西秦岭格尔托金矿工艺矿物学与选冶实验

,  ,

downloadPDF
文章导航 > 矿产综合利用 > 2022 > 43(4): 94-99

上一篇

下一篇

王滔, 李林积, 梁硕鹏. 西秦岭格尔托金矿工艺矿物学与选冶实验[J]. 矿产综合利用, 2022, 43(4): 94-99. doi: 10.3969/j.issn.1000-6532.2022.04.017
引用本文: 王滔, 李林积, 梁硕鹏. 西秦岭格尔托金矿工艺矿物学与选冶实验[J]. 矿产综合利用, 2022, 43(4): 94-99. doi: 10.3969/j.issn.1000-6532.2022.04.017
shu
Wang Tao, Li Linji, Liang Shuopeng. Process Mineralogy and Beneficiation-Metallurgy Test of Geertuo Gold Deposit, West Qinling[J]. Multipurpose Utilization of Mineral Resources, 2022, 43(4): 94-99. doi: 10.3969/j.issn.1000-6532.2022.04.017
Citation: Wang Tao, Li Linji, Liang Shuopeng. Process Mineralogy and Beneficiation-Metallurgy Test of Geertuo Gold Deposit, West Qinling[J]. Multipurpose Utilization of Mineral Resources, 2022, 43(4): 94-99. doi: 10.3969/j.issn.1000-6532.2022.04.017
shu

西秦岭格尔托金矿工艺矿物学与选冶实验

  • 甘肃省地质矿产勘查开发局第三地质矿产勘查院，甘肃　兰州　730050

详细信息
    作者简介: 王滔（1984-），男，硕士，工程师，从事固体矿产勘查工作。

  • 中图分类号: TD982;P618.1

Process Mineralogy and Beneficiation-Metallurgy Test of Geertuo Gold Deposit, West Qinling

  • Geological and Mineral Exploration Team No.3, Gansu Bureau of Geology and Mineral Exploration and Development, Lanzhou, Gansu, China

    摘要

  • 通过详细的野外地质调查，利用高精度矿相显微镜、图像分析仪、X射线衍射分析仪、扫描电镜等检测方法，对格尔托金矿工艺矿物学特征进行研究，结果显示：金属矿物主要为赤-褐铁矿，非金属矿物主要为方解石和石英。金主要以自然金的形式存在，含量99%以上，粒度3～20 μm，属显微金。金与载体矿物之间的嵌布关系主要有裂隙金、粒间金和包裹金。根据矿石矿物特征，选冶对比实验表明全泥氰化浸出方案是该类矿山较佳的选冶工艺。

    Through detailed field geological survey, using high-precision mineral phase microscope, image analyzer, X-ray diffraction analyzer, scanning electron microscope and other testing methods, the research on the mineralogical characteristics of the Geertuo gold deposit, the results show that the metallic minerals are mainly hematite and limonite, and the non-metallic minerals are mainly calcite and quartz. Gold mainly exists in the form of natural gold, the content is more than 99%, and the particle size is between 3 μm and 20 μm, which belongs to microscopic gold. The intercalation relationship between gold and carrier minerals mainly includes fractured gold, intergranular gold and encapsulated gold. According to the characteristics of ore and minerals, the comparison test of beneficiation and smelting shows that the all-slime cyanide leaching scheme is a better beneficiation and smelting process for this type of mine.

    • HTML全文
  • 加载中

  • 图 1  原矿X射线衍射分析

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  金矿物能谱分析结果

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  金颗粒的电子显微镜BSE照片

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  铁矿物的显微镜下照片

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  方解石与石英的显微镜下照片

    Figure 5.

    下载: 全尺寸图片 幻灯片

    表 1  原矿化学多项分析结果/%

    Table 1.  Multiple chemistry analysis results of raw ore

    Au*Ag*Cu*Pb*Zn*As*SPTFeTiO2
    3.651.4810.18.752.591560.030.0381.460.13
    SiO2Al2O3CaOMgOK2ONa2OMnO总碳LOI
    43.253.8626.490.170.170.0640.0315.8824.2
    *单位为g/t
    下载: 导出CSV

