Sequence stratigraphy and sedimentary evolution in the Lower Cretaceous of the Eastern Depression in the North Yellow Sea Basin
-
摘要:
北黄海盆地东部坳陷下白垩统是一套有利的油气勘探储集层，对其精细的地层划分及沉积演化的研究薄弱，制约了对东部坳陷油气勘探前景的深入认识。本文通过对东部坳陷钻井的岩芯观察，测井、录井分析及地震层序的井震标定，认为北黄海盆地东部坳陷下白垩统发育典型的陆相层序，可划分为3个三级层序，从底部向上依次为K1SQ1、K1SQ2和K1SQ3。在钻井上仅可见K1SQ1和K1SQ2两个三级层序，且K1SQ2层序的下降半旋回不完整，只残留该层序的上升半旋回。K1SQ1时期为湖盆断陷伸展期，发育一个完整的湖进—湖退旋回。早期盆地边缘发育河流相，南部主控断裂带发育扇三角洲相，北部缓坡带发育辫状河三角洲相；中后期由于湖平面上升，发育泥岩为主的湖泊沉积；晚期北部缓坡带见小规模辫状河三角洲沉积。K1SQ2时期为湖盆稳定裂陷期，继承了K1SQ1时期的沉积特征并略有收缩。K1SQ3时期为湖盆断陷萎缩期，以发育大范围的河流相沉积为特征。
Abstract:The Lower Cretaceous of the Eastern Depression in the North Yellow Sea Basin is a favorable reservoir for hydrocarbon exploration. However, scarce studies on its fine stratigraphic delineation and sedimentary evolution have restricted the deep understanding of the prospect of hydrocarbon exploration in the eastern depression. Through the core observation, logging and recording analyses, and well-seismic calibration in the eastern depression, it is concluded that the Lower Cretaceous mainly developed 3 third-order sequences, K1SQ1, K1SQ2, and K1SQ3 in bottom-up order. Only 2 third-order sequences, K1SQ1 and K1SQ2, are visible in the drilling, and the descending half-circle of the K1SQ2 sequence is always incomplete, with only the ascending half-cycle of the sequence remaining. The K1SQ1 was in the period of faulting extension, and the vertical lithological sequence exhibited a complete depositional cycle with progradation-retrogradation. In the early stage, there were fluvial phases which developed at mainly the basin margins, the fan-delta phases were in the southern rift zone of the basin, and the braided river-delta phase was in the northern slow-slope zone. Due to the uprising of the lake level, mudstone-dominated lake deposits were developed in the middle and late stages. In the advanced stage, small-scale braided river delta deposits developed in the northern slow-slope zone. The K1SQ2 was in the period of stabilized rupture, which inherited the depositional characteristics of the K1SQ1 period and contracted slightly. The K1SQ3 was in the period of faulting abortion, which was characterized by the development of a large area of fluvial phase deposits.
-
-
[1] Mitchum R M, Sangree J B, Vail P R, et al. Recognizing sequences and systems tracts from well logs, seismic data, and biostratigraphy: examples from the late Cenozoic of the Gulf of Mexico[M]//Weimer P, Posamentier H. Siliciclastic Sequence Stratigraphy: Recent Developments and Applications. Tulsa: American Association of Petroleum Geologists, 1993.
[2] Van Wagoner J C, Mitchum R M, Campion K M, et al. Siliciclastic Sequence Stratigraphy in Well Logs, Cores, and Outcrops: Concepts for High-Resolution Correlation of Time and Facies[M]. Tulsa: Association of Petroleum Geologists, 1990: 7-66.
[3] Hunt D, Tucker M E. Stranded parasequences and the forced regressive wedge systems tract: deposition during base-level fall—reply[J]. Sedimentary Geology, 1995, 95(1-2):147-160. doi: 10.1016/0037-0738(94)00123-C
[4] Helland-Hansen W, Gjelberg J G. Conceptual basis and variability in sequence stratigraphy: a different perspective[J]. Sedimentary Geology, 1994, 92(1-2):31-52. doi: 10.1016/0037-0738(94)90053-1
[5] Shanley K W, McCabe P J. Perspectives on the sequence stratigraphy of continental strata[J]. AAPG Bulletin, 1994, 78(4):544-568.
[6] 李思田, 林畅松, 解习农, 等. 大型陆相盆地层序地层学研究: 以鄂尔多斯中生代盆地为例[J]. 地学前缘, 1995, 2(3-4):133-136,148
LI Sitian, LIN Changsong, XIE Xinong, et al. Approaches of nonmarine sequence stratigraphy: a case study on the Mesozoic Ordos Bain[J]. Earth Science Frontiers, 1995, 2(3-4):133-136,148.]
