南祁连哈拉湖地区中奥陶世花岗岩地球化学特征及年代学意义

李五福; 张新远; 曹锦山; 王国良; 王春涛; 王伟; 乔国栋; 刘建栋; 陈丽娟

南祁连哈拉湖地区中奥陶世花岗岩地球化学特征及年代学意义

1.
青海省地质调查院, 青海西宁 810012

2.
青海省青藏高原北部地质过程与矿产资源重点实验室, 青海西宁 810012

基金项目:
中国地质调查局项目《青海区域地质调查与片区总结》（编号：12120114079701）和《青海省德令哈市哈拉湖西地区四幅1：5万区域地质矿产调查》（编号：1212011221151）

详细信息

作者简介: 李五福(1982-), 男, 硕士, 高级工程师, 从事区域地质调查研究。E-mail:15422504@qq.com

通讯作者: 张新远(1988-), 男, 硕士, 工程师, 从事区域地质调查研究。E-mail:235299800@qq.com

中图分类号: P534.42;P588.12⁺1

收稿日期: 2018-11-27

修回日期: 2019-01-18

刊出日期: 2020-03-15

Geochemical characteristics and chronological significance of Middle Ordovician granite in Halahu area of southern Qilian Mountain

1.
Geological Survey Institute of Qinghai Province, Xi'ning 810012, Qinghai, China

2.
Northern Tibetan Plateau Geological Process and Mineral Resources Key Laboratory of Qinghai Province, Xi'ning 810012, Qinghai, China

More Information

Corresponding author: ZHANG Xinyuan, 235299800@qq.com

Received Date: 27 November 2018

Revised Date: 18 January 2019

Publish Date: 15 March 2020

摘要

摘要:
哈拉湖地区奥陶纪花岗岩相对富钠（Na₂O>K₂O），具有中钾-高钾钙碱性系列特征，岩石类型以辉长闪长岩和花岗闪长岩为主。岩石稀土及微量元素特征均显示物质来源有地幔物质参与，构造环境判别图显示形成于大洋俯冲的环境。利用LA-ICP-MS进行锆石U-Pb同位素年龄测定，样品锆石²⁰⁶Pb/²³⁸U年龄加权平均值为466±4 Ma，限定该花岗岩的形成时代为中奥陶世，该时期北祁连洋发生双向扩张俯冲，南部中祁连陆块遭受俯冲挤压，导致地幔物质上涌，同时陆壳部分熔融，岩体为两者混合形成的产物，该岩体年龄的确定为祁连洋的多阶段俯冲提供了新的证据。
- 南祁连 /
- 奥陶纪 /
- 岛弧 /
- 花岗岩
Abstract:
The Ordovician granite in the Hala Lake area is characterized by relatively rich sodium (Na₂O>K₂O) and medium potassium-high potassium calc-alkaline series.Rock types include gabbroic diorite and granodiorite.The whole-rock rare earth and trace element characteristics indicate that the material source was derived from mantle material, and the tectonic environment was most likely the island arc granite formed during the ocean subduction.The zircon U-Pb isotope ages were determined by LA-ICP-MS.These zircons yielded a ²⁰⁶Pb/²³⁸U weighted mean age of 466±4 Ma, suggesting that the granite was formed in Middle Ordovician.In the two-way expansion and subduction stage of the North Qilian Ocean, the southern Zhongqilian block was subjected to subduction and extrusion, which caused the mantle material to migrate upward.At the same time, the continental crust was partially melted and the intrusions were formed by the mixture of the two melts.The age of the intrusion provides new evidence for multi-stage subduction of the Qilian Ocean.
- South Qilian /
- Ordovician /
- island arc /
- granite

HTML全文

图 1 哈拉湖地区大地构造位置图(a, 据参考文献[35]修改)和地质简图(b)

Figure 1.

下载: 全尺寸图片幻灯片

图 2 哈拉湖中奥陶世侵入岩TAS图解^[36]

Figure 2.

下载: 全尺寸图片幻灯片

图 3 英云闪长岩野外(a)和镜下照片(b)

Figure 3.

