Middle-late Miocene fault activity and its petroleum exploration significance of middle-shallow layers in the Xihu Sag, East China Sea
-
摘要:
西湖凹陷中新世中晚期经历了强烈的挤压反转，发育了大量晚期活动断层。然而目前对中新世中晚期活动断裂类型、分布及性质的系统性认识不足，制约了浅部新层系油气勘探的进展。本文基于近年来西湖凹陷中西部地区三维连片地震解释成果，系统分析了西湖凹陷中西部中新世中晚期活动断裂的类型、分布及其性质，并在此基础上探讨断裂活动对中浅层油气勘探的指示意义。结果表明，该时期断裂在中浅层具有集中成带发育特征，受刚性基底差异分布所引起的局部应力场影响，不同区带断裂样式及性质呈现出明显多样性。其中，中央反转背斜带主要发育压性通源断裂，同时背斜核部伴生张性、张扭性悬挂断裂；西部斜坡带北段高带以发育张性通源断裂为主，南段发育压性通源断裂；西次凹局部发育具弱走滑特征的悬挂断裂。基于以上认识，认为凹陷北段中浅层具有较好的油气勘探前景，中央反转背斜带北段在压性通源断裂发育背景下，通过深层超压驱动，并经由悬挂断裂“接力中转”，利于油气在中浅层聚集成藏；西部斜坡带北段在张性通源断裂侧向封堵能力有限的条件下，西缘海礁隆起区潜山及上覆层系具备富集油气的有利条件。
Abstract:The Xihu Sag experienced strong compression inversion in the middle-late Miocene, and developed a large number of late active faults. However, the lack of systematic understanding of the type, distribution and properties of active fault in the middle-late Miocene has restricted the progress of oil and gas exploration in shallow and new strata. The type, distribution and property of the middle-late Miocene active fault in the central and western part of the Xihu Sag were systematically analyzed, based on which the fault activity significance of petroleum exploration in the middle-shallow layers was discussed. Results show that the fault is characteristic of concentrated zonation in this period, the fault properties and combination patterns in different zones show obvious diversity due to the change of local stress field caused by the distribution of rigid basement rock. Among them, the central inversion belt is dominated by compressional oil-source fracture, and the associated anticline core is mostly dominated by tension and torsion hanging fracture. The high belt of the western slope is dominated by tensional oil-source fracture in the northern section, and the southern section of the slope is dominated by compressional oil-source fracture. The western sub-sag is dominated by local hanging fracture, which has weak strike slip characteristics. Based on the above understanding, we considered that the middle-shallow layers in the northern section of the Xihu Sag are the replacement areas worthy of future exploration. In the northern section of the Central Inversion Belt, under the background of development of compressional oil-source fracture, driven by deep overpressure and "relay-transfer" through the hanging fracture, which is favorable for oil and gas accumulation in the middle-shallow layers. In the northern section of the western slope belt, under the condition of limited lateral sealing ability of tensional oil-source fracture, the buried hill and overlying strata in the convex area of the western margin have the conditions to capture hydrocarbon.
-
Key words:
- fracture system /
- oil-source fracture /
- late-stage accumulation /
- middle-shallow layer /
- middle-late Miocene /
- Xihu Sag
-
-
[1] 周心怀, 蒋一鸣, 唐贤君. 西湖凹陷成盆背景、原型盆地演化及勘探启示[J]. 中国海上油气, 2019, 31(3):1-10
ZHOU Xinhuai, JIANG Yiming, TANG Xianjun. Tectonic setting, prototype Basin evolution and exploration enlightenment of Xihu Sag in East China Sea Basin [J]. China Offshore Oil and Gas, 2019, 31(3): 1-10.
