Distribution of rare earth elements in surface sediments of the South Yellow Sea and its implication to sediment provenances
-
摘要:
对南黄海表层沉积物稀土元素数据进行了系统总结，旨在揭示其赋存特征、分布规律及主要来源。结果表明，南黄海稀土元素含量为77.2～261.78 μg/g，平均值为166.46 μg/g；空间上分布规律显著，高值区出现在南黄海中部泥质区，含量基本在180 μg/g以上，而低值区则呈斑块状出现在靠近山东半岛近岸一带，含量多低于130 μg/g。稀土元素的球粒陨石配分模式和上陆壳（UCC）配分模式显示各海域总体特征较为一致，与中国大陆的稀土元素配分曲线类似，指示了较强的陆源特征，河流携带的陆源入海物质是其主要的物质来源。通过对稀土元素各特征参数进行相关性分析，发现南黄海稀土元素组成与沉积物粒度呈较为明显的正相关，表明了沉积物粒度、矿物组成对稀土元素含量具有显著的控制作用。对比分析稀土元素空间分布规律和南黄海主要入海河流沉积物稀土组成，结果表明南黄海绝大部分沉积物来自于中国大陆河流，包括长江、黄河和老黄河等大型河流。在不同环流体系控制下，大型入海河流控制了南黄海不同区域的物质分布：西北部主要来自黄河入海物质，山东半岛沿岸流是其主要输运动力；老黄河物质主要沉积在西部海域，主要驱动力是苏北沿岸流；南部物质主要来自长江入海物质，长江冲淡水和闽浙沿岸流控制了其分布范围；东部近岸区域则以朝鲜半岛入海河流携带陆源物质为主，主要输运动力为朝鲜沿岸流。在此基础上，以La/Yb=11.7为界，可将整个南黄海划分为两个物源区，西部大部分海域为中国大陆来源，而东部近岸区则为朝鲜半岛来源，两者分界线基本接近于黄海海槽的位置。总体而言，大中型河流带来的陆源物源、沉积物粒度以及海域流系格局控制了南黄海表层沉积物稀土元素的组成特征和分布格局。
Abstract:To reveal their compositions, distributions, and provenances of rare earth elements in the sediment from the South Yellow Sea, the data in the surface sediments in the area were studied systematically. The results show that the content of rare earth elements ranged from 77.2 to 261.78 μg/g, with the average value of 166.46 μg/g. The spatial distribution pattern of rare earth element is distinct, showing relative higher value in the muddy area in the central of the South Yellow Sea, where the content is generally more than 180 μg/g, while the lower value area appears as patches close to the coastal regions of Shandong Peninsula, and the content is mostly less than 130 μg/g. The normalized rare earth elements patterns of chondrite and upper continental crust (UCC) show overall pictures of the entire study area, which is similar to the distribution pattern of rare earth elements in Chinese mainland, indicating clear terrigenous imprint of riverine materials, reflecting the intimacy as the main sediment provenance of the South Yellow Sea. Meanwhile, as shown in the correlation analysis of the characteristic parameters of rare earth elements, the composition of rare earth elements in the South Yellow Sea is significantly positively correlated with the grain size of sediments, indicating that the sediment grain size and mineral composition controlled the content and composition of rare earth elements in the study area. Based on the spatial distribution pattern of rare earth elements and those from the main rivers into the South Yellow Sea, we believed that the sediment of South Yellow Sea is mainly from the Chinese large rivers, including Yangtze River, modern Yellow River, and old Yellow River. The northwest part is mainly from the Yellow River materials, and the coastal current of Shandong Peninsula is its main transport power. The material of the old Yellow River mainly deposit in the west of the South Yellow Sea, and the main driving force is the coastal current of Jiangsu Province. The material in the southern part of the South Yellow Sea mainly come from the material entering the sea from the Yangtze River, which is controlled by the Yangtze River diluted water and the coastal current of Fujian and Zhejiang. The east coast of the South Yellow Sea is dominated by terrestrial materials carried by the rivers in the Korean Peninsula, and the main transport power is the Korean coastal current. Taking La/Yb=11.7 as the demarcation line, the entire South Yellow Sea can be divided into two realms. Most of the western materials are from Chinese mainland, while the eastern coastal area from the Korean Peninsula. The boundary between these two realms is close to the middle line of the Yellow Sea trough. Therefore, we confirm that the terrestrial provenance, sediment grain size, and marine current system pattern control the composition and distribution pattern of rare earth elements in the surface sediments of the South Yellow Sea.