下载: 全尺寸图片幻灯片

图 4 哈拉湖中奥陶世侵入岩SiO₂-K₂O(a)和AFM图解(b)

Figure 4.

下载: 全尺寸图片幻灯片

图 5 哈拉湖中奥陶世侵入岩稀土元素配分图(a)和原始地幔标准化微量元素蛛网图(b)

Figure 5.

下载: 全尺寸图片幻灯片

图 6 哈拉湖地区辉长闪长岩同位素测年锆石阴极发光图像(IU-Pb0803)

Figure 6.

下载: 全尺寸图片幻灯片

图 7 哈拉湖地区辉长闪长岩锆石U-Pb谐和图(a)和²⁰⁶Pb/²³⁸U年龄加权平均值图(b)(IU-Pb0803)

Figure 7.

下载: 全尺寸图片幻灯片

表 1 哈拉湖地区中奥陶世侵入岩地球化学分析结果

Table 1. Geochemical compositions of Middle Ordovician intrusions in Halahu area

样品号	ⅠGs2003	IGsC3097 -1	QⅣPM21GS5 -1	ⅠPm103Gs2 -1	ⅠPm103Gs16 -1	ⅠGS0809
岩性	石英闪长岩		英云闪长岩		辉长闪长岩
SiO₂	56.89	57.45	57.99	50.44	50.45	51.64
TiO₂	0.80	0.80	0.77	0.83	0.90	0.74
Al₂O₃	14.87	15.53	16.32	12.19	12.27	12.26
Fe₂O₃	3.47	3.97	3.78	2.23	2.14	1.36
FeO	4.12	3.73	4.75	7.65	7.67	8.80
MnO	0.12	0.12	0.16	0.17	0.18	0.20
MgO	4.71	4.41	3.79	9.07	8.99	9.46
CaO	5.14	4.48	3.30	10.08	10.11	6.85
Na₂O	2.64	2.81	5.56	2.10	2.34	2.35
K₂O	2.64	2.72	0.90	1.59	1.43	2.04
P₂O₅	0.26	0.27	0.14	0.17	0.23	0.24
烧失量	3.62	3.01	1.84	2.40	2.27	3.24
总量	99.71	99.70	99.73	99.76	99.74	99.74
Mg^#	60.32	59.57	51.86	65.41	65.25	64.33
A/NK	2.07	2.05	1.61	2.36	2.27	2.02
A/CNK	0.90	0.99	1.01	0.52	0.52	0.66
La	23.70	22.80	10.77	16.06	18.06	21.46
Ce	45.54	46.30	23.36	32.07	36.55	42.58
Pr	5.72	5.95	3.10	4.13	5.14	5.27
Nd	22.12	22.91	12.81	16.84	21.57	20.34
Sm	4.38	4.44	3.12	3.62	4.71	4.37
Eu	1.09	1.15	0.92	0.96	1.21	1.09
Gd	4.08	3.97	3.24	3.62	4.42	3.79
Tb	0.70	0.63	0.59	0.59	0.71	0.64
Dy	3.82	3.87	3.77	3.27	3.73	3.69
Ho	0.81	0.77	0.84	0.68	0.76	0.76
Er	2.27	2.15	2.46	1.85	2.09	2.07
Tm	0.35	0.34	0.38	0.30	0.32	0.34
Yb	2.32	2.07	2.50	2.00	2.04	2.04
Lu	0.35	0.31	0.37	0.32	0.30	0.30
Sr	474.99	484.95	300.81	428.41	448.96	277.45
Rb	87.91	87.36	20.10	35.85	28.86	61.12
Ba	671.66	760.40	246.84	379.85	439.84	405.40
Th	8.05	9.21	5.41	4.96	5.68	7.13
Ta	0.70	0.69	0.47	1.28	0.82	0.54
Nb	6.31	7.46	6.16	5.53	6.12	7.09
Zr	124.90	129.00	82.20	67.70	75.00	96.40
Hf	4.31	4.52	2.43	2.04	2.36	2.57
Cr	115.81	91.19	30.35	274.80	279.40	369.60
V	207.94	183.50		272.83	252.36	220.00
U	1.57	1.73	1.14	1.03	1.24	1.71
Y	20.22	19.43	20.56	17.40	19.09	17.77
Sc	19.20	18.18		38.23	41.17	30.16
注：主量元素含量单位为%，微量和稀土元素含量单位为10^-6

