Ore-controlling structure and deep prospecting of the Bayan Obo large-sized REE-Nb-Fe ore deposit, Inner Mongolia
-
摘要:
对白云鄂博超大型稀土-铌-铁矿田内褶皱及断层构造特征进行了剖析和总结，认为矿区内构造活动演化具有多期性，中元古代—海西期至少发育4期构造活动，包括近东西向控岩断层（F1）、近东西向逆-平移断层（F2）、近东西向褶皱和韧性剪切构造、北东向左行走滑正断层（F3），并将其对成岩成矿的影响及控制作用作了详细分析。认为：①沿白云石碳酸岩与顶底板围岩界线分布的近东西向断层控制了白云石碳酸岩的产出和矿体的形成；②白云石碳酸岩侵位之后，近东西向逆-平移断层对矿体进行了第一次破坏，导致主矿、东矿的深部矿体向东平移，钻孔WK14-01的深部矿体应为主矿深部的矿体平移所致；③成矿期后发育一期近南北向的挤压变形事件对矿体进行了第二次破坏，导致矿区白云鄂博群紧闭褶皱的形成和矿体发生透镜体化；④主矿、东矿之间的北东向左行走滑正断层对矿体进行了第三次破坏，导致主、东矿位置的错动。这些认识将对矿区深部及外围找矿工作具有重要的指导意义。
Abstract:Analysis on folds and faults of the Bayan Obo REE-Nb-Fe orefield indicates that its structural activities witnessed multi-stage evolution.There exist at least four periods of structural activities from Mesoproterozoic to Hercynian which control metallogenesis and diagenesis, including the nearly EW-trending litho-controlling fault (F1), the nearly EW-trending strike-slip fault (F2), the nearly EW-trending ductile shear zone and folds and the left lateral strike slip normal fault (F3).Based on a comprehensive analysis it is concluded that: a.The nearly EW-trending fault (F1) distributed along the boundary between dolomite carbonatite and hangingwall or footwall controls the intrusive occurrence and the formation of ore bodies; b.After the emplacement of dolomite carbonatite, the ore body was destroyed by the nearly EW-trending strike-slip faults (F2) for the first time.As a result, the deep ore bodies in the south of the Main and East mines moved from west to east, and the deep orebody encountered by borehole WK14-01 should be caused by the translation of deep orebody in the south of the Main mine; c.The post-ore NS-trending compression destroyed ore body for the second time and brought about tight folding of the Bayan Obo Group strata and lensing of ore body; d.The left lateral strike slip normal fault (F3) distributed between the main mine and east mine destroyed ore bodies for the third time and led to the dislocation of the Main mine and East mine.The above research results and understanding will be of great guiding significance to the prospecting in the deep and periphery of the mine.
-
-
[1] 刘玉宝. 浅议白云鄂博矿铌资源开发及展望[J]. 稀土信息, 2015, 378(9): 34-35. https://www.cnki.com.cn/Article/CJFDTOTAL-XTXX201509016.htm
[2] 周振玲, 李功元, 宋同云, 等. 内蒙古白云鄂博白云石碳酸岩的地质特征及其成因探讨[J]. 地质论评, 1980, 26(1): 35-42, 92. doi: 10.3321/j.issn:0371-5736.1980.01.006
[3] 孟庆昌. 白云鄂博碳酸岩矿床的成因特征[J]. 地质与勘探, 1981, (3): 10-17.
