Tectonic characteristics and extensional-compressional rates of the North-east Sag of South Yellow Sea Basin
-
摘要:
通过选取南黄海盆地东北凹典型地震剖面，开展精细的构造解释，系统梳理了东北凹构造样式特征。采用平衡剖面恢复技术和伸缩率计算方法，恢复了东北凹各时期的地质演化剖面，分析了东北凹不同构造演化阶段的伸缩率变化特征。研究表明，南黄海盆地东北凹主要发育伸展构造、走滑构造（负花状）和反转构造等多种构造组合样式，经历了晚侏罗世的仪征运动和渐新世末的三垛运动，相应地在中—上侏罗统和渐新统沉积时期，东北凹处于明显的收缩阶段，伴随发育TK40和T20不整合界面。同时，本文结合区域应力场特征，探讨了南黄海盆地东北凹的构造演化历程：以两次构造运动为界，划分为3个构造演化阶段（晚三叠世—侏罗纪的初始断陷阶段、白垩纪—渐新世的裂陷-反转阶段、新近纪—第四纪的区域沉降阶段）。南黄海盆地东北凹伸缩率的时空变化及构造演化过程，是对“晚中生代以来，古太平洋板块相对欧亚板块俯冲汇聚速率和方向的改变”的局部响应。
Abstract:Typical seismic sections are selected for delicate structural interpretation upon the basis of structural features of the North-east Sag of the South Yellow Sea Basin. The balanced cross-section technique and the extensional - compressional rates calculation method are used to reconstruct the tectonic evolution cross-sections for different tectonic evolutionary stages. The characteristics of extensional - compressional rates are analyzed. The results suggest that the North-east Sag of the South Yellow Sea basin is characterized by extensional structures, strike slip structures (negative flower patterns), inversion structures etc. by the Yizheng movement in Late Jurassic and the Sanduo movement by the end of Oligocene. Accordingly, the sag was obviously in compressional status during the deposition of Late Jurassic and Oligocene when the Tk40 and T20 unconformity interfaces were formed. In order to quantify the characteristics of the regional stress field, the paper also reconstructed the tectonic evolution of the north-east sag. Taking the two tectonic movements as the boundaries, the sag is subdivided into three stages of tectonic evolution i.e. the initial faulting- depression stage from Late Triassic to Jurassic, the rifting inversion stage from Cretaceous to Oligocene, and the regional subsidence stage from Neogene to Quaternary. The temporal and spatial variations in the extensional - compressional rates and the tectonic evolution of north-east sag in South Yellow Sea basin represent the local response to the regional stress field, such as the change in convergence rate and motion azimuth between the Pacific plate and the Eurasian plate since Late Mesozoic.
-
-
表 2 南黄海盆地东北凹伸缩率计算结果
Table 2. The extensional and compressional rate of north-east sag，the South Yellow Sea Basin
时代 T3 J1 J2+3 K E1+2 E3 剖面A-A' 2.6% 3.5% −3.2% 3.2% 5.6% −4.5% 剖面B-B' 3.7% 4.5% −6.2% 1.5% 4.4% −5.2% 剖面C-C' 1.8% 2.6% −7.6% 2.3% 7.0% −3.0%
下载: 导出CSV
-
[1] 高顺莉, 周祖翼. 南黄海盆地东北凹侏罗纪地层的发现及其分布特征[J]. 高校地质学报, 2014, 20(2):286-293 doi: 10.3969/j.issn.1006-7493.2014.02.013
