南澜沧江构造带景洪怕冷岩体锆石U-Pb年龄、Lu-Hf同位素特征及其对古特提斯构造演化的约束

,  ,  ,  ,  ,  ,  ,  ,  ,

文章导航 > 地质通报 > 2021 > 40(7): 1068-1083

上一篇

下一篇

王伟, 孙载波, 周坤, 刘和松, 吴嘉林, 丛峰, 赵江泰, 刘卫东, 李小军, 刘梦琼. 南澜沧江构造带景洪怕冷岩体锆石U-Pb年龄、Lu-Hf同位素特征及其对古特提斯构造演化的约束[J]. 地质通报, 2021, 40(7): 1068-1083.
引用本文: 王伟, 孙载波, 周坤, 刘和松, 吴嘉林, 丛峰, 赵江泰, 刘卫东, 李小军, 刘梦琼. 南澜沧江构造带景洪怕冷岩体锆石U-Pb年龄、Lu-Hf同位素特征及其对古特提斯构造演化的约束[J]. 地质通报, 2021, 40(7): 1068-1083.
shu
WANG Wei, SUN Zaibo, ZHOU Kun, LIU Hesong, WU Jialin, CONG Feng, ZHAO Jiangtai, LIU Weidong, LI Xiaojun, LIU Mengqiong. Zircon U-Pb geochronology and Lu-Hf isotope of the Jinghong Paleng pluton in southern Lancangjiang tectonic belt, and its constraints on the tectonic evolution of the Paleo-Tethys[J]. Geological Bulletin of China, 2021, 40(7): 1068-1083.
Citation: WANG Wei, SUN Zaibo, ZHOU Kun, LIU Hesong, WU Jialin, CONG Feng, ZHAO Jiangtai, LIU Weidong, LI Xiaojun, LIU Mengqiong. Zircon U-Pb geochronology and Lu-Hf isotope of the Jinghong Paleng pluton in southern Lancangjiang tectonic belt, and its constraints on the tectonic evolution of the Paleo-Tethys[J]. Geological Bulletin of China, 2021, 40(7): 1068-1083.
shu

南澜沧江构造带景洪怕冷岩体锆石U-Pb年龄、Lu-Hf同位素特征及其对古特提斯构造演化的约束

  • 1.

    云南省地质调查院, 云南 昆明 650216

  • 2.

    自然资源部三江成矿作用及资源勘查利用重点实验室, 云南 昆明 650061

  • 3.

    云南大学地球科学学院, 云南 昆明 650500

  • 4.

    中国地质调查局成都地质调查中心, 四川 成都 610081

  • 5.

    云南省建筑工程设计院有限公司, 云南 昆明 650217

  • 基金项目:
    中国地质调查局项目《全国陆域及海区地质图件更新与共享》子项目《云南省系列地质图件数据处理与洋板块地质研究》(编号：DD20190370)、国家自然科学基金项目《三江南段景洪大勐龙地区高压变质岩p-T-t轨迹及其对原-古特提斯构造演化的制约》(批准号：42062005)、云南省自然资源厅地勘基金项目《云南1：5万曼各、小街、曼班、大勐龙、万纳兰、勐宋坝六幅区域地质调查》(编号：D2017014)
详细信息
    作者简介: 王伟(1970-), 男, 教授级高工, 从事区域地质调查与微体古生物研究工作。E-mail: 1553974947@qq.com
    通讯作者: 孙载波(1981-), 男, 硕士, 高级工程师, 从事区域地质调查与基础地质研究工作。E-mail: ynddyszb@163.com

  • 中图分类号: P597

Zircon U-Pb geochronology and Lu-Hf isotope of the Jinghong Paleng pluton in southern Lancangjiang tectonic belt, and its constraints on the tectonic evolution of the Paleo-Tethys

  • 1.

    Yunnan Institute of Geological Survey, Kunming 650216, Yunnan, China

  • 2.

    Key Laboratory of Sanjiang Metallogeny and Resources Exploration and Utilization, Ministry of Natural Resources, Kunming 650061, Yunnan, China

  • 3.

    School of Earth Sciences, Yunnan University, Kunming 650500, Yunnan, China

  • 4.

    Chengdu Center of China Geological Survey, Chengdu 610081, Sichuan, China

  • 5.

    Yunnan Archtectural Engineering Design Compang Limited, Kunming 650217, Yunnan, China

More Information

    摘要

  • 景洪怕冷岩体位于景洪市大勐龙镇西侧，该岩体以闪长岩为主，内部包裹了辉长岩、角闪岩、辉石岩、角闪橄榄岩等小型岩体。利用LA-ICP-MS锆石U-Pb法对怕冷岩体中的辉长岩、黑云英云闪长岩和斜长角闪岩进行精确定年，获得其结晶年龄分别为252.5±1.6 Ma、264.3±2.0 Ma和273.6±1.9 Ma，表明该岩体的形成时代为中—晚二叠世。与该构造带上的其他岩体相比，形成时代较晚，可能为洋盆俯冲晚期岩浆流动分异作用较弱形成。全岩主量和微量元素研究表明，闪长岩和辉长岩均具有典型岛弧岩浆岩的地球化学特征，指示该岩体形成于与板块俯冲有关的大洋岛弧环境。斜长角闪岩锆石初始(176Hf/177Hf)i值为0.282833~0.282858，对应的εHf(t)变化范围在8.8~13.2之间，单阶段亏损地幔Hf模式年龄tDM1为370~549 Ma (平均值为470 Ma)，明显老于原岩结晶时代。结合区域地质资料分析，滇西地区古特提斯洋(昌宁-孟连洋)的俯冲于晚石炭世开始，直到晚二叠世末期洋盆才闭合进入弧陆碰撞造山阶段。

