广西某低品位金矿氰化浸出助浸剂实验研究

,  ,  ,  ,  ,

文章导航 > 矿产综合利用 > 2023 > 44(2): 63-69

上一篇

下一篇

苑林松, 代淑娟, 苏馨, 余鑫, 岳翔, 刘春琦. 广西某低品位金矿氰化浸出助浸剂实验研究[J]. 矿产综合利用, 2023, 44(2): 63-69. doi: 10.3969/j.issn.1000-6532.2023.02.012
引用本文: 苑林松, 代淑娟, 苏馨, 余鑫, 岳翔, 刘春琦. 广西某低品位金矿氰化浸出助浸剂实验研究[J]. 矿产综合利用, 2023, 44(2): 63-69. doi: 10.3969/j.issn.1000-6532.2023.02.012
shu
Yuan Linsong, Dai Shujuan, Su Xin, Yu Xin, Yue Xiang, Liu Chunqi. Experimental Study on Cyanidation Leaching of a Low-grade Gold Mine in Guangxi[J]. Multipurpose Utilization of Mineral Resources, 2023, 44(2): 63-69. doi: 10.3969/j.issn.1000-6532.2023.02.012
Citation: Yuan Linsong, Dai Shujuan, Su Xin, Yu Xin, Yue Xiang, Liu Chunqi. Experimental Study on Cyanidation Leaching of a Low-grade Gold Mine in Guangxi[J]. Multipurpose Utilization of Mineral Resources, 2023, 44(2): 63-69. doi: 10.3969/j.issn.1000-6532.2023.02.012
shu

广西某低品位金矿氰化浸出助浸剂实验研究

  • 1.

    辽宁科技大学矿业工程学院，辽宁　鞍山　114051

  • 2.

    攀钢集团矿业有限公司设计研究院，四川　攀枝花　617036

  • 基金项目: 国家自然科学基金（51574146）
详细信息
    作者简介: 苑林松（1997-），男，硕士，研究方向为硫化矿浮选
    通讯作者: 代淑娟（1967-），女，博士，教授，研究方向为难处理金选冶及菱镁矿选矿研究

  • 中图分类号: TD952

Experimental Study on Cyanidation Leaching of a Low-grade Gold Mine in Guangxi

  • 1.

    School of Mining Engineering, University of Science and Technology Liaoning, Anshan, Liaoning, China

  • 2.

    Design and Research Institute of Pangang Group Mining Co. Ltd., Panzhihua, Sichuan, China

More Information

    摘要

  • 广西某低品位金矿石含金量为1.29 g/t，脉石矿物以石英为主，有色金属铜、铅、锌等及有害元素砷的含量极低。对该矿石进行氰化浸金实验研究，分别考查磨矿细度、溶液pH值、氰化物用量、搅拌转速、浸出时间对金浸出效果的影响；通过单矿物氰化助浸实验，确定多种助浸效果较好的助浸剂，并按同一比例混合，获得了三种新型助浸剂A、B、C；针对广西某低品位金矿石，进行氰化浸出助浸实验。结果表明，矿样细度-0.074 mm 93.27%，溶液pH值为10.5，氰化钾用量为4 kg/t，搅拌转速为1500 r/min，浸出时间为24 h的实验条件下，金的浸出率为92.58%；而氰化钾用量减少至3 kg/t，其余条件不变的情况下，加入新型助浸剂A浸出18 h后，金的浸出率可达93%。新型助浸剂的加入有效地提高了金的浸出率，同时将氰化物的损耗降低了25%，浸出时间缩短了6 h以上。

    Gold content of a low-grade gold ore in Guangxi is 1.29 g/t, the gangue minerals are mainly quartz, and the content of non-ferrous metals such as copper, lead, zinc and other harmful elements arsenic is extremely low. The cyanide gold leaching test was carried out on the ore, and the effects of grinding fineness, pH value of solution, cyanide dosage, stirring speed and leaching time on the gold leaching effect were investigated respectively; The leaching aids with better leaching effect were mixed in the same proportion, and three new leaching aids A, B and C were obtained; for a low-grade gold ore in Guangxi, a cyanide leaching aid leaching test was carried out. The results show that the sample fineness of -0.074 mm accounts for 93.27%, the pH value of the solution is 10.5, the dosage of potassium cyanide is 4 kg/t, the stirring speed is 1500 r/min, and the leaching time is 24 h, the gold leaching rate is 24 h. 92.58%; the amount of potassium cyanide was reduced to 3 kg/t, and the other conditions remained unchanged, after adding the new leaching aid A for 18 h, the leaching rate of gold could reach more than 93%. The addition of the new leaching aid effectively improves the leaching rate of gold, reduces the loss of cyanide by 25%, and shortens the leaching time by more than 6 h.

    • HTML全文
  • 加载中

  • 图 1  磨矿细度对金的浸出率的影响

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  溶液pH值对金的浸出率的影响

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  氰化钾用量对金的浸出率的影响

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  搅拌转速对金的浸出率的影响

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  浸出时间对金的浸出率的影响

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  过氧化氢和柠檬酸三钠助浸氰化浸出效果

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  EDTA-4Na和氯化羟胺助浸氰化浸出效果

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  EDTA-4Na和硝酸铅助浸氰化浸出效果

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  助浸剂A、B、C对金的浸出率的影响

    Figure 9.