GAO Shunli, ZHOU Zuyi. Discovery of the Jurassic strata in the north-east sag of South Yellow Sea [J]. Geological Journal of China Universities, 2014, 20(2): 286-293. doi: 10.3969/j.issn.1006-7493.2014.02.013
[2] 高顺莉, 徐曦, 周祖翼. 南黄海北部盆地晚白垩世以来构造变形与盆地成因[J]. 石油与天然气地质, 2015, 36(6):924-933 doi: 10.11743/ogg20150607
GAO Shunli, XU Xi, ZHOU Zuyi. Structural deformation and genesis of the northern sub-basin in South Yellow Sea since Late Cretaceous [J]. Oil & Gas Geology, 2015, 36(6): 924-933. doi: 10.11743/ogg20150607
[3] 张海军, 曹强, 孙建峰. 地层剥蚀厚度恢复研究: 以南黄海北部盆地东北凹陷为例[J]. 中国石油勘探, 2008, 13(5):21-25 doi: 10.3969/j.issn.1672-7703.2008.05.004
ZHANG Haijun, CAO Qiang, SUN Jianfeng. Study on strata eroded thickness restoration: a case study of northeast depression in northern South Yellow sea basin [J]. China Petroleum Exploration, 2008, 13(5): 21-25. doi: 10.3969/j.issn.1672-7703.2008.05.004
[4] 郭飞飞, 曹强, 唐文旭. 南黄海北部盆地东北凹陷地层剥蚀厚度恢复[J]. 海洋地质与第四纪地质, 2009, 29(5):99-105
GUO Feifei, CAO Qiang, TANG Wenxu. Study on strata erosion thickness restoration in Northeast Depression of South Yellow Sea basin [J]. Marine Geology & Quaternary Geology, 2009, 29(5): 99-105.
[5] 李楠, 李巍然, 龙海燕. 南黄海盆地北部坳陷正反转构造[J]. 海洋地质与第四纪地质, 2013, 33(3):95-100
LI Nan, LI Weiran, LONG Haiyan. Study of positive inversion structures in the North depression of the South Yellow Sea basin [J]. Marine Geology & Quaternary Geology, 2013, 33(3): 95-100.
[6] 雷宝华, 陈建文, 梁杰, 等. 印支运动以来南黄海盆地的构造变形与演化[J]. 海洋地质与第四纪地质, 2018, 38(3):45-54
LEI Baohua, CHEN Jianwen, LIANG Jie, et al. Tectonic deformation and evolution of the South Yellow Sea basin since Indosinian movement [J]. Marine Geology & Quaternary Geology, 2018, 38(3): 45-54.
[7] 韩宗珠, 刘涵, 许红, 等. 南黄海盆地盆山耦合作用与地质演化[J]. 海洋地质前沿, 2015, 31(4):55-62
HAN Zongzhu, LIU Han, XU Hong, et al. Geological evolution and basin-range coupling relationship of the south Yellow sea basin [J]. Marine Geology Frontiers, 2015, 31(4): 55-62.
[8] Pang Y M, Zhang X H, Guo X W, et al. Basin modeling in the initial stage of exploration: A case study from the North Subbasin of the South Yellow Sea Basin [J]. Acta Oceanologica Sinica, 2017, 36(9): 65-78. doi: 10.1007/s13131-017-1112-1
[9] Zhang M H, Xu D S, Chen J W. Geological structure of the Yellow Sea area from regional gravity and magnetic interpretation [J]. Applied Geophysics, 2007, 4(2): 75-83. doi: 10.1007/s11770-007-0011-1
[10] 王巍, 陈高, 王家林, 等. 苏北南黄海盆地区域构造特征分析[J]. 地震学刊, 1999(1):47-55
WANG Wei, CHEN Gao, WANG Jialin, et al. Analysis for regional structural characteristics of north Jiangsu-South Yellow Sea basin [J]. Journal of Seismology, 1999(1): 47-55.