    Outcropped in the western Damenglong Town of Jinghong City, the Paleng pluton is lithologically dominated by diorite in which several small gabbro, amphibolite, pyroxenite and hornblende peridotite plutons are emplaced. By means of LA-ICP-MS zircon U-Pb method, gabbro, tonalite and amphibolite in the Paleng pluton were dated, and yielded crystallization age of 252.5±1.6 Ma, 264.3±2.0 Ma and 273.6±1.9 Ma, respectively, which indicates that the Paleng pluton was emplaced in Middle-Late Permian. Compared with other plutons along this tectonic belt, it was emplaced relatively late, and might be formed from weaker differentiation in the late stage of ocean basin subduction. The study of whole rock major and trace elements shows that both the diorite and gabbro have the geochemical characteristics of typical island-arc magmatism, indicating that the pluton was formed in the oceanic island arc environment related to plate subduction. The initial Hf isotope ratios(176Hf/177Hf)i of the zircons from amphibolites range from 0.282833 to 0.282858, with corresponding εHf(t) values of 8.8~13.2. These zircons have depleted mantle Hf model ages(tDM1) of 416~499 Ma, with an average of 470 Ma, obviously older than the crystallization of the original rocks(273.6 Ma). Combined with the analysis of regional geological data, the subduction of the ancient Tethys Ocean(Changning-Menglian Ocean) in western Yunnan began in the Late Carboniferous, and the ocean basin closed and entered the arc-continent collision orogenic stage until the end of the Late Permian.

    • HTML全文
  • 加载中

  • 图 1  景洪市大勐龙地区地质简图(底图据参考文献③)

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  怕冷岩体变质辉长岩、斜长角闪岩野外露头照片(a、c)及显微镜下照片(b、d)

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  景洪怕冷岩体基性岩Zr/TiO2-Nb/Y(a)、SiO2-Nb/Y(b)(底图据参考文献[20])、SiO2-(Na2O+K2O)(c)和SiO2-K2O(d)判别图解

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  景洪怕冷岩体基性岩球粒陨石标准化稀土元素配分模式图(a)和原始地幔标准化微量元素蛛网图(b)(球粒陨石和原始地幔标准值据参考文献[26][27])

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  样品锆石阴极发光(CL)图像和U-Pb年龄谐和图

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  斜长角闪岩(D3507-1)锆石t-εHf(t)图解(a)和亏损地幔Hf模式年龄tDM1频数直方图(b)

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  景洪怕冷岩体基性岩Hf/3-Th-Ta(a)和Hf/3-Th-Nb/16(b)构造环境判别图解[36]

    Figure 7.

    下载: 全尺寸图片 幻灯片

    表 1  景洪怕冷岩体基性岩主量、微量和稀土元素组成

    Table 1.  Major, trace element and REE compositions for the basites from the Paleng pluton in the Jinghong area

    样品号 DMbp-16 -1 DMbp-16 -1-3 DMbw-29 -2 DMbw-29 -2-1 MSB-14 -1-1 MSB-14 -2-1 PM003-62 -1
    SiO2 50.59 49.92 48.80 53.23 52.77 50.36 45.48
    TiO2 0.96 0.67 0.52 0.51 0.58 0.78 0.55
    Al2O3 19.01 18.97 17.03 16.59 17.70 17.44 20.09
    Fe2O3 3.35 0.62 0.50 0.84 1.25 0.98 1.50
    FeO 4.30 7.15 8.61 7.43 7.18 8.56 6.44
    MnO 0.15 0.14 0.18 0.19 0.19 0.20 0.14
    MgO 5.63 5.63 9.87 6.36 4.98 6.53 8.34
    CaO 8.59 8.91 7.27 9.16 8.72 8.59 8.69
    Na2O 3.53 3.49 2.95 3.93 4.35 3.45 1.10
    K2O 0.54 0.54 0.31 0.32 0.22 0.38 1.61
    P2O5 0.13 0.21 0.08 0.08 0.11 0.08 0.03
    烧失量 2.29 2.98 2.47 0.09 0.73 1.29 4.81
    合计 99.07 99.23 98.59 98.73 98.78 98.64 98.78
    Mg# 66.03 58.58 67.31 60.59 55.47 57.81 69.94
    Na2O+ K2O 3.87 4.03 3.26 4.25 4.57 3.83 2.71
    Na2O/K2O 6.54 6.46 9.52 12.28 19.77 9.08 0.68
    Cu 39.00 16.30 2.90 6.42 8.57 6.99 50.30
    Zn 75.40 82.50 48.30 41.90 134.00 88.60 78.00
    Cr 111.00 90.30 507.00 346.00 165.00 81.50 364.00
    Ni 50.40 44.40 141.00 62.00 32.00 5.39 56.50
    Co 31.30 31.80 37.90 25.20 28.10 23.20 36.80
    Rb 27.20 29.00 13.00 12.70 8.31 14.30 130.00
    Sr 524.00 412.00 208.00 299.00 512.00 220.00 299.00
    Ba 96.20 67.60 81.40 62.50 66.10 99.80 0.39
    V 255.00 167.00 244.00 217.00 261.00 153.00 218.00
    Sc 29.00 33.80 38.80 35.30 35.10 37.90 49.60
    Nb 2.38 1.48 1.55 1.94 2.73 1.63 0.60
    Zr 12.00 9.17 8.62 13.20 11.30 8.27 11.60
    Hf 0.53 0.40 0.41 0.60 0.68 0.47 0.56
    U 0.06 0.12 0.14 0.20 0.94 0.42 4.38
    Th 0.12 0.17 0.54 0.63 2.65 0.61 0.58
    La 5.74 4.67 3.14 4.24 12.30 3.16 3.22
    Ce 11.40 9.65 6.76 8.67 24.40 6.76 5.34
    Pr 1.64 1.34 1.00 1.16 3.11 1.01 1.06
    Nd 7.96 6.38 4.94 5.51 13.00 5.01 5.52
    Sm 2.04 1.59 1.37 1.49 2.89 1.48 1.71
    Eu 0.87 0.73 0.40 0.42 0.87 0.51 0.57
    Gd 2.11 1.67 1.62 1.65 2.75 1.74 1.34
    Tb 0.42 0.34 0.37 0.38 0.52 0.40 0.35
    Dy 2.51 1.99 2.32 2.50 3.01 2.67 2.44
    Ho 0.52 0.41 0.53 0.55 0.63 0.59 0.50
    Er 1.43 1.11 1.47 1.56 1.79 1.63 1.18
    Tm 0.25 0.19 0.25 0.28 0.34 0.29 0.23
    Yb 1.66 1.17 1.61 1.70 2.22 1.76 1.34
    Lu 0.24 0.17 0.22 0.23 0.34 0.25 0.18
    Y 13.90 10.30 13.60 14.70 17.30 15.10 13.10
    ΣREE 52.69 41.71 39.60 45.04 85.47 42.36 38.08
    δEu 1.27 1.36 0.82 0.82 0.93 0.97 1.11
    δCe 0.88 0.92 0.91 0.93 0.93 0.91 0.69
    (La/Yb)N 2.33 2.69 1.31 1.68 3.74 1.21 1.62
    (Gd/Yb)N 1.03 1.15 0.81 0.78 1.00 0.80 0.81
    (La/Sm)N 1.77 1.85 1.44 1.79 2.68 1.34 1.18
    注：主量元素含量单位为%，微量元素和稀土元素含量单位为10-6；Mg#=100×Mg/(Mg+Fe)(原子数)；δEu=2EuN/(SmN+GdN)，δCe=2CeN/(LaN+ PrN)，其中N为球粒陨石标准化值
    下载: 导出CSV