[4] Drew L J, Qing R M, Wei J S. The Bayan Obo iron-rare-earth-niobium deposits, Inner Mongolia, China[J]. Lithos, 1990, 26(1/2): 43-65. http://www.sciencedirect.com/science/article/pii/0024493790900408
[5] Le Bas M J, Keller J, 陶克捷, 等. 白云鄂博火成碳酸岩墙的研究[J]. 地质科学, 1992, (A12): 130-138. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX1992S1011.htm
[6] Le Bas M J, Spiro B, Yang X M. Oxygen, carbon and strontium isotope study of the carbonatitic dolomite host of the Bayan Obo Fe-Nb-REE deposit, Inner Mongolia, N China[J]. Mineralogical Magazine, 1997, 61(4): 531-541. http://ci.nii.ac.jp/naid/80009836693
[7] Le Bas M J, Yang X M, Taylor R N, et al. New evidence from a calcite-dolomite carbonatite dyke for the magmatic origin of the massive Bayan Obo ore-bearing dolomite marble, Inner Mongolia, China[J]. Mineralogy and Petrology, 2007, 90(3/4): 223-248. http://link.springer.com/10.1007/s00710-006-0177-x
[8] 郝梓国, 王希斌, 李震, 等. 白云鄂博碳酸岩型REE-Nb-Fe矿床——一个罕见的中元古代破火山机构成岩成矿实例[J]. 地质学报, 2002, 76(4): 525-540. doi: 10.3321/j.issn:0001-5717.2002.04.010
[9] Yang X M, Le Bas M J. Chemical compositions of carbonate minerals from Bayan Obo, Inner Mongolia, China: implications for petrogenesis[J]. Lithos, 2004, 72(1/2): 97-116. http://www.sciencedirect.com/science/article/pii/S0024493703001592
[10] Yang K F, Fan H R, M. Santosh, et al. Mesoproterozoic carbonatitic magmatism in the Bayan Obo deposit, Inner Mongolia, North China: Constraints for the mechanism of super accumulation of rare earth elements[J]. Ore Geology Reviews, 2011, 40(1): 122-131. doi: 10.1016/j.oregeorev.2011.05.008
[11] Fan H R, Hu F F, Yang K F, et al. Integrated U-Pb and Sm-Nd geochronology for a REE-rich carbonatite dyke at the giant Bayan Obo REE deposit, Northern China[J]. Ore Geology Reviews, 2014, 63: 510-519. doi: 10.1016/j.oregeorev.2014.03.005
[12] 袁忠信, 白鸽, 吴澄宇, 等. 内蒙白云鄂博铌, 稀土, 铁矿床的成矿时代和矿床成因[J]. 矿床地质, 1991, 10(1): 59-70, 58. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ199101007.htm
[13] 张宗清, 唐索寒, 王进辉, 等. 白云鄂博稀土矿床形成年龄的新数据[J]. 地球学报, 1994, 15(Z1): 85-94. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB4Z1.012.htm
[14] 任英忱, 张英臣, 张宗清. 白云鄂博稀土超大型矿床的成矿时代及其主要地质热事件[J]地球学报, 1994, 15(1/2): 95-101. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB4Z1.013.htm
[15] Wang J W, Mitsunobu Tatsumoto, Li X B, et al. A precise 232Th-208Pb chronology of fine-grained monazite: Age of the Bayan Obo REE-Fe-Nb ore deposit, China[J]. Geochimica et Cosmochimica Acta, 1994, 58(15): 3155-3169. doi: 10.1016/0016-7037(94)90043-4
[16] 刘兰笙, 高翎, 杜安道, 等. 白云鄂博稀土矿床中辉钼矿的铼-饿同位素年龄[J]. 矿床地质, 1996, 15(2): 188-191. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ199602009.htm
[17] 裘愉卓. 白云鄂博独居石SHRIMP定年的思考[J]. 地球学报, 1997, 18(z1): 211-213. https://cpfd.cnki.com.cn/Article/CPFDTOTAL-DQXB199711001070.htm
[18] Chao E C T, Back J M, Minkin J A, et al. The Sedimentary Carbonate-Hosted Giant Bayan Obo REE-Fe-Nb Ore Deposit of Inner Mongolia, China: A Cornerstone Example for Giant Polymetaliic Ore Deposits of Hydrotherrnal Origin[M]. United States Government Printing Office, Washington: 1997.
