Research on Basic Performance and Aging Durability of Iron Tailings Asphalt Mixture
-
摘要:
为了避免过度使用天然砂石材料做为沥青混合料的骨料以及符合绿色发展的战略方针,采用固体废弃物铁尾矿来代替砂石材料来制备一种新型的铁尾矿沥青混合料。采用质谱仪对所选用铁尾矿进行化学成分分析,并对不同铁尾矿掺量作用下沥青混合料的针入度、锥入度、软化点、延度、粘度以及老化耐久性等方面进行了研究。研究结果表明:铁尾矿沥青混合料的较佳制备温度选定为180℃;综合经济效益和有效性确定铁尾矿的较佳掺量为30%;相对老化后的铁尾矿沥青材料而言,在同一铁尾矿掺量作用下两种不同沥青混合料老化前的针入度和延度均出现了降低的趋势,但是在同一铁尾矿掺量作用下两种不同沥青混合料老化前的软化点却出现了增大的趋势。综合分析得到:温度为180℃以及铁尾矿掺量为30%制备的沥青混合料可以满足公路的路用要求。所有沥青试样的光谱变化规律基本一致,说明了掺入铁尾矿改性沥青的结构与未掺入铁尾矿沥青的结构基本一致;但是随着铁尾矿掺量的增大,沥青的FT-IR光谱在同一波数作用下却呈现出不断减小的变化趋势,说明了铁尾矿可以有效改善沥青的物理性能。
Abstract:In order to avoid excessive use of natural sand and gravel materials as aggregates of asphalt mixtures and to comply with the strategic policy of green development, solid waste iron tailings are used to replace sand and gravel materials to prepare a new type of iron tailings asphalt mixture. A mass spectrometer was used to analyze the chemical composition of the selected iron tailings. The penetration, penetration, softening point, ductility, viscosity and aging durability of asphalt mixture under different iron tailings content are studied. The research results show that the optimal preparation temperature of iron tailings asphalt mixture is selected as 180℃. Comprehensive analysis of economic benefits and effectiveness can determine the optimal content of iron tailings is 30%. Compared with the aged iron tailings asphalt material, the penetration and ductility of the two different asphalt mixtures before aging have a tendency to decrease under the same iron tailing content. However, under the effect of the same iron tailings content, the softening point of the two different asphalt mixtures before aging has a tendency to increase. Comprehensive analysis can be obtained: the asphalt mixture prepared with a temperature of 180°C and an iron tailing content of 30% can meet the road requirements of highways. The spectrum change law of all asphalt samples is basically the same. It shows that the structure of modified asphalt mixed with iron tailings is basically the same as that without iron tailings asphalt. However, with the increase of the iron tailings content, the FT-IR spectrum of the asphalt shows a decreasing trend under the same wave number. It shows that iron tailings can effectively improve the physical properties of asphalt.
-
Key words:
- Iron tailings /
- Asphalt mixture /
- Aging /
- Durability /
- Road requirements /
- FT-IR spectroscopy
-
-
表 1 尾矿内部主要成分/%
Table 1. Main components inside tailings
SiO2 Fe2O3 Al2O3 MgO 其他 69.89 15.26 8.21 2.38 4.26 表 2 筛分实验结果
Table 2. Screening test results
孔径/mm 20 10 5 2 1 0.5 0.25 0.075 剩余量/% 100 71.64 43.03 17.28 14.73 10.32 8.39 5.39 表 3 SBS改性沥青的技术指标
Table 3. Technical indicators of SBS modified asphalt
