Acid Production Potential of Lead-zinc Waste Rocks and Analysis of Heavy Metal Eluviating at Simulated Strong Acid Rain Environment
-
摘要:
这是一篇矿山生态修复领域的论文。矿山开发过程中不可避免产生大量废石，废石中重金属元素在风化、淋溶等作用下释放，将对矿区周边水土环境质量产生影响。为了研究某铅锌矿废石重金属元素淋溶规律，分析了该废石的化学组成和产酸潜力。模拟强酸雨环境下，分析了废石中重金属元素溶出率及淋溶前后废石的矿物组成。结果表明：该废石中重金属Cu、Pb、Zn、Cd、As元素无独立矿物，在废石中分散赋存；废石酸中和能力较高，净产酸量NAG为0 kg H2SO4/t，无产酸潜力。在模拟强酸雨淋溶实验中，淋出液pH值均呈弱碱性，这与废石含较多的碱性矿物有关，废石具有一定的酸缓冲能力；第1轮淋溶过程Cu、Pb、Zn、Cd、As元素随淋溶时间延长累积溶出率逐渐升高；第2轮淋溶2周期后Cu、Pb、Zn、Cd元素累积溶出率趋于稳定，后续基本不溶出；As元素累积溶出率随淋溶时间延长而升高；总体而言，废石中重金属溶出率低。废石淋溶前后矿物成分不变，矿物含量略有变化。本文可为矿山废石堆场管理及其周边重金属污染防治提供依据。
Abstract:This is an article in the field of ecological restoration of mines. A large amount of waste rock is inevitably produced in the process of mine development, and the release of heavy metal elements in the waste rock at the effect of weathering and eluviating will pose a threat to the water-and-soil quality around the mining area. In order to study the eluviating rule of heavy metal elements in lead-zinc waste rocks, the chemical composition and acid production potential of the waste rocks were analyzed. The leaching rates of heavy metal elements in the waste rocks and their mineral composition before and after eluviating were analyzed at simulated strong acid rain environment. The results showed that heavy metals elements of Cu, Pb, Zn, Cd, A sin the waste rocks had no independent minerals and were dispersed. The waste rocks had an ability of high acid neutralization, whose NAG was 0, with no acid production potential. In the eluviating tests at simulated strong acid rain environment, the pH values of leached solution were weakly alkaline, which was related to the waste rocks containing more alkaline minerals, and the waste rocks had a certain acid buffer capacity. The cumulative leaching rates of Cu, Pb, Zn, Cd and As increased with the leaching time in the first round. After the second round, the cumulative leaching rates of Cu, Pb, Zn and Cd tended to be stable, with almost nothing dissolved in the subsequent cycles. The cumulative leaching rates of As increased with the leaching time. In general, the leaching rates of heavy metals in the waste rocks were low. The mineral composition of the waste rocks was stable before and after leaching, and the mineral contents changed slightly. This article can provide a basis for the management of mine waste-rock dumps and the prevention and control of heavy metal pollution around them.
-
-
表 1 废石中重金属元素结果/（mg/kg）
Table 1. Results of heavy metal elements in waste rocks
名称 Cu Pb Zn Cr Ni Cd As Hg 废石中的含量 470 620 1 200 87 73 6 120 0.079 农用地土壤污染风险筛选值 50 100 200 250 70 0.4 30 0.5 宜春土壤背景值[24] 22.14 33.01 71.3 58.08 21.43 0.11 11.67 0.1
下载: 导出CSV
表 2 淋溶前后废石矿物成分检测结果/%
Table 2. Results of waste rocks mineral composition before and after eluviating test
矿物名称 废石 废石淋溶渣 石英 50～55 50～55 白云母 20～25 20～25 白云石 8～10 8～10 菱铁矿 6～8 4～6 斜长石 4～6 5～7 高岭石 1 3 黄铁矿 1 1
下载: 导出CSV
-
[1] 刘晓, 张宇, 王楠, 等. 我国铅锌矿资源现状及其发展对策研究[J]. 中国矿业, 2015(增刊1):6-9.LIU X, ZHANG Y, WANG N, et al. Pb-Zn metalresources situation and suggestion for Pb-Zn metals industry development in China[J]. China Mining Magazine, 2015(S1):6-9. doi: 10.3969/j.issn.1004-4051.2015.z1.002
LIU X, ZHANG Y, WANG N, et al. Pb-Zn metalresources situation and suggestion for Pb-Zn metals industry development in China[J]. China Mining Magazine, 2015(S1):6-9. doi: 10.3969/j.issn.1004-4051.2015.z1.002
[2] 蓝卓越, 高天锐, 吕晋芳, 等. 矿山废石对环境的污染及其综合利用研究现状[J]. 矿产保护与利用, 2021, 41(3):126-131.LAN Z Y, GAO T R, LYU J F, et al. Research status of environmental pollution and comprehensive utilization of mine waste rocks[J]. Conservation and Utilization of Mineral Resources, 2021, 41(3):126-131.