    表 2  景洪怕冷岩体锆石LA-ICP-MS U-Th-Pb同位素数据

    Table 2.  LA-ICP-MS zircon U-Th-Pb dating data of the Paleng pluton in the Jinghong area

    点号 元素/10-6 Th/U 同位素比值 同位素年龄/Ma
    Pb Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ
    PM003-62-1变质辉长岩
    01 219 540 98.3 5.49 0.0513 0.0025 0.2868 0.0137 0.0404 0.0005 257 109.2 256 10.8 255 3.2
    02 237 586 118 4.97 0.0483 0.0023 0.2625 0.0121 0.0397 0.0005 122 111.1 237 9.8 251 3.1
    03 179 451 102 4.42 0.0502 0.0025 0.2718 0.0130 0.0396 0.0005 211 117.6 244 10.4 250 3.3
    04 263 634 128 4.95 0.0509 0.0024 0.2794 0.0130 0.0400 0.0005 235 109.2 250 10.3 253 3.1
    05 190 474 95.4 4.97 0.0555 0.0034 0.3073 0.0218 0.0395 0.0006 435 132.4 272 17.0 250 3.6
    06 152 314 90.9 3.46 0.0542 0.0028 0.2988 0.0148 0.0400 0.0005 389 119.4 265 11.6 253 3.2
    07 224 568 127 4.47 0.0509 0.0024 0.2840 0.0131 0.0404 0.0005 235 109.2 254 10.3 256 2.9
    08 357 889 177 5.02 0.0525 0.0020 0.2950 0.0105 0.0408 0.0004 309 85.2 262 8.2 258 2.6
    09 184 452 111 4.08 0.0496 0.0025 0.2804 0.0138 0.0415 0.0007 176 125.0 251 10.9 262 4.3
    10 297 714 147 4.85 0.0475 0.0021 0.2644 0.0121 0.0404 0.0005 76.0 113.0 238 9.7 255 3.3
    11 245 635 160 3.96 0.0472 0.0020 0.2642 0.0111 0.0405 0.0005 61.2 105.5 238 8.9 256 2.8
    12 175 439 109 4.02 0.0461 0.0022 0.2635 0.0126 0.0412 0.0004 400 -278 238 10.2 260 2.8
    13 214 536 151 3.55 0.0494 0.0023 0.2726 0.0122 0.0402 0.0005 165 109.2 245 9.8 254 2.9
    14 168 418 121 3.44 0.0479 0.0024 0.2595 0.0121 0.0396 0.0004 100 105.5 234 9.8 250 2.7
    15 159 401 114 3.51 0.0466 0.0026 0.2514 0.0127 0.0396 0.0006 33.4 120.4 228 10.3 250 3.5
    16 273 685 190 3.60 0.0527 0.0021 0.2886 0.0114 0.0396 0.0004 317 116.7 257 9.0 250 2.7
    17 142 370 107 3.45 0.0533 0.0026 0.2914 0.0141 0.0401 0.0006 343 108.3 260 11.1 253 3.5
    18 155 386 108 3.59 0.0515 0.0028 0.2732 0.0140 0.0388 0.0006 261 128.7 245 11.1 245 3.7
    19 137 354 117 3.04 0.0518 0.0026 0.2774 0.0139 0.0391 0.0005 276 116.7 249 11.0 247 2.9
    20 181 470 161 2.92 0.0483 0.0021 0.2640 0.0113 0.0396 0.0005 122 101.8 238 9.1 250 2.8
    21 181 463 148 3.14 0.0569 0.0029 0.3048 0.0162 0.0387 0.0005 487 111.1 270 12.6 245 3.2
    22 104 270 105 2.58 0.0490 0.0031 0.2691 0.0162 0.0401 0.0005 146 140.7 242 13.0 254 3.4
    23 196 526 164 3.20 0.0505 0.0021 0.2751 0.0113 0.0395 0.0004 217 94.4 247 9.0 250 2.8
    24 194 539 150 3.59 0.0518 0.0023 0.2794 0.0129 0.0389 0.0005 276 101.8 250 10.3 246 2.9
    25 120 305 125 2.45 0.0537 0.0026 0.3038 0.0145 0.0412 0.0005 367 104.6 269 11.3 260 3.3
    26 127 296 130 2.28 0.0569 0.0026 0.3153 0.0147 0.0400 0.0005 487 100.0 278 11.3 253 3.0
    27 126 333 135 2.47 0.0538 0.0025 0.2903 0.0128 0.0394 0.0005 361 101.8 259 10.1 249 3.1
    28 137 378 135 2.81 0.0531 0.0027 0.2833 0.0135 0.0391 0.0005 345 119.4 253 10.7 247 3.0
    29 145 389 136 2.86 0.0516 0.0025 0.2926 0.0145 0.0410 0.0005 333 111.1 261 11.4 259 3.4
    30 119 315 122 2.59 0.0493 0.0027 0.2718 0.0137 0.0405 0.0006 167 125.0 244 11.0 256 3.4
    DMbw-29-4黑云英云闪长岩
    01 15.6 207 307 0.67 0.0536 0.0021 0.3154 0.0125 0.0427 0.0004 354 90.7 278 9.7 269 2.7
    02 11.1 120 232 0.52 0.0554 0.0026 0.3170 0.0144 0.0417 0.0005 432 105.5 280 11.1 263 3.1
    03 14.1 183 285 0.64 0.0539 0.0019 0.3110 0.0109 0.0420 0.0005 365 79.6 275 8.5 265 3.0
    04 11.6 123 245 0.50 0.0558 0.0023 0.3144 0.0126 0.0411 0.0004 443 92.6 278 9.7 259 2.6
    05 18.9 262 380 0.69 0.0514 0.0019 0.2948 0.0109 0.0416 0.0004 257 87.0 262 8.6 263 2.6
    06 4.9 44.5 105 0.42 0.0510 0.0039 0.2827 0.0190 0.0407 0.0006 243 174.1 253 15.1 257 3.8
    07 20.5 238 428 0.56 0.0506 0.0018 0.2879 0.0097 0.0414 0.0004 220 50.9 257 7.6 262 2.3
    08 10.9 111 230 0.48 0.0561 0.0022 0.3206 0.0126 0.0416 0.0004 457 88.9 282 9.7 262 2.6
    09 12.4 146 258 0.57 0.0549 0.0026 0.3143 0.0138 0.0422 0.0005 406 105.5 278 10.7 267 3.2
    10 7.6 92.3 161 0.57 0.0506 0.0027 0.2845 0.0155 0.0407 0.0006 220 119.4 254 12.2 257 3.6