检测指标 规范要求 实验结果 针入度(25℃,100 g,5 s)/(0.1 mm) 60~80 68.0 延度(5 cm/min,5℃)/cm ≥30 38.0 软化点/℃ ≥55 74.5 密度(15℃)/(g·cm-3) - 1.03 180℃/135℃粘度/Pa·s ≤3.0 1.55 闪点 ≥230 274.0 TFOT 后残留物
( 163℃,5 h)质量变化/% ≤±1.0 -0.15 针入度比/% ≥60 74.2 延度( 5℃) /% ≥20 26.2 -
[1] 刘国威, 朱李俊, 金强, 等. 钢渣沥青混凝土研究进展[J]. 矿产综合利用, 2016(2):11-16. doi: 10.3969/j.issn.1000-6532.2016.02.002
LIU G W, ZHU L J, JIN Q, et al. Research progress of steel slag asphalt concrete[J]. Multipurpose Utilization of Mineral Resources, 2016(2):11-16. doi: 10.3969/j.issn.1000-6532.2016.02.002
[2] 王新强, 王国清, 王庆凯, 等. 高掺量胶粉改性沥青混合料动态粘弹性分析[J]. 硅酸盐通报, 2018, 37(10):3303-3309+3316. doi: 10.16552/j.cnki.issn1001-1625.2018.10.049
WANG X Q, WANG G Q, WANG Q K, et al. Dynamic viscoelastic analysis of modified asphalt mixture with high content of rubber powder[J]. The Chinese Ceramics Bulletin, 2018, 37(10):3303-3309+3316. doi: 10.16552/j.cnki.issn1001-1625.2018.10.049
[3] 冯振刚, 孙安石, 张东阳, 等. 废橡胶裂解炭黑改性沥青混合料的黏弹特性研究[J]. 郑州大学学报(工学版), 2018, 39(1):7-11. doi: 10.13705/j.issn.1671-6833.2018.01.013
FENG Z G, SUN A S, ZHANG D Y, et al. Study on viscoelastic properties of modified asphalt mixture with pyrolysis carbon black from waste rubber[J]. Journal of Zhengzhou University(Engineering Edition), 2018, 39(1):7-11. doi: 10.13705/j.issn.1671-6833.2018.01.013
[4] 陈磊磊, 钱振东. 基于简单性能实验的环氧沥青混合料动态模量研究[J]. 建筑材料学报, 2013, 16(2):341-344. doi: 10.3969/j.issn.1007-9629.2013.02.029
CHEN L L, QIAN Z D. Research on dynamic modulus of epoxy asphalt mixture based on simple performance test[J]. Journal of Building Materials, 2013, 16(2):341-344. doi: 10.3969/j.issn.1007-9629.2013.02.029
[5] 胡超, 包惠明, 迟恩涛, 等. 高岭土尾矿沥青混合料抗腐性能实验与机理研究[J]. 矿产综合利用, 2020(5):161-168. doi: 10.3969/j.issn.1000-6532.2020.05.026
HU C, BAO H M, CHI E T, et al. Anti-corrosion performance test and mechanism study of kaolin tailings asphalt mixture[J]. Multipurpose Utilization of Mineral Resources, 2020(5):161-168. doi: 10.3969/j.issn.1000-6532.2020.05.026
[6] 时正武. 辽宁朝阳地区铁尾矿砂路面典型结构的研究[D]. 大连: 大连理工大学, 2013.
SHI Z W. Research on the typical structure of iron tailing sand pavement in Chaoyang area, Liaoning [D]. Dalian: Dalian University of Technology, 2013.
[7] 陈静云, 王维营, 孙依人, 等. 基于BBR与FT-IR的沥青胶结料低温性能与抗老化能力分析[J]. 中外公路, 2019, 39(1):200-205. doi: 10.14048/j.issn.1671-2579.2019.01.041
CHEN J Y, WANG W Y, SUN Y R, et al. Analysis of low temperature performance and anti-aging ability of asphalt binder based on BBR and FT-IR[J]. China and Foreign Highways, 2019, 39(1):200-205. doi: 10.14048/j.issn.1671-2579.2019.01.041
[8] 王逸波, 焦彬如. 耐紫外线老化改性沥青材料的制备与性能研究[J]. 功能材料, 2021, 52(3):3140-3144. doi: 10.3969/j.issn.1001-9731.2021.03.021
WANG Y B, JIAO B R. Preparation and performance of modified asphalt materials resistant to ultraviolet aging[J]. Functional Materials, 2021, 52(3):3140-3144. doi: 10.3969/j.issn.1001-9731.2021.03.021
-