[2] 蔡华, 张建培, 唐贤君. 西湖凹陷断裂系统特征及其控藏机制[J]. 天然气工业, 2014, 34(10):18-26 doi: 10.3787/j.issn.1000-0976.2014.10.003
CAI Hua, ZHANG Jianpei, TANG Xianjun. Characteristics of the fault systems and their control on hydrocarbon accumulation in the Xihu Sag, East China Sea Shelf Basin [J]. Natural Gas Industry, 2014, 34(10): 18-26. doi: 10.3787/j.issn.1000-0976.2014.10.003
[3] 熊斌辉, 王春红, 张锦伟, 等. 西湖凹陷龙井运动特征[J]. 中国海上油气, 2008, 20(2):77-81 doi: 10.3969/j.issn.1673-1506.2008.02.002
XIONG Binhui, WANG Chunhong, ZHANG Jinwei, et al. Longjing movement characteristics in Xihu Sag [J]. China Offshore Oil and Gas, 2008, 20(2): 77-81. doi: 10.3969/j.issn.1673-1506.2008.02.002
[4] 郭真, 刘池洋, 田建锋. 东海陆架盆地龙井运动构造影响及其发育背景[J]. 西北大学学报:自然科学版, 2015, 45(5):801-810
GUO Zhen, LIU Chiyang, TIAN Jianfeng. Longjing movement structural effect and developmental background in East China Sea Basin [J]. Journal of Northwest University:Natural Science Edition, 2015, 45(5): 801-810.
[5] 叶加仁, 陈海红, 陈景阳, 等. 东海西湖凹陷成藏流体历史分析[J]. 天然气工业, 2006, 26(9):40-43 doi: 10.3321/j.issn:1000-0976.2006.09.012
YE Jiaren, CHEN Haihong, CHEN Jingyang, et al. Fluid history analysis in the Xihu Depression, East China Sea [J]. Natural Gas Industry, 2006, 26(9): 40-43. doi: 10.3321/j.issn:1000-0976.2006.09.012
[6] 周心怀. 西湖凹陷地质认识创新与油气勘探领域突破[J]. 中国海上油气, 2020, 32(1):1-12
ZHOU Xinhuai. Geological understanding and innovation in Xihu Sag and breakthroughs in oil and gas exploration [J]. China Offshore Oil and Gas, 2020, 32(1): 1-12.
[7] 雷闯, 叶加仁, 吴景富, 等. 低勘探程度盆地成藏动力学过程: 以西湖凹陷中部地区为例[J]. 地球科学-中国地质大学学报, 2014, 39(7):837-847 doi: 10.3799/dqkx.2014.078
LEI Chuang, YE Jiaren, WU Jingfu, et al. Dynamic process of hydrocarbon accumulation in low-exploration Basins: a case study of Xihu Depression [J]. Earth Science-Journal of China University of Geosciences, 2014, 39(7): 837-847. doi: 10.3799/dqkx.2014.078
[8] 高伟中, 谭思哲, 田超, 等. 西湖凹陷中央反转构造带圈闭油气充满度差异性原因分析[J]. 中国海上油气, 2019, 31(3):20-28
GAO Weizhong, TAN Sizhe, TIAN Chao, et al. Analysis on the oil and gas fullness difference of the Central Inversion Tectonic belt of Xihu Sag in East China Sea Basin [J]. China Offshore Oil and Gas, 2019, 31(3): 20-28.
[9] 陈志勇, 葛和平. 西湖凹陷反转构造与油气聚集[J]. 中国海上油气, 2003, 17(1):20-24
CHEN Zhiyong, GE Heping. Inversion structures and hydrocarbon accumulation in Xihu Sag, east China sea Basin [J]. China Offshore Oil and Gas, 2003, 17(1): 20-24.
