南海中沙群岛海域表层沉积物粒度特征及其输运趋势

陈俊锦, 张经纬, 刘时桥, 陈万利, 秦永鹏, 吴时国. 南海中沙群岛海域表层沉积物粒度特征及其输运趋势[J]. 海洋地质与第四纪地质, 2022, 42(2): 15-27. doi: 10.16562/j.cnki.0256-1492.2021090901
引用本文: 陈俊锦, 张经纬, 刘时桥, 陈万利, 秦永鹏, 吴时国. 南海中沙群岛海域表层沉积物粒度特征及其输运趋势[J]. 海洋地质与第四纪地质, 2022, 42(2): 15-27. doi: 10.16562/j.cnki.0256-1492.2021090901
CHEN Junjin, ZHANG Jingwei, LIU Shiqiao, CHEN Wanli, QIN Yongpeng, WU Shiguo. Grain size distribution pattern of surface sediments and its implications for transportation trend: A case from the waters off Zhongsha Islands, the South China Sea[J]. Marine Geology & Quaternary Geology, 2022, 42(2): 15-27. doi: 10.16562/j.cnki.0256-1492.2021090901
Citation: CHEN Junjin, ZHANG Jingwei, LIU Shiqiao, CHEN Wanli, QIN Yongpeng, WU Shiguo. Grain size distribution pattern of surface sediments and its implications for transportation trend: A case from the waters off Zhongsha Islands, the South China Sea[J]. Marine Geology & Quaternary Geology, 2022, 42(2): 15-27. doi: 10.16562/j.cnki.0256-1492.2021090901

南海中沙群岛海域表层沉积物粒度特征及其输运趋势

  • 基金项目: 国家自然科学基金-广东省联合基金重点基金项目“南沙海区减薄陆壳裂陷盆地构造演化及特色深水油气系统”(U1701245);中国地质调查局项目“海南中沙群岛海域海洋区域地质调查”(DD20191027);中国科学院边缘海与大洋地质重点实验室资助项目“西沙群岛宣德孤立碳酸盐台地周缘深水沉积体系研究”(OMG202010);中国工程科技发展战略海南研究院咨询研究项目“海洋地球物理大数据平台建设及其在南海资源勘探开发战略规划中的应用”(20-NH-ZT-01)
详细信息
    作者简介: 陈俊锦(1996—),男,硕士研究生,主要从事海洋地质、海洋地球物理研究,E-mail:chenjj@idsse.ac.cn
    通讯作者: 张经纬(1996—),男,助理工程师,主要从事海底地质研究,E-mail:17801040683@163.com
  • 中图分类号: P736.21

Grain size distribution pattern of surface sediments and its implications for transportation trend: A case from the waters off Zhongsha Islands, the South China Sea

More Information
  • 对南海中沙群岛海域232个表层沉积物样品进行了粒度分析,以探讨研究区沉积物来源、沉积环境和输运趋势。根据Folk沉积物命名法,将研究区沉积物划分为砂、粉砂质砂、砂质粉砂、砂质泥、粉砂和泥等6种类型,以砂质泥和泥为主,粒径较粗、分选较好的沉积物主要分布在中沙台地海域。通过对组分含量、粒度参数和水深进行聚类分析和主成分分析,综合考虑沉积物来源和海底地形地貌的影响,将研究区划分为5类沉积区:台地区、台地阶地区、台地周缘斜坡区、海槽海岭区和深海盆地区结合沉积环境分区进行了粒径趋势分析,研究显示,沉积物主要以中沙台地和西沙隆起海域为中心向周缘输运,在中沙海槽海域形成汇聚区。研究区沉积物输运格局主要受季风、海流、潮汐和波浪等因素的共同控制,与沉积物来源、海底地形地貌和实测水动力条件相吻合。

  • 加载中
  • 图 1  研究区地理位置及采样站位

    Figure 1.

    图 2  研究区表层沉积物粒级组分百分含量分布

    Figure 2.

    图 3  研究区表层沉积物粒度参数分布

    Figure 3.

