Development of Mesozoic secondary pore zones in the Eastern Depression of North Yellow Sea Basin
-
摘要:
北黄海盆地东部坳陷中生界储层以特低孔、超低渗型为主,对本区次生孔隙的研究是寻找优质储层和有利油气聚集区的重要内容,对油气勘探有重要意义。利用钻井、岩心和物性资料分析,采用岩石薄片鉴定,阴极发光和扫描电镜等方法,对北黄海盆地东部坳陷储层的岩石类型、孔渗特征以及孔隙类型进行研究,确定了次生孔隙带的发育规律及其影响因素。研究认为本区次生孔隙的发育除受到成岩作用因素影响外,还受到物质成分、沉积相带、地层不整合和构造裂隙等因素的控制。其中,沿地层不整合风化界面和大断裂的淋滤作用是形成次生孔隙、改善储层物性的重要因素。综合分析认为,研究区中部地区地层不整合界面附近是有利的次生孔隙带发育位置。
Abstract:The Mesozoic reservoirs in the Eastern Depression of North Yellow Sea Basin are commonly characterized by very low porosity and permeability. The most important task in the exploration of oil and gas of the basin is to study the secondary pores for finding the high quality reservoirs and favorable hydrocarbon accumulation areas. Combining the drilling, cores and physical property data, using the methods of thin section identification, cathodoluminescence and scanning electron microscope, characteristics of porosity and permeability and pore types are studied in this paper. Secondary pore zones and their influencing factors are discussed. It is found that the development of secondary pores is influenced not only by diagenesis, but also by the material composition, sedimentary facies, stratigraphic unconformity, and structural fractures. The eluviations along the stratigraphic unconformities, weathering surfaces and faults are the most important factors for the formation of secondary pore and improvement of reservoir properties. In sum, the favorable position for the secondary pores is always close to the unconformity surfaces in the middle Eastern Depression of the North Yellow Sea Basin.
-
Key words:
- secondary pore zone /
- unconformity /
- North Yellow Sea Basin /
- Mesozoic
-
-
表 1 北黄海盆地东部坳陷中生界储层孔隙类型及特征
Table 1. The Mesozoic reservoir porosity types and characteristics in the Eastern Depression,the North Yellow Sea Basin
孔隙类型 特征 原生孔隙 粒间孔 胶结作用剩余孔隙 杂基微孔隙 黏土矿物晶间孔、凝灰质填隙物孔 次生孔隙 粒间溶孔 粒间填隙物溶蚀 粒内溶孔 石英、长石粒内溶蚀 微收缩孔 矿物蚀变、凝灰质脱玻化 裂缝 碎屑颗粒表面破裂缝、构造裂隙 -
[1] 刘振湖, 高红芳, 胡小强, 等. 北黄海盆地东部坳陷中生界含油气系统研究[J]. 中国海上油气, 2007, 19(4):229-233 doi: 10.3969/j.issn.1673-1506.2007.04.003
LIU Zhenhu, GAO Hongfang, HU Xiaoqiang, et al. A study on the Mesozoic petroleum system in East Depression, North Yellow Sea basin [J]. China Offshore Oil and Gas, 2007, 19(4): 229-233. doi: 10.3969/j.issn.1673-1506.2007.04.003
[2] 陈玲, 白志琳, 李文勇. 北黄海盆地中新生代沉积坳陷特征及其油气勘探方向[J]. 石油物探, 2006, 45(3):319-323 doi: 10.3969/j.issn.1000-1441.2006.03.021
CHEN Ling, BAI Zhilin, LI Wenyong. The character of Mid-Cenozoic sedimental depression and oil-gas explorating direction in North Yellow Sea [J]. Geophysical Prospecting for Petroleum, 2006, 45(3): 319-323. doi: 10.3969/j.issn.1000-1441.2006.03.021
[3] 蔡乾忠. 横贯黄海的中朝造山带与北、南黄海成盆成烃关系[J]. 石油与天然气地质, 2005, 26(2):185-192, 196 doi: 10.3321/j.issn:0253-9985.2005.02.010
CAI Qianzhong. Relationship between Sino-Korean orogenic belt traversing Yellow Sea and basin evolution and hydrocarbon generation in North and South Yellow Sea basin [J]. Oil & Gas Geology, 2005, 26(2): 185-192, 196. doi: 10.3321/j.issn:0253-9985.2005.02.010
[4] 王强, 王应斌, 张友. 北黄海中生代残留盆地砂岩成岩作用及其对孔隙的影响[J]. 海洋地质前沿, 2011, 27(8):16-25
WANG Qiang, WANG Yingbin, ZHANG You. Sandstone diagenesis in Mesozoic residual basin of North Yellow Sea and its impact on porosity [J]. Marine Geology Frontiers, 2011, 27(8): 16-25.
