摘要:
为了查明青海某铜阳极泥中贵金属的矿物组成、嵌布关系等特征，优化铜阳极泥中贵金属提取工艺，采用化学分析方法、XRD、SEM电镜和能谱分析等手段对青海某铜阳极泥进行了详细的工艺矿物学研究。结果表明：铜阳极泥中颗粒粒度<38 μm 69.22%，38～4 5 μm 8.58%，>45 μm 22.20%；主要元素为Pb、Cu、Se、Au、Ag，其含量分布为25.43%、18.01%、4.23%、1161.4 g/t、70446.1 g/t；主要物相有铅矾（硫酸铅）、硒铜银矿、硒银矿、铜的砷酸盐（光线矿或翠绿砷铜矿、羟砷铜矿）、铜的氧卤化物或氢氧卤化物（氯铜矿或斜氯铜矿、副氯铜矿）、锑的砷酸盐、锡石、硅酸盐矿物等；金的粒度分布小于2 μm，形态主要为圆点状，与硒铜银矿边缘或包裹连生；银的粒度分布不均匀，最大粒度为20 μm，最小粒度小于5 μm，主要以硒铜银矿、硒银矿、硫铜银矿、卤化银形式存在。
Abstract:In order to improve the technology of the process of noble metal extracted from high lead copper anode slime, the technological mineralogy investigation of the anode slime was studied by chemical analysis methods, XRD, particle size analysis, SEM and EDS. The results showed that the particle size in the anode slime which was less than 38 μm accounted for 69.22%, the particle size ranged from 38 to 45 μm accounted for 8.58%, and that of more than 45 μm accounted for 22.20%. The main elements were Pb, Cu, Se, Au, Ag, and its content distribution was 25.43%, 18.01%, 4.23%, 1161.4 g/t, 70446.1 g/t. The main phases were lead alum (lead sulfate), selenium copper silver ore, selenium silver ore, copper arsenate (light ores or emerald green arsenic copper ores, hydroxyarsenic copper ores), copper oxyhalides or oxyhydrogen halides (chlor-copper ores, oblique chlor-copper ores, para-chloro-copper ores), antimony arsenate, cassiterite, silicate minerals, etc.. The gold particle size was less than 2μm, the shape is mainly dots, and it is connected with the edge or package of the selenium copper silver mine. The silver particle size was uneven, with a maximum particle size of 20 μm and a minimum particle size of less than 5 μm. The main phases were selenium copper silver ores, selenium silver ores, sulfur copper silver ores, and silver halide.
-
Key words:
- Copper anode slime /
- Process mineralogy /
- Noble metal /
- Gold /
- Silver
-
-
表 1 铜阳极泥粒度分布
Table 1. Copper anode slime particle size distribution
粒级/mm 重量/g 分布率/% +0.045 96.20 22.20 -0.045+0.038 37.20 8.58 -0.038 300.00 69.22 合计 433.40 100.00
下载: 导出CSV
表 2 阳极泥多元素化学分析定量结果/%
Table 2. Quantitative analysis results of copper anode slime
Pb Cu Zn SiO2 S Fe As Au Ag* 25.43 18.01 0.65 0.58 7.35 0.18 0.58 1161.4 70446.1 *单位为g/t。
下载: 导出CSV
-
[1] 郑若峰, 刘川, 秦渝. 铜镍电解阳极泥中金、铂、钯的提取试验研究[J]. 黄金, 2004, 25(6):37. doi: 10.3969/j.issn.1001-1277.2004.06.011
ZHENG R F, LIU C, QIN Y. Experimental study on the extraction of gold, platinum and palladium from copper-nickel electrolytic anode mud[J]. Gold, 2004, 25(6):37. doi: 10.3969/j.issn.1001-1277.2004.06.011
[2] WANG X W, CHEN Q Y, YIN Z L, et al. Identification of arsenate antimonates in copper anode slimes[J]. Hydrometallurgy, 2006(84):211-217.
[3] 黄旺银, 苏庆平. 铜湿法冶金现状及发展趋势[J]. 安徽化工, 2011, 37(2):13-14. doi: 10.3969/j.issn.1008-553X.2011.02.004
HUANG W Y, SU Q P. The situation and development of copper hydrometallurgy[J]. Anhui Chemical, 2011, 37(2):13-14. doi: 10.3969/j.issn.1008-553X.2011.02.004
[4] ANTIPOV N I, TARASOV A V. Hydrometallurgical methods of recycling interelectrode slime[J]. Metallurgist, 2002, 46:229-233. doi: 10.1023/A:1020963316696
[5] 郭学益, 肖彩梅, 钟菊芽, 等. 铜阳极泥处理过程中贵金属的行为[J]. 中国有色金属学报, 2010, 20(5):991-998.
GUO X Y, XIAO C M, ZHONG J Y, et al. The behavior of noble metal in the treatment of copper anode slime[J]. The Chinese of Nonferrous Metals Society, 2010, 20(5):991-998.
[6] 柳青, 王吉坤. 国内主要厂家阳极泥处理工艺流程改进状况[J]. 南方金属, 2008, 2(2):25-27. doi: 10.3969/j.issn.1009-9700.2008.02.009
LIU Q, WANG J K. The improvement status of anode slime treatment process in China[J]. Southern Metals, 2008, 2(2):25-27. doi: 10.3969/j.issn.1009-9700.2008.02.009
[7] 王玮, 唐尊球, 陈晓东. 论金川集团有限公司原生铜精矿及二次铜精矿所产阳极泥处理工艺[J]. 有色冶金设计与研究, 2002, 23(3):16-20. doi: 10.3969/j.issn.1004-4345.2002.03.005
WANG W, TANG Z Q, CHEN X D. The technology of the treatment of the anode slime of the primary copper concentrate and secondary copper concentrate in Jinchuan[J]. Nonferrous Metals Engineering & Research, 2002, 23(3):16-20. doi: 10.3969/j.issn.1004-4345.2002.03.005
-
