辽西钒钛磁铁矿氧化球团制备实验

韩通; 肖顺鑫; 程功金; 杨合; 薛向欣

doi:10.3969/j.issn.1000-6532.2023.03.002

辽西钒钛磁铁矿氧化球团制备实验

东北大学冶金学院，辽宁　沈阳　110819

基金项目: 国家自然科学基金辽宁联合基金项目（U1908226）；国家自然科学基金青年基金项（21908020）

详细信息

作者简介: 韩通（1995-），男，硕士研究生，从事炼铁工艺研究

通讯作者: 薛向欣（1954-），男，博士，教授，研究方向为钢铁冶炼。

中图分类号: TD981

收稿日期: 2021-06-22

刊出日期: 2023-06-25

Preparation of Vanadium Titano-Magnetite Oxide Pellets from Western Liaoning Province

School of Metallurgy, Northeastern University, Shenyang, Liaoning, China

More Information

Corresponding author: Xue Xiangxin, xuexx@mail.neu.edu.cn

Received Date: 22 June 2021

Publish Date: 25 June 2023

摘要

摘要:
这是一篇冶金工程领域的论文。以辽西钒钛磁铁精矿为原料制备球团，研究球团的预热特性和焙烧特性。结果表明，在900 ℃下预热15 min，预热球强度可达819 N；在较佳预热制度下，1100 ℃焙烧15 min，焙烧球强度达到了3020 N。该球团不难氧化，在900 ℃、15 min下，其氧化度达97%，且温度对氧化度的影响强于时间。随预氧化温度的提高，球团物相由磁铁矿和钛铁矿最终转变为赤铁矿和铁板钛矿。随着焙烧温度的提高，球团内晶体不断长大，气孔减少，结构更致密。
- 冶金工程 /
- 钒钛磁铁矿 /
- 氧化球团 /
- 预热 /
- 焙烧 /
- 抗压强度
Abstract:
This is a paper in the field of metallurgical engineering. Pellets were prepared from vanadium and titanium magnetite concentrates from Liaoxi, and the preheating characteristics and roasting characteristics of the pellets were studied. Results show that the strength of preheating ball can reach 819 N when preheating for 15 min at 900℃, and the strength of the ball reached 3020 N at 1100℃ for 15 min under the optimum preheating system. The oxidation degree of the pellet is 97% at 900℃ for 15 min, and the temperature has a stronger influence on the oxidation degree than time.With the increase of oxidation temperature, with the increase of preoxidation temperature, magnetite in the pellets changes into hematite and ilmenite into ferrobrookite. With the increase of calcination temperature, the crystal in pellet grows up, the porosity decreases and the structure becomes denser.
- Metallurgical engineering /
- Vanadium titano-magnetite /
- Oxidized pellets /
- Preheat /
- Roasting /
- Compressive strength

HTML全文

图 1 钒钛磁铁精矿XRD

Figure 1.

下载: 全尺寸图片幻灯片

图 2 预热温度与预热球强度的关系

Figure 2.

下载: 全尺寸图片幻灯片

图 3 预热时间与预热球强度的关系

Figure 3.

下载: 全尺寸图片幻灯片

图 4 预热球团的微观结构

Figure 4.

下载: 全尺寸图片幻灯片

图 5 焙烧温度与焙烧球强度的关系

Figure 5.

下载: 全尺寸图片幻灯片

图 6 焙烧时间与焙烧球强度的关系

Figure 6.

下载: 全尺寸图片幻灯片

图 7 预热温度和时间对球团氧化度的影响

Figure 7.

下载: 全尺寸图片幻灯片

图 8 不同氧化温度下球团的XRD

Figure 8.

下载: 全尺寸图片幻灯片

图 9 不同焙烧温度下球团的微观结构

Figure 9.

下载: 全尺寸图片幻灯片

图 10 不同焙烧时间下球团的矿相组成

Figure 10.

下载: 全尺寸图片幻灯片

表 1 钒钛磁铁矿的主要化学成分/%

Table 1. Chemical compositions of raw materials

TFe V FeO MgO CaO SiO₂ Al₂O₃ TiO₂

43.62 0.97 17.58 0.57 4.17 7.19 1.87 21.92

下载: 导出CSV

表 2 膨润土的主要化学成分/%

Table 2. Chemical composition of binder

SiO₂ CaO MgO Al₂O K₂O Na₂O

44.88 4.08 2.88 12.88 1.03 4.18

下载: 导出CSV

参考文献(10)