[5] 金仁植, 费琪, 杨香华, 等. 北黄海盆地含油气系统与勘探前景[J]. 石油实验地质, 2006, 28(5):445-449, 457 doi: 10.3969/j.issn.1001-6112.2006.05.008
Kim in Sik, FEI Qi, YANG Xianghua, et al. The petroleum system and exploration prospect in the east of North Yellow Sea basin [J]. Petroleum Geology & Experiment, 2006, 28(5): 445-449, 457. doi: 10.3969/j.issn.1001-6112.2006.05.008
[6] Gong J M, Wen Z H, Chen J W, et al. Geologic characteristics and hydrocarbon-generating potential of Mesozoic strata in the North Yellow Sea basin [J]. Marine Geology & Quaternary Geology, 2000, 20(2): 69-78.
[7] 王强, 王应斌, 张友. 北黄海东部坳陷中生界储层特征[J]. 沉积与特提斯地质, 2010, 30(4):97-103 doi: 10.3969/j.issn.1009-3850.2010.04.015
WANG Qiang, WANG Yingbin, ZHANG You. Characteristics of the Mesozoic reservoirs in the eastern depression of the Northern Yellow Sea basin [J]. Sedimentary Geology and Tethyan Geology, 2010, 30(4): 97-103. doi: 10.3969/j.issn.1009-3850.2010.04.015
[8] 梁杰, 温珍河, 肖国林, 等. 北黄海盆地东部坳陷储层特征及影响因素[J]. 海洋地质与第四纪地质, 2013, 33(2):111-119
LIANG Jie, WEN Zhenhe, XIAO Guolin, et al. Reservoir characteristics and influential factors in the Eastern Depression of the North Yellow Sea basin [J]. Marine Geology & Quaternary Geology, 2013, 33(2): 111-119.
[9] 梁杰, 温珍河, 肖国林, 等. 热液作用对北黄海盆地东部坳陷中生界储层的影响[J]. 海洋地质与第四纪地质, 2015, 35(5):117-123
LIANG Jie, WEN Zhenhe, XIAO Guolin, et al. The impact of hydrothermal activity on the reservoirs in the East Depression of the North Yellow Sea basin [J]. Marine Geology & Quaternary Geology, 2015, 35(5): 117-123.
[10] 蔡乾忠. 黄海含油气盆地区域地质与大地构造环境[J]. 洋地质动态, 2002, 18(11):8-12
CAI Qianzhong. Regional geology and geotectonic environment of petroliferous basins in the Yellow Sea [J]. Marine Geology Letters, 2002, 18(11): 8-12.
[11] 郑求根, 蔡立国, 丁文龙, 等. 黄海海域盆地的形成与演化[J]. 石油与天然气地质, 2005, 26(5):647-654 doi: 10.3321/j.issn:0253-9985.2005.05.015
ZHENG Qiugen, CAI Liguo, DING Wenlong, et al. Development and evolution of basins in Yellow Sea [J]. Oil & Gas Geology, 2005, 26(5): 647-654. doi: 10.3321/j.issn:0253-9985.2005.05.015
[12] 李文勇, 李东旭, 夏斌, 等. 北黄海盆地构造演化特征分析[J]. 现代地质, 2006, 20(2):268-276 doi: 10.3969/j.issn.1000-8527.2006.02.010
LI Wenyong, LI Xudong, XIA Bin, et al. Characteristics of structural evolution in North Yellow Sea basin [J]. Geoscience, 2006, 20(2): 268-276. doi: 10.3969/j.issn.1000-8527.2006.02.010
[13] 吴淑玉, 刘俊, 肖国林, 等. 匹配追踪算法频谱分解的碎屑岩薄砂体储层预测——以北黄海盆地东部坳陷下白垩统为例[J]. 海洋地质与第四纪地质, 2017, 37(3):197-207
WU Shuyu, LIU Jun, XIAO Guolin, et al. Thin clasic sand reservoir prediction based on matching pursuit spectrum decomposition-A case of Eastern Depression of North Yellow Sea basin [J]. Marine Geology and Quaternary Geology, 2017, 37(3): 197-207.