    表 2  原矿金物相分析结果

    Table 2.  Results of the phase analysis of the original ore gold

    名称连生体金自然金硫化物中金碳酸盐中金氧化铁中金硅酸盐中金合计
    含量/（g·t-1)0.0723.00.270.320.0740.0353.649
    占有率/%1.9780.847.488.692.030.96100.00
    下载: 导出CSV

    表 3  选冶方式对比结果

    Table 3.  Comparison results of beneficiation methods

    选冶方式产品名称产率/%品位/(g·t-1)浸出率/%备注
    全泥氰化浸出含金贵液--88.22
    浸渣0.4311.78
    原矿3.65100
    中性油浮选
    除碳-氰化浸出    		含金贵液84.56柴油
    碳质0.7717.63.72
    浸渣99.230.43111.72
    含金贵液79.04煤油
    碳质1.4522.79
    浸渣98.550.44311.96
    焙烧除碳-氰化浸出含金贵液83.2原矿细磨-焙烧
    烧损5.5//
    浸渣94.50.65216.8
    含金贵液88.03原矿焙烧-细磨
    烧损1.59//
    浸渣98.410.44411.97
    中性油浮选除碳-
    碳质焙烧-氰化浸出    		含金贵液67.5煤油
    碳质含金贵液19.72
    烧损0.18//
    碳质浸渣8.580.821.93
    浸渣91.240.43410.85
    下载: 导出CSV
    • 参考文献(16)
  • [1]

    梁硕鹏, 陈耀宇, 李林积, 等. 甘肃玛曲格尔托金矿床矿区地质及主矿体特征[J]. 甘肃地质, 2021, 30(1):49-56.

    LIANG S P, CHEN Y Y, LI L J, et al. Mining area geology and main orebody characteristics of the Geertuo gold deposit in Maqu County, Gansu Province[J]. Gansu Geology, 2021, 30(1):49-56.

    [2]

    李林积, 王丹, 邱鹏玉. 西秦岭格尔托金矿金的赋存状态及可选性试验研究[J]. 矿产综合利用, 2019(4):83-86. doi: 10.3969/j.issn.1000-6532.2019.04.017

    LI L J, WANG D, QIU P Y. Experimental study on occurrence and optionality of gold in Gelto gold deposit, Western Qinling[J]. Multipurpose Utilization of Mineral Resources, 2019(4):83-86. doi: 10.3969/j.issn.1000-6532.2019.04.017

    [3]

    王越, 王婧, 李潇雨, 等. 川西某金矿工艺矿物学研究及对选矿工艺的影响[J]. 矿产综合利用, 2021(4):206-210. doi: 10.3969/j.issn.1000-6532.2021.04.034

    WANG Y, WANG J, LI X Y, et al. Process mineralogy study of the gold deposit in Western Sichuan area and its influence on mineral processing technology[J]. Multipurpose Utilization of Mineral Resources, 2021(4):206-210. doi: 10.3969/j.issn.1000-6532.2021.04.034

    [4]

    王梅君, 谢洪珍. Solomon某金矿浸出工艺探索研究[J]. 矿产综合利用, 2020(2):71-74. doi: 10.3969/j.issn.1000-6532.2020.02.012

    WANG M J, XIE H Z. Study on leaching technology of a gold ore in Solomon[J]. Multipurpose Utilization of Mineral Resources, 2020(2):71-74. doi: 10.3969/j.issn.1000-6532.2020.02.012

    [5]

    魏旭, 李磊, 张青, 等. 安徽省蚌埠五河蓝天铜金矿床物质组分及赋存状态[J]. 矿产综合利用, 2021(4):188-192. doi: 10.3969/j.issn.1000-6532.2021.04.030

    WEI X, LI L, ZHANG Q, et al. Study on material composition and occurrence status of the copper-gold deposit in Lantian, Wuhe, Bengbu City, Anhui Province[J]. Multipurpose Utilization of Mineral Resources, 2021(4):188-192. doi: 10.3969/j.issn.1000-6532.2021.04.030

    [6]

    刘坤, 王婷霞, 李健民, 等. 天水某金矿工艺矿物学及选矿试验研究[J]. 矿产综合利用, 2020(5):101-104. doi: 10.3969/j.issn.1000-6532.2020.05.014

    LIU K, WANG T X, LI J M, et al. Process mineralogy and mineral processing of a gold mine in Tianshui[J]. Multipurpose Utilization of Mineral Resources, 2020(5):101-104. doi: 10.3969/j.issn.1000-6532.2020.05.014

    [7]

    李向东, 王晓伟. 大水金矿成矿地质特征及控矿因素分析[J]. 甘肃科技, 2006, 22(8): 64-67.

