Zircon U-Pb ages and geochemical characteristics of Early Indosinian Liuwanshan granites, Guangxi
-
摘要:
广西六万山印支早期花岗岩的岩性主要为堇青黑云二长花岗岩,根据岩石结构特征及侵入接触关系可划分为4个侵入单元。利用LA-ICP-MS U-Pb同位素测定技术,4个侵入单元的锆石206Pb/238U年龄加权平均值分别为252.8±1.9Ma(MSWD=0.92)、249.2±1.9Ma(MSWD=1.2)、248.3±3.2Ma(MSWD=2.1)、246.8±2.8Ma(MSWD=2.2)。地球化学分析结果表明,花岗岩在岩石化学上富集大离子亲石元素Rb、K等,相对亏损高场强元素Ta、Nb、Ti等,反映出与俯冲带有关的岛弧岩浆岩相似的地球化学特征。稀土元素球粒陨石标准化配分曲线呈右倾型,具明显的Eu负异常,相对富集重稀土元素,与典型壳源花岗岩配分曲线一致。部分熔融与分离结晶模型(La/Sm-La)显示,花岗岩主要由部分熔融作用形成,演化过程经历了一定程度的分离结晶作用。结合花岗岩岩石化学特征、微量元素地球化学特征及花岗岩构造环境判别图解,认为六万山印支早期花岗岩的形成经历了早期洋-陆俯冲阶段到晚期陆-陆碰撞阶段的构造演化过程。
-
关键词:
- 六万山 /
- LA-ICP-MS锆石U-Pb年龄 /
- 地球化学 /
- 花岗岩成因
Abstract:The Liuwanshan granites consist mainly of cordierite-bearing biotite monzogranite, which can be divided into four emplacement units according to rock structure and the emplacement relationship. LA-ICP-MS zircon U-Pb dating shows that the 206Pb/238U weighted average ages of zircons from these emplaced units are 252.8±1.9Ma (MSWD=0.92), 249.2±1.9Ma (MSWD=1.2), 248.3 ± 3.2Ma (MSWD=2.1), and 246.8 ± 2.8Ma (MSWD=2.2), respectively. Geochemical data reveal that these granites are characterized by enrichment of large ion lithophile elements (LILE, such as Rb and K) and relative depletion of high field strength elements (HFSE, such as Nb, Ta and Ti), suggesting geochemical characteristics of typical subduction-related arc magmatic rocks. REE distribution patterns show right-inclined shape with obvious Eu negative anomaly and relative enrichment of HREE, which is consistent with crust-source granites distribution patterns. La-La/Sm diagram indicates that the Liuwanshan granites were mainly formed by partial melting and experienced a certain degree of fractional crystallization. Combined with petrochemical characteristics, trace elements geochemeical characteristics and tectonic setting discrimination diagrams, the authors have reached the conclusion that Liuwanshan granites were formed in a tectonic setting of early ocean-continent subduction and later continental collision.
-
Key words:
- Liuwanshan /
- LA-ICP-MS zircon U-Pb dating /
- geochemestry /
- genesis of granites
-
-
图 4 六万山印支早期花岗岩特征值相关曲线(图例代号同图 1)
Figure 4.
图 6 六万山印支早期花岗岩La-La/Sm图解(图例代号同图 1)
Figure 6.
图 7 六万山印支早期花岗岩的构造环境判别图解(图例代号同图 1)
Figure 7.