[14] 刘金萍, 王改云, 杜民, 等. 北黄海盆地东部坳陷中生界烃源岩特征[J]. 中国海上油气, 2013, 25(4):12-16
LIU Jinping, WANG Gaiyun, DU Min, et al. Analyzing characteristics of Mesozoic hydrocarbon source rocks in the Eastern depression, North Yellow Sea basin [J]. China Offshore Oil and Gas, 2013, 25(4): 12-16.
[15] 刘振湖, 王飞宇, 刘金萍, 等. 北黄海盆地东部坳陷油气成藏时间研究[J]. 石油实验地质, 2014, 36(5):550-554 doi: 10.11781/sysydz201405550
LIU Zhenhu, WANG Feiyu, LIU Jinping, et al. Time of hydrocarbon accumulation in eastern depression of North Yellow Sea basin [J]. Petroleum Geology & Experiment, 2014, 36(5): 550-554. doi: 10.11781/sysydz201405550
[16] 王后金, 王嘹亮, 冯长茂. 北黄海盆地的成盆动力学机制探讨[J]. 石油天然气学报, 2014, 36(5):1-7 doi: 10.3969/j.issn.1000-9752.2014.05.001
WANG Houjin, WANG Liaoliang, FENG Changmao. On dynamic mechanism of tectonic evolution in the North Yellow Sea basin [J]. Journal of Oil and Gas Technology, 2014, 36(5): 1-7. doi: 10.3969/j.issn.1000-9752.2014.05.001
[17] 杜民, 胡小强, 王改云. 北黄海盆地东部坳陷东南部层序地层特征及沉积体系[J]. 海洋地质前沿, 2014, 30(1):25-33
DU Min, HU Xiaoqiang, WANG Gaiyun. Sequence stratigraphic characteristics and depositional systems in the southeast of the eastern depression of the North Yellow Sea basin [J]. Marine Geology Frontiers, 2014, 30(1): 25-33.
[18] 张莉, 周永章, 王嘹亮, 等. 北黄海盆地生烃条件研究[J]. 天然气工业, 2009, 29(1):21-25 doi: 10.3787/j.issn.1000-0976.2009.01.005
ZHANG Li, ZHOU Yongzhang, WANG Liaoliang, et al. A study on hydrocarbon generation conditions in the North Yellow Sea basin [J]. Natural Gas Industry, 2009, 29(1): 21-25. doi: 10.3787/j.issn.1000-0976.2009.01.005
[19] 袁书坤, 王英民, 刘振湖, 等. 北黄海盆地东部坳陷不整合类型及油气成藏模式[J]. 石油勘探与开发, 2010, 37(6):663-667
YUAN Shukun, WANG Yingmin, LIU Zhenhu, et al. Unconformity types and hydrocarbon accumulation models in the eastern depression of the North Yellow Sea basin [J]. Petroleum Exploration and Development, 2010, 37(6): 663-667.
[20] Gao D, Cheng R H, Shen Y J, et al. Weathered and volcanic provenance-sedimentary system and its influence on reservoir quality in the east of the eastern depression, the North Yellow Sea basin [J]. Journal of Earth Science, 2018, 29(2): 353-368. doi: 10.1007/s12583-017-0945-z
[21] 高丹, 程日辉, 沈艳杰, 等. 北黄海盆地东部坳陷侏罗纪西南物源-沉积体系与源区构造背景[J]. 地球科学, 2016, 41(7):1171-1187
GAO Dan, CHENG Rihui, SHEN Yanjie, et al. Southwestern provenance-sedimentary system and provenance tectonic setting of eastern sag in the North Yellow Sea basin [J]. Earth Science, 2016, 41(7): 1171-1187.