[19] 张宗清, 唐索寒, 王进辉, 等. 白云鄂博矿床形成于不同时代的信息——矿床西矿体的年龄和讨论[J]. 中国地质, 2003, 30(2): 130-137. doi: 10.3969/j.issn.1000-3657.2003.02.004
[20] 袁忠信. 再谈白云鄂博矿床的成矿时代和矿床成因[J]. 地质学报, 2012, 86(5): 683-686. doi: 10.3969/j.issn.0001-5717.2012.05.002
[21] 朱祥坤, 孙剑. 内蒙古白云鄂博矿床的稀土矿化时代与期次[J]. 地球学报, 2012, 33(6): 845-856. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201206002.htm
[22] Ling M X, Zhang H, Li He, et al. The Permian-Triassic granitoids in Bayan Obo, North China Craton: A geochemical and geochronological study[J]. Lithos, 2014, 190/191: 430-439. doi: 10.1016/j.lithos.2014.01.002
[23] Zhu X K, Sun J, and Pan C X. Sm-Nd isotopic constraints on rare-earth mineralization in the Bayan Obo ore deposit, Inner Mongolia, China[J]. Ore Geology Reviews, 2015, 64: 543-553. doi: 10.1016/j.oregeorev.2014.05.015
[24] Song W L, Xu C, Smith M P, et al. Genesis of the world's largest rare earth element deposit, Bayan Obo, China: Protracted mineralization evolution over 8: 65-74, 132[J]. Geology, 2018, 46(4): 323-326. doi: 10.1130/G39801.1
[25] 张培善, 陶克捷, 李方华. 中华铈矿Ba2Ce(CO3)3F——新发现的一种稀土矿物[J]. 矿物学报, 1981, (2): 65-74, 132. doi: 10.3321/j.issn:1000-4734.1981.02.001
[26] 张培善, 陶克捷. 氟碳铈钡矿(Cebaite)的新资料[J]. 地质科学, 1983, (4): 409-413. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX198304012.htm
[27] 傅平秋, 苏贤泽. 新矿物——白云鄂博矿[J]. 矿物学报, 1987, (4): 3-11, 99. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB198704000.htm
[28] 杨学明, 杨晓勇, 陈双喜, 等. 白云鄂博钡稀土氟碳酸盐矿物的新产状及其矿物学特征[J]. 科学通报, 1999, 44(9): 984-989. doi: 10.3321/j.issn:0023-074X.1999.09.021
[29] 张培善, 陶克捷, 杨主明, 等. 白云鄂博稀土、铌钽矿物及其成因探讨[J]. 中国稀土学报, 2001, (2): 97-102. doi: 10.3321/j.issn:1000-4343.2001.02.001
[30] 杨主明, 李禾. 白云鄂博矿物学研究新进展[C]//2007年中国稀土资源综合利用与环境保护研讨会论文集. 2007.
[31] Fan H R, Yang K F, Hu F F, et al. The giant Bayan Obo REE-Nb-Fe deposit, China: Controversy and ore genesis[J]. Geoscience Frontiers, 2016, 7(3): 335-344. doi: 10.1016/j.gsf.2015.11.005
[32] 谢玉玲, 曲云伟, 杨占峰, 等. 白云鄂博铁、铌、稀土矿床: 研究进展、存在问题和新认识[J]. 矿床地质, 2019, 38(5): 983-1003. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ201905003.htm
[33] Zhao G, Wilde S, Cawood P, et al. Tectonothermal history of the basement rocks in the western zone of the North China Craton and its tectonic implications[J]. Tectonophysics, 1999, 310(1/4): 37-53. http://www.sciencedirect.com/science/article/pii/S0040195199001523
[34] Zhao G, Sun M, Wilde S A, et al. Late Archean to Paleoproterozoic evolution of the North China Craton: Key issues revisited[J]. Journal of Asian Earthences, 2005, 24(5): 519-522. http://www.sciencedirect.com/science/article/pii/S1367912004001269
[35] Zhai M G. Cratonization and the Ancient North China Continent: A summary and review. Science[J] China Earth Sciences, 2011, 54(8): 1110-1120. doi: 10.1007/s11430-011-4250-x
[36] Zhai M G. Santoshcd. Metallogeny of the North China Craton: Link with secular changes in the evolving Earth[J]. Gondwana Research. 2013, 24(1): 275-297. doi: 10.1016/j.gr.2013.02.007
[37] Zhai M G, Hu B, Zhao T P, et al. Late Paleoproterozoic-Neoproterozoic multi-rifting events in the North China Craton and their geological significance: A study advance and review[J]. Tectonophysics, 2015, 662: 153-166. doi: 10.1016/j.tecto.2015.01.019
[38] Liu Y L, Yang G, Chen J F, et al. Re-Os dating of pyrite from Giant Bayan Obo REE-Nb-Fe deposit[J]. Chinese Science Bulletin, 2004, 49(24): 2627-2631. doi: 10.1360/04wd0185
[39] Smith M P, Campbell L S, Kynicky J. A review of the genesis of the world class Bayan Obo Fe-REE-Nb deposits, Inner Mongolia, China: Multistage processes and outstanding questions[J]. Ore Geology Reviews, 2015, 64: 459-476. doi: 10.1016/j.oregeorev.2014.03.007
[40] 李继亮. 白云鄂博群的酸性火山岩[J]. 地质科学, 1983, (1): 36-44. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX198301003.htm
[41] 周建波, 郑永飞, 杨晓勇, 等. 白云鄂博地区构造格局与古板块构造演化[J]. 高校地质学报, 2002, (1): 46-61. doi: 10.3969/j.issn.1006-7493.2002.01.006
[42] 张鹏远, 李双庆, 王长尧, 等. 白云鄂博地区地质构造特征[C]//中国地质科学院天津地质矿产研究所文集(28), 1993: 88.