-
Key words:
- surface sediment /
- rare earth elements /
- provenance /
- South Yellow Sea
-
-
表 1 南黄海海域表层沉积物及周边入海河流沉积物稀土元素含量及特征参数
Table 1. REE content and characteristic parameters of surface sediments in the South Yellow Sea and surrounding rivers
∑REE / (μg/g) ∑LREE /(μg/g) ∑HREE /(μg/g) ∑LREE/
∑HREEδEu δCe (La/Yb)N (Gd/Yb) N 南黄海 最大值 261.78 235.72 24.41 13.728 0.78 1.14 19.18 2.85 最小值 77.19 70.54 6.07 7.30 0.46 0.67 8.26 1.46 平均值 166.46 148.99 16.28 9.18 0.65 0.99 10.51 1.86
河
流长江[26] 186.66 167.04 18.32 9.12 0.64 1.01 10.74 1.95 黄河[26] 148.08 131.87 15.24 8.65 0.60 1.00 9.68 1.84 汉江[25] 221.69 204.47 17.21 11.87 0.63 1.05 13.03 1.67 锦江[25] 225.20 207.48 17.73 11.71 0.71 1.04 13.28 1.72 荣山江[25] 202.90 186.34 16.56 11.25 0.76 1.05 12.30 1.68
下载: 导出CSV
表 2 南黄海稀土元素特征参数相关性分析
Table 2. Correlation analysis of rare earth element characteristic parameters in the South Yellow Sea
∑REE ∑LREE/∑HREE δEu δCe (La/Yb) N (La/Sm) N (Sm/Nd) N (Gd/Yb) N Mz ∑REE 1 ∑LREE/∑HREE 0.857** 1 δEu 0.297** −0.230** 1 δCe −0.564** −0.252** −0.619** 1 (La/Yb)n −0.105 −0.236** 0.232** 0.129 1 (La/Sm)n 0.299** −0.197** 0.961** −0.655** 0.087 1 (Sm/Nd)n 0.330** −0.010 0.639** −0.316** 0.052 0.630** 1 (Gd/Yb)n −0.417** −0.250** −0.315** 0.214** 0.031 −0.262** −0.352** 1 Mz 0.328** 0.404** −0.113 −0.029 −0.039 −0.070 −0.012 −0.031 1
下载: 导出CSV
-
[1] McLennan S M. Rare earth elements in sedimentary rocks: Influence of provenance and sedimentary processes [J]. Reviews in Mineralogy and Geochemistry, 1989, 21(1): 169-200.
[2] Cullers R L. The controls on the major and trace element variation of shales, siltstones, and sandstones of Pennsylvanian-Permian age from uplifted continental blocks in Colorado to platform sediment in Kansas, USA [J]. Geochimica et Cosmochimica Acta, 1994, 58(22): 4955-4972. doi: 10.1016/0016-7037(94)90224-0
[3] Munksgaard N C, Lim K, Parry D L. Rare earth elements as provenance indicators in North Australian estuarine and coastal marine sediments [J]. Estuarine, Coastal and Shelf Science, 2003, 57(3): 399-409. doi: 10.1016/S0272-7714(02)00368-2
[4] Liu S F, Zhang H, Zhu A M, et al. Distribution of rare earth elements in surface sediments of the western Gulf of Thailand: Constraints from sedimentology and mineralogy [J]. Quaternary International, 2019, 527: 52-63. doi: 10.1016/j.quaint.2018.08.010
[5] Murray R W, Buchholtzten Brink M R, Brumsack H J, et al. Rare earth elements in Japan Sea sediments and diagenetic behavior of Ce/Ce*: results from ODP Leg 127 [J]. Geochimica et Cosmochimica Acta, 1991, 55(9): 2453-2466. doi: 10.1016/0016-7037(91)90365-C
[6] 杨守业, 李从先, Lee C B, 等. 黄海周边河流的稀土元素地球化学及沉积物物源示踪[J]. 科学通报, 2003, 48(11):1135-1139 doi: 10.3321/j.issn:0023-074X.2003.11.004
