Comprehensive geological survey and research on Wuzhizhou Island of Sanya City based on UAV tilt photography technology
-
摘要:
交通不便、植被覆盖茂盛、地形险峻等因素导致无居民海岛开展综合地质调查研究极其困难。为了补充登岛调查人员不足，降低安全风险，提高作业效率，本文探索无人机倾斜摄影技术在无居民海岛综合地质调查中的应用。利用飞马D20无人机搭载5镜头D-OP3000模块，快速获取海岛低空（190 m）、多角度、高精度影像数据，影像平均地面分辨率优于0.03 m。对获取的影像数据应用Smart3D软件生成数字正射影像（DOM）、构建海岛实景三维模型，并基于实景三维模型实现对海岛进行全方位观测，提升对海岛的宏观认识。通过对数字正射影像及海岛实景三维模型进行综合研究，结合实地调查，获取了蜈支洲岛线性断裂特征，探讨了其成因；提取了蜈支洲岛土地开发利用现状信息；识别出岛岸崩塌、断裂活动及岛滩侵蚀等地质灾害隐患点15处，并提出了防治建议，为海岛开发利用、生态保护修复、地质灾害治理及海岛综合管理提供了科学依据。
Abstract:It is extremely difficult to carry out comprehensive geological surveys on uninhabited island due to factors such as inconvenient transportation, lush vegetation coverage, and steep terrain. To overcome the shortage in in-situ investigational staff, reduce safety risks, and improve the working efficiency, the UAV (manned aerial vehicle) tilt photography technology was applied and tested in the Wuzhizhou Island, Hainan Province. A FEIMA D20 UAV carries a D-OP3000 module that equipped with 5 lens with which low-altitude (190m), multi-angle, and high-precision image data could be obtained quickly. The average ground resolution of the image was finer than 0.03m. In addition, Smart3D software was used to generate digital orthophoto maps (DOM) and to build a real-scene 3D model of the island. Therefore, the island could be observed in an omnidirectional way, and the overall understanding of the island was enhanced. Combined with a comprehensive study of digital orthophoto maps, the real-scene 3D model and field investigation, and the linear fracture characteristics of Wuzhizhou Island were obtained, and its origination was explored. The information of current status of land development and utilization of the island was extracted and 15 hidden risk points of geological disasters were spotted, including costal bluff collapse, fault activity, and beach erosion, to which countermeasures were proposed. This study provided a scientific basis for island development and utilization, ecological protection and restoration, geological disaster management, and comprehensive management of the islands alike.
-
-
表 1 飞马D20无人机和D-OP3000相机硬件参数
Table 1. Hardware parameters of FEIMA D20 UAV and D-OP3000 cameras
飞马D20性能参数 D-OP3000性能参数 序号 项目 参数 序号 项目 参数 1 材质 碳纤维+
镁铝合金1 型号 D-OP3000 2 最大载荷 6 kg 2 相机数量 5 3 巡航速度 8 m/s 3 传感器尺寸 23.5×
15.6 mm4 最大续航时间 60 min 4 有效像素 约2430万×
5像素5 测控半径 30 km 5 镜头焦距（下视） 25 mm定焦 6 起降方式 垂直起降 6 镜头焦距（倾斜） 35 mm定焦
下载: 导出CSV
表 2 像控点信息表
Table 2. Information at the image control points
点名 原始经纬度 原始大地高度/m 解状态 解算卫星 基站ID 基站距离/m Pt11 18°18′43.3060″N、109°45′59.2932″E 14.773 固定解 38 268 2 874.959 Pt12 18°18′42.7392″N、109°46′02.1141″E −0.483 固定解 39 268 2 800.159 Pt15 18°18′58.1493″N、109°45′51.4230″E −5.797 固定解 39 1164 2 714.165 Pt16 18°18′58.1498″N、109°45′51.4233″E −5.799 固定解 39 1164 2 714.169 Pt17 18°18′52.3249″N、109°45′43.6898″E −6.689 固定解 33 1164 2 558.176 Pt18 18°18′53.5039″N、109°45′35.4785″E −6.397 固定解 39 1164 2 321.49 Pt19 18°18′53.5801″N、109°45′28.1935″E −5.010 固定解 35 1164 2 125.469 Pt20 18°18′44.8661″N、109°45′37.2398″E 16.349 固定解 33 1164 2 483.683 Pt21 18°18′38.1566″N、109°45′34.4190″E 49.754 固定解 39 1164 2 518.853 Pt22 18°18′35.4427″N、109°45′41.7395″E 58.335 固定解 39 1164 2 744.847