    下载: 全尺寸图片 幻灯片

    图 10  助浸剂助浸氰化浸金后的红外光谱

    Figure 10.

    下载: 全尺寸图片 幻灯片

    表 1  广西某金矿石X射线荧光光谱分析/%

    Table 1.  X-ray fluorescence spectrum analysis of a gold ore in Guangxi

    Na2OMgOAl2O3SiO2P2O5SO3K2OCaOTiO2Cr2O3Fe2O3CuOAs2O3BaOAgPbO
    0.0320.1756.92690.130.0270.1180.8150.1330.0990.0111.4520.0060.0020.0210.0030.012
    下载: 导出CSV

    表 2  广西某金矿石化学多元素分析/%

    Table 2.  Multi-element analysis of petrochemistry of a gold mine in Guangxi

    Au/(g·t-1)ZnTFeMgOAl2O3CaOSSiO2
    1.290.0051.2210.1646.8970.0950.09291.051
    下载: 导出CSV

    表 3  助浸剂氰化浸出实验结果

    Table 3.  Cyanide leaching test results of leaching aid

    药剂种类氧化型氨类有机型重金属
    H2O2KMnO4KCrO7ADPHHASTCEDTA-4NaSucPb(NO3)2
    浸出率/%92.584.551.884.599.396.799.599.594.399.6
    下载: 导出CSV

    表 4  两种助浸剂混合助浸实验结果

    Table 4.  Results of two leaching aids mixed with leaching aids

    助浸剂组合①+②①+③①+④①+⑤②+③②+④②+⑤③+④③+⑤④+⑤
    浸出率/%91.8492.6177.7891.7782.8298.2980.8991.1581.1499.34
    下载: 导出CSV
    • 参考文献(8)
  • [1]

    申大志, 庄荣传, 谢洪珍. 强化氰化浸金技术进展[J]. 矿产综合利用, 2014(2):15-19. SHEN D Z, ZHUANG R C, XIE H Z. Research and application of intensifying cyanide leaching for gold[J]. Multipurpose Utilization of Mineral Resources, 2014(2):15-19.

    [2]

    张兴仁. 强化氰化工艺, 提高浸金效果[J]. 矿产综合利用, 1994(6):35-41. ZHANG X R. Strengthen the cyanidation process to improve the effect of gold leaching[J]. Multipurpose Utilization of Mineral Resources, 1994(6):35-41.

    [3]

    雷占昌, 韩斯琴图, 蒋常菊. 酸浸预处理提高金矿焙烧烟尘中金浸出率的研究[J]. 矿冶工程, 2019, 39(3):107-109. LEI Z C, HANSI Q T, JIANG C J. Pretreatment of acid leaching for increasing the leaching rate of gold from refractory gold ore roasting dust[J]. Mining and Metallurgical Engineering, 2019, 39(3):107-109.

    [4]

    梁晓, 胡瑞彪, 冯泽平. 广东某复杂难选难浸金矿工艺矿物学[J]. 矿产综合利用, 2019(6):65-68. LIANG X, HU R B, FENG Z P. Study on the technological mineralogy of a complex refractory gold ore in Guangdong[J]. Multipurpose Utilization of Mineral Resources, 2019(6):65-68. doi: 10.3969/j.issn.1000-6532.2019.06.014

    [5]

    李敦钫. 氨水对浸金氰化液离子平衡影响分析[J]. 昆明理工大学学报, 2001, 26(2):12-15. LI D F. Analysis of influence of aammonia on ionic equilibrium in cyanide solution[J]. Journal of Kunming University of Science and Technology, 2001, 26(2):12-15.

    [6]

    王梅君, 谢洪珍. Solomon某金矿浸出工艺探索研究[J]. 矿产综合利用, 2020(2):71-74. WANG M J, XIE H Z. Study on leaching technology of a gold ore in Solomon[J]. Multipurpose Utilization of Mineral Resources, 2020(2):71-74.

    [7]

    邓元良, 明平田, 王广伟, 等. 某金精矿焙烧氧化-氰化尾矿工艺矿物学研究[J]. 矿产综合利用, 2020(4):121-125. DENG Y L, MING P T, WANG G W, et al. Research on process mineralogy of roasting oxidation - cyanide tailings of a gold concentrate[J]. Multipurpose Utilization of Mineral Resources, 2020(4):121-125. doi: 10.3969/j.issn.1000-6532.2020.04.020

    [8]

    李大江, 郭持皓, 袁朝新, 等. 氰化尾渣浮选精矿焙砂提金工艺研究[J]. 矿产综合利用, 2019(5):107-110. LI D J, GUO C H, YUAN C X, et al. Study on gold recover from cyanide tailings floatation sulfur concentrate roasting residue[J]. Multipurpose Utilization of Mineral Resources, 2019(5):107-110.