[1]	陈露露. 我国钒钛磁铁矿资源利用现状[J]. 中国资源综合利用, 2015, 33(10):31-33. CHEN L L. Current status of vanadium-titanium magnetite resource utilization in China[J]. China Resource Utilization, 2015, 33(10):31-33. doi: 10.3969/j.issn.1008-9500.2015.10.014 CHEN L L. Current status of vanadium-titanium magnetite resource utilization in China[J]. China Resource Utilization, 2015, 33(10): 31-33. doi: 10.3969/j.issn.1008-9500.2015.10.014
[2]	李大成, 纪安, 扈玫珑. 钒钛磁铁矿提钒新工艺研究[J]. 重庆大学学报, 2018, 41(10):45-52. LI D C, JI A, HU M L. Research on new process of vanadium extraction from vanadium-titanium magnetite[J]. Journal of Chongqing University, 2018, 41(10):45-52. doi: 10.11835/j.issn.1000-582X.2018.10.005 LI D C, JI A, HU M L. Research on new process of vanadium extraction from vanadium-titanium magnetite[J]. Journal of Chongqing University, 2018, 41(10): 45-52. doi: 10.11835/j.issn.1000-582X.2018.10.005
[3]	陈福林, 杨晓军, 蔡先炎, 等. 攀西地区白马辉长岩型超低品位钒钛磁铁矿选铁试验研究[J]. 矿产综合利用, 2020(6):26-30. CHEN F L, YANG X J, CAI X Y, et al. Experimental Study on Iron Separation of Baima Gabbro-type Ultra-low-grade Vanadium-Titanomagnetite in Panxi Area[J]. Multipurpose Utilization of Mineral Resources, 2020(6):26-30. doi: 10.3969/j.issn.1000-6532.2020.06.005 CHEN F L, YANG X J, CAI X Y, et al. Experimental Study on Iron Separation of Baima Gabbro-type Ultra-low-grade Vanadium-Titanomagnetite in Panxi Area[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 26-30. doi: 10.3969/j.issn.1000-6532.2020.06.005
[4]	印万忠, 徐东, 杨耀辉, 等. 承德某钒钛磁铁矿尾矿资源化利用技术研究[J]. 矿产综合利用, 2020(6):37-42. YIN W Z, XU D, YANG Y H, et al. Research on the recycling technology for a vanadium-titanium magnetite tailings in Chengde[J]. Multipurpose Utilization of Mineral Resources, 2020(6):37-42. doi: 10.3969/j.issn.1000-6532.2020.06.007 YIN W Z, XU D, YANG Y H, et al. Research on the recycling technology for a vanadium-titanium magnetite tailings in Chengde[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 37-42. doi: 10.3969/j.issn.1000-6532.2020.06.007
[5]	严伟平, 曾小波. 攀西地区钒钛磁铁矿资源开发利用水平评估方法研究[J]. 矿产综合利用, 2020(6):79-83. YAN W P, ZENG X B. Study on the evaluation method of development and utilization level of vanadium-titanium magnetite mine in Panxi district[J]. Multipurpose Utilization of Mineral Resources, 2020(6):79-83. YAN W P, ZENG X B. Study on the evaluation method of development and utilization level of vanadium-titanium magnetite mine in Panxi district[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 79-83.
[6]	李潇雨, 朱志敏, 周家云, 等. 钒钛磁铁矿尾矿资源调查取样方法比较——以红格尾矿库为例[J]. 矿产综合利用, 2020(6):96-99. LI X Y, ZHU Z M, ZHOU J Y, et al. Comparison of sampling methods for investigation of vanadium-titanium magnetite tailings resources - taking Hongge tailings pond as an example[J]. Multipurpose Utilization of Mineral Resources, 2020(6):96-99. LI X Y, ZHU Z M, ZHOU J Y, et al. Comparison of sampling methods for investigation of vanadium-titanium magnetite tailings resources -- taking Hongge tailings pond as an example[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 96-99.
[7]	陈许玲, 黄云松, 范晓慧, 等. 钒钛磁铁矿球团氧化焙烧行为和固结特性[J]. 中南大学学报(自然科学版), 2016, 47(2):359-366. CHEN X L, HUANG Y S, FAN X H, et al. Oxidation roasting behavior and consolidation characteristics of vanadium-titanium magnetite pellets[J]. Journal of Central South University (Natural Science Edition), 2016, 47(2):359-366. CHEN X L, HUANG Y S, FAN X H, et al. Oxidation roasting behavior and consolidation characteristics of vanadium-titanium magnetite pellets[J]. Journal of Central South University (Natural Science Edition), 2016, 47(2): 359-366.
[8]	蒙飞宇, 黄帮福. 钒钛磁铁矿氧化球团固结性能强化研究[J]. 烧结球团, 2020, 45(5):49-53. MENG F Y, HUANG B F. Enhanced consolidation performance of vanadium-titanium magnetite oxide pellets[J]. Sintered pellets, 2020, 45(5):49-53. MENG F Y, HUANG B F. Enhanced consolidation performance of vanadium-titanium magnetite oxide pellets[J]. Sintered pellets, 2020, 45(5): 49-53.
[9]	陈双印, 储满生, 唐珏, 等. 预氧化对钒钛磁铁矿球团矿相及内部结构的影响[J]. 东北大学学报(自然科学版), 2013, 34(4):536-541. CHEN S Y, CHU M S, TANG Y, et al. Effect of pre-oxidation on the phase and internal structure of vanadium-titanium magnetite pellets[J]. Journal of Northeastern University (Natural Science Edition), 2013, 34(4):536-541. CHEN S Y, CHU M S, TANG Y, et al. Effect of pre-oxidation on the phase and internal structure of vanadium-titanium magnetite pellets[J]. Journal of Northeastern University (Natural Science Edition), 2013, 34(4): 536-541.
[10]	许承宝, 张一敏, 刘涛, 等. 辽西某钒钛磁铁矿工艺矿物学研究[J]. 有色金属(选矿部分), 2018(3):1-5. XU C B, ZHANG Y M, LIU T, et al. Process mineralogy study of a vanadium-titanium magnetite in western Liaoning[J]. Nonferrous Metals (Mineral Processing Section), 2018(3):1-5. XU C B, ZHANG Y M, LIU T, et al. Process mineralogy study of a vanadium-titanium magnetite in western Liaoning[J]. Nonferrous Metals (Mineral Processing Section), 2018(3): 1-5.
