基于分形纹理特征的侧扫声呐图像沉船识别方法研究

董凌宇; 单瑞; 刘慧敏; 于得水; 杜凯

doi:10.16562/j.cnki.0256-1492.2020070301

基于分形纹理特征的侧扫声呐图像沉船识别方法研究

1.
中国地质调查局青岛海洋地质研究所，青岛 266071

2.
青岛海洋科学与技术国家实验室海洋矿产资源评价与探测技术功能实验室，青岛 266071

基金项目: 国家自然科学基金“高频GNSS单点测速数据提取海浪参数方法研究”（41406115）；中国地质调查局项目“深海调查-测量”（DD20191003）；青岛市南区科技发展资金项目“轻便型GNSS浪潮测量浮标关键技术研究”（2016-3-015-ZH）

详细信息

作者简介: 董凌宇（1994—），男，硕士，研究实习员，主要从事地球物理数据处理与方法研究，E-mail：17663985486@163.com

通讯作者: 单瑞（1985—），男，硕士，助理研究员，主要从事海洋地球物理及海洋测绘研究工作，E-mail：shanrui416@163.com

中图分类号: P714.8

收稿日期: 2020-07-03

修回日期: 2020-08-19

刊出日期: 2021-08-28

Shipwreck identification with side scan sonar image based on fractal texture

1.
Qingdao Institute of Marine Geology, CGS, Qingdao 266071, China

2.
Laboratory for Marine Mineral Resources, Qingdao National Laboratory for Marine Science and Technology, Qingdao 266071, China

More Information

Corresponding author: SHAN Rui, shanrui416@163.com

Received Date: 03 July 2020

Revised Date: 19 August 2020

Publish Date: 28 August 2021

摘要

摘要:
为提高侧扫声呐图像中沉船等目标信息的识别精度和识别效率，根据盒维数、毯维数与多重分形谱的侧扫声呐图像纹理特征提取算法，构建了基于分形纹理特征的Adaboost级联分类器沉船目标识别流程。结合实测侧扫声呐图像数据进行水下沉船识别实验，并与灰度共生矩阵和Tamura纹理特征的识别结果进行对比。研究表明，基于分形纹理特征的识别方法综合考虑了图像全局与局部纹理特征，且不依赖人工选取阈值参数与特征向量，可有效提高目标识别精度和识别效率。
- 沉船识别 /
- 纹理特征 /
- 盒维数 /
- 毯维数 /
- 多重分形谱
Abstract:
In order to improve the accuracy and efficiency for recognition of underwater targets, fractal texture features including box dimension, blanket dimension and multifractal spectrum are calculated by texture feature extraction algorithm with side scan sonar images, and the shipwreck identification procedure based on Adaboost cascade classifier is constructed. The shipwreck recognition experiments have been carried out, and the results are compared. Research shows that the recognition method based on fractal texture features comprehensively considers the global and local texture features of the image, and does not rely on manual selection of threshold parameters and feature vectors, which can improve the accuracy and efficiency of target recognition.
- shipwreck identification /
- texture feature /
- box dimension /
- blanket dimension /
- multifractal spectrum

HTML全文

图 1 Adaboost级联分类器

Figure 1.

下载: 全尺寸图片幻灯片

图 2 基于分形纹理特征的Adaboost目标识别流程

Figure 2.

下载: 全尺寸图片幻灯片

图 3 目标识别中的正样本与负样本

Figure 3.

下载: 全尺寸图片幻灯片

图 4 盒维数计算

Figure 4.

下载: 全尺寸图片幻灯片

图 5 不同毯子厚度的分类结果比较

Figure 5.

下载: 全尺寸图片幻灯片

图 6 不同样本的多重分形谱结果

Figure 6.

下载: 全尺寸图片幻灯片

表 1 沉船及非沉船目标的多重分形谱参数

Table 1. Parameters of multifractal spectrum of shipwrecked and non-wrecked targets

目标	α_min	α_max	f_min	f_max	Δα	Δf
沉船1	1.81	2.96	0.07	2.00	1.15	1.93
沉船2	1.92	2.21	1.68	2.00	0.29	0.32
沉船3	1.90	2.35	1.13	2.00	0.45	0.87
非沉船1	1.99	2.04	1.75	2.00	0.05	0.25
非沉船2	1.98	2.05	1.75	2.00	0.07	0.25
非沉船3	1.96	2.03	1.80	2.00	0.07	0.20
注：①α_min和α_max分别代表了图像测度集的最小概率和最大概率，其差值Δα表明图像在概率测度分布中的差异程度，Δα越大则图像各测度区域和分形层次的区别越大，多重分形性质越明显；Δα越小则图像各测度区域和分形层次的区别越小，多重分形性质越微弱。 ②f_min和f_ma_x分布代表了图像测度集的最大值和最小值，其差值Δf表明图像在图像测度子集纹理复杂程度上的差异，Δf差值越大则表明图像不同测度子集纹理区别越明显。

下载: 导出CSV

表 2 分形纹理特征识别结果

Table 2. Recognition of fractal texture feature

识别方法	精确度/%	召回率/%	F₁/%
盒维数	50	78.95	61.2
毯维数	88.2	78.9	83.3
多重分形谱	95	100	97.4

下载: 导出CSV

表 3 多重分形谱、GLCM、Tamura三种纹理特征识别结果

Table 3. Recognition results of multifractal spectrum, GLCM and Tamura

识别方法	精确率/%	召回率/%	F₁/%
多重分形谱	95	100	97.4
GLCM（d=10）	100	94.7	97.2
Tamura六特征值	94.1	84.2	88.9

下载: 导出CSV
