Distribution of shallow gas at an offshore platform site in Bohai Bay and its genetic mechanism
-
摘要:
海底浅层气严重影响海底地层的结构稳定性,因此成为影响近海海洋平台安全的重要因素。基于高精度浅地层剖面及单道地震等物探调查资料,识别了渤海湾某海洋平台周边的浅层气分布状况及顶界埋深,并分析了研究区浅层气的成因。浅地层和单道地震资料解释的浅层气分布和顶界埋深具有非常好的一致性,平台周边1 km2范围内的浅层气主要分布在平台北侧及紧贴平台西南角,呈片状或条状分布,局部呈点状分布,顶界埋深在0.6~4.0 m之间。研究区内浅层气为浅层生物成气,但该区域断层发育,不排除热解成因浅层气的存在。指出浅层气体对海洋平台的影响主要表现在变形和失稳2个方面,对海洋平台采取针对性的防护措施具有现实意义。
Abstract:Submarine shallow gas has a serious impact on the structural stability of seafloor strata, so it has become an important factor affecting the safety of offshore platforms.Based on high-precision shallow stratigraphic profiles and single channel seismic data, the distribution and top buried depth of shallow gas around an offshore platform in Bohai Bay were identified, and the origin of shallow gas in the study area was analyzed.The distribution of shallow gas interpreted by shallow strata and single channel seismic data is very consistent with the top buried depth.The shallow gas in the area of 1 km2 around the platform is mainly distributed in its north side and adjacent to its southwest corner in the form of patches or strips and locally in the form of points.The burial depth of top boundary is between 0.6 m and 4.0m.The shallow gas in the study area is shallow biogenic gas, but the fault development in this area does not rule out the existence of pyrolytic shallow gas.The influence of shallow gas on offshore platform is mainly manifested in two aspects of deformation and instability.This conclusion has practical significance for taking targeted protective measures for offshore platform.
-
Key words:
- Bohai Bay /
- offshore platform /
- shallow gas /
- distribution /
- genetic mechanism
-
[1] Floodgate G D, Judd A D. The origins of shallow gas[J]. Continental Shelf Research, 1992, 12(10): 1145-1156. doi: 10.1016/0278-4343(92)90075-U
[2] 李萍, 杜军, 刘乐军, 等. 我国近海海底浅层气分布特征[J]. 中国地质灾害与防治学报, 2010, 21(1): 69-74. doi: 10.3969/j.issn.1003-8035.2010.01.015
[3] 邢磊, 焦静娟, 刘雪芹, 等. 渤海海域浅层气分布及地震特征分析[J]. 中国海洋大学学报, 2014, 47(11): 71-78. https://www.cnki.com.cn/Article/CJFDTOTAL-QDHY201711010.htm
[4] Young-Jun K, Snons C, Jong-Hwa C, et al. Identification of shallow gas by seismic data and AVO processing: Example from the southwestern continental shelf of the Ulleung Basin, East Sea, Korea[J]. Marine and Petroleum Geology, 2020, 117, DOI:10.1016/j.marpetgeo.2020.104346.
[5] 秦芹. 南海北部白云凹陷浅层气的地球物理识别、成因和运移模式的研究[D]. 中国科学院深海科学与工程研究所硕士学位论文, 2017.
[6] Hagen R A, Vogt P R. Seasonal variability of shallow biogenic gas in Chesapenke Bay[J]. Marine Geology, 1999, 158(1): 75-88. http://www.sciencedirect.com/science/article/pii/S0025322798001856
[7] Sauter E J, Muyakshin S I, Charlou J L, et al. Methane discharge from a deep-sea submarine mud volcano into the upper water column by gas hydrate-coated methane bubbles[J]. Earth and Planetary Science Letters, 2006, 243(3): 354-365. http://www.sciencedirect.com/science/article/pii/S0012821X0600077X
[8] 吴时国, 孙运宝, 李清平, 等. 南海深水地质灾害[M]. 北京: 科学出版社, 2019: 154-163.
[9] 杨鸿波, 齐恒之. 渤海油田浅层气井喷预防及控制技术[J]. 中国海上油气, 2004, 16(1): 43-46. doi: 10.3969/j.issn.1673-1506.2004.01.008
[10] 谭振华, 陈红, 沙东, 等. 大港滩海(浅海)区浅层气井喷原因分析及预防技术探讨[J]. 天然气地球科学, 2005, 16(3): 369-373. doi: 10.3969/j.issn.1672-1926.2005.03.024
[11] 夏真, 马胜中, 石要红. 伶仃洋海底浅层气的基本特征[J]. 第四纪研究, 2006, 26(3): 456-461. doi: 10.3321/j.issn:1001-7410.2006.03.019
[12] 叶银灿. 中国海洋灾害地质学[M]. 北京: 海洋出版社, 2012.
[13] 汪泽成, 刘和甫, 段周芳, 等. 黄骅坳陷中新生代构造负反转分析[J]. 地球科学, 1998, 23(3): 289-293. doi: 10.3321/j.issn:1000-2383.1998.03.015
[14] 李岳桐, 王文庆, 王刚, 等. 渤海湾盆地黄骅坳陷新构造运动特征及其控藏作用[J]. 东北石油大学学报, 2019, 43(6): 94-104. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201906011.htm
[15] 李延成. 渤海的地质演化与断裂活动[J]. 海洋地质与第四纪地质, 1993, 13(2): 25-33. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ199302003.htm
[16] 叶银灿, 陈俊仁, 潘国富, 等. 海底浅层气的成因、赋存特征及其对工程的危害[J]. 东海海洋, 2003, 21(1): 27-36. https://www.cnki.com.cn/Article/CJFDTOTAL-DHHY200301005.htm
[17] 琼斯, 金翔龙. 海洋地球物理[M]. 北京: 科学出版社, 2010.
[18] 田立柱. 渤海湾西北部浅表地层结构特征[D]. 吉林大学硕士学位论文, 2007.
[19] 杨子赓, 张志询, 王学言. 渤海湾北部浅海海洋地质环境演变与灾害地质问题[C]//寸丹集——庆贺刘光鼎院士工作50周年学术论文集. 1998.
[20] 钟方杰, 朱建群. 应用持水特征曲线预测浅层气藏压力[J]. 施工技术, 2007, 36(S): 494-496. https://www.cnki.com.cn/Article/CJFDTOTAL-SGJS2007S1173.htm
[21] 郁孟龙. 东海沿海浅层气体对水利工程的危害及防治措施[J]. 中国水利, 2011, 16: 37-40. https://www.cnki.com.cn/Article/CJFDTOTAL-SLZG201116019.htm