下载: 导出CSV

表 2 哈拉湖地区辉长闪长岩锆石U-Th-Pb同位素测定结果(IU-Pb0803)

Table 2. Zircon U-Th-Pb isotope determination results for gabbroic diorite in Halahu area

点号	Pb /10^-6	U /10^-6	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁸Pb/²³²Th	1σ	²³²Th/²³⁸U	1σ	²⁰⁶Pb/²³⁸U 年龄/Ma	1σ	²⁰⁷Pb/²³⁵U 年龄/Ma	1σ
1	59	777	0.0758	0.0008	0.602	0.012	0.0575	0.0009	0.0303	0.0010	0.0247	0.0005	471	5	478	10
2	98	714	0.1424	0.0014	1.342	0.019	0.0683	0.0008	0.0472	0.0013	0.137	0.001	858	8	864	12
3	41	502	0.0780	0.0008	0.620	0.013	0.0576	0.0011	0.0215	0.0006	0.572	0.003	484	5	490	10
4	44	574	0.0758	0.0007	0.598	0.009	0.0572	0.0008	0.0261	0.0006	0.318	0.002	471	5	476	7
5	23	294	0.0757	0.0007	0.590	0.014	0.0565	0.0012	0.0230	0.0005	0.3880	0.0004	470	5	471	11
6	38	474	0.0758	0.0007	0.592	0.012	0.0566	0.0011	0.0224	0.0005	0.528	0.001	471	5	472	10
7	41	570	0.0716	0.0007	0.565	0.010	0.0572	0.0009	0.0331	0.0008	0.2261	0.0001	446	5	455	8
8	49	590	0.0797	0.0008	0.640	0.009	0.0582	0.0008	0.0130	0.0004	0.924	0.002	494	4	502	7
9	91	1181	0.0762	0.0008	0.610	0.010	0.0581	0.0008	0.0224	0.0006	0.369	0.003	473	5	484	8
10	34	449	0.0743	0.0007	0.590	0.011	0.0576	0.0010	0.0242	0.0006	0.3392	0.0007	462	5	471	9
11	94	1275	0.0727	0.0007	0.576	0.008	0.0575	0.0007	0.0230	0.0005	0.3392	0.0004	453	4	462	7
12	53	676	0.0759	0.0007	0.598	0.014	0.0572	0.0013	0.0241	0.0006	0.3989	0.0004	472	4	476	11
13	19	244	0.0750	0.0008	0.599	0.018	0.0579	0.0016	0.0125	0.0003	0.946	0.005	466	5	477	14
14	43	568	0.0737	0.0007	0.577	0.011	0.0568	0.0010	0.0215	0.0005	0.4411	0.0003	458	5	462	9
15	73	995	0.0736	0.0007	0.578	0.009	0.0570	0.0009	0.0165	0.0004	0.450	0.003	458	4	463	7
16	46	762	0.0587	0.0006	0.446	0.007	0.0551	0.0008	0.0100	0.0003	0.7160	0.0005	368	5	374	6
17	60	821	0.0749	0.0007	0.589	0.010	0.0570	0.0008	0.0160	0.0005	0.317	0.002	465	4	470	8
18	44	564	0.0748	0.0007	0.583	0.012	0.0565	0.0011	0.0219	0.0006	0.490	0.001	465	4	466	9
20	28	405	0.0735	0.0007	0.576	0.013	0.0569	0.0013	0.0210	0.0005	0.0628	0.0000	457	4	462	11
21	35	471	0.0742	0.0007	0.585	0.011	0.0572	0.0009	0.0217	0.0005	0.3703	0.0004	462	4	468	8
22	150	1821	0.0732	0.0007	0.596	0.009	0.0590	0.0007	0.0210	0.0005	0.819	0.002	456	5	475	7
23	122	1841	0.0647	0.0006	0.498	0.007	0.0559	0.0007	0.0160	0.0004	0.497	0.002	404	4	411	6
24	95	1320	0.0722	0.0007	0.560	0.008	0.0563	0.0007	0.0226	0.0006	0.3214	0.0007	449	4	452	7