[7] 顾家裕, 郭彬程, 张兴阳. 中国陆相盆地层序地层格架及模式[J]. 石油勘探与开发, 2005, 32(5):11-15 doi: 10.3321/j.issn:1000-0747.2005.05.002
GU Jiayu, GUO Bincheng, ZHANG Xingyang. Sequence stratigraphic framework and model of the continental basins in China[J]. Petroleum Exploration and Development, 2005, 32(5):11-15.] doi: 10.3321/j.issn:1000-0747.2005.05.002
[8] 于兴河, 姜辉, 李胜利, 等. 中国东部中、新生代陆相断陷盆地沉积充填模式及其控制因素: 以济阳坳陷东营凹陷为例[J]. 岩性油气藏, 2007, 19(1):39-45 doi: 10.3969/j.issn.1673-8926.2007.01.007
YU Xinghe, JIANG Hui, LI Shengli, et al. Depositional filling models and controlling factors on Mesozoic and Cenozoic fault basins of terrestrial facies in eastern China: a case study of Dongying sag of Jiyang depression[J]. Lithologic Reservoirs, 2007, 19(1):39-45.] doi: 10.3969/j.issn.1673-8926.2007.01.007
[9] 操应长. 断陷湖盆层序地层学[M]. 北京: 地质出版社, 2005: 36-59
CAO Yingchang. Rift Lacustrine Basin Sequence Stratigraphy[M]. Beijing: Geology Press, 2005: 36-59.]
[10] 刘振湖, 高红芳, 胡小强, 等. 北黄海盆地东部坳陷中生界含油气系统研究[J]. 中国海上油气, 2007, 19(4):229-233 doi: 10.3969/j.issn.1673-1506.2007.04.003
LIU Zhenhu, GAO Hongfang, HU Xiaoqiang, et al. A study on the Mesozoic petroleum system in East depression, North Yellow Sea basin[J]. China Offshore Oil and Gas, 2007, 19(4):229-233.] doi: 10.3969/j.issn.1673-1506.2007.04.003
[11] 龚承林, 雷怀彦, 王英民, 等. 北黄海盆地东部坳陷构造演化与油气地质特征[J]. 海洋地质与第四纪地质, 2009, 29(1):79-86
GONG Chenglin, LEI Huaiyan, WANG Yingmin, et al. Hydrocarbon geologic characters and structural evolution in the eastern depression of North Yellow sea Basin[J]. Marine Geology & Quaternary Geology, 2009, 29(1):79-86.]
[12] Zhang Y G, Chen Q H, Sun K, et al. Characteristics and influencing factors of Cretaceous reservoir in eastern depression of North Yellow Sea basin[J]. Journal of Petroleum Exploration and Production Technology, 2022, 12(7):1907-1918. doi: 10.1007/s13202-021-01362-4
[13] 杜民, 胡小强, 王改云. 北黄海盆地东部坳陷东南部层序地层特征及沉积体系[J]. 海洋地质前沿, 2014, 30(1):25-33
DU Min, HU Xiaoqiang, WANG Gaiyun. Sequence stratigraphic characteristics and depositional systems in the southeast of the eastern depression of the North Yellow Sea Basin[J]. Marine Geology Frontiers, 2014, 30(1):25-33.]
[14] 王改云, 刘金萍, 王后金, 等. 北黄海盆地东部坳陷中生界沉积特征及演化[J]. 沉积学报, 2015, 33(3):561-567
WANG Gaiyun, LIU Jinping, WANG Houjin, et al. Sedimentary characteristics and evolution of Mesozoic in the eastern depression, North Yellow Sea Basin[J]. Acta Sedimentologica Sinica, 2015, 33(3):561-567.]
[15] 王改云, 刘金萍, 王嘹亮, 等. 北黄海东部次盆地下白垩统沉积环境及沉积充填[J]. 中国地质, 2018, 45(1):69-80 doi: 10.12029/gc20180107
WANG Gaiyun, LIU Jinping, WANG Liaoliang, et al. Early Cretaceous sedimentary environment and filling in the Eastern Sub-basin, North Yellow Sea[J]. Geology in China, 2018, 45(1):69-80.] doi: 10.12029/gc20180107
[16] 王任, 石万忠, 肖丹, 等. 北黄海盆地下白垩统层序构成特点及控制因素[J]. 石油学报, 2015, 36(12):1531-1542 doi: 10.7623/syxb201512007
WANG Ren, SHI Wanzhong, XIAO Dan, et al. Architecture characteristics and control factors of Lower Cretaceous sequence in North Yellow Sea Basin[J]. Acta Petrolei Sinica, 2015, 36(12):1531-1542.] doi: 10.7623/syxb201512007
[17] 蔡乾忠. 黄海含油气盆地区域地质与大地构造环境[J]. 海洋地质动态, 2002, 18(11):8-12 doi: 10.3969/j.issn.1009-2722.2002.11.005
CAI Qianzhong. Regional geology and geotectonic environment of petroliferous basins in the Yellow Sea[J]. Marine Geology Frontiers, 2002, 18(11):8-12.] doi: 10.3969/j.issn.1009-2722.2002.11.005
[18] 简晓玲, 刘金萍, 王改云. 北黄海东部次盆地中新生代原型盆地分析[J]. 中国海上油气, 2019, 31(1):22-31
JIAN Xiaoling, LIU Jinping, WANG Gaiyun. Analysis of Meso-Cenozoic prototype basins in the East sub-basin, northern Yellow Sea[J]. China Offshore Oil and Gas, 2019, 31(1):22-31.]