LAN Z Y, GAO T R, LYU J F, et al. Research status of environmental pollution and comprehensive utilization of mine waste rocks[J]. Conservation and Utilization of Mineral Resources, 2021, 41(3):126-131.
[3] 徐争启, 倪师军, 滕彦国, 等. 矿业活动固体废弃物中重金属元素释放机理的浸出实验[J]. 地质通报, 2012, 31(1):101-107.XU Z Q, NI S J, TENG Y G, et al. Researchon releasing of heavy metals in solid wastes from mining activity[J]. Geological Bulletin of China, 2012, 31(1):101-107. doi: 10.3969/j.issn.1671-2552.2012.01.012
XU Z Q, NI S J, TENG Y G, et al. Researchon releasing of heavy metals in solid wastes from mining activity[J]. Geological Bulletin of China, 2012, 31(1):101-107. doi: 10.3969/j.issn.1671-2552.2012.01.012
[4] LI L, ZHU L. International development trend analysis for patented technology of the soil heavy metal pollution and remediation[J]. Science Focus, 2016, 11(2):25-32.
[5] 秦燕, 徐晓春, 谢巧勤, 等. 铜矿采矿废石重金属环境污染的淋溶实验研究-以安徽铜陵凤凰山矿田药园山铜矿床为例[J]. 地球学报, 2008, 29(2):247-252.QIN Y, XU X C, XIE Q Q, et al. Leaching experiments of environmental pollution caused by heavy metals of waste rocks in the copper mine: a case study of the Yaoyuanshan ore deposit in the Fenghuangshan copper ore field, Tongling, Anhui, China[J]. Acta Geoscientica Sinica, 2008, 29(2):247-252. doi: 10.3321/j.issn:1006-3021.2008.02.017
QIN Y, XU X C, XIE Q Q, et al. Leaching experiments of environmental pollution caused by heavy metals of waste rocks in the copper mine: a case study of the Yaoyuanshan ore deposit in the Fenghuangshan copper ore field, Tongling, Anhui, China[J]. Acta Geoscientica Sinica, 2008, 29(2):247-252. doi: 10.3321/j.issn:1006-3021.2008.02.017
[6] 张永康, 冯乃琦, 张耀, 等. 某铅锌矿区土壤重金属污染分析[J]. 有色金属(冶炼部分), 2021(3):102-108.ZHANG Y K, FENG N Q, ZHANG Y, et al. Analysis of heavy metal pollution in soil of a lead-zinc mining area[J]. Nonferrous Metals (Extractive Metallurgy), 2021(3):102-108.
ZHANG Y K, FENG N Q, ZHANG Y, et al. Analysis of heavy metal pollution in soil of a lead-zinc mining area[J]. Nonferrous Metals (Extractive Metallurgy), 2021(3):102-108.
[7] 姜利国, 梁冰, 尹成薇. 冻-融及干-湿循环对采矿废石风化产酸影响的实验研究[J]. 安全与环境学报, 2014, 14(3):262-267.JIANG L G, LIANG B, YI C W. Experiments on the weathering effects of freezing-thawing and drying-wetting circulation on the mining waste rock behaviors[J]. Journal of Safety and Environment, 2014, 14(3):262-267.
JIANG L G, LIANG B, YI C W. Experiments on the weathering effects of freezing-thawing and drying-wetting circulation on the mining waste rock behaviors[J]. Journal of Safety and Environment, 2014, 14(3):262-267.
[8] 韩玉立, 王琼, 韩烈保. 德兴铜矿不同年份废石产酸规律研究[J]. 环境科学学报, 2015, 35(3):805-811.HAN Y L, WANG Q, HAN L B. Acid production rules of waste rocks in different years from Dexing copper mine[J]. Acta Scientiae Circumstantiae, 2015, 35(3):805-811.
HAN Y L, WANG Q, HAN L B. Acid production rules of waste rocks in different years from Dexing copper mine[J]. Acta Scientiae Circumstantiae, 2015, 35(3):805-811.
[9] 林海, 李洁, 董颖博, 等. 不同淋溶方法下石煤钒矿废石释钒特性[J]. 稀有金属, 2017, 41(12):1391-1396.LIN H, LI J, DONG Y B, et al. Vanadium leaching characteristics of stone coal waste rocks under different leaching methods[J]. Chinese Journal of Rare Metals, 2017, 41(12):1391-1396.