    12 12.6 152 251 0.61 0.0575 0.0025 0.3379 0.0155 0.0425 0.0005 522 96.3 296 11.8 268 3.1
    13 10.4 141 206 0.69 0.0570 0.0029 0.3324 0.0174 0.0425 0.0005 500 119.4 291 13.2 268 3.2
    14 11.9 135 242 0.56 0.0525 0.0022 0.3070 0.0127 0.0426 0.0004 309 94.4 272 9.9 269 2.7
    15 8.7 102 176 0.58 0.0482 0.0024 0.2819 0.0142 0.0424 0.0005 109 111.1 252 11.2 268 3.2
    16 7.4 86.3 150 0.58 0.0497 0.0025 0.2878 0.0141 0.0425 0.0006 183 118.5 257 11.1 268 3.7
    17 14.8 192 303 0.63 0.0532 0.0021 0.3021 0.0112 0.0414 0.0004 339 91.7 268 8.7 262 2.4
    18 9.2 112 187 0.60 0.0497 0.0025 0.2864 0.0135 0.0421 0.0005 183 116.7 256 10.7 266 2.9
    19 15.1 167 317 0.53 0.0523 0.0018 0.2918 0.0099 0.0407 0.0004 298 81.5 260 7.8 257 2.5
    20 8.3 81.9 176 0.47 0.0479 0.0021 0.2710 0.0118 0.0412 0.0005 94.5 103.7 243 9.4 260 3.0
    21 16.2 202 325 0.62 0.0560 0.0019 0.3182 0.0108 0.0413 0.0004 450 77.8 280 8.3 261 2.4
    22 13.3 170 272 0.62 0.0510 0.0021 0.2867 0.0121 0.0408 0.0004 239 96.3 256 9.5 258 2.5
    23 15.5 223 312 0.71 0.0502 0.0020 0.2842 0.0118 0.0409 0.0004 206 94.4 254 9.3 258 2.3
    24 11.1 140 219 0.64 0.0523 0.0021 0.3030 0.0114 0.0422 0.0005 298 88.0 269 8.9 267 3.1
    25 10.4 128 210 0.61 0.0525 0.0021 0.2992 0.0122 0.0413 0.0005 306 94.4 266 9.5 261 2.9
    26 11.8 157 239 0.66 0.0513 0.0023 0.2898 0.0134 0.0407 0.0004 254 110.2 258 10.5 257 2.6
    27 13.3 148 273 0.54 0.0527 0.0019 0.3037 0.0111 0.0418 0.0005 322 85.2 269 8.6 264 2.9
    28 10.6 125 219 0.57 0.0499 0.0025 0.2807 0.0133 0.0411 0.0005 191 112.0 251 10.6 260 3.0
    29 17.4 190 353 0.54 0.0514 0.0017 0.3015 0.0104 0.0423 0.0004 261 77.8 268 8.1 267 2.6
    30 14.8 179 306 0.59 0.0522 0.0019 0.2974 0.0104 0.0412 0.0004 295 81.5 264 8.2 261 2.6
    MSB-14-1斜长角闪岩
    01 21.39 340 393 0.87 0.0536 0.0022 0.3325 0.0141 0.0448 0.0006 354 99.1 291 10.7 283 3.7
    02 22.77 334 428 0.78 0.0489 0.0023 0.2951 0.0139 0.0437 0.0006 139 111.1 263 10.9 276 3.6
    03 20.77 217 415 0.52 0.0560 0.0021 0.3371 0.0129 0.0435 0.0005 454 117.6 295 9.8 275 3.1
    04 6.36 35.0 137 0.26 0.0527 0.0039 0.3144 0.0195 0.0441 0.0008 322 137.9 278 15.0 278 5.0
    05 4.84 32.4 102 0.32 0.0565 0.0040 0.3317 0.0204 0.0435 0.0008 472 163.9 291 15.5 275 5.0
    06 12.23 140 261 0.54 0.0536 0.0029 0.2973 0.0154 0.0403 0.0006 354 125.0 264 12.1 254 3.9
    07 8.72 60.7 181 0.33 0.0546 0.0032 0.3247 0.0180 0.0437 0.0007 398 131.5 286 13.8 276 4.6
    08 7.07 67.7 142 0.48 0.0492 0.0038 0.2857 0.0194 0.0431 0.0007 167 161.1 255 15.3 272 4.5
    09 18.31 250 353 0.71 0.0502 0.0024 0.2965 0.0134 0.0432 0.0006 211 117.6 264 10.5 273 3.7
    10 14.96 106 312 0.34 0.0568 0.0027 0.3416 0.0155 0.0436 0.0006 483 103.7 298 11.8 275 3.5
    11 23.25 397 430 0.92 0.0534 0.0022 0.3175 0.0131 0.0430 0.0005 343 89.8 280 10.1 272 3.3
    12 29.3 447 537 0.83 0.0525 0.0021 0.3184 0.0120 0.0441 0.0006 306 88.9 281 9.2 278 3.4
    13 25.9 413 483 0.86 0.0522 0.0019 0.3119 0.0113 0.0430 0.0004 300 81.5 276 8.8 272 2.8
    14 13.13 124 263 0.47 0.0528 0.0026 0.3167 0.0147 0.0437 0.0006 320 113.0 279 11.3 276 3.8
    15 24.51 263 492 0.54 0.0521 0.0022 0.3169 0.0131 0.0439 0.0006 300 94.4 280 10.1 277 3.5
    16 12.65 176 248 0.71 0.0516 0.0026 0.3039 0.0151 0.0423 0.0005 333 119.4 269 11.7 267 3.3
    17 7.99 91.7 157 0.58 0.0526 0.0036 0.3193 0.0208 0.0440 0.0007 322 155.5 281 16.0 278 4.2
    18 12.83 121 261 0.46 0.0533 0.0028 0.3228 0.0156 0.0440 0.0006 343 118.5 284 12.0 278 3.6
    20 28.92 336 588 0.57 0.0523 0.0020 0.3097 0.0119 0.0426 0.0005 298 87.0 274 9.2 269 3.0
    21 7.19 70.5 143 0.49 0.0531 0.0033 0.3180 0.0168 0.0438 0.0008 332 144.4 280 12.9 276 4.7
    22 7.73 79.3 156 0.51 0.0552 0.0035 0.3234 0.0183 0.0431 0.0007 420 147.2 284 14.0 272 4.1
    23 22.95 249 460 0.54 0.0509 0.0021 0.3040 0.0122 0.0431 0.0006 239 94.4 270 9.5 272 3.5
    24 6.69 69.3 132 0.52 0.0551 0.0041 0.3352 0.0228 0.0438 0.0008 413 166.7 293 17.3 277 4.9
    下载: 导出CSV