YANG Shouye, LI Congxian, Lee C B, et al. REE geochemistry of suspended sediments from the rivers around the Yellow Sea and provenance indicators [J]. Chinese Science Bulletin, 2003, 48(11): 1135-1139. doi: 10.3321/j.issn:0023-074X.2003.11.004
[7] 窦衍光, 李军, 李炎. 北部湾东部海域表层沉积物稀土元素组成及物源指示意义[J]. 地球化学, 2012, 41(2):147-157 doi: 10.3969/j.issn.0379-1726.2012.02.006
DOU Yanguang, LI Jun, LI Yan. Rare earth element compositions and provenance implication of surface sediments in the eastern Beibu Gulf [J]. Geochimica, 2012, 41(2): 147-157. doi: 10.3969/j.issn.0379-1726.2012.02.006
[8] Mi B B, Liu S F, Shi X F, et al. A high resolution record of rare earth element compositional changes from the mud deposit on the inner shelf of the East China Sea: Implications for paleoenvironmental changes [J]. Quaternary International, 2017, 447: 35-45. doi: 10.1016/j.quaint.2016.09.056
[9] Milliman J D, Meade R H. World-wide delivery of river sediment to the oceans [J]. The Journal of Geology, 1983, 91(1): 1-21. doi: 10.1086/628741
[10] 程天文, 赵楚年. 我国主要河流入海径流量、输沙量及对沿岸的影响[J]. 海洋学报, 1985, 7(4):460-471
CHENG Tianwen, ZHAO Chunian. 1985. Runoff and sediment discharge into the sea of major rivers in China and their impact on the coast regions [J]. Acta Oceanologica Sinica, 1985, 7(4): 460-471.
[11] 杨作升, 王海成, 乔淑卿. 黄河与长江入海沉积物中碳酸盐含量和矿物颗粒形态特征及影响因素[J]. 海洋与湖沼, 2009, 40(6):674-681 doi: 10.3321/j.issn:0029-814X.2009.06.002
YANG Zuosheng, WANG Haicheng, QIAO Shuqing. Carbonate minerals in estuary sediments of the Changjiang (Yangtze River) and Huanghe (Yellow River): the content, morphology, and influential factors [J]. Oceanologia et Limnologia Sinica, 2009, 40(6): 674-681. doi: 10.3321/j.issn:0029-814X.2009.06.002
[12] 秦蕴珊, 郑铁民.. 黄东海地质[M]. 北京: 科学出版社, 1982
QIN Yunshan, ZHENG Tiemin. Geology of the Yellow Sea and East China Sea[M]. Beijing: Science Press, 1982.
[13] 石学法, 刘升发, 乔淑卿, 等. 中国东部近海沉积物地球化学: 分布特征、控制因素与古气候记录[J]. 矿物岩石地球化学通报, 2015, 34(5):885-894
SHI Xuefa, LIU Shengfa, QIAO Shuqing, et al. Geochemical characteristics, controlling factor and record of paleoclimate in sediments from eastern China Seas [J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2015, 34(5): 885-894.
[14] Dou Y G, Yang S Y, Liu Z X, et al. Provenance discrimination of siliciclastic sediments in the middle Okinawa Trough since 30 ka: Constraints from rare earth element compositions [J]. Marine Geology, 2010, 275(1-4): 212-220. doi: 10.1016/j.margeo.2010.06.002
[15] 密蓓蓓, 王中波, 仇晓华, 等. 中全新世以来冲绳海槽氧化还原环境重建及其气候效应[J]. 海洋地质与第四纪地质, 2019, 39(4):107-115
MI Beibei, WANG Zhongbo, QIU Xiaohua, et al. Reconstruction of the redox environment in Okinawa Trough and its climatic implications since mid-Holocene [J]. Marine Geology & Quaternary Geology, 2019, 39(4): 107-115.