LIN H, LI J, DONG Y B, et al. Vanadium leaching characteristics of stone coal waste rocks under different leaching methods[J]. Chinese Journal of Rare Metals, 2017, 41(12):1391-1396.
[10] 张耀, 张永康, 刘岩, 等. 江西赣州矿山废石酸化潜力[J]. 现代矿业, 2019(1):119-122.ZHANG Y, ZHANG Y K, LIU Y, et al. Acidification potential of waste ores in Ganzhou city, Jiangxi province[J]. Modern Mining, 2019(1):119-122. doi: 10.3969/j.issn.1674-6082.2019.01.027
ZHANG Y, ZHANG Y K, LIU Y, et al. Acidification potential of waste ores in Ganzhou city, Jiangxi province[J]. Modern Mining, 2019(1):119-122. doi: 10.3969/j.issn.1674-6082.2019.01.027
[11] 林海, 李洁, 董颖博. 粒度对石煤钒矿废石重金属静态淋溶的影响规律[J]. 稀有金属, 2017, 41(12): 694-700.LIN H, LI J, DONG Y B. Heavy metal static leaching rules affected by different particle sizes of vanadium waste Rock[J]. Chinese Journal of Rare Metals, 2017, 41(12): 694-700.
LIN H, LI J, DONG Y B. Heavy metal static leaching rules affected by different particle sizes of vanadium waste Rock[J]. Chinese Journal of Rare Metals, 2017, 41(12): 694-700.
[12] 林海, 于明利, 董颖博. 不同粒度锡采矿废石重金属淋溶规律及影响机制[J]. 中国环境科学, 2014, 34(3):664-671.LIN H, YU M L, DONG Y B. The heavy mental leaching rules and influence mechanism of different particle size of tin mining waste rock[J]. China Environmental Science, 2014, 34(3):664-671.
LIN H, YU M L, DONG Y B. The heavy mental leaching rules and influence mechanism of different particle size of tin mining waste rock[J]. China Environmental Science, 2014, 34(3):664-671.
[13] 刘应冬, 徐力, 王先达, 等. 攀枝花钒钛磁铁矿尾矿中主要金属元素淋滤浸出行为研究[J]. 矿产综合利用, 2020(6):88-94.LIU Y D, XU L, WANG X D, et al. Study on leaching behavior of main metal elements from Panzhihua vanadium-titanium magnetite tailings[J]. Multipurpose Utilization of Mineral Resources, 2020(6):88-94. doi: 10.3969/j.issn.1000-6532.2020.06.015
LIU Y D, XU L, WANG X D, et al. Study on leaching behavior of main metal elements from Panzhihua vanadium-titanium magnetite tailings[J]. Multipurpose Utilization of Mineral Resources, 2020(6):88-94. doi: 10.3969/j.issn.1000-6532.2020.06.015
[14] 罗丽萍, 刘应冬, 范良千, 等. 攀枝花地区煤矸石中重金属元素浸出行为研究[J]. 矿产综合利用, 2021(4):59-65.LUO L P, LIU Y D, FAN L Q, et al. Leaching behavior of main heavy metal from coal gangue in Panzhihua Region[J]. Multipurpose Utilization of Mineral Resources, 2021(4):59-65. doi: 10.3969/j.issn.1000-6532.2021.04.009
LUO L P, LIU Y D, FAN L Q, et al. Leaching behavior of main heavy metal from coal gangue in Panzhihua Region[J]. Multipurpose Utilization of Mineral Resources, 2021(4):59-65. doi: 10.3969/j.issn.1000-6532.2021.04.009
[15] 钱玲, 李冰, 陈希, 等. 黄金尾砂重金属淋溶释放规律[J]. 东南大学学报(自然科学版), 2020, 50(6):1084-1089.QIAN L, LI B, CHEN X, et al. Leaching characteristics and release rule of heavy metals from gold tailings[J]. Journal of Southeast University: Natural Science Edition, 2020, 50(6):1084-1089. doi: 10.3969/j.issn.1001-0505.2020.06.013
QIAN L, LI B, CHEN X, et al. Leaching characteristics and release rule of heavy metals from gold tailings[J]. Journal of Southeast University: Natural Science Edition, 2020, 50(6):1084-1089. doi: 10.3969/j.issn.1001-0505.2020.06.013
[16] 袁丽, 刘阳生. 铅锌尾矿中重金属在模拟酸雨淋溶下的浸出规律[J]. 环境工程, 2012(2):586-590,292.YUAN L, LIU Y S. The leaching principles of heavy metals in lead and zinc talings in simulation acid rain[J]. Environmental Engineering, 2012(2):586-590,292.
YUAN L, LIU Y S. The leaching principles of heavy metals in lead and zinc talings in simulation acid rain[J]. Environmental Engineering, 2012(2):586-590,292.
