可溶性淀粉在长石与石英浮选分离中的作用

肖亚雄; 石晴; 冯其明

doi:10.3969/j.issn.1000-6532.2022.02.014

可溶性淀粉在长石与石英浮选分离中的作用

1.
中国电建集团中南勘测设计研究院有限公司, 湖南　长沙　410014

2.
中南大学资源加工与生物工程学院, 湖南　长沙　410083

详细信息

作者简介: 肖亚雄（1988-），男，硕士，主要从事矿物加工技术研究工作

中图分类号: TD97

收稿日期: 2020-05-15

修回日期: 2020-07-23

刊出日期: 2022-04-25

Role of Soluble Starch in the Flotation Separation of Feldspar and Quartz

1.
Power China Zhongnan Engineering corporation Limited, Changsha, Hunan, China

2.
School of Minerals Processing and Bioengineering, Central South University, Changsha, Hunan, China

Received Date: 15 May 2020

Revised Date: 23 July 2020

Publish Date: 25 April 2022

摘要

摘要:
通过单矿物浮选实验、动电位测试及吸附量的测定，揭示了可溶性淀粉在长石与石英浮选分离中的作用。结果表明：采用十二胺（DDA）和十二烷基磺酸钠(SDS)作为混合捕收剂，可溶性淀粉对长石与石英皆有抑制作用，相对而言可溶性淀粉对石英的抑制作用较强，对长石的抑制作用较弱；动电位测试表明，长石在可溶性淀粉中的zeta电位相对于在纯水中的zeta电位只是略微向正方向移动，pH值为 5～7的范围内，石英在可溶性淀粉溶液中的zeta电位明显向正方向移动；吸附量的测定结果表明，在中性矿浆条件下，淀粉用量在20-80 mg/L的范围内，其在石英表面的吸附量大于在长石表面的吸附量，淀粉阻碍了捕收剂在石英表面的吸附，因此淀粉能够有效地抑制石英，而对长石抑制作用较弱。
- 可溶性淀粉 /
- 长石 /
- 石英 /
- 浮选
Abstract:
The role of soluble starch in the flotation separation of feldspar from quartz was revealed through the single mineral flotation test, potentiodynamic test and absorption measurement. The results showed that soluble starch inhibited the flotation of feldspar and quartz when dodecylamine (DDA) and sodium dodecyl sulfonate (SDS) were used as mixed collectors. Compared to feldspar, the inhibition effect of soluble starch on quartz was stronger. The results of potentiodynamic test showed that the zeta potential of feldspar in soluble starch solution slightly shifted to the positive direction compared to that in pure water. However, the zeta potential of quartz in the soluble starch solution significantly shifted to the positive direction compared to that in pure water in the pH range of 5 to 7. The results of absorption measurement showed that when the dosage of starch was in the range of 20-80 mg/L, the adsorption capacity of quartz on the starch was larger than that of feldspar under the neutral pulp conditions. These results demonstrated that starch could hinder the adsorption of the collector on the quartz, and thus effectively depress the flotation of quartz. By contrast, the inhibition of starch on feldspar was weaker.
- Soluble starch /
- Feldspar /
- Quartz /
- Flotation

HTML全文

图 1 淀粉的标准曲线

Figure 1.

下载: 全尺寸图片幻灯片

图 2 pH值对可溶性淀粉抑制长石与石英的影响

Figure 2.

下载: 全尺寸图片幻灯片

图 3 可溶性淀粉用量对长石与石英回收率的影响

Figure 3.

下载: 全尺寸图片幻灯片

图 4 长石与石英在可溶性淀粉溶液中的zeta电位

Figure 4.

下载: 全尺寸图片幻灯片

图 5 可溶性淀粉用量对长石与石英的Zeta电位的影响

Figure 5.

下载: 全尺寸图片幻灯片

图 6 可溶性淀粉在矿物表面的吸附量

Figure 6.

下载: 全尺寸图片幻灯片

表 1 长石和石英单矿物主要成分及含量/%

Table 1. Chemical analysis results of feldspar and quartz

名称 Al₂O₃ SiO₂ K₂O Na₂O Fe₂O₃ BaO CaO

长石 18.45 63.21 12.99 2.49 0.04 0.65 0.09
石英 - 98.9 - - 0.08 - 0.01

下载: 导出CSV

参考文献(8)

[1]	董伟霞, 顾幸勇, 包启富. 长石矿物及应用[M]. 北京: 化学工业出版社, 2010. DONG W X, GU X Y, BAO Q F. Feldspar mineral and its application [M]Beijing: Chemical Industry Press, 2010.
[2]	孙传尧, 印万忠. 硅酸盐矿物浮选原理[M]. 北京: 科学出版社, 2001: 17-18. SUN C Y, YIN W Z. Flotation principle of silicate minerals [M]. Beijing: Science Press, 2001: 17-18.
[3]	周海玲, 刘永胜. 油酸钠在红柱石与粉石英表面的吸附机理[J]. 矿产综合利用, 2020(2):198-202. doi: 10.3969/j.issn.1000-6532.2020.02.036 ZHOU H L, LIU Y S. Adsorption mechanism of sodium oleate on andalusite[J]. Multipurpose Utilization of Mineral Resources, 2020(2):198-202. doi: 10.3969/j.issn.1000-6532.2020.02.036
[4]	王淀佐. 浮选剂作用原理及应用[M]. 北京: 冶金工业出版社, 1982. WANG D Z. Principle and Application of Flotation Agent [M]. Beijing: Metallurgical Industry Press, 1982.
[5]	Neymayer P. Lima, George E. S. Valadao, Antonio E. C. Peres. Effect of amine and starch dosages on the reverse cationic flotation of an iron ore[J]. Minerals Engineering, 2013, 45:180-184. doi: 10.1016/j.mineng.2013.03.001
[6]	XIA L Y, ZHONG H, LIU G Y. Flotation techniques for separation of diaspore from bauxite using Gemini collector and starch depressant[J]. Transactions of Nonferrous Metals Society of China, 2010, 20:495-501. doi: 10.1016/S1003-6326(09)60168-0
[7]	印万忠, 孙传尧. 淀粉及其与Pb²⁺对硅酸盐矿物抑制和协同抑制作用的晶体化学分析[J]. 矿冶, 1999, 8(1):19-24. doi: 10.3969/j.issn.1005-7854.1999.01.005 YIN W Z, SUN C Y. Crystal chemistry analysis of the inhibitory and synergistic inhibitory effects of starch and Pb²⁺ on silicate minerals[J]. Mining and Metallurgy, 1999, 8(1):19-24. doi: 10.3969/j.issn.1005-7854.1999.01.005
[8]	汪桂杰, 孙伟. 几种改性淀粉对赤铁矿和石英抑制效果的研究[J]. 矿业研究与开发, 2013, 33(5):35-38. WANG G J, SUN W. Study on the inhibitory effect of several modified starches on hematite and quartz[J]. Mining Research and Development, 2013, 33(5):35-38.