下载: 导出CSV

参考文献(49)

[1]	Song S G, Niu Y L, Zhang L F, et al.Time constraints on orogenesis from oceanic subduction to continental subduction, collision, and exhumation:an example from North Qilian and North Qaidam HP-UHP belts[J].Acta Petrologica Sinica, 2009, 25:2067-2077. http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSXB200909003.htm
[2]	许志琴, 徐惠芬, 张建新, 等.北祁连走廊南山加里东俯冲杂岩增生地体及其动力学[J].地质学报, 1994, 68:1-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199400804917
[3]	张雪亭, 杨生德, 杨站军, 等.青海省板块构造研究1:100万青海省大地构造说明书[M].北京:地质出版社, 2007:1-221.
[4]	Xiao W J, Windley B F, Yong Y, et al.Early Paleozoic to Devonian multiple-accretionary model for the Qilian Shan, NW China[J].Journal of Asian Earth Sciences, 2009, 35(3/4):323-333. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-j.jseaes.2008.10.001/
[5]	Yan Z, Aitchison J C, Fu C L, et al.Hualong Complex, South Qilian terrane:U-Pb and Lu-Hf constraints on Neoproterozoic micro-continental fragments accreted to the northern Proto-Tethyan margin[J].Precambrian Research, 2015, 266:65-85.
[6]	Xia L Q, Li X M, Yu J Y, et al.Mid-late Neoproterozoic to Early Paleozoic volcanism and tectonic evolution of the Qilianshan, NW China[J].Geo.Res.J., 2016, 9/12:1-41. https://www.sciencedirect.com/science/article/abs/pii/S2214242816300092
[7]	Zhang J X, Yu S Y, Mattinson C G..Early Paleozoic polyphase metamorphism in northern Tibet, China[J].Gondwana Research, 2017, 41:267-289. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=7367864fc4cf6d175a90dfd73ec90132
[8]	Fu C L, Yan Z, Guo X Q, et al.Assembly and dispersal history of continental blocks within the Altun-Qilian-North Qaidam mountain belt, NW China[J].International Geology Review, 2018:1-24. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=10.1080/00206814.2018.1428831
[9]	Lu S N, Li H K, Zhang C L, et al.Geological and geo-chronologicai evidence for the Precambrian evolution of the tarim Craton and surrounding continental fragments[J].Precambrian Research, 2008, 160:94-107. http://www.sciencedirect.com/science/article/pii/S0301926807001581
[10]	陈宣华, 邵兆刚, 熊小松, 等.祁连山带断裂构造体系、深部结构与构造演化[J].中国地质, 2019, 46(5):995-1020.
[11]	Wang Q Y, Pan Y M, Chen N S.Proterozoic polymetamorphism in the Quanji Block, northwestern china:evidence from microtextures, garnet compositions and monazite CHIME ages[J].Journal of Asian Earth Sciences, 2009, 34:686-698. http://www.sciencedirect.com/science/article/pii/S1367912008001600
[12]	Song S G, Niu Y L, Zhang L F, et al.Tectonic evolution of early Paleozoic HP metamorphic rocks in the North Qilian Mountains, NW China:New perspectives[J].Journal of Asian Earth Sciences, 2009, 35:334-353. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-j.jseaes.2008.11.005/
[13]	Xu Y J, Du Y S, Cawood P A, et al.Detrital zircon record of continental collision:assembly of the Qilian Orogen, China[J].Sedimentary Geology, 2010, 230(1/2):35-45. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-j.sedgeo.2010.06.020/