[17] 濮阳雪华, 邓汝英, 王春春, 等. 德兴铜矿尾砂重金属在模拟降雨下的淋溶特征[J]. 环境工程, 2019, 37(5):61-65.PUYANG X H, DENG R Y, WANG C C, et al. Leaching characteristics of heavy metals from tailings under simulated rain fall in Dexing copper mine[J]. Environmental Engineering, 2019, 37(5):61-65.
PUYANG X H, DENG R Y, WANG C C, et al. Leaching characteristics of heavy metals from tailings under simulated rain fall in Dexing copper mine[J]. Environmental Engineering, 2019, 37(5):61-65.
[18] 罗乐, 王金霞, 周皓. 锰渣中重金属在模拟酸雨环境下的浸出规律[J]. 湿法冶金, 2019, 38(5):352-357.LUO L, WANG J X, ZHOU H. Leaching regularities of heavy metals in electrolytic manganese residue using simulation acid rain[J]. Hydrometallurgy of China, 2019, 38(5):352-357.
LUO L, WANG J X, ZHOU H. Leaching regularities of heavy metals in electrolytic manganese residue using simulation acid rain[J]. Hydrometallurgy of China, 2019, 38(5):352-357.
[19] Xu Zh Q, Ni Sh J, Teng Y G, et al. Leaching experiment on the release mechanism of heavy metal elements in solid waste from mining activities[J]. Geological Bulletin, 2012, 31(1):101-107.
[20] 彭越, 马文明. 云南某炼锌尾矿砂重金属释放实验研究[J]. 西南民族大学学报(自然科学版), 2020, 46(1):26-32.PENG Y, MA W M. Experimental research on heavy metal release from a zinc mine tailings in Yunnan province[J]. Journal of Southwest Minzu University(Natural Science Edition), 2020, 46(1):26-32.
PENG Y, MA W M. Experimental research on heavy metal release from a zinc mine tailings in Yunnan province[J]. Journal of Southwest Minzu University(Natural Science Edition), 2020, 46(1):26-32.
[21] 李晓涵, 吴永贵, 刘明凤, 等. 模拟酸雨对铅锌冶炼废渣重金属释放及生物毒性的影响[J]. 农业环境科学学报, 2020, 39(11):2504-2514.LI X H, WU Y G, LIU M F, et al. Effects of simulated acid rain on heavy metal release and biological toxicity of lead and zinc smelting waste residues[J]. Journal of Agro-Environment Science, 2020, 39(11):2504-2514. doi: 10.11654/jaes.2020-0440
LI X H, WU Y G, LIU M F, et al. Effects of simulated acid rain on heavy metal release and biological toxicity of lead and zinc smelting waste residues[J]. Journal of Agro-Environment Science, 2020, 39(11):2504-2514. doi: 10.11654/jaes.2020-0440
[22] 韦岩松, 甘志欢, 韦德阳, 等. 模拟酸雨对冶炼废渣中重金属溶出行为的影响[J]. 湿法冶金, 2018, 37(2):135-137.WEI Y S, GAN Z H, WEI D Y, et al. Effect of simulated acid rain on leaching of heavy metals in smelting slag heap[J]. Hydrometallurgy of China, 2018, 37(2):135-137.
WEI Y S, GAN Z H, WEI D Y, et al. Effect of simulated acid rain on leaching of heavy metals in smelting slag heap[J]. Hydrometallurgy of China, 2018, 37(2):135-137.
[23] 李媛媛, 吴平霄, 党志. 模拟酸雨对大宝山尾矿淋滤实验研究[J]. 环境污染与防治, 2012, 34(8):6-9.LI Y Y, WU P X, DANG Z. Experimental study on the leaching effect of simulated acid rain on tailings of Dabaoshan mine[J]. Environmental Pollution & Control, 2012, 34(8):6-9. doi: 10.3969/j.issn.1001-3865.2012.08.002
LI Y Y, WU P X, DANG Z. Experimental study on the leaching effect of simulated acid rain on tailings of Dabaoshan mine[J]. Environmental Pollution & Control, 2012, 34(8):6-9. doi: 10.3969/j.issn.1001-3865.2012.08.002
[24] 何积力, 徐光炎, 朱惠民, 等. 江西省土壤环境背景值研究[M]. 北京: 中国环境科学出版社, 2006: 135-142.HE J L, XU G Y, ZHU H M, et al. Study on the environmental background values of soils in Jiangxi Province[M]. Beijing: China Environmental Science Press , 2006: 135-142.
HE J L, XU G Y, ZHU H M, et al. Study on the environmental background values of soils in Jiangxi Province[M]. Beijing: China Environmental Science Press , 2006: 135-142.
-