下载: 导出CSV
-
[1] 龚旭峥, 高亚萍, 杨小央. 倾斜摄影实景三维技术在海岛调查中的应用[J]. 测绘技术装备, 2020, 22(4):69-70 doi: 10.3969/j.issn.1674-4950.2020.04.020
GONG Xuzheng, GAO Yaping, YANG Xiaoyang. Application of real 3D scene from tilt photogrammetry in island survey [J]. Geomatics Technology and Equipment, 2020, 22(4): 69-70. doi: 10.3969/j.issn.1674-4950.2020.04.020
[2] 卢汉明, 胡东平, 刘继东. 卫星遥感影像在海岛(礁)测图中的应用研究[J]. 海洋测绘, 2015, 35(1):70-72,75 doi: 10.3969/j.issn.1671-3044.2015.01.019
LU Hanming, HU Dongping, LIU Jidong. Application of satellite remote sensing imagery in island/reefs mapping [J]. Hydrographic Surveying and Charting, 2015, 35(1): 70-72,75. doi: 10.3969/j.issn.1671-3044.2015.01.019
[3] 李亚萍. 高分辨率遥感影像海岛礁地表覆盖变化检测与分析[D]. 兰州交通大学硕士学位论文, 2015: 1-78
LI Yaping. Change detection and analysis of surface coverage on Island and reefs via high resolution remote sensing image[D]. Master Dissertation of Lanzhou Jiaotong University, 2015: 1-78.
[4] 李晓敏, 马毅, 张杰, 等. 基于高分遥感的西沙群岛典型海岛时空变化分析[J]. 海洋通报, 2020, 39(6):717-729
LI Xiaomin, MA Yi, ZHANG Jie, et al. Spatial and temporal dynamics of typical islands in the Xisha Islands using high-resolution satellite images [J]. Marine Science Bulletin, 2020, 39(6): 717-729.
[5] 刘志军. 无居民海岛及其人类活动特征遥感识别方法研究[D]. 武汉大学博士学位论文, 2010: 1-42
LIU Zhijun. The study to the unhabitted islands and its human activity characteristics based on remote sensing[D]. Doctor Dissertation of Wuhan University, 2010: 1-42.
[6] 马毅, 张杰, 李晓敏, 等. 遥感技术应用于海岛保护与利用规划的可行性研究[J]. 海洋开发与管理, 2009, 26(7):92-95 doi: 10.3969/j.issn.1005-9857.2009.07.019
MA Yi, ZHANG Jie, LI Xiaomin, et al. On the feasibility of the application of remote sensing technology to island conservation and usage planning [J]. Ocean Development and Management, 2009, 26(7): 92-95. doi: 10.3969/j.issn.1005-9857.2009.07.019
[7] 许祝华, 张彦彦, 杨晖, 等. 海域无人机遥感监测三维立体监管系统的建设与研究[J]. 海洋开发与管理, 2013, 30(6):16-18 doi: 10.3969/j.issn.1005-9857.2013.06.004
XU Zhuhua, ZHANG Yanyan, YANG Hui, et al. Construction and research of three-dimensional monitoring system for remote sensing monitoring of marine drones [J]. Ocean Development and Management, 2013, 30(6): 16-18. doi: 10.3969/j.issn.1005-9857.2013.06.004
[8] 杨国东, 王民水. 倾斜摄影测量技术应用及展望[J]. 测绘与空间地理信息, 2016, 39(1):13-15,18 doi: 10.3969/j.issn.1672-5867.2016.01.004
YANG Guodong, WANG Minshui. The tilt photographic measuration technique and expectation [J]. Geomatics & Spatial Information Technology, 2016, 39(1): 13-15,18. doi: 10.3969/j.issn.1672-5867.2016.01.004
[9] 金伟, 葛宏立, 杜华强, 等. 无人机遥感发展与应用概况[J]. 遥感信息, 2009(1):88-92 doi: 10.3969/j.issn.1000-3177.2009.01.017
JIN Wei, GE Hongli, DU Huaqiang, et al. A review on unmanned aerial vehicle remote sensing and its application [J]. Remote Sensing Information, 2009(1): 88-92. doi: 10.3969/j.issn.1000-3177.2009.01.017
[10] 刘倩, 梁志海, 范慧芳. 浅谈无人机遥感的发展及其行业应用[J]. 测绘与空间地理信息, 2016, 39(6):167-169 doi: 10.3969/j.issn.1672-5867.2016.06.053