[10] 张敏强, 钟志洪, 夏斌, 等. 东海西湖凹陷中南部晚中新世构造反转与油气运聚[J]. 中国海上油气, 2005, 17(2):73-79 doi: 10.3969/j.issn.1673-1506.2005.02.001
ZHANG Minqiang, ZHONG Zhihong, XIA Bin, et al. Late Miocene tectonic inversion and hydrocarbon migration and accumulation in central and southern Xihu Sag, East China Sea [J]. China Offshore Oil and Gas, 2005, 17(2): 73-79. doi: 10.3969/j.issn.1673-1506.2005.02.001
[11] 张建培, 张涛, 刘景彦, 等. 西湖凹陷反转构造分布与样式[J]. 海洋石油, 2008, 28(4):14-20 doi: 10.3969/j.issn.1008-2336.2008.04.003
ZHANG Jianpei, ZHANG Tao, LIU Jingyan, et al. Distribution and style of inversed structures in Xihu Depression [J]. Offshore Oil, 2008, 28(4): 14-20. doi: 10.3969/j.issn.1008-2336.2008.04.003
[12] 杨风丽, 王敏雪, 庄建建, 等. 西湖凹陷反转构造定量运动学过程及对油气的控制作用[J]. 石油学报, 2010, 31(4):596-601 doi: 10.7623/syxb201004013
YANG Fengli, WANG Minxue, ZHUANG Jianjian, et al. Kinematical processes of inversion structure and its contribution to hydrocarbon accumulation in Xihu Depression of East China Sea Basin [J]. Acta Petrolei Sinica, 2010, 31(4): 596-601. doi: 10.7623/syxb201004013
[13] 郭真, 刘池洋, 田建锋. 东海盆地西湖凹陷反转构造特征及其形成的动力环境[J]. 地学前缘, 2015, 22(3):59-67 doi: 10.13745/j.esf.2015.03.005
GUO Zhen, LIU Chiyang, TIAN Jianfeng. Structural characteristics and main controlling factors of inversion structures in Xihu Depression in Donghai Basin [J]. Earth Science Frontiers, 2015, 22(3): 59-67. doi: 10.13745/j.esf.2015.03.005
[14] 张国华, 张建培. 东海陆架盆地构造反转特征及成因机制探讨[J]. 地学前缘, 2015, 22(1):260-270 doi: 10.13745/j.esf.2015.01.022
ZHANG Guohua, ZHANG Jianpei. A discussion on the tectonic inversion and its genetic mechanism in the East China Sea Shelf Basin [J]. Earth Science Frontiers, 2015, 22(1): 260-270. doi: 10.13745/j.esf.2015.01.022
[15] 邓军, 王庆飞, 黄定华, 等. 鄂尔多斯盆地基底演化及其对盖层控制作用[J]. 地学前缘, 2005, 12(3):91-99 doi: 10.3321/j.issn:1005-2321.2005.03.011
DENG Jun, WANG Qingfei, HUANG Dinghua, et al. Basement evolution of the Ordos Basin and its constraint on cap rock [J]. Earth Science Frontiers, 2005, 12(3): 91-99. doi: 10.3321/j.issn:1005-2321.2005.03.011
[16] 包洪平, 邵东波, 郝松立, 等. 鄂尔多斯盆地基底结构及早期沉积盖层演化[J]. 地学前缘, 2019, 26(1):33-43 doi: 10.13745/j.esf.sf.2019.1.6
BAO Hongping, SHAO Dongbo, HAO Songli, et, al. Basement structure and evolution of early sedimentary cover of the Ordos Basin [J]. Earth Science Frontiers, 2019, 26(1): 33-43. doi: 10.13745/j.esf.sf.2019.1.6
[17] 贾东, 陈竹新, 贾承造, 等. 龙门山前陆褶皱冲断带构造解析与川西前陆盆地的发育[J]. 高校地质学报, 2003, 9(3):402-410 doi: 10.3969/j.issn.1006-7493.2003.03.010
JIA Dong, CHEN Zhuxin, JIA Chengzao, et al. Structural features of the Longmen Shan fold and thrust belt and Development of the western Sichuan foreland Basin, Central China [J]. Geological Journal of China Universities, 2003, 9(3): 402-410. doi: 10.3969/j.issn.1006-7493.2003.03.010
[18] 蒋一鸣, 何新建, 唐贤君, 等. 钓鱼岛隆褶带物质构成及东海西湖凹陷原型盆地东边界再认识[J]. 地球科学, 2019, 44(3):773-783
JIANG Yiming, HE Xinjian, TANG Xianjun, et al. Material composition of Diaoyu Islands folded zone and reanalysis of eastern boundary of prototype Basin of Xihu Sag in East China Sea [J]. Earth Science, 2019, 44(3): 773-783.