[14]	Zhang Z W, Li W Y, Gao Y B, et al.Sulfide mineralization associated with arc magmatism in the Qilian Block, western china:zircon U-Pb age and Sr-Nd-Os-S isotope constraints from the Yulonggou and Yaqu gabbroic intrusions[J].Mineralium Deposita, 2014, 49(2):279-292. http://link.springer.com/article/10.1007/s00126-013-0488-x
[15]	李文渊.古亚洲洋与古特提斯洋关系初探[J].岩石学报, 2018, 34(8):2201-2210. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201808001
[16]	Song S G, Niu Y L, Su L, et al.Tectonics of the North Qilian orogeny, NW China[J].Gondwana Research, 2013, 23:1378-1401. http://www.sciencedirect.com/science/article/pii/S1342937X12000445
[17]	许志琴, 张建新, 许惠芬, 等.中国主要大陆山链韧性剪切带及动力学[M].北京:地质出版社, 1997:1-99.
[18]	冯益民, 何世平.祁连山大地构造与造山作用[M].北京:地质出版社, 1996:1-101.
[19]	张建新, 许志琴, 陈文, 等.北祁连中段增生杂岩/火山弧的时代探讨[J].岩石矿物杂志, 1997, 16(2):112-119. http://www.cqvip.com/Main/Detail.aspx?id=2511814
[20]	夏林圻, 夏祖春, 徐学义.北祁连山奥陶纪弧后盆地火山岩浆成因[J].中国地质, 2003, 30(1):48-60. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi200301006
[21]	Song S G, Yang L M, Zhang Y Q, et al.Qi-Qin accretionary belt in Central China Orogen:Accretion by trench jam of oceanic plateau and formation of intra-oceanic arc in the Early Paleozoic Qin-Qi-Kun Ocean[J].Science Bulletin, 2017, 62:1035-1038. http://www.cqvip.com/QK/86894X/201715/673136310.html
[22]	吴才来, 徐学义, 高前明, 等.北祁连早古生代花岗质岩浆作用及构造演化[J].岩石学报, 2010, 26(4):1027-1044. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201004003
[23]	宋述光, 张立飞, Niu Y, 等.青藏高原北缘早古生代板块构造演化和大陆深俯冲[J].地质通报, 2004, 23(9/10):918-925. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=200409164&flag=1
[24]	丁仨平, 裴先治, 李佐臣, 等.祁连造山带中段雾宿山群的构造属性探讨[J].中国地质, 2008, 35(4):577-589. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi200804002
[25]	刘志武, 王崇礼, 石小虎.南祁连党河南山花岗岩类特征及其构造环境[J].现代地质, 2006, 20(4):545-554. http://d.old.wanfangdata.com.cn/Periodical/xddz200604004
[26]	师江朋, 霍腾飞, 来强, 等.南祁连北缘东段早志留世刚察大寺花岗岩的成因:锆石LA-ICP-MS U-Pb年代学和岩石地球化学制约[J].地球学报, 2015, 36(6):781-789. http://d.old.wanfangdata.com.cn/Periodical/dqxb201506013
[27]	罗志文, 张志诚, 李建锋, 等.中南祁连西缘肃北三个洼塘地区古生代两类花岗质侵入岩年代学及其地质意义[J].岩石学报, 2015, 31(1):176-188. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201501013
[28]	郭周平, 李文渊, 张照伟, 等.南祁连化隆地区鲁满山花岗岩的岩石成因:地球化学、锆石U-Pb年代学及Hf同位素约束[J].中国地质, 2015, 42(4):864-880. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi201504006
[29]	Yang H, Zhang H F, Luo B J, et al.Early Pale0zoic intrusive rocks from the eastern Qilian Orogen NE Tibetan plateau:petrogenesis and tectonic significance[J].Lithos, 2015, 224/225:13-31.
[30]	李春昱, 刘仰文, 朱宝清, 等.秦岭及祁连山构造发展史[C]//国际交流地质学术论文集(1).北京: 地质出版社, 1978: 174-187.
[31]	李五福, 张新远, 王春涛, 等.祁连山哈拉湖地区奥陶纪岛弧火山岩及其构造意义[J].地质通报, 2019, (388):1287-1296. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20190804&flag=1
[32]	左国朝, 张淑玲, 程建生, 等.祁连地区蛇绿岩带划分及其构造意义[C]//张旗.蛇绿岩与地球动力学研究.北京: 地质出版社, 1996: 129-134.