[16] Lim D I, Choi J Y, Jung H S, et al. Recent sediment accumulation and origin of shelf mud deposits in the Yellow and East China Seas [J]. Progress in Oceanography, 2007, 73(2): 145-159. doi: 10.1016/j.pocean.2007.02.004
[17] Liu J, Saito Y, Wang H, et al. Sedimentary evolution of the Holocene subaqueous clinoform off the Shandong Peninsula in the Yellow Sea [J]. Marine Geology, 2007, 236(3-4): 165-187. doi: 10.1016/j.margeo.2006.10.031
[18] 密蓓蓓, 张勇, 梅西, 等. 中国东部海域表层沉积物稀土元素赋存特征及物源探讨[J]. 中国地质, 2020, 47(5):1530-1541
MI Beibei, ZHANG Yong, MEI Xi, et al. The rare earth element content in surface sediments of coastal areas in eastern China’s sea areas and an analysis of material sources [J]. Geology in China, 2020, 47(5): 1530-1541.
[19] 胡邦琦, 杨作升, 赵美训, 等. 南黄海中部泥质区7200年以来东亚冬季风变化的沉积记录[J]. 中国科学:地球科学, 2012, 55(10):1656-1668 doi: 10.1007/s11430-012-4447-7
HU Bangqi, YANG Zuosheng, ZHAO Meixun, et al. Grain size records reveal variability of the East Asian Winter Monsoon since the Middle Holocene in the Central Yellow Sea mud area, China [J]. Science China Earth Sciences, 2012, 55(10): 1656-1668. doi: 10.1007/s11430-012-4447-7
[20] Lu J, Li A C, Zhang J, et al. Yangtze River-derived sediments in the southwestern South Yellow Sea: Provenance discrimination and seasonal transport mechanisms [J]. Journal of Asian Earth Sciences, 2019, 176: 353-367. doi: 10.1016/j.jseaes.2019.03.007
[21] Jung H S, Lim D, Jeong D H, et al. Discrimination of sediment provenance in the Yellow Sea: Secondary grain-size effect and REE proxy [J]. Journal of Asian Earth Sciences, 2016, 123: 78-84. doi: 10.1016/j.jseaes.2016.03.020
[22] Lim D, Jung H S, Choi J Y. REE partitioning in riverine sediments around the Yellow Sea and its importance in shelf sediment provenance [J]. Marine Geology, 2014, 357: 12-24. doi: 10.1016/j.margeo.2014.07.002
[23] Yang S Y, Jung H S, Lim D I, et al. A review on the provenance discrimination of sediments in the Yellow Sea [J]. Earth-Science Reviews, 2003, 63(1-2): 93-120. doi: 10.1016/S0012-8252(03)00033-3
[24] 朱赖民, 杜俊民, 张远辉, 等. 南黄海中部E2柱样沉积物来源的稀土元素及微量元素示踪[J]. 环境科学学报, 2006, 26(3):495-500
ZHU Laimin, DU Junmin, ZHANG Yuanhui, et al. Tracing the sediment source at E2 hole in the South Yellow Sea with rare earth element and trace element [J]. Acta Scientiae Circumstantiae, 2006, 26(3): 495-500.
[25] Xu Z K, Lim D, Choi J, et al. Rare earth elements in bottom sediments of major rivers around the Yellow Sea: Implications for sediment provenance [J]. Geo-Marine Letters, 2009, 29(5): 291-300. doi: 10.1007/s00367-009-0142-x
[26] Yang S Y, Jung H S, Choi M S, et al. The rare earth element compositions of the Changjiang (Yangtze) and Huanghe (Yellow) river sediments [J]. Earth and Planetary Science Letters, 2002, 201(2): 407-419. doi: 10.1016/S0012-821X(02)00715-X
[27] 赵一阳, 鄢明才. 中国浅海沉积物地球化学[M]. 北京: 科学出版社, 1994
ZHAO Yiyang, YAN Mingcai. Geochemistry of Sediments of the China Shelf Sea[M]. Beijing: Science Press, 1994.
[28] 王金土. 黄海表层沉积物稀土元素地球化学[J]. 地球化学, 1990(1):44-53 doi: 10.3321/j.issn:0379-1726.1990.01.005
WANG Jintu. REE geochemistry of surficial sediments from the Yellow Sea of China [J]. Geochimica, 1990(1): 44-53. doi: 10.3321/j.issn:0379-1726.1990.01.005
[29] 赵志根, 高良敏. δEu、δCe计算方法的标准化问题[J]. 标准化报道, 1998, 19(5):23-25
ZHAO Zhigen, GAO Liangmin. Discussion about standardization of methods to calculate δEu、δCe [J]. Reporting of Standardization, 1998, 19(5): 23-25.