表 1 六万山印支早期花岗岩主量、微量和稀土元素组成及其相关参数
Table 1. Major, trace elements and REE composition and related parameters of Early Indosinian Liuwanshan granites
侵位单元
样品编号ηγcT11 ηγcT21 ηγcT31 ηγcT61 D4054-
Rz1D4059-
Rz1D5170-
Rz1D5174-
Rz1D2706-
Rz1D1210-
Rz1D2682-
Rz1D1054-
TW1PM03-37-
Rz1PM03-
43-GSYPM03-
9-XT1D2524-
Rz1PM03-
41-Rz1D5361-
Rz2D1218-
Rz2D5475-
Rz1SiO2 73.33 68.99 68.35 70.87 70.18 76.82 73.29 72.70 70.11 72.33 69.08 74.49 76.21 75.42 76.76 73.66 TiO2 0.65 0.60 0.63 0.58 0.54 0.30 0.48 0.41 0.47 0.15 0.34 0.39 0.08 0.08 0.12 0.15 Al2O3 16.51 17.56 15.49 14.05 14.30 11.87 13.11 13.12 14.91 15.40 16.26 12.52 13.51 13.09 13.25 13.64 Fe2O3 0.86 1.27 1.17 1.06 0.43 0.02 0.21 0.10 0.11 0.10 1.35 0.12 0.32 0.28 0.28 0.60 FeO 2.12 2.24 2.84 2.64 3.19 2.18 2.97 2.28 2.99 0.93 1.17 2.17 0.36 0.67 0.12 2.11 CaO 0.09 0.27 2.50 1.32 1.83 0.63 1.01 1.27 0.96 0.18 0.16 1.45 0.26 0.31 0.27 0.11 MgO 0.17 1.35 1.60 1.40 1.40 0.57 1.19 0.75 0.90 0.24 0.46 0.62 0.07 0.17 0.09 0.27 MnO 0.005 0.048 0.054 0.042 0.066 0.053 0.057 0.056 0.066 0.044 0.044 0.054 0.025 0.017 0.033 0.026 Na2O 0.19 0.46 2.29 2.10 2.14 1.85 1.93 2.09 1.51 1.50 1.48 2.02 2.19 2.18 2.32 0.83 K2O 3.60 4.56 2.78 3.92 3.90 4.26 4.03 4.64 5.28 6.44 6.46 4.66 5.42 6.95 5.81 6.14 P2O5 0.123 0.160 0.184 0.199 0.165 0.166 0.174 0.178 0.194 0.154 0.173 0.182 0.163 0.110 0.124 0.121 LOI (烧失量) 2.16 2.30 1.94 1.65 1.71 1.20 1.43 2.28 2.37 2.45 2.93 1.21 1.36 0.69 0.79 2.33 总量 99.82 99.81 99.84 99.83 99.86 99.92 99.87 99.88 99.88 99.93 99.91 99.88 99.98 99.98 99.97 99.98 Na2O+K2O 3.79 5.02 5.07 6.02 6.05 6.10 5.96 6.73 6.80 7.94 7.94 6.68 7.61 9.13 8.13 6.96 K2O/Na2O 18.90 9.87 1.21 1.87 1.82 2.30 2.08 2.22 3.49 4.28 4.36 2.31 2.47 3.18 2.51 7.43 A/CNK 3.77 2.84 1.37 1.39 1.29 1.35 1.40 1.22 1.50 1.58 1.67 1.14 1.36 1.12 1.25 1.66 A/NK 3.93 3.09 2.28 1.83 1.85 1.55 1.74 1.55 1.82 1.63 1.72 1.50 1.43 1.18 1.31 1.71 La 47.6 62.8 52.0 47.1 40.44 29.28 33.81 31.27 32.41 19.32 52.40 31.84 9.80 64.4 12.72 20.9 Ce 103.0 129.0 100.0 95.3 81.13 60.50 68.17 63.21 66.60 40.33 94.93 66.03 23.51 131 30.11 43.3 Pr 11.9 15.4 11.9 11.1 9.63 7.45 8.06 7.54 8.08 4.72 13.82 7.84 2.95 14.8 3.82 5.34 Nd 49.3 60.4 46.8 45.6 35.20 27.32 29.90 28.20 30.27 16.53 49.98 29.39 10.53 60.3 13.33 20.8 Sm 9.36 11.2 8.46 8.37 7.14 6.49 5.87 6.04 6.91 4.03 10.21 6.66 3.75 11.5 4.46 5.58 Eu 2.08 1.36 1.81 1.47 1.14 0.65 1.05 0.89 0.96 0.67 