    表 3  斜长角闪岩(D3507-1)锆石Hf同位素数据

    Table 3.  Zircon Hf isotopic compositions of the amphibolite sample(D3507-1)

    测点号 176Yb/177Hf 176Lu/177Hf 176Hf/177Hf 2σ εHf(0) εHf(t) tDM /Ma tDMC/Ma fLu/Hf
    01 0.044439 0.002098 0.282917 0.000030 4.7 10.4 488 607 -0.94
    02 0.023963 0.001226 0.282926 0.000027 5.0 10.8 465 578 -0.96
    03 0.027106 0.001363 0.282993 0.000030 7.4 13.2 370 426 -0.96
    04 0.010873 0.000602 0.282956 0.000026 6.1 12.0 415 501 -0.98
    05 0.003159 0.000178 0.282922 0.000022 4.8 10.9 458 575 -0.99
    06 0.022416 0.001131 0.282883 0.000025 3.4 9.3 526 675 -0.97
    07 0.017125 0.000926 0.282889 0.000023 3.7 9.6 513 657 -0.97
    08 0.029747 0.001493 0.282925 0.000027 5.0 10.8 469 582 -0.96
    09 0.035089 0.001686 0.282912 0.000031 4.5 10.3 490 614 -0.95
    10 0.013654 0.000742 0.282909 0.000020 4.4 10.3 483 610 -0.98
    11 0.039804 0.001947 0.282871 0.000031 3.0 8.8 554 711 -0.94
    12 0.042567 0.002038 0.282933 0.000030 5.2 11.0 465 571 -0.94
    13 0.020519 0.001069 0.282870 0.000027 3.0 8.9 542 702 -0.97
    14 0.032379 0.001575 0.282871 0.000030 3.0 8.8 549 707 -0.95
    15 0.036359 0.001788 0.282939 0.000030 5.4 11.2 454 555 -0.95
    16 0.039328 0.001953 0.282957 0.000030 6.1 11.8 429 515 -0.94
    17 0.027146 0.001356 0.282940 0.000026 5.5 11.3 446 547 -0.96
    18 0.018016 0.000959 0.282942 0.000027 5.5 11.5 439 539 -0.97
    19 0.016588 0.000870 0.282976 0.000026 6.7 12.7 390 460 -0.97
    20 0.015335 0.000775 0.282930 0.000021 5.1 11.1 454 564 -0.98
    注：εHf(t)=10000×{[(176 Hf/177Hf)s－(176 Lu/177Hf)s×(eλt-1)]/[(176 Hf/177Hf)CHUR, 0-(176 Lu/177Hf)CHUR ×(eλt-1)]-1}, tDM=1/λ×ln{1+[(176 Hf/177Hf)s－(176 Hf/177Hf)DM]/[(176 Lu/177Hf)s－(176 Lu/177Hf)DM]}, tDMC=tDM-(tDM-t) ×[(fcc-fs)/(fcc-fDM)]，fLu/Hf=(176 Lu/177Hf)s/(176 Lu/177Hf)CHUR-1，其中：λ=1.867×10-11/a; (176 Hf/177Hf)s和(176 Hf/177Hf)S为样品测量值；(176 Lu/177Hf)CHUR=0.0332；(176 Hf/177Hf)CHUR, 0=0.282772；(176 Lu/177Hf)DM=0.0384，(176 Hf/177Hf)DM=0.28325；(176 Lu/177Hf)平均地壳=0.015；fcc=[(176Lu/177Hf)平均地壳/(176 Lu/177Hf)CHUR]-1；fs= fLu/Hf；fDM=[(176 Lu/177Hf)DM/(176 Lu/177Hf)CHUR]-1;t为锆石结晶年龄
    下载: 导出CSV
    • 参考文献(65)
  • [1]