[30] 秦蕴珊, 赵一阳, 陈丽蓉, 等. 东海地质[M]. 北京: 科学出版社, 1987
QIN Yunshan, ZHAO Yiyang, CHEN Lirong, et al. Geology of the East China Sea[M]. Beijing: Science Press, 1987.
[31] 蒋富清, 周晓静, 李安春, 等. δEuN-ΣREEs图解定量区分长江和黄河沉积物[J]. 中国科学D辑:地球科学, 2009, 52(2):232-241 doi: 10.1007/s11430-009-0018-y
JIANG Fuqing, ZHOU Xiaojing, LI Anchun, et al. Quantitatively distinguishing sediments from the Yangtze River and the Yellow River using δEuN-ΣREEs plot [J]. Science in China Series D:Earth Sciences, 2009, 52(2): 232-241. doi: 10.1007/s11430-009-0018-y
[32] MacRae N D, Nesbitt H W, Kronberg B I. Development of a positive Eu anomaly during diagenesis [J]. Earth and Planetary Science Letters, 1992, 109(3-4): 585-591. doi: 10.1016/0012-821X(92)90116-D
[33] 杨守业, 李从先. REE示踪沉积物物源研究进展[J]. 地球科学进展, 1999, 14(2):164-167 doi: 10.3321/j.issn:1001-8166.1999.02.010
YANG Shouye, LI Congxian. Research progress in REE tracer for sediment source [J]. Advances in Earth Science, 1999, 14(2): 164-167. doi: 10.3321/j.issn:1001-8166.1999.02.010
[34] 严杰, 高建华, 李军, 等. 鸭绿江河口及近岸地区稀土元素的物源指示意义[J]. 海洋地质与第四纪地质, 2010, 30(4):95-103
YAN Jie, GAO Jianhua, LI Jun, et al. Implications of REE for provenance in the Yalu estuary and its adjacent sea area [J]. Marine Geology & Quaternary Geology, 2010, 30(4): 95-103.
[35] Caggianelli A, Fiore S, Mongelli G, et al. REE distribution in the clay fraction of pelites from the southern Apennines, Italy [J]. Chemical Geology, 1992, 99(4): 253-263. doi: 10.1016/0009-2541(92)90180-D
[36] Cullers R L, Barrett T, Carlson R, et al. Rare-earth element and mineralogic changes in Holocene soil and stream sediment: a case study in the wet mountains, Colorado, U. S. A. [J]. Chemical Geology, 1987, 63(3-4): 275-297. doi: 10.1016/0009-2541(87)90167-7
[37] 李俊, 弓振斌, 李云春, 等. 近岸和河口地区稀土元素地球化学研究进展[J]. 地球科学进展, 2005, 20(1):64-73 doi: 10.3321/j.issn:1001-8166.2005.01.012
LI Jun, GONG Zhenbin, LI Yunchun, et al. Marine geochemistry approaches of rare earth elements in coastal and estuarial areas [J]. Advances in Earth Science, 2005, 20(1): 64-73. doi: 10.3321/j.issn:1001-8166.2005.01.012
[38] 赵一阳, 李凤业, 秦朝阳, 等. 试论南黄海中部泥的物源及成因[J]. 地球化学, 1991(2):112-117 doi: 10.19700/j.0379-1726.1991.02.002
ZHAO Yiyang, LI Fengye, QIN Zhaoyang, et al. Source and genesis of mud in the central part of the South Yellow Sea in special reference to geochemical data [J]. Geochimica, 1991(2): 112-117. doi: 10.19700/j.0379-1726.1991.02.002
[39] 郭炳火, 黄振宗, 李培英, 等. 中国近海及邻近海域海洋环境[M]. 北京: 海洋出版社, 2004
GUO Binghuo, HUANG Zhenzong, LI Peiying, et al. Marine Environment in the Chinese Offshore Waters and Adjacent Sea Areas[M]. Beijing: Ocean Press, 2004.
[40] 苏纪兰. 中国近海的环流动力机制研究[J]. 海洋学报, 2001, 23(4):1-16
SU Jilan. A review of circulation dynamics of the coastal oceans near China [J]. Acta Oceanologica Sinica, 2001, 23(4): 1-16.