[11] 郝天珧, SUH M, 王谦身, 等. 根据重力数据研究黄海周边断裂带在海区的延伸[J]. 地球物理学报, 2002, 45(3):385-397 doi: 10.3321/j.issn:0001-5733.2002.03.010
HAO Tianyao, SUH M, WANG Qianshen, et al. A study on the extension of fault zones in Yellow Sea and its adjacent areas based on gravity data [J]. Chinese Journal of Geophysics, 2002, 45(3): 385-397. doi: 10.3321/j.issn:0001-5733.2002.03.010
[12] 胥颐, 郝天珧, 李志伟, 等. 中国边缘海域及其邻区的岩石层结构与构造分析[J]. 地学前缘, 2008, 15(3):55-63 doi: 10.3321/j.issn:1005-2321.2008.03.003
XU Yi, HAO Tianyao, LI Zhiwei, et al. Analysis of lithospheric structure and tectonics of the Chinese marginal seas and adjacent region [J]. Earth Science Frontiers, 2008, 15(3): 55-63. doi: 10.3321/j.issn:1005-2321.2008.03.003
[13] 李慧君. 南黄海盆地海相中—古生界构造区划[J]. 海洋地质前沿, 2014, 30(10):8-13
LI Huijun. The tectonic division of the Mesozoic-Paleozoic in the south Yellow sea basin [J]. Marine Geology Frontiers, 2014, 30(10): 8-13.
[14] 周建勋. 同沉积挤压盆地构造演化恢复的平衡剖面方法及其应用[J]. 地球学报, 2005, 26(2):151-156 doi: 10.3321/j.issn:1006-3021.2005.02.008
ZHOU Jianxun. The balanced cross-section method for restoration of structural evolution in compressional basins with synkinematic sedimentation and its application [J]. Acta Geoscientica Sinica, 2005, 26(2): 151-156. doi: 10.3321/j.issn:1006-3021.2005.02.008
[15] 李三忠, 索艳慧, 戴黎明, 等. 渤海湾盆地形成与华北克拉通破坏[J]. 地学前缘, 2010, 17(4):64-89
LI Sanzhong, SUO Yanhui, DAI Liming, et al. Development of the Bohai Bay Basin and destruction of the North China craton [J]. Earth Science Frontiers, 2010, 17(4): 64-89.
[16] 万天丰, 朱鸿. 中国大陆及邻区中生代—新生代大地构造与环境变迁[J]. 现代地质, 2002, 16(2):107-120 doi: 10.3969/j.issn.1000-8527.2002.02.001
WAN Tianfeng, ZHU Hong. Tectonics and environment change of Meso-Cenozoic in China continent and its adjacent areas [J]. Geoscience, 2002, 16(2): 107-120. doi: 10.3969/j.issn.1000-8527.2002.02.001
[17] Li S Z, Jahna B M, Zhao S J, et al. Triassic southeastward subduction of North China Block to South China Block: Insights from new geological, geophysical and geochemical data [J]. Earth-Science Reviews, 2017, 166: 270-285. doi: 10.1016/j.earscirev.2017.01.009
[18] 朱光, 刘国生, 李双应, 等. 下扬子地区盆地的“四层楼”结构及其动力学机制[J]. 合肥工业大学学报: 自然科学版, 2002, 23(1):47-52
ZHU Guang, LIU Guosheng, LI Shuangying, et al. “Four-story” structure of the basins in the Lower Yangtze region and their geodynamic setting [J]. Journal of Hefei University of Technology: Natural Science, 2002, 23(1): 47-52.
[19] 朱光, 刘程, 顾承串, 等. 郯庐断裂带晚中生代演化对西太平洋俯冲历史的指示[J]. 中国科学: 地球科学, 2018, 61(4):386-405 doi: 10.1007/s11430-017-9136-4
ZHU Guang, LIU Cheng, GU Chengchuan, et al. Oceanic plate subduction history in the western Pacific Ocean: Constraint from late Mesozoic evolution of the Tan-Lu Fault Zone [J]. Science China Earth Sciences, 2018, 61(4): 386-405. doi: 10.1007/s11430-017-9136-4
[20] Maruyama S, Isozaki Y, Kimura G, et al. Paleo-geographic maps of the Japanese islands: plate tectonic synthesis from 750 Ma to the present [J]. The Island Arc, 1997, 6(1): 121-142. doi: 10.1111/j.1440-1738.1997.tb00043.x
-
