with English abstract)] doi: 10.3321/j.issn:1000-6915.2006.03.011
SUN Hongyue, SHANG Yuequan. Groundwater effect on landslide and its control along Shangyu-Sanmen highway in Zhejiang Province［J］. Chinese Journal of Rock Mechanics and Engineering, 2006, 25（3）: 505 − 510. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-6915.2006.03.011
[9] 赵杰. 截水隧洞在箭丰尾滑坡治理工程中的应用[J]. 甘肃科技,2014,30(15):112 − 115. [ZHAO Jie. Application of intercepting tunnel in Jianfengwei landslide treatment project[J]. Gansu Science and Technology,2014,30(15):112 − 115. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-0952.2014.15.042
ZHAO Jie. Application of intercepting tunnel in Jianfengwei landslide treatment project［J］. Gansu Science and Technology, 2014, 30（15）: 112 − 115. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-0952.2014.15.042
[10] 尚岳全,蔡岳良,魏振磊,等. 滑坡虹吸排水方法[J]. 工程地质学报,2015,23(4):706 − 711. [SHANG Yuequan,CAI Yueliang,WEI Zhenlei,et al. Siphon drainage method for landslide prevention[J]. Journal of Engineering Geology,2015,23(4):706 − 711. (in Chinese with English abstract)]
SHANG Yuequan, CAI Yueliang, WEI Zhenlei, et al. Siphon drainage method for landslide prevention［J］. Journal of Engineering Geology, 2015, 23（4）: 706 − 711. （in Chinese with English abstract）
[11] 孙红月,帅飞翔,尚岳全,等. 边坡俯倾排水孔负压排水法研究[J]. 工程地质学报,2019,27(3):585 − 591. [SUN Hongyue,SHUAI Feixiang,SHANG Yuequan,et al. Study on negative pressure drainage method of downdip bolehole in slope[J]. Journal of Engineering Geology,2019,27(3):585 − 591. (in Chinese with English abstract)]
SUN Hongyue, SHUAI Feixiang, SHANG Yuequan, et al. Study on negative pressure drainage method of downdip bolehole in slope［J］. Journal of Engineering Geology, 2019, 27（3）: 585 − 591. （in Chinese with English abstract）
[12] 任姗姗,尚岳全,何婷婷,等. 边坡虹吸排水数值模拟方法及应用[J]. 岩石力学与工程学报,2013,32(10):2022 − 2027. [REN Shanshan,SHANG Yuequan,HE Tingting,et al. Numerical simulation method for siphonic drainage in slope and its application[J]. Chinese Journal of Rock Mechanics and Engineering,2013,32(10):2022 − 2027. (in Chinese with English abstract)]
REN Shanshan, SHANG Yuequan, HE Tingting, et al. Numerical simulation method for siphonic drainage in slope and its application［J］. Chinese Journal of Rock Mechanics and Engineering, 2013, 32（10）: 2022 − 2027. （in Chinese with English abstract）
[13] 汪磊,尚岳全,吕俊俊,等. 虹吸排水抗淤堵能力模型试验与理论分析[J]. 中南大学学报(自然科学版),2019,50(2):384 − 389. [WANG Lei,SHANG Yuequan,LYU Junjun,et al. Model test and theoretical analysis of anti clogging capacity of siphon drainage[J]. Journal of Central South University (Science and Technology),2019,50(2):384 − 389. (in Chinese with English abstract)] doi: 10.11817/j.issn.1672-7207.2019.02.018
WANG Lei, SHANG Yuequan, LYU Junjun, et al. Model test and theoretical analysis of anti clogging capacity of siphon drainage［J］. Journal of Central South University （Science and Technology）, 2019, 50（2）: 384 − 389. （in Chinese with English abstract） doi: 10.11817/j.issn.1672-7207.2019.02.018
[14] 马翔,赖国泉. 某山区机场高填方滑坡变形特征分析[J]. 中国地质灾害与防治学报,2019,30(4):16 − 23. [MA Xiang,LAI Guoquan. Analysis on deformation monitoring of a high fill landslide in a mountain airport[J]. The Chinese Journal of Geological Hazard and Control,2019,30(4):16 − 23. (in Chinese with English abstract)]
MA Xiang, LAI Guoquan. Analysis on deformation monitoring of a high fill landslide in a mountain airport［J］. The Chinese Journal of Geological Hazard and Control, 2019, 30（4）: 16 − 23. （in Chinese with English abstract）
[15] 张珍,李世海,马力. 重庆地区滑坡与降雨关系的概率分析[J]. 岩石力学与工程学报,2005,24(17):3185 − 3191. [ZHANG Zhen,LI Shihai,MA Li. Probability analysis of relationship between landslide and rainfall in Chongqing area[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(17):3185 − 3191. (in Chinese with English abstract)] doi: 10.3321/j.issn:1000-6915.2005.17.029
ZHANG Zhen, LI Shihai, MA Li. Probability analysis of relationship between landslide and rainfall in Chongqing area［J］. Chinese Journal of Rock Mechanics and Engineering, 2005, 24（17）: 3185 − 3191. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-6915.2005.17.029
[16] 蒋涛,崔圣华,冉耀. 开挖和降雨耦合诱发滑坡机理分析——以四川万源前进广场滑坡为例[J]. 中国地质灾害与防治学报,2023,34(3):20 − 30. [JIANG Tao,CUI Shenghua,RAN Yao. Analysis of landslide mechanism induced by excavation and rainfall:A case study of the Qianjin Square landslide in Wanyuan City,Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2023,34(3):20 − 30. (in Chinese with English abstract)]
JIANG Tao, CUI Shenghua, RAN Yao. Analysis of landslide mechanism induced by excavation and rainfall: A case study of the Qianjin Square landslide in Wanyuan City, Sichuan Province［J］. The Chinese Journal of Geological Hazard and Control, 2023, 34（3）: 20 − 30. （in Chinese with English abstract）
[17] 孟生勇,江兴元,杨义,等. 降雨诱发堆积体滑坡水土响应与稳定性时空演化试验研究[J]. 水文地质工程地质,2023,50(1):104 − 112. [MENG Shengyong,JIANG Xingyuan,YANG Yi,et al. An experimental study of spatial-temporal evolution of water-soil response and stability of a rainfall-induced accumulation landslide[J]. Hydrogeology & Engineering Geology,2023,50(1):104 − 112. (in Chinese with English abstract)]
MENG Shengyong, JIANG Xingyuan, YANG Yi, et al. An experimental study of spatial-temporal evolution of water-soil response and stability of a rainfall-induced accumulation landslide［J］. Hydrogeology & Engineering Geology, 2023, 50（1）: 104 − 112. （in Chinese with English abstract）
-