[19] 胡小强, 唐大卿, 王嘹亮, 等. 北黄海盆地东部坳陷断裂构造分析[J]. 地质科技情报, 2017, 36(1):117-127
HU Xiaoqiang, TANG Daqing, WANG Liaoliang, et al. Fault structures in the eastern depression of the North Yellow Sea basin[J]. Geological Science and Technology Information, 2017, 36(1):117-127.]
[20] 陈书伟, 魏文艳, 龚胜利, 等. 北黄海东部坳陷中侏罗世-早白垩世孢粉组合序列[J]. 地层学杂志, 2019, 43(1):51-62
CHEN Shuwei, WEI Wenyan, GONG Shengli, et al. Middle Jurassic to early cretaceous palynological assemblages in the eastern depression, North Yellow Sea basin[J]. Journal of Stratigraphy, 2019, 43(1):51-62.]
[21] Vail P R. Seismic stratigraphy interpretation using sequence stratigraphy: Part 1: seismic stratigraphy interpretation procedure[M]//Bally A W. Atlas of Seismic Stratigraphy. Tulsa: American Association of Petroleum Geologists, 1987: 1-10.
[22] Cross T A, Baker M R, Chapin M A, et al. Applications of high-resolution sequence stratigraphy to reservoir analysis[M]//Eschard R, Dologez B. Subsurface Reservoir Characterization from Outcrop Observation. Paris: Editions Technip, 1993: 11-33.
[23] Catuneanu O. Principles of Sequence Stratigraphy[M]. Amsterdam: Elsevier, 2006: 1-369.
[24] 李绍虎. 浅议层序边界[J]. 地学前缘, 2012, 19(1):20-31
LI Shaohu. About sequence boundary[J]. Earth Science Frontiers, 2012, 19(1):20-31.]
[25] 于兴河. 碎屑岩系油气储层沉积学[M]. 2版. 北京: 石油工业出版社, 2008
YU Xinghe. Clastic Hydrocarbon Reservoir Sedimentology [M]. 2nd ed. Beijing: Petroleum Industry Press, 2008.]
[26] 朱筱敏. 层序地层学[M]. 2版. 青岛: 中国石油大学出版社, 2023
ZHU Xiaomin. Sequence Stratigraphy[M]. 2nd ed. Qingdao: China University of Petroleum Press, 2023.]
[27] 邹才能, 侯连华, 杨帆, 等. 碎屑岩风化壳结构及油气地质意义[J]. 中国科学: 地球科学, 2014, 44(12): 2652-2664
ZOU Caineng, HOU Lianhua, YANG Fan, et al. Structure of weathered clastic crust and its petroleum potential[J]. Science China Earth Sciences, 2014, 57(12): 3015-3026.]
[28] 周瑶琪, 张悦, 周腾飞, 等. 黄海及邻区晚中生代构造转换与原型盆地构造格局[J]. 地球科学, 2023, 48(4):1461-1480
ZHOU Yaoqi, ZHANG Yue, ZHOU Tengfei, et al. Tectonic transition of the Late-Mesozoic Yellow Sea and adjacent region and its tectonic framework of the proto-basin[J]. Earth Science, 2023, 48(4):1461-1480.]
[29] Yu H T, Xu Z J, Cheng R H, et al. Late Mesozoic transformation from the compressive to extensional tectonic regime of the Eastern North China Craton: sedimentary records from the North Yellow Sea Basin[J]. Journal of Asian Earth Sciences, 2023, 256:105809. doi: 10.1016/j.jseaes.2023.105809
[30] 张自力, 朱筱敏, 张锐锋, 等. 典型箕状断陷湖盆层序划分及层序结构样式: 以霸县凹陷古近系为例[J]. 地球科学, 2020, 45(11):4218-4235
ZHANG Zili, ZHU Xiaomin, ZHANG Ruifeng, et al. Sequence framework and sequence filling style in lacustrine rift basin: taking Paleogene in Baxian sag as an example[J]. Earth Science, 2020, 45(11):4218-4235.]
[31] 朱筱敏, 康安, 王贵文. 陆相坳陷型和断陷型湖盆层序地层样式探讨[J]. 沉积学报, 2003, 21(2):283-287 doi: 10.3969/j.issn.1000-0550.2003.02.015
ZHU Xiaomin, KANG An, WANG Guiwen. Sequence stratigraphic models of depression and faulted-down lake basins[J]. Acta Sedimentologica Sinica, 2003, 21(2):283-287.] doi: 10.3969/j.issn.1000-0550.2003.02.015
-