[19] 蒋一鸣, 邹玮, 刘金水, 等. 东海西湖凹陷中新世末反转背斜构造成因机制: 来自基底结构差异的新认识[J]. 地球科学, 2020, 45(3):968-979
JANG Yiming, ZOU Wei, LIU Jinshui, et al. Genetic mechanism of inversion anticline structure at the end of Miocene in Xihu Sag, East China Sea: a new understanding of basement structure difference [J]. Earth Science, 2020, 45(3): 968-979.
[20] 张进江, 丁林. 青藏高原东西向伸展及其地质意义[J]. 地质科学, 2003, 38(2):179-189 doi: 10.3321/j.issn:0563-5020.2003.02.005
ZHANG Jinjiang, DING Lin. East-West extension in Tibetan Plateau and its significance to tectonic evolution [J]. Chinese Journal of Geology, 2003, 38(2): 179-189. doi: 10.3321/j.issn:0563-5020.2003.02.005
[21] 潘裕生, 钟嘉猷, 周勇. 青藏高原南北向地堑系的实验研究[J]. 地质科学, 2003, 38(2):172-178,213 doi: 10.3321/j.issn:0563-5020.2003.02.004
PAN Yusheng, ZHONG Jiayou, ZHOU Yong. Mechanism of N-S trending graben system in Qinghai-Tibetan Plateau [J]. Chinese Journal of Geology, 2003, 38(2): 172-178,213. doi: 10.3321/j.issn:0563-5020.2003.02.004
[22] 严俊君, 黄太柱. 塔里木盆地北部构造样式[J]. 地球科学-中国地质大学学报, 1995, 20(3):264-270
YAN Junjun, HUANG Taizhu. Structural styles of northern Tarim Basin, Xinjiang [J]. Earth Science-Journal of China University of Geosciences, 1995, 20(3): 264-270.
[23] 王燮培, 严俊君. 塔里木盆地北部断裂格架分析[J]. 地球科学-中国地质大学学报, 1995, 20(3):237-242
WANG Xiepei, YAN Junjun. Structural framework of major faults in northern Tarim Basin, Xinjiang [J]. Earth Science-Journal of China University of Geosciences, 1995, 20(3): 237-242.
[24] 蒋一鸣, 刁慧, 曾文倩. 东海盆地西湖凹陷平湖组煤系烃源岩条件及成烃模式[J]. 地质科技通报, 2020, 39(3):30-39
JIANG Yiming, DIAO Hui, ZENG Wenqian. Coal source rock conditions and hydrocarbon generation model of Pinghu Formation in Xihu Depression, East China Sea Basin [J]. Bulletin of Geological Science and Technology, 2020, 39(3): 30-39.
[25] 张先平, 张树林, 陈海红, 等. 东海西湖凹陷平湖构造带异常压力与油气成藏[J]. 海洋地质与第四纪地质, 2007, 27(3):93-97 doi: 10.16562/j.cnki.0256-1492.2007.03.015
ZHANG Xianping, ZHANG Shulin, CHEN Haihong, et al. Abnormal pressure and related reservoir Formation in the Pinghu structural belts of Xihu Depression, East China Sea [J]. Marine Geology & Quaternary Geology, 2007, 27(3): 93-97. doi: 10.16562/j.cnki.0256-1492.2007.03.015
[26] 覃军, 蒋一鸣, 李宁, 等. 东海陆架盆地西湖凹陷Y构造油气成藏过程及勘探启示[J]. 海洋地质与第四纪地质, 2019, 39(6):159-168 doi: 10.16562/j.cnki.0256-1492.2019070601
QIN Jun, JIANG Yiming, LI Ning, et al. Hydrocarbon accumulation process in the structure Y of Xihu Sag, East China Sea Shelf Basin and its implications for feature exploration [J]. Marine Geology & Quaternary Geology, 2019, 39(6): 159-168. doi: 10.16562/j.cnki.0256-1492.2019070601
-