LIU Qian, LIANG Zhihai, FAN Huifang. The development of UAV remote sensing and its application in Geo-information related industries [J]. Geomatics & Spatial Information Technology, 2016, 39(6): 167-169. doi: 10.3969/j.issn.1672-5867.2016.06.053
[11] 杨燕明, 郑凌虹, 文洪涛, 等. 无人机遥感技术在海岛管理中的应用研究[J]. 海洋开发与管理, 2011, 28(1):6-10 doi: 10.3969/j.issn.1005-9857.2011.01.002
YANG Yanming, ZHENG Linghong, WEN Hongtao, et al. Application of UAV remote sensing technology in island management [J]. Ocean Development and Management, 2011, 28(1): 6-10. doi: 10.3969/j.issn.1005-9857.2011.01.002
[12] 方德涛, 刘珊珊, 张笑. 低空无人机遥感系统在海岛潮间带监测中的应用[J]. 北京测绘, 2019, 33(1):71-75 doi: 10.19580/j.cnki.1007-3000.2019.01.016
FANG Detao, LIU Shanshan, ZHANG Xiao. Application of low altitude UAV remote sensing in intertidal zone monitoring of islands [J]. Beijing Surveying and Mapping, 2019, 33(1): 71-75. doi: 10.19580/j.cnki.1007-3000.2019.01.016
[13] 邓才龙, 刘焱雄, 田梓文, 等. 无人机遥感在海岛海岸带监测中的应用研究[J]. 海岸工程, 2014, 33(4):41-48 doi: 10.3969/j.issn.1002-3682.2014.04.005
DENG Cailong, LIU Yanxiong, TIAN Ziwen, et al. Application of UAV remote sensing in the monitoring of islands and coastal zones [J]. Coastal Engineering, 2014, 33(4): 41-48. doi: 10.3969/j.issn.1002-3682.2014.04.005
[14] 黄学富, 张宏胜, 孙福成. 三亚蜈支洲岛景区开发现状及发展对策分析[J]. 经济研究导刊, 2021(2):41-44 doi: 10.3969/j.issn.1673-291X.2021.02.012
HUANG Xuefu, ZHANG Hongsheng, SUN Fucheng. Analysis on the current situation and countermeasures of the development of Wuzhizhou Island scenic spot in Sanya [J]. Economic Research Guide, 2021(2): 41-44. doi: 10.3969/j.issn.1673-291X.2021.02.012
[15] 张晓浩, 黄华梅, 吴秋生, 等. 三亚市蜈支洲岛海岸侵蚀与沉积的定量分析[J]. 热带海洋学报, 2015, 34(5):51-56 doi: 10.11978/2014125
ZHANG Xiaohao, HUANG Huamei, WU Qiusheng, et al. Quantitative analysis of coastal erosion and deposition on Wuzhizhou Island of Sanya City [J]. Journal of Tropical Oceanography, 2015, 34(5): 51-56. doi: 10.11978/2014125
[16] 匡巧娟. 海南蜈支洲岛景观资源的保护与利用研究[D]. 海南大学硕士学位论文, 2018: 1-79
KUANG Qiaojuan. The study of protection and utilization on landscape resources in Hainan Wuzhizhou Island[D]. Master Dissertation of Hainan University, 2018: 1-79.
[17] 马文刚, 夏景全, 魏一凡, 等. 三亚蜈支洲岛海洋牧场近岛区底表大型底栖动物群落结构及评价[J]. 热带海洋学报, 2022, 41(3):135-146 doi: 10.11978/2021125
MA Wen’gang, XIA Jingquan, WEI Yifan, et al. Community structure evaluation of epifaunal macrozoobenthos in the near-island waters of marine ranching in Wuzhizhou Island, Sanya [J]. Journal of Tropical Oceanography, 2022, 41(3): 135-146. doi: 10.11978/2021125
[18] Huang J Z, Wang F X, Zhao H W, et al. Reef benthic composition and coral communities at the Wuzhizhou Island in the south China sea: The impacts of anthropogenic disturbance [J]. Estuarine, Coastal and Shelf Science, 2020, 243: 106863. doi: 10.1016/j.ecss.2020.106863
[19] 国家市场监督管理总局, 国家标准化管理委员会. GB/T 39612-2020 低空数字航摄与数据处理规范[S]. 北京: 中国标准出版社, 2020
State Administration of Market Supervision and Administration of the People's Republic of China, Standardization Administration of the People's Republic of China. GB/T 39612-2020 Specifications for low-altitude digital aerial photography and data processing[S]. Beijing: Standards Press of China, 2020.