[41] Guan B X. Patterns and structures of the currents in Bohai, Huanghai and East China Seas[J]. Springer Netherlands, 1994: 17-26.
[42] 袁萍, 王厚杰, 毕乃双, 等. 中国东部陆架海锋面的时空变化及其对细颗粒沉积物输运和沉积的影响[J]. 海洋地质与第四纪地质, 2020, 40(3):25-42 doi: 10.16562/j.cnki.0256-1492.2019050602
YUAN Ping, WANG Houjie, BI Naishuang, et al. Temporal and spatial variations of oceanic fronts and their impact on transportation and deposition of fine-grained sediments in the East China Shelf Seas [J]. Marine Geology & Quaternary Geology, 2020, 40(3): 25-42. doi: 10.16562/j.cnki.0256-1492.2019050602
[43] 梅西, 李学杰, 密蓓蓓, 等. 中国海域表层沉积物分布规律及沉积分异模式[J]. 中国地质, 2020, 47(5):1447-1462
MEI Xi, LI Xuejie, MI Beibei, et al. Distribution regularity and sedimentary differentiation patterns of China seas surface sediments [J]. Geology in China, 2020, 47(5): 1447-1462.
[44] 蓝先洪, 王红霞, 张志珣, 等. 南黄海表层沉积物稀土元素分布与物源关系[J]. 中国稀土学报, 2006, 24(6):745-749 doi: 10.1016/S1002-0721(07)60021-0
LAN Xianhong, WANG Hongxia, ZHANG Zhixun, et al. Distributions of rare earth elements and provenance relations in the surface sediments of the South Yellow Sea [J]. Journal of the Chinese Rare Earth Society, 2006, 24(6): 745-749. doi: 10.1016/S1002-0721(07)60021-0
[45] 朱爱美, 刘季花, 张辉, 等. 东海内陆架泥质区表层沉积物稀土元素的分布特征[J]. 海洋地质与第四纪地质, 2012, 32(1):1-10
ZHU Aimei, LIU Jihua, ZHANG Hui, et al. Distribution pattern of REEs in the inner-shelf mud area of East China Sea [J]. Marine Geology & Quaternary Geology, 2012, 32(1): 1-10.
[46] 李文建, 王珍岩, 黄海军. 夏季南黄海悬浮体粒度分布及其影响因素[J]. 海洋地质与第四纪地质, 2020, 40(6):49-60
LI Wenjian, WANG Zhenyan, HUANG Haijun. Grain size distribution pattern and influencing factors of suspended matters in the Southern Yellow Sea during summer season [J]. Marine Geology & Quaternary Geology, 2020, 40(6): 49-60.
[47] 刘健, 秦华峰, 孔祥淮, 等. 黄东海陆架及朝鲜海峡泥质沉积物的磁学特征比较研究[J]. 第四纪研究, 2007, 27(6):1031-1039 doi: 10.3321/j.issn:1001-7410.2007.06.019
LIU Jian, QIN Huafeng, KONG Xianghuai, et al. Comparative researches on the magnetic properties of muddy sediments from the Yellow Sea and East China Sea shelves and the Korea strait [J]. Quaternary Sciences, 2007, 27(6): 1031-1039. doi: 10.3321/j.issn:1001-7410.2007.06.019
[48] Chough S K, Lee H J, Yoon S H. Marine Geology of Korean Seas[M]. 2nd ed. Amsterdam: Elsevier Science B. V. , 2000.
[49] Lee H J. A review on the Holocene evolution of an inner-shelf mud deposit in the southeastern Yellow Sea: the Huksan Mud Belt [J]. Ocean Science Journal, 2015, 50(4): 615-621. doi: 10.1007/s12601-015-0056-7
[50] Yang S Y, Youn J S. Geochemical compositions and provenance discrimination of the central south Yellow Sea sediments [J]. Marine Geology, 2007, 243(1-4): 229-241. doi: 10.1016/j.margeo.2007.05.001
[51] Schubel J R, Shen H T, Park M J. Comparative analysis of estuaries bordering the Yellow Sea[M]//Wolfe D A. Estuarine Variability. New York: Academic Press, 1986: 43-62.
-