[33]	Wan Y S, Zhang J X, Yang J S, et al.Geochemistry of highgrade metamorphic rocks of the North Qaidam Mountains and their geological significance[J].Journal of Asian Earth Sciences, 2006, 28:174-184. http://www.sciencedirect.com/science/article/pii/S1367912006000307
[34]	何世平, 李荣社, 王超, 等.祁连山西段甘肃肃北地区北大河岩群片麻状斜长角闪岩的形成时代[J].地质通报, 2010, 29(9):1275-1280. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20100903&flag=1
[35]	Song S G, Niu Y L, Su L, et al.Continental orogenesis from ocean subduction, continent collision/subduction, to orogen collapse, and orogen recycling:The example of the North Qaidam UHPM belt, NW China[J].Earth-Science Reviews, 2014, 129:59-84. http://www.sciencedirect.com/science/article/pii/S0012825213002055
[36]	Middlemost E A K.Naming materials in the magma/igneous rock system[J].Earth Science Reviews, 1994, 37(3/4):215-224. http://www.sciencedirect.com/science/article/pii/0012825294900299
[37]	Peccerillo R, Taylor S R.Geochemistry of eocene calc-alkaline volcanic rocks from the Kastamonu area, Northern Turkey[J].Contributions to Mineralogy & Petrology, 1976, 58(1):63-81. http://d.old.wanfangdata.com.cn/NSTLQK/10.1007-BF00384745/
[38]	Irvine T N, Baragar W R A.A guide to the chemical classification ofthe common volcanic rocks[J].Canadian Journal of Earth Sciences, 1971, 8(5):523-548. https://link.springer.com/article/10.1007%2FBF02596878
[39]	Boynton W V.Cosmochemistry of the Rare Earth Elements:Meteoric Studies[J].Rare Earth Element Geochemistry, 1984, 2:63-114. https://www.sciencedirect.com/science/article/pii/B9780444421487500083
[40]	Sun S S, Mcdonough W F.Chemical and lsotopic Systematics of Oceanic Basalts:Implications for Mantle Composition and Processes[J].Geological Society London Special Publications, 1989, 42(1):313-345. https://www.researchgate.net/publication/231575101_Chemical_and_isotopic_systematics_of_oceanic_basalts_Implications_for_mantle_composition_and_processes
[41]	冯益民.祁连山大地构造与造山作用[M].北京:地质出版社, 1996.
[42]	夏林圻, 夏祖春.北祁连山古洋壳火山作用基本特征[C]//中国矿物学岩石学地球化学研究新进展学术交流会, 1994.
[43]	夏林圻, 夏祖春, 徐学义.北祁连山奥陶纪弧后盆地火山岩浆成因[J].中国地质, 2003, 30(1):48-60. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi200301006
[44]	张建新, 孟繁聪.北祁连和北阿尔金硬柱石榴辉岩:冷洋壳俯冲作用的证据[J].科学通报, 2006, 51(14):1683-1688. http://d.wanfangdata.com.cn/Periodical/kxtb200614011
[45]	张建新, 孟繁聪, Mattinson C G.南阿尔金-柴北缘HP/UHP变质带研究进展、问题及挑战[J].高校地质学报, 2007, 13(3):526-545.
[46]	张建新, 许志琴.北祁连中段加里东俯冲-增生杂岩/火山弧带及其变形特征[J].地球学报, 1995, (2):36-46. http://www.cnki.com.cn/Article/CJFDTotal-DQXB502.003.htm
[47]	董顺利, 李忠, 高剑, 等.阿尔金-祁连-昆仑造山带早古生代构造格架及结晶岩年代研究进展[J].地质论评.2013, 59(4):731-747. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=HYC201405070000001439
[48]	Zhang Y Q, Song S G, Yang L M, et al.Basalts and picrites from a plume-type ophiolite in the South Qilian Accretionary Belt, Qilian Orogen:Accretion of a Cambrian Oceanic Plateau?[J].Lithos, 2017, 278:97-110.
①	宋述光, 苏犁, 张贵宾, 等.秦-祁-昆地区典型高压变质带与蛇绿混杂岩带关系研究.北京大学, 2015: 1-505.