[20] 范诗玥, 张峰, 卢文虎, 等. 基于红黑树数据结构的海岸线无人机正射影像拼接研究[J]. 海洋通报, 2016, 35(2):132-139 doi: 10.11840/j.issn.1001-6392.2016.02.002
FAN Shiyue, ZHANG Feng, LU Wenhu, et al. Study on the coastline orthophoto mosaic using UAV images based on red-black data structure [J]. Marine Science Bulletin, 2016, 35(2): 132-139. doi: 10.11840/j.issn.1001-6392.2016.02.002
[21] 闫烨琛, 高学飞, 于向吉, 等. 无人机倾斜摄影测量技术在地质灾害隐患调查中的应用研究[J]. 科技创新与应用, 2022, 12(17):193-196
YAN Yechen, GAO Xuefei, YU Xiangji, et al. Research on the application of UAV oblique photogrammetry technology in the investigation of geological hazards [J]. Technology Innovation and Application, 2022, 12(17): 193-196.
[22] 张川, 赵志国, 赵向东, 等. POS辅助空三数据建立立体模型及精度检测[J]. 测绘与空间地理信息, 2018, 41(2):171-173 doi: 10.3969/j.issn.1672-5867.2018.02.048
ZHANG Chuan, ZHAO Zhiguo, ZHAO Xiangdong, et al. Three-dimensional model building and precision testing with data of POS supported aerial triangulation [J]. Geomatics & Spatial Information Technology, 2018, 41(2): 171-173. doi: 10.3969/j.issn.1672-5867.2018.02.048
[23] 郝思宝. 数字正射影像建库关键技术研究[D]. 南京师范大学硕士学位论文, 2007: 1-52
HAO Sibao. Research on the key technologies of building digital orthophoto map database[D]. Master Dissertation of Nanjing Normal University, 2007: 1-52.
[24] 夏邦栋. 普通地质学[M]. 2版. 北京: 地质出版社, 1995
XIA Bangdong. Physical Geology[M]. 2nd ed. Beijing: Geological Press, 1995.
[25] 董荣. 花岗岩球状风化的形成机理新析[J]. 矿产与地质, 2016, 30(5):842-845 doi: 10.3969/j.issn.1001-5663.2016.05.025
DONG Rong. A new analysis of the formation mechanism of granite spherical weathering process [J]. Mineral Resources and Geology, 2016, 30(5): 842-845. doi: 10.3969/j.issn.1001-5663.2016.05.025
[26] 中华人民共和国国家质量监督检验检疫总局, 中国国家标准化管理委员会. GB/T 21010-2017 土地利用现状分类[S]. 北京: 中国标准出版社, 2017
General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China. GB/T 21010-2017 Current land use classification[S]. Beijing: Standards Press of China, 2017.
[27] 杜军, 李培英. 海岛地质灾害风险评价指标体系初建[J]. 海洋开发与管理, 2010, 27(S1):80-82 doi: 10.3969/j.issn.1005-9857.2010.z1.017
DU Jun, LI Peiying. On the building of risk assessment system for geological hazards of island [J]. Ocean Development and Management, 2010, 27(S1): 80-82. doi: 10.3969/j.issn.1005-9857.2010.z1.017
[28] 李拴虎, 刘乐军, 高伟. 福建东山岛地质灾害区划[J]. 海洋地质前沿, 2013, 29(8):45-52 doi: 10.16028/j.1009-2722.2013.08.010
LI Shuanhu, LIU Lejun, GAO Wei. Geo-Hazard classification in Dongshan Island of Fujian Province [J]. Marine Geology Frontiers, 2013, 29(8): 45-52. doi: 10.16028/j.1009-2722.2013.08.010
[29] 李萍, 刘杰, 徐元芹, 等. 我国典型海岛主要地质灾害类型及防治措施[J]. 海洋开发与管理, 2018, 35(5):60-64 doi: 10.3969/j.issn.1005-9857.2018.05.012
LI Ping, LIU Jie, XU Yuanqin, et al. Main geological disasters in typical Islands and preventive Measures in China [J]. Ocean Development and Management, 2018, 35(5): 60-64. doi: 10.3969/j.issn.1005-9857.2018.05.012
[30] 徐元芹, 刘乐军, 李培英, 等. 我国典型海岛地质灾害类型特征及成因分析[J]. 海洋学报, 2015, 37(9):71-83
XU Yuanqin, LIU Lejun, LI Peiying, et al. Geology disaster feature and genetic analysis of typical islands, China [J]. Haiyang Xuebao, 2015, 37(9): 71-83.