    图 4  研究区表层沉积物分类三元图

    Figure 4.

    图 5  研究区表层沉积物类型空间分布

    Figure 5.

    图 6  表层沉积物R型聚类分析谱系

    Figure 6.

    图 7  研究区沉积环境分区

    Figure 7.

    图 8  研究区沉积物净输运趋势

    Figure 8.

    图 9  研究区MX1—MX4站位底流流速及流向

    Figure 9.

    表 1  主成分分析因子载荷矩阵

    Table 1.  Principal component analysis factor loading matrix

    变量因子1因子2因子3因子4
    砂含量−0.967−0.0640.165−0.181
    平均粒径0.9550.101−0.2010.183
    粉砂含量0.9530.141−0.1010.186
    黏土含量0.937−0.050−0.2470.164
    峰态−0.0600.9800.0510.033
    分选系数0.2090.943−0.0460.166
    偏态−0.3060.0240.926−0.218
    水深0.3920.211−0.2810.850
    下载: 导出CSV

    表 2  研究区各沉积环境分区相关参数统计值

    Table 2.  Statistical values of relevant parameters in subareas of the study area

    沉积环
    境分区
    主要底质
    类型
    砂/%粉砂/%黏土/%平均粒径/Φ分选系数偏态峰态水深/m
    砂、粉砂质砂72.98(0~
    100)
    19.01(0~
    62.89)
    8.01(0~
    43.13)
    3.04(0.61~
    7.81)
    1.62(0.58~
    2.74)
    1.51(−0.66~
    2.7)
    2.38(0.76~
    3.49)
    108(24~
    475)
    砂质粉砂51.19(37.18~
    83.65)
    39.51(13.39~
    49.57)
    9.30(2.96~
    13.25)
    4.36(2.63~
    5.07)
    2.10(1.9~
    2.28)
    2.16(2.08~
    2.28)
    2.95(2.83~
    3.06)
    373(312~
    481)
    砂质粉砂、砂质泥14.91(0~
    63.62)
    54.78(29.1~
    67.8)
    30.31(7.27~
    45.46)
    6.68(3.67~
    7.81)
    2.16(1.67~
    3.16)
    0.30(−1.23~
    2.39)
    2.63(2.07~
    3.65)
    1904(386~
    3352)
    砂质泥、泥10.14(0~
    41.62)
    56.09(38.56~
    66.91)
    33.77(14.85~
    43.98)
    7.01(5.07~
    7.8)
    2.08(1.57~
    3.05)
    −0.39(−1.32~
    2.1)
    2.56(1.97~
    3.51)
    2784(1080~
    3796)
    砂质泥18.69(6.54~
    42.23)
    53.26(37.77~
    59.39)
    28.05(19.67~
    36.14)
    6.50(5.25~
    7.25)
    2.30(1.95~
    3.06)
    −0.49(−1.29~
    1.77)
    2.80(2.42~
    3.52)
    4077(3631~
    5230)
     注:平均值(最小值~最大值)。
    下载: 导出CSV
  • [1]

    Pedreros R, Howa H L, Michel D. Application of grain size trend analysis for the determination of sediment transport pathways in intertidal areas [J]. Marine Geology, 1996, 135(1-4): 35-49. doi: 10.1016/S0025-3227(96)00042-4

    [2]

    Folk R L. A review of grain‐size parameters [J]. Sedimentology, 1966, 6(2): 73-93. doi: 10.1111/j.1365-3091.1966.tb01572.x

    [3]

    McLaren P. An Interpretation of Trends in Grain Size Measures [J]. Journal of Sedimentary Research, 1981, 51(2): 611-624.

    [4]

    McLaren P, Bowles D. The effects of sediment transport on grain-size distributions [J]. Journal of Sedimentary Research, 1985, 55(4): 457-470.

    [5]

    Asselman N E M. Grain-size trends used to assess the effective discharge for floodplain sedimentation, River Waal, the Netherlands [J]. Journal of Sedimentary Research, 1999, 69(1): 51-61. doi: 10.2110/jsr.69.51

    [6]

    Friedman G M. Distinction between dune, beach, and river sands from their textural characteristics [J]. Journal of Sedimentary Research, 1961, 31(4): 514-529.