    刘本培, 冯庆来, 方念桥, 等. 滇西昌宁-孟连和澜沧江带带古特提斯多岛洋构造演化[J]. 地球科学, 1993, 18(5): 529-539.

    [2]

    莫宣学, 沈上越, 朱勤文, 等. 三江中南段火山岩-蛇绿岩与成矿[M]. 北京: 地质出版社, 1998: 123-132.

    [3]

    钟大赉. 滇川西部古特提斯造山带[M]. 北京: 科学出版社, 1998: 1-231.

    [4]

    潘桂棠, 徐强, 侯增谦, 等. 西南"三江"多岛弧造山过程、成矿系统与资源评价[M]. 北京: 地质出版社, 2003: 106-112.

    [5]

    Sone M, Metcalfe I. Parallel Tettyan Sutures in mainland SE Asia: new issights for Palaeo-Tethys closure[J]. Comptes Rendus Geoscience, 2008, 340(2/3): 166-179. http://www.sciencedirect.com/science/article/pii/S163107130700260X

    [6]

    李文昌, 潘桂棠, 侯增谦, 等. 西南"三江"多岛弧盆-碰撞造山成矿理论与勘查技术[M]. 北京: 地质出版社, 2010: 92-104.

    [7]

    邓军, 王庆飞, 李龚健. 复合造山和复合成矿系统: 三江特提斯例析[J]. 岩石学报, 2016, 32(8): 2225-2247. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201608001.htm

    [8]

    王保弟, 王立全, 王冬兵, 等. 三江昌宁-孟连带原-古特提斯构造演化[J]. 地球科学, 2018, 43(8): 2527-2550. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201808001.htm

    [9]

    张翼飞, 段锦荪, 张罡, 等. 滇西蛇绿岩带地质构造演化与澜沧江板块缝合线研究[M]. 昆明: 云南科技出版社, 2001: 1-101.

    [10]

    张魁武, 张旗, 李达周. 云南景洪南联山橄榄岩-闪长岩型岩体的特征及地质意义[J]. 矿物岩石, 1991, 11(3): 21-28. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS199103003.htm

    [11]

    张旗, 张魁武, 李达周, 等. 横断山区镁铁-超镁铁岩[M]. 北京: 科学出版社, 1992: 1-126.

    [12]

    赵大升, 张旗, 王明新, 等. 云南景洪县怕冷橄榄岩-闪长岩型杂岩的地球化学特征及其构造意义[J]. 矿物岩石, 1991, 11(9): 688-690. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB199109014.htm

    [13]

    Zong K Q, Klemd R, Yuan Y, et al. The assembly of Rodinia: The correlation of early Neoproterozoic (ca. 900 Ma) high-grade metamorphism and continental arc formation in the southern Beishan Orogen, southern Central Asian Orogenic Belt (CAOB)[J]. Precambrian Research, 2017, 290: 32-48. doi: 10.1016/j.precamres.2016.12.010

    [14]

    Hu Z C, Zhang W, Liu Y S, et al. "Wave" signal smoothing and mercury removing device for laser ablation quadrupole and multiple collector ICP-MS analysis: application to lead isotope analysis[J]. Analytical Chemistry, 2015, 87: 1152-1157. doi: 10.1021/ac503749k

    [15]

    Liu Y S, Gao S, Hu Z C, et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons of mantle xenoliths[J]. Journal of Petrology, 2010, 51: 537-571. doi: 10.1093/petrology/egp082

    [16]

    Liu Y S, Hu Z C, Zong K Q, et al. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICP-MS[J]. Chinese Science Bulletin, 2010, 55(15): 1535-1546. doi: 10.1007/s11434-010-3052-4

    [17]

    Ludwig K R. ISOPLOT 3.00: A Geochronological Toolkit for Microsoft Excel[J]. Berkeley Geochronology Center, California, Berkeley, 2003: 1-39. http://www.researchgate.net/publication/301951506_User's_Manual_for_IsoplotEx_rev_300_A_Geochronological_Toolkit_for_Microsoft_Excel

    [18]

    Hu Z C, Liu Y S, Gao S, et al. Improved in situ Hf isotope ratio analysis of zircon using newly designed X skimmer cone and jet sample cone in combination with the addition of nitrogen by laser ablation multiple collector ICP-MS[J]. Journal of Analytical Atomic Spectrometry, 2012, 27(9): 1391-1399. doi: 10.1039/c2ja30078h

    [19]

    Lin J, Liu Y S, Yang Y H, et al. Calibration and correction of LA-ICP-MS and LA-ICP-MS analyses for element contents and isotopic ratios[J]. Solid Earth Sciences, 2016, 1(1): 5-27. doi: 10.1016/j.sesci.2016.04.002

    [20]

    Wilson M. Igneous Petrogenesis[M]. London: Unwin Hyman, 1989: 1-416.

    [21]

    Condie K C. Geochemical changes in baslts and andesites across the Archean-Proterozoic boundary: Identification and significance[J]. Lithos, 1989, 23(1/2): 1-18. http://www.sciencedirect.com/science/article/pii/0024493789900200

    [22]

    张旗, 周国庆. 中国蛇绿岩[M]. 北京: 科学出版社, 2001: 1-182.

