Application Research of High-intensity mixing Technology and Equipment in a Concentrator of Jiama, Tibet
-
摘要:
针对传统轴流型调浆搅拌槽剪切能力不足，西藏甲玛某选矿厂采用了强化调浆技术及设备（调浆改质机），使矿浆中矿物颗粒与浮选药剂充分接触并混合。实验室对比实验可知，适当地提高浮选前搅拌调浆的转速及适当地延长浮选前搅拌调浆的时间，可在一定范围内提高浮选回收率。生产指标对比表明，在两个系列处理相同矿石，同时保持相同浓度、细度、药剂制度及流程的情况下，使用该设备的系列Cu、Au、Ag、Mo回收率比不使用的系列分别高0.53%、3.92%、1.04%及6.25%。该设备强化了叶轮剪切作用，增加了药剂与矿物颗粒的碰撞机会，充分发挥了药剂效果，在一定程度上提高了选矿指标。
Abstract:In order to solve the shortage of shear capacity of the conventional axial-flow agitator, a concentrator of Jiama in Tibet has adopted a new type of high-intensity mixing technology and equipment. The mineral particles in the pulp and flotation agents can be fully contacted and mixed. The laboratory comparison test shows that appropriately increasing the speed of stirring and adjusting slurry before flotation and appropriately extending the time of stirring and adjusting slurry before flotation can increase the flotation recovery rate within a certain range. The comparison of production indexes shows that the recovery rates of Cu, Au, Ag and Mo with the equipment are 0.53%, 3.92%, 1.04% and 6.25% higher than those without the equipment when the two series treat the same ore with the same concentration, fineness, reagents system and process. The equipment strengthens the shearing effect of impeller, increases the chance of collision between reagents and mineral particles, gives full play to the effect of reagents and improves the beneficiation index.
-
-
表 1 调浆改质机及传统轴流型搅拌槽参数对比
Table 1. Parameter comparison of ore pulp refiner and conventional axial-flow agitator
型号参数 调浆改质机KGJ2.5/750 传统轴流型搅拌桶 筒体直径/mm 2500 2000 有效容积/m³ 13 2.5 叶轮直径/mm 1200 1000 电机功率/kw 75 7.5 外形尺寸/mm 2883×2674×4649 2000×2000 转速/(r·min-1) 150 120 矿浆停留时间/min 约2.5 约0.5
下载: 导出CSV
表 2 工业实验选矿指标对比
Table 2. Comparison of ore dressing indexes in industrial test
系列 产品名称 产率/% 品位/% 回收率/% Cu Au* Ag* Mo Cu Au Ag Mo 一系列 混合精矿 4.22 19.69 7.08 409.00 0.34 91.26 90.49 64.78 71.70 尾矿 95.78 0.08 0.03 9.79 0.01 8.74 9.51 35.22 28.30 原矿 100.00 0.91 0.33 26.63 0.02 100.00 100.00 100.00 100.00 二系列 混合精矿 4.31 18.68 5.74 395.00 0.31 89.37 74.89 61.87 46.03 尾矿 95.69 0.10 0.09 10.95 0.02 10.63 25.11 38.13 53.97 原矿 100.00 0.90 0.33 27.49 0.03 100.00 100.00 100.00 100.00 *单位为g/t。
下载: 导出CSV
-
[1] 周胜, 李茂林, 崔瑞, 等. 物料性质对搅拌混合影响的数值模拟研究[J]. 矿产综合利用, 2020(1):177-183. ZHOU S, LI M L, CUI R, et al. Numerical simulation of the effect of material properties on mixing[J]. Multipurpose Utilization of Mineral Resources, 2020(1):177-183. doi: 10.3969/j.issn.1000-6532.2020.01.036
[2] 张福亚. 矿浆预处理设备的应用进展[J]. 金属矿山, 2019(1):1-6. ZHANG F Y. Application and development of pulp pre-processing equipment[J]. Metal Mine, 2019(1):1-6. doi: 10.19614/j.cnki.jsks.201901001
[3] 程万里, 邓政斌, 刘志红, 等. 煤泥浮选中矿物颗粒间相互作用力的研究进展[J]. 矿产综合利用, 2020(3):48-55. CHENG W L, DENG Z B, LIU Z H, et al. Research progress of interaction force between mineral particles in coal slurry flotation[J]. Multipurpose Utilization of Mineral Resources, 2020(3):48-55. doi: 10.3969/j.issn.1000-6532.2020.03.008
[4] 马力强, 孙先凤, 黄根, 等. 煤泥调浆机理与设备发展历程及应用[J]. 洁净煤技术, 2018, 24(1):1-5. MA L Q, SUN X F, HUANG G, et al. Mechanism of coal slime conditioning and equipment development history and industrial application[J]. Clean Coal Technology, 2018, 24(1):1-5. doi: 10.13226/j.issn.1006-6772.2018.01.001
[5] 谢国龙, 雷同, 郭小慧, 等. M-COL2100型表面改质机在司马煤业有限公司选煤厂的应用[J]. 选煤技术, 2008(5):39-40. XIE G L, LEI T, GUO X H, et al. Application of M-COL2100 surface modification machine in Sima coal preparation plant[J]. Coal Preparation Technology, 2008(5):39-40. doi: 10.3969/j.issn.1001-3571.2008.05.014
[6] 李振, 刘炯天, 闫小康, 等. 浮选过程中搅拌调浆特性研究[J]. 中国矿业大学学报, 2011, 40(1):133-139. LI Z, LIU J T, YAN X K, et al. Research on the characteristics of stirred pulp-mixing in the flotation process[J]. Journal of China University of Mining & Technology, 2011, 40(1):133-139.
[7] 冯博, 冯其明, 卢毅屏. 强搅拌调浆在金川硫化铜镍矿浮选中的作用机理研究[J]. 稀有金属, 2014(5):861-867. FENG B, FENG Q M, LU Y P. The effect and mechanism of high intensity conditioning on the flotation of Jinchuan nickel sulphide ore[J]. Chinese Journal of Rare Metals, 2014(5):861-867.
[8] 董英择, 卢毅屏, 马忠鑫, 等. 调浆强度对磁黄铁矿表面组分的影响[J]. 中南大学学报(自然科学版), 2017, 48(2):277-281. DONG Y Z, LU Y P, MA Z X, et al. Effect of mixing intensity on surface components of pyrrhotite[J]. Journal of Central South University (Science and Technology), 2017, 48(2):277-281.
[9] 冯程, 卢毅屏, 冯其明, 等. 强搅拌调浆对硫化镍矿浮选的作用[J]. 中南大学学报(自然科学版), 2016, 47(11):3621-3626. FENG C, LU Y P, FENG Q M, et al. Effect of high intensity conditioning on flotation of nickel sulfide mineral[J]. Journal of Central South University (Science and Technology), 2016, 47(11):3621-3626.
[10] 袁喜振, 苏敏, 邓林欣, 等. 谦比希铜矿的选矿指标优化实验[J]. 矿产综合利用, 2021(6):185-189. YUAN X Z, SU M, DENG L X, et al. Optimization test of beneficiation index of Chambishi Copper Mine[J]. Multipurpose Utilization of Mineral Resources, 2021(6):185-189. doi: 10.3969/j.issn.1000-6532.2021.06.032
-