[22] Emery D, Myers K J, Young R. Ancient subaerial exposure and freshwater leaching in sandstones [J]. Geology, 1990, 18(12): 1178-1181. doi: 10.1130/0091-7613(1990)018<1178:ASEAFL>2.3.CO;2
[23] Ramm M. Porosity-depth trends in reservoir sandstones: theoretical models related to Jurassic sandstones offshore Norway [J]. Marine and Petroleum Geology, 1992, 9(5): 553-567.
[24] 张文才, 李贺, 李会军, 等. 南堡凹陷高柳地区深层次生孔隙成因及分布特征[J]. 石油勘探与开发, 2008, 35(3):308-312 doi: 10.3321/j.issn:1000-0747.2008.03.007
ZHANG Wencai, LI He, LI Huijun, et al. Genesis and distribution of secondary porosity in the deep horizon of Gaoliu area, Nanpu Sag [J]. Petroleum Exploration and Development, 2008, 35(3): 308-312. doi: 10.3321/j.issn:1000-0747.2008.03.007
[25] 陈亮, 金庆焕, 刘振湖, 等. 太阳盆地中新生代断裂特征及成因机制[J]. 海洋地质与第四纪地质, 2008, 28(2):53-60
CHEN Liang, JIN Qinghuan, LIU Zhenhu, et al. Features and genetic mechanism of faults in the Sun Basin in Mesozoic and Cenozoic times [J]. Marine Geology & Quaternary Geology, 2008, 28(2): 53-60.
[26] Schmidt V, McDonald D A. The role of secondary porosity in the course of sandstone diagenesis[Z]. SEPM Special Publication No. 26, 1979: 175-207.
[27] Gibling M R, Martel A T, Nguyen M H, et al. Fluid evolution and diagenesis of a Carboniferous channel sandstone in the Prince Colliery, Nova Scotia, Canada [J]. Bulletin of Canadian Petroleum Geology, 2000, 48(2): 95-115.
[28] Salem A M, Morad S, Mato L F, et al. Diagenesis and reservoir-quality evolution of fluvial sandstones during progressive burial and uplift: evidence from the Upper Jurassic Boipeba member, Recôncavo Basin, northeastern Brazil [J]. AAPG Bulletin, 2000, 84(7): 1015-1040.
[29] Taylor K G, Gawthorpe R L, Curtis C D, et al. Carbonate cementation in a sequence-stratigraphic framework: Upper Cretaceous sandstones, book cliffs, Utah-Colorado [J]. Journal of Sedimentary Research, 2000, 70(2): 360-372.
[30] Surdam R C, Boese S W, Crossey L J. The chemistry of secondary porosity: Part 2. Aspects of porosity modification [J]. AAPG Memoir, 1984, 37(2): 127-149.
[31] 王勇, 钟建华, 陈昊, 等. 东濮凹陷古近系深层次生孔隙垂向分布特征及成因[J]. 石油勘探与开发, 2006, 33(5):576-580 doi: 10.3321/j.issn:1000-0747.2006.05.012
WANG Yong, ZHONG Jianhua, CHEN Hao, et al. Vertical distribution and genesis of the secondary pore in deep formation of Paleogene at Dongpu Sag [J]. Petroleum Exploration and Development, 2006, 33(5): 576-580. doi: 10.3321/j.issn:1000-0747.2006.05.012
[32] 王鹏, 赵澄林. 东濮凹陷杜桥白地区深部储集层次生孔隙成因探讨[J]. 石油勘探与开发, 2001, 28(4):44-46 doi: 10.3321/j.issn:1000-0747.2001.04.013
WANG Peng, ZHAO Chenglin. An approach to the generating mechanism of secondary pores in Duqiaobai area of Dongpu depression [J]. Petroleum Exploration and Development, 2001, 28(4): 44-46. doi: 10.3321/j.issn:1000-0747.2001.04.013
[33] 远光辉, 操应长, 杨田, 等. 论碎屑岩储层成岩过程中有机酸的溶蚀增孔能力[J]. 地学前缘, 2013, 20(5):207-219
YUAN Guanghui, CAO Yingchang, YANG Tian, et al. Porosity enhancement potential through mineral dissolution by organic acids in the diagenetic process of clastic reservoir [J]. Earth Science Frontiers, 2013, 20(5): 207-219.
-