[31] 孙丽. 厦门海岸侵蚀淤积灾害及防治研究[D]. 中国地质大学(北京)硕士学位论文, 2017
SUN Li. Study on disasters and prevention of erosion and sedimentation in Xiamen coast[D]. Master Dissertation of China University of Geosciences (Beijing), 2017.
[32] 桂峰, 樊超. 海岛生态环境调查与评价[M]. 北京: 海洋出版社, 2018: 1-13
GUI Feng, FAN Chao. Ecological Environment Investigation and Evaluation of Islands[M]. Beijing: China Ocean Press, 2018: 1-13.
[33] 谢财富, 丁式江, 傅太安, 等. 乐东县幅(E49C002001东北角)、陵水县幅(E49C002002西北角)1: 25万区域地质调查报告[R]. 宜昌: 宜昌地质矿产研究所, 2004
XIE Caifu, DING Shijiang, FU Taian, et al. 1: 250 000 Regional geological survey report of Ledong County mapheet (E49C002001, Northeast Corner) and Lingshui County mapsheet (E49C002002, Northwest Corner)[R]. Yichang: Yichang Institute of Geology and Mineral Resources, 2004.
[34] 全国海岛资源综合调查报告编写组. 全国海岛资源综合调查报告[M]. 北京: 海洋出版社, 1996: 91-115
Compilation Group of the National Island Resources Comprehensive Survey Report. National Comprehensive Survey Report on Island Resources[M]. Beijing: China Ocean Press, 1996: 91-115.
[35] 张业明, 谢才富, 付太安, 等. 海南岛地质构造演化刍论[J]. 科学技术与工程, 2005, 5(20):1485-1487 doi: 10.3969/j.issn.1671-1815.2005.20.005
ZHANG Yeming, XIE Caifu, FU Taian, et al. Tectonic evolution of Hainan Island [J]. Science Technology and Engineering, 2005, 5(20): 1485-1487. doi: 10.3969/j.issn.1671-1815.2005.20.005
[36] 唐立梅, 陈汉林, 董传万, 等. 中国东南部晚中生代构造伸展作用: 来自海南岛基性岩墙群的证据[J]. 岩石学报, 2010, 26(4):1204-1216
TANG Limei, CHEN Hanlin, DONG Chuanwan, et al. Late Mesozoic tectonic extension in SE China: evidence from the basic dike swarms in Hainan Island, China [J]. Acta Petrologica Sinica, 2010, 26(4): 1204-1216.
[37] 徐栋, 杨敏, 苗宇宏, 等. 基于无人机高光谱遥感的海岛岸线精准提取方法研究与应用[J]. 海洋科学, 2020, 44(12):54-60
XU Dong, YANG Min, MIAO Yuhong, et al. Research and application of accurate extraction method of island shoreline based on hyperspectral remote sensing of unmanned aerial vehicle [J]. Marine Sciences, 2020, 44(12): 54-60.
[38] 沈蔚, 王家为, 王林振, 等. 一种基岩海(岛)岸线自动提取新方法[J]. 上海海洋大学学报, 2015, 24(6):975-981 doi: 10.12024/jsou.20140901184
SHEN Wei, WANG Jiawei, WANG Linzhen, et al. One new method of bedrock (island) coastline extraction [J]. Journal of Shanghai Ocean University, 2015, 24(6): 975-981. doi: 10.12024/jsou.20140901184
[39] 常立侠, 冼嘉俊, 陈昌亮, 等. 海岛岸线界定标准及方法初探[J]. 海岸工程, 2015, 34(2):89-96 doi: 10.3969/j.issn.1002-3682.2015.02.011
CHANG Lixia, XIAN Jiajun, CHEN Changliang, et al. A preliminary study on the standard and method of Island coastline definition [J]. Coastal Engineering, 2015, 34(2): 89-96. doi: 10.3969/j.issn.1002-3682.2015.02.011
[40] 李刚, 万荣胜, 陈泓君, 等. 海南岛南部海岸线变迁及其成因[J]. 海洋地质前沿, 2018, 34(1):48-54 doi: 10.16028/j.1009-2722.2018.01008
LI Gang, WAN Rongsheng, CHEN Hongjun, et al. Coastline changes and their origin in the southern Hainan Island [J]. Marine Geology Frontiers, 2018, 34(1): 48-54. doi: 10.16028/j.1009-2722.2018.01008
-