    [7]

    Visher G S. Grain Size Distributions and Depositional Processes [J]. Journal Of Sedimentary Research, 1969, 39(3): 1074-1106.

    [8]

    Plomaritis T A, Paphitis D, Collins M. The use of grain size trend analysis in macrotidal areas with breakwaters: Implications of settling velocity and spatial sampling density [J]. Marine Geology, 2008, 253(3-4): 132-148. doi: 10.1016/j.margeo.2008.05.003

    [9]

    Cheng P, Gao S, Bokuniewicz H. Net sediment transport patterns over the Bohai Strait based on grain size trend analysis [J]. Estuarine, Coastal and Shelf Science, 2004, 60(2): 203-212. doi: 10.1016/j.ecss.2003.12.009

    [10]

    Gao S, Collins M. Net sediment transport patterns inferred from grain-size trends, based upon definition of "transport vectors" [J]. Sedimentary Geology, 1992, 80(1-2): 47-60.

    [11]

    Gao S, Collins M B. Analysis of grain size trends, for defining sediment transport pathways in marine environments [J]. Journal of Coastal Research, 1994, 10(1): 70-78.

    [12]

    Balsinha M, Fernandes C, Oliveira A, et al. Sediment transport patterns on the Estremadura Spur continental shelf: Insights from grain-size trend analysis [J]. Journal of Sea Research, 2014, 93: 28-32. doi: 10.1016/j.seares.2014.04.001

    [13]

    Liang J, Liu J, Xu G, et al. Grain-size characteristics and net transport patterns of surficial sediments in the Zhejiang nearshore area, East China Sea [J]. Oceanologia, 2020, 62(1): 12-22. doi: 10.1016/j.oceano.2019.06.002

    [14]

    Wang C T, Chen M, Qi H S, et al. Grain-Size Distribution of Surface Sediments in the Chanthaburi Coast, Thailand and Implications for the Sedimentary Dynamic Environment [J]. Journal of Marine Science and Engineering, 2020, 8(4): 242. doi: 10.3390/jmse8040242

    [15]

    Liu J T, Liu K J, Huang J C. The effect of a submarine canyon on the river sediment dispersal and inner shelf sediment movements in southern Taiwan [J]. Marine Geology, 2002, 181(4): 357-386. doi: 10.1016/S0025-3227(01)00219-5

    [16]

    Sánchez A, Shumilin E, Rodríguez-Figueroa G. Sediment transport patterns inferred from grain size trends and trace metal dispersion near the Santa Rosalía mining district, Gulf of California [J]. Sedimentary Geology, 2019, 380: 158-163. doi: 10.1016/j.sedgeo.2018.12.006

    [17]

    Zhang W, Zheng J H, Ji X M, et al. Surficial sediment distribution and the associated net sediment transport pattern in the Pearl River Estuary, South China [J]. Continental Shelf Research, 2013, 61-62: 41-51. doi: 10.1016/j.csr.2013.04.011

    [18]

    Li T, Li T J. Sediment transport processes in the Pearl River Estuary as revealed by grain-size end-member modeling and sediment trend analysis [J]. Geo-Marine Letters, 2018, 38(2): 167-178. doi: 10.1007/s00367-017-0518-2

    [19]

    李泽文, 栾振东, 阎军, 等. 南海北部外陆架表层沉积物粒度参数特征及物源分析[J]. 海洋科学, 2011, 35(12):92-100

    LI Zewen, LUAN Zhendong, YAN Jun, et al. Characterization of grain size parameters and the provenance analysis of the surface sediment in the outer shelf of the northern South China Sea [J]. Marine Sciences, 2011, 35(12): 92-100.