    [23]

    Kersting A B, Arculus R J. Klyuchevskoy volcano, Kamchatka, Russia: The role of high-flux recharged, tapped, and fractionated magma chamber (s) in the genesis of high-Al2O3 from high-MgO basalt[J]. Journal of Petrology, 1994, 35(1): 1-41. doi: 10.1093/petrology/35.1.1

    [24]

    Winchester J A, Flody P A. Geochmical magma type discrimination: application to altered and metamophosed basic ignous rocks[J]. Earth & Planetary Science Letters, 1977, 28: 459-469. http://www.sciencedirect.com/science/article/pii/0012821X76902077

    [25]

    Shinjo R, Chung S L, Kato Y, et al. Geochemical and Sr-Nd isotopic characteristics of volcanic rocks from the Okinawa Trough and Ryukyu Arc: Implications for the evolution of a young, intracontinetal back arc basin[J]. Journal of Geophysical Research, 1999, 104: 10591-10608. doi: 10.1029/1999JB900040

    [26]

    Taylor S R, Mclennan S M. The continental crust: Its composition and evolution[M]. Oxford: Blackell Scientific Publications, 1985: 54-372.

    [27]

    Sun S, Mcdonough W. Chemical and isotopic systematics of oceanic basalts: for Implications for mantle composition and processes[C]//Saunders A, Norry M. Magmatism in the Ocean Basin. Geological Society Special Publication, 1989, 42: 313-345.

    [28]

    吴元保, 郑永飞. 锆石成因矿物学研究及其对U-Pb年龄解释的制约[J]. 科学通报, 2004, 49(16): 1589-1604. doi: 10.3321/j.issn:0023-074X.2004.16.002

    [29]

    李钢柱, 苏尚国, 雷玮琰, 等. 三江地区澜沧江带南段南林山基性岩体锆石U-Pb年龄及岩石地球化学特征[J]. 地学前缘, 2011, 18(5): 206-212. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201105019.htm

    [30]

    徐桂香, 刘桂春, 刘军平, 等. 云南景洪南联山闪长岩体锆石U-Pb年龄及其意义[J]. 云南地质, 2016, 35(2): 131-136. doi: 10.3969/j.issn.1004-1885.2016.02.001

    [31]

    Hennig D, Lehmanneh B D, Frei D, et al. Early Permian seafloor to continental arc magmatism in the eastern Paleo-Tethys: U-Pb age and Nd-Sr isotope data from the southern Lancangjiang zone, Yunnan China[J]. Lithos, 2009, 113(3): 408-422. http://www.sciencedirect.com/science/article/pii/S0024493709001819

    [32]

    孙载波, 卢晓萍, 俞赛赢, 等. 云南景洪曼秀闪长岩体锆石U-Pb年龄与岩石地球化学特征[J]. 矿物学报, 2015, 35(4): 473-480. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB201504010.htm

    [33]

    王晓峰. 滇西南南澜沧江镁铁-超镁铁杂岩的岩石学研究——以雅口岩体为例[D]. 昆明理工大学硕士学位论文, 2012: 1-58.

    [34]

    李钢柱, 苏尚国, 段向东, 等. 三江地区澜沧江带南段半坡杂岩体锆石U-Pb年龄、岩石地球化学特征及板块构造环境[J]. 地学前缘, 2012, 19(4): 96-109. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201204010.htm

    [35]

    张海, 金灿海, 范文玉, 等. 云南景谷半坡铂钯多金属矿床辉长岩锆石U-Pb同位素定年及其意义[J]. 中国地质, 2013, 40(5): 1433-1442. doi: 10.3969/j.issn.1000-3657.2013.05.008

    [36]

    Wood D A. The application of a Th, Hf, Ta diagram to problems of tectonomagmatic classification and to establishing the nature of crustal contamination of basaltic lavas of the British Tertiary Volcanic Province[J]. Earth & Planetary Science Letters, 1980, 50(1): 11-30. http://www.sciencedirect.com/science/article/pii/0012821X80901168

    [37]

    吴福元, 李献华, 郑永飞, 等. Lu-Hf同位素体系及其岩石学应用[J]. 岩石学报, 2007, 23(2): 185-219. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200702002.htm

    [38]

    Peter D K, Roland M. Lu-Hf and Sm-Nd isotope systems in zircon[J]. Reviews in Mineralogy and Geochemistry, 2003, 53(1): 327-341. doi: 10.2113/0530327

    [39]

    刘德利, 刘继顺, 张彩华, 等. 滇西南澜沧江结合带北段云县花岗岩的地质特征及形成环境[J]. 岩石矿物学杂志, 2008, 27(1): 23-31. doi: 10.3969/j.issn.1000-6524.2008.01.003

    [40]

    孔会磊, 董国臣, 莫宣学, 等. 滇西三江地区临沧花岗岩的岩石成因——地球化学、锆石U-Pb年代学及Hf同位素约束[J]. 岩石学报, 2012, 28(5): 1438-1452. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201205010.htm

    [41]

    Dong G C, Mo X X, Zhao Z D, et al. Zircon U-Pb dating and the prtrological and geochemical constraints on Lincang granite in western Yunnan, China: Implications for the closure of the Paleo-Tethys Ocean[J]. Journal of Asian Earth Science, 2013, 62(62): 282-294. http://www.sciencedirect.com/science/article/pii/S1367912012004208

    [42]

    Peng T P, Wilde S A, Wang Y J, et al. Mid-Triassic felsic igneous rocks from the southern Lancangjiang Zone, SW China: Petrogenesis and implications for the evolution of Paleo-Tethys[J]. Lithos, 2013, 168/169(2): 15-32. http://www.sciencedirect.com/science/article/pii/S0024493713000303

    [43]