[43] 费晓杰. 从同位素年龄看白云鄂博稀土-铌-铁矿床区域地质演化历史[J]. 地质与勘探, 2019, 55(2): 461-471. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKT201902002.htm
[44] 白瑾, 黄学光, 郭进京. 中国前寒武纪地壳演化(第二版)[M]. 北京: 地质出版社, 1996.
[45] 翟明国, 卞爱国. 华北克拉通新太古代末超大陆拼合及古元古代末-中元古代裂解[J]. 中国科学: 地球科学, 2000, 30(S1): 129-137. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2000S1016.htm
[46] 李江海, 钱祥麟, 黄雄南, 等. 华北陆块基底构造格局及早期大陆克拉通化过程[J]. 岩石学报, 2000, 16(1): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200001000.htm
[47] 李江海, 侯贵廷, 黄雄南, 等. 华北克拉通对前寒武纪超大陆旋回的基本制约[J]. 岩石学报, 2001, 17(2): 177-186. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200102000.htm
[48] 李江海, 牛向龙, 程素华, 等. 大陆克拉通早期构造演化历史探讨: 以华北为例[J]. 地球科学-中国地质大学学报, 2006, 31(3): 285-293. doi: 10.3321/j.issn:1000-2383.2006.03.001
[49] 耿元生, 万渝生, 沈其韩. 华北克拉通早前寒武纪基性火山作用与地壳增生[J]. 地质学报, 2002, (2): 199-208. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE200202009.htm
[50] Timothy M, Kusky, Li J H. Paleoproterozoic tectonic evolution of the North Chin Craton[J]. Journal of Asian Earth Sciences, 2003, 22(4): 383-397. doi: 10.1016/S1367-9120(03)00071-3
[51] 刘喜山. 大青山造山带中基底再造杂岩的特征及其指示意义[J]. 岩石学报, 1994, 10(4): 413-426. doi: 10.3321/j.issn:1000-0569.1994.04.005
[52] 范宏瑞, 杨奎锋, 胡芳芳, 等. 内蒙古白云鄂博地区基底岩石锆石年代学及对构造背景的指示[J]. 岩石学报, 2010, 26(5): 1342-1350. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201005002.htm
[53] 翟明国, 彭澎. 华北克拉通古元古代构造事件[J]. 岩石学报, 2007, (11): 2665-2682. doi: 10.3969/j.issn.1000-0569.2007.11.001
[54] 王楫, 李双庆, 王保良, 等. 狼山: 白云鄂博裂谷系[M]. 北京: 北京大学出版社, 1992: 16-71.
[55] Li S Z, Zhao G C, Sun M, et al. Are the South and North Liaohe Groups of North China Craton different exotic terranes? Nd isotope constraints[J]. Gondwana Research, 2006, 9(1/2): 198-208. http://www.sciencedirect.com/science/article/pii/S1342937X05000183
[56] 中国科学院地球化学研究所. 白云鄂博矿床地球化学[M]. 北京: 科学出版社, 1988.
[57] 刘继顺. 韧性剪切带中金成矿研究的若干问题[J]. 地质论评, 1996, 42(2): 123-128. doi: 10.3321/j.issn:0371-5736.1996.02.004
-