    [20]

    张洪运, 庄丽华, 阎军, 等. 南海北部陆架坡折附近表层沉积物的粒度特征和其输运趋势[J]. 海洋科学, 2019, 43(10):96-105

    ZHANG Hongyun, ZHUANG Lihua, YAN Jun, et al. Grain size characteristics of surface sediments and their transport patterns near the shelf break of the northern South China Sea [J]. Marine Sciences, 2019, 43(10): 96-105.

    [21]

    李亮, 何其江, 龙根元, 等. 南海宣德海域表层沉积物粒度特征及其输运趋势[J]. 海洋地质与第四纪地质, 2017, 37(6):140-148

    LI Liang, HE Qijiang, LONG Genyuan, et al. Sediment grain size distribution pattern and transportation trend in the Xuande Water, South China Sea [J]. Marine Geology & Quaternary Geology, 2017, 37(6): 140-148.

    [22]

    朱文聪, 李娜娜, 艾红, 等. 西沙和中沙群岛海域生物多样性特点[J]. 广东农业科学, 2010, 37(12):1-6 doi: 10.3969/j.issn.1004-874X.2010.12.002

    ZHU Wencong, LI Nana, AI Hong, et al. The characteristics of biodiversity of fish in Xisha & Zhongsha Islands [J]. Guangdong Agricultural Sciences, 2010, 37(12): 1-6. doi: 10.3969/j.issn.1004-874X.2010.12.002

    [23]

    李亚芳, 杜飞雁, 王亮根, 等. 南海中沙西沙海域海樽类群落结构特征研究[J]. 南方水产科学, 2016, 12(4):64-70 doi: 10.3969/j.issn.2095-0780.2016.04.008

    LI Yafang, DU Feiyan, WANG Lianggen, et al. Community structure of Thaliacea in the Zhongsha and Xisha Islands, South China Sea [J]. South China Fisheries Science, 2016, 12(4): 64-70. doi: 10.3969/j.issn.2095-0780.2016.04.008

    [24]

    余克服. 南海珊瑚礁及其对全新世环境变化的记录与响应[J]. 中国科学:地球科学, 2012, 42(8):1160-1172

    YU Kefu. Coral reefs in the South China Sea: their response to and records on past environmental changes [J]. Science China Earth Sciences, 2012, 42(8): 1160-1172.

    [25]

    Huang X X, Betzler C, Wu S G, et al. First documentation of seismic stratigraphy and depositional signatures of Zhongsha atoll (Macclesfield Bank), South China Sea [J]. Marine and Petroleum Geology, 2020: 104349.

    [26]

    Li Y H, Huang H B, Grevemeyer I, et al. Crustal structure beneath the Zhongsha Block and the adjacent abyssal basins, South China Sea: New insights into rifting and initiation of seafloor spreading [J]. Gondwana Research, 2021, 99: 53-76. doi: 10.1016/j.gr.2021.06.015

    [27]

    赵斌, 高红芳, 张衡, 等. 基于深度域地震成像的中沙海槽盆地东北部结构构造研究[J]. 热带海洋学报, 2019, 38(2):95-102

    ZHAO Bin, GAO Hongfang, ZHANG Heng, et al. Structure study of the northeastern Zhongsha Trough Basin in the South China Sea based on prestack depth migration seismic imaging [J]. Journal of Tropical Oceanography, 2019, 38(2): 95-102.

    [28]

    徐子英, 汪俊, 高红芳, 等. 中沙地块南部断裂发育特征及其成因机制[J]. 中国地质, 2020, 47(5):1438-1446

    XU Ziying, WANG Jun, GAO Hongfang, et al. The characteristics and formation mechanism of the faults in the southern part of the Zhongsha Bank, South China Sea [J]. Geology in China, 2020, 47(5): 1438-1446.

    [29]

    Quan Q, Xue H J. Layered model and insights into the vertical coupling of the South China Sea circulation in the upper and middle layers [J]. Ocean Modelling, 2018, 129: 75-92. doi: 10.1016/j.ocemod.2018.06.006

    [30]

    Wang G H, Xie S P, Qu T D, et al. Deep South China Sea circulation [J]. Geophysical Research Letters, 2011, 38(5): L05601.