    王舫, 刘福来, 刘平华, 等. 澜沧江南段临沧花岗岩的锆石U-Pb年龄及构造意义[J]. 岩石学报, 2014, 30(10): 3034-3050. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201410018.htm

    [44]

    Wang C M, Deng J, Santosh M, et al. Age and origin of the Bulangshan and Mengsong granitoids and their significance for post-collisional tectonics in the Changning-Menglian Paleo-Tethys Orogen[J]. Journal of Asian Earth Science, 2015, 113(4): 656-676. http://www.sciencedirect.com/science/article/pii/S1367912015002539

    [45]

    曾文涛, 孙载波, 周坤, 等. 滇西双江县勐库地区临沧花岗岩中暗色包体锆石U-Pb年代学及及其地质意义[J]. 沉积与特提斯地质, 2018, 38(1): 23-36. doi: 10.3969/j.issn.1009-3850.2018.01.003

    [46]

    赵枫, 李龚健, 张鹏飞, 等. 西南三江临沧花岗岩基成因与构造启示: 元素地球化学、锆石U-Pb年龄及Hf同位素约束[J]. 岩石学报, 2018, 34(5): 1397-1412. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201805013.htm

    [47]

    彭头平, 王岳军, 范蔚茗, 等. 澜沧江南段早中生代酸性火成岩SHRIMP锆石U-Pb定年及构造意义[J]. 中国科学(D辑), 2006, 36(2): 123-132. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK200602001.htm

    [48]

    范蔚茗, 彭头平, 王岳军. 滇西古特提斯俯冲-碰撞过程的岩浆作用记录[J]. 地学前缘, 2009, 16(6): 291-302. doi: 10.3321/j.issn:1005-2321.2009.06.031

    [49]

    王硕, 董国臣, 莫宣学, 等. 澜沧江南带三叠纪火山岩岩石学、地球化学特征、Ar-Ar年代学研究及其构造意义[J]. 岩石学报, 2012, 28(4): 1148-1162. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201204013.htm

    [50]

    韦诚, 戚学祥, 常裕林, 等. 澜沧江构造带中南段小定西组火山岩形成时代的厘定及其构造意义[J]. 地质学报, 2016, 90(11): 3192-3214. doi: 10.3969/j.issn.0001-5717.2016.11.014

    [51]

    李国昌, 王巍, 杨立刚, 等. 滇西凤庆三岔河晚三叠世火山岩年代学、地球化学特征及其地质意义[J]. 现代地质, 2018, 32(6): 1263-1271. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201806014.htm

    [52]

    吴嘉林, 孙载波, 周坤, 等. 云南双江县勐库地区三叠纪火山岩的发现及其意义[J]. 云南地质, 2018, 37(3): 261-268. doi: 10.3969/j.issn.1004-1885.2018.03.002

    [53]

    简平, 汪啸风, 何龙清, 等. 云南新平县双沟蛇绿岩U-Pb年代学初步研究[J]. 岩石学报, 1998, 14(2): 207-211. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB802.007.htm

    [54]

    简平, 刘敦一, 孙晓猛, 等. 滇川西部金沙江石炭纪蛇绿混杂岩SHRIMP测年: 古特提斯洋壳演化的同位素年代学制约[J]. 地质学报, 2003, 77(2): 1-13. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE200302017.htm

    [55]

    刘翠, 邓晋福, 刘俊来, 等. 哀牢山构造岩浆岩带晚二叠世-早三叠世火山岩特征及其构造环境[J]. 岩石学报, 2011, 27(12): 3590-3602. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201112008.htm

    [56]

    李龚健, 王庆飞, 禹丽, 等. 哀牢山古特提斯洋缝合时限: 晚二叠世花岗岩类锆石U-Pb年代学与地球化学制约[J]. 岩石学报, 2013, 29(11): 3883-3900. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201311020.htm

    [57]

    刘汇川, 王岳军, 蔡永丰, 等. 哀牢山构造带晚二叠世末期过铝质花岗岩锆石U-Pb年代学及Hf同位素组成研究[J]. 大地构造与成矿学, 2013, 37(1): 87-98. doi: 10.3969/j.issn.1001-1552.2013.01.010

    [58]

    孙崇波, 李忠权, 王道永, 等. 哀牢山构造带南段马玉花岗闪长岩花岗岩地球化学特征及其锆石U-Pb年龄[J]. 地质通报, 2019, 38(2/3): 223-230. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=2019020305&flag=1

    [59]

    Zi J W, Cawood P A, Fan W M, et al. Generation of Early Indosinian enriched mantle-derived granitoid pluton in the Sanjiang Orogen(SW China) in response to closure of the Paleo-Tethys[J]. Lithos, 2012, 140(5): 166-182. http://www.sciencedirect.com/science/article/pii/S0024493712000503

    [60]

    刘军平, 田素梅, 丛峰, 等. 滇西澜沧江构造带沙乐花岗岩的锆石U-Pb年龄、地球化学特征及其地质意义[J]. 沉积与特提斯地质, 2017, 37(4): 29-40. doi: 10.3969/j.issn.1009-3850.2017.04.005

    ①

    云南省地质调查院. 云南省成矿地质背景研究报告. 2013.

    ②

    云南省地质调查院. 1: 250 000澜沧县、勐海县区域地质调查报告. 2012.

    ③

    云南省地质调查院. 1: 50 000曼各、小街、曼班、大勐龙、万纳兰、勐宋坝幅区域地质调查报告. 2020.

    ④

    云南省地质调查院. 1: 50 000半坡、大山、谦六、芒蚌街、丫口街、官房幅区域地质调查报告. 2014.

    ⑤

    云南省地质调查院. 1: 50 000那许、黄竹林、弯手寨、黄草坝幅区域地质调查报告. 2000.

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

图(7)

表(3)

计量
  • 文章访问数:  944
  • PDF下载数:  7
  • 施引文献:  0
出版历程
收稿日期:  2019-11-10
修回日期:  2020-04-09
刊出日期:  2021-07-15

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