    LI X D, WANG X W. Ore-forming geological characteristics and ore-controlling factors analysis of Dashui gold ore deposit. Gansu Science and Technology, 2006, 22(8): 64-67.

    [8]

    闫升好, 王安建, 高兰, 等. 大水式金矿床稳定同位素、稀土元素地球化学研究. 矿床地质, 2000, 19(1): 37-45.

    YAN S H, WANG A J, GAO L, et al. Ree geochemistry and implications of stable isotopes in Dashui type gold deposits. Mineral deposits, 2000, 19(1): 37-45.

    [9]

    张国伟, 郭安林, 姚安平. 中国大陆构造中的西秦岭—松潘大陆构造结[J]. 地学前缘(中国地质大学, 北京), 2004, 11(3): 23-32.

    ZHANG G W, GUO A L, YAO A P. Western Qinling-Songpan continental tectonic node in China continental tectonics. Earth Science Frontiers(China University of Geosciences, Beijing), 2004, 11(3): 23-32.

    [10]

    卢纪英, 李作华, 张复新. 秦岭板块金矿床[M]. 西安: 陕西科学技术出版社, 2000: 306-313.

    LU J Y, LI Z H, ZHANG F X. Gold deposit in Qinling plate[M]. Xi’an: Shaanxi Science and Technology Press, 2000: 306-313.

    [11]

    姚敬劬. 关于胶体分散金[J]. 地质与勘探, 1982(8):30-33.

    YAO J Q. About colloidal dispersion gold[J]. Geology and Prospecting, 1982(8):30-33.

    [12]

    明平田, 李飞. 某微细粒蚀变岩型金矿高效浮选新工艺研究[J]. 矿产综合利用, 2019(5):127-133. doi: 10.3969/j.issn.1000-6532.2019.05.027

    MING P T, LI F. Study on a new high-efficiency flotation process for a microgranular altered rock gold mine[J]. Multipurpose Utilization of Mineral Resources, 2019(5):127-133. doi: 10.3969/j.issn.1000-6532.2019.05.027

    [13]

    张虹, 张雨田, 孙景敏, 等. 缅甸某金矿的重- 浸选矿试验研究[J]. 矿产综合利用, 2020(4):106-110. doi: 10.3969/j.issn.1000-6532.2020.04.017

    ZHANG H, ZHANG Y T, SUN J M, et al. Experimental study on a gold ore with gravity separation-cyanidationfor gravity tailings rocess[J]. Multipurpose Utilization of Mineral Resources, 2020(4):106-110. doi: 10.3969/j.issn.1000-6532.2020.04.017

    [14]

    肖坤明. 云南某低硫化物金矿可选性试验研究[J]. 矿产综合利用, 2019(2):57-59. doi: 10.3969/j.issn.1000-6532.2019.02.011

    XIAO K M. Experimental study on beneficiation of a low sulfide gold ore in Yunnan[J]. Multipurpose Utilization of Mineral Resources, 2019(2):57-59. doi: 10.3969/j.issn.1000-6532.2019.02.011

    [15]

    邓元良, 明平田, 王广伟, 等. 某金精矿焙烧氧化- 氰化尾矿工艺矿物学研究[J]. 矿产综合利用, 2020(4):121-125. doi: 10.3969/j.issn.1000-6532.2020.04.020

    DENG Y L, MING P T, WANG G W, et al. Research on process mineralogy of roasting oxidation - cyanide tailings of a gold concentrate[J]. Multipurpose Utilization of Mineral Resources, 2020(4):121-125. doi: 10.3969/j.issn.1000-6532.2020.04.020

    [16]

    王明双. 高银合质金快速提取金的工艺研究[J]. 矿产综合利用, 2021(4):150-153. doi: 10.3969/j.issn.1000-6532.2021.04.023

    WANG M S. Process study on the rapid extraction of gold from gold alloy with high silver content[J]. Multipurpose Utilization of Mineral Resources, 2021(4):150-153. doi: 10.3969/j.issn.1000-6532.2021.04.023