    [31]

    Wyrtki K. Physical Oceanography of the Southeast Asian Waters: Naga Report Volume 2: Scientific Results of Marine Investigations of the South China Sea and the Gulf of Thailand[M]. ‎California: Scripps Institution of Oceanography, University of California, 1961.

    [32]

    Zhu Y H, Sun J C, Wang Y G, et al. Overview of the multi-layer circulation in the South China Sea [J]. Progress in Oceanography, 2019, 175: 171-182. doi: 10.1016/j.pocean.2019.04.001

    [33]

    黎雨晗, 黄海波, 丘学林, 等. 中沙海域的广角与多道地震探测[J]. 地球物理学报, 2020, 63(4):1523-1537 doi: 10.6038/cjg2020N0259

    LI Yuhan, HUANG Haibo, QIU Xuelin, et al. Wide-angle and multi-channel seismic surveys in Zhongsha waters [J]. Chinese Journal of Geophysics, 2020, 63(4): 1523-1537. doi: 10.6038/cjg2020N0259

    [34]

    黄金森. 中沙环礁特征[J]. 海洋地质与第四纪地质, 1987, 7(2):23-26

    HUANG Jinsen. Features of the Zhongsha Atoll in the South China Sea [J]. Marine Geology & Quaternary Geology, 1987, 7(2): 23-26.

    [35]

    Wentworth C K. A scale of grade and class terms for clastic sediments [J]. The Journal of Geology, 1922, 30(5): 377-392. doi: 10.1086/622910

    [36]

    Folk R L, Andrews P B, Lewis D W. Detrital sedimentary rock classification and nomenclature for use in New Zealand [J]. New Zealand Journal of Geology and Geophysics, 1970, 13(4): 937-968. doi: 10.1080/00288306.1970.10418211

    [37]

    McManus J. Grain size determination and interpretation[M]//Tucker M. Techniques in Sedimentology. Oxford: Blackwell, 1988: 63-85.

    [38]

    Gao S, Collins M B, Lanckneus J, et al. Grain size trends associated with net sediment transport patterns: An example from the Belgian continental shelf [J]. Marine Geology, 1994, 121(3-4): 171-185. doi: 10.1016/0025-3227(94)90029-9

    [39]

    Gao S. A FORTRAN program for grain-size trend analysis to define net sediment transport pathways [J]. Computers & Geosciences, 1996, 22(4): 449-452.

    [40]

    Gao S, Collins M. The use of grain size trends in marine sediment dynamics: A review [J]. Chinese Journal of Oceanology and Limnology, 2001, 19(3): 265-271. doi: 10.1007/BF02850664

    [41]

    Gao S, Collins M, McLaren P, et al. A critique of the "McLaren Method" for defining sediment transport paths; discussion and reply [J]. Journal of Sedimentary Research, 1991, 61(1): 143-147. doi: 10.1306/D42676A9-2B26-11D7-8648000102C1865D

    [42]

    姜在兴. 沉积学[M]. 2版. 北京: 石油工业出版社, 2010: 52

    JIANG Zaixing. Sedimentology[M]. 2nd ed. Beijing: Petroleum Industry Press, 2010: 52.

    [43]

    李玉中, 陈沈良. 系统聚类分析在现代沉积环境划分中的应用: 以崎岖列岛海区为例[J]. 沉积学报, 2003, 21(3): 487-494.

    LI Yuzhong, CHEN Shenliang. Application of system cluster analysis to classification of modern sedimentary environment: a case study in Qiqu Archipelago Area[J]. Acta Sedimentologica Sinica, 2003, 21(3): 487-494.

    [44]

    陈翰, 陈忠, 颜文, 等. 汕头近岸海域表层沉积物粒度特征及其输运趋势[J]. 沉积学报, 2014, 32(2):314-324

    CHEN Han, CHEN Zhong, YAN Wen, et al. Grain Size Characteristics of Surface Sediments and Their Transport Patterns over the Coastal Waters of Shantou City, Guangdong Province [J]. Acta Sedimentologica Sinica, 2014, 32(2): 314-324.