1.27 0.92 0.13 1.25 0.16 0.35 Gd 7.80 9.28 7.39 6.71 6.13 6.10 5.21 5.30 6.56 3.62 7.31 6.06 3.68 9.31 4.23 4.16 Tb 1.39 1.55 1.12 1.19 0.87 1.18 0.78 0.79 1.09 0.67 1.04 1.05 0.87 1.54 1.01 1.16 Dy 7.28 8.11 4.99 6.28 4.73 7.19 4.49 4.36 6.47 4.39 5.47 6.30 5.92 7.74 7.03 8.63 Ho 1.31 1.53 0.89 1.20 0.87 1.39 0.81 0.77 1.21 0.84 0.96 1.20 1.08 1.30 1.35 1.80 Er 3.14 3.90 2.17 2.93 2.27 3.63 2.23 2.06 3.08 2.24 2.55 3.18 2.54 3.06 3.46 4.25 Tm 0.60 0.73 0.38 0.55 0.37 0.59 0.36 0.33 0.49 0.38 0.41 0.52 0.39 0.49 0.60 0.91 Yb 3.26 4.14 2.17 3.11 2.19 3.46 2.12 2.12 2.94 2.36 2.40 3.05 2.16 2.60 3.30 4.65 Lu 0.49 0.62 0.31 0.45 0.37 0.57 0.33 0.36 0.46 0.44 0.43 0.48 0.47 0.40 0.65 0.77 Y 30.8 38.8 21.4 30.2 23.77 37.71 22.51 21.98 33.04 23.86 23.60 32.98 31.95 33.8 39.12 50.0 LREE 222.87 280.46 221.26 208.91 174.68 131.70 146.86 137.14 145.23 85.59 222.61 142.69 50.67 283.55 64.60 96.15 HREE 25.27 29.85 19.42 22.41 17.81 24.12 16.32 16.09 22.28 14.93 20.57 21.84 17.12 26.44 21.62 26.33 ΣREE 248.14 310.31 240.67 231.33 192.49 155.82 163.19 153.23 167.50 100.53 243.18 164.53 67.79 310.00 86.23 122.49 LREE/HREE 8.82 9.39 11.39 9.32 9.81 5.46 9.00 8.52 6.52 5.73 10.82 6.53 2.96 10.72 2.99 3.65 δEu 0.744 0.408 0.698 0.598 0.526 0.318 0.581 0.481 0.434 0.537 0.448 0.445 0.104 0.370 0.114 0.223 δCe 1.058 1.019 0.988 1.021 1.008 1.004 1.012 1.010 1.009 1.036 0.865 1.025 1.071 1.042 1.059 1.004 (La/Yb)N 10.48 10.88 17.20 10.86 13.22 6.07 11.45 10.58 7.92 5.86 15.68 7.48 3.26 17.76 2.76 3.22 (La/Sm)N 3.28 3.63 3.97 3.63 3.66 2.91 3.72 3.34 3.03 3.10 3.31 3.08 1.69 3.62 1.84 2.42 (Gd/Yb)N 1.98 1.85 2.82 1.78 2.31 1.46 2.03 2.07 1.85 1.27 2.52 1.64 1.41 2.96 1.06 0.74 Li 33.4 56.9 39.2 46.6 79.64 54.37 47.23 56.23 30.79 33.61 71.09 33.23 22.31 13.7 19.24 69.8 Be 0.97 1.86 1.86 1.63 2.74 2.20 1.95 1.91 3.17 1.30 2.36 1.72 2.27 0.88 0.81 1.04 Sc 10.23 8.84 7.86 8.93 10.25 10.16 13.67 10.22 6.47 5.75 7.95 8.88 3.83 1.95 8.26 3.30 V 63.8 63.5 59.4 58.4 60.6 43.2 72.0 52.9 42.1 22.0 40.4 42.0 13.7 6.33 20.3 3.43 Cr 31.9 27.7 34.5 28.6 37.5 25.3 41.3 24.3 26.7 13.0 18.9 18.2 10.8 1.94 11.0 1.93 Co 2.69 9.83 11.2 9.65 10.2 4.5 9.8 6.4 7.8 2.4 6.8 4.7 1.2 1.38 0.2 2.31 Ni 7.21 17.2 17.5 19.0 20.1 9.4 22.7 11.7 12.5 3.7 8.9 7.4 1.5 0.72 0.8 2.03 Ga 21.0 20.4 18.4 19.1 20.26 16.97 19.59 19.87 22.68 20.22 22.03 16.98 19.39 12.7 18.10 16.0 Rb 123 167 72.2 175 223.5 275.0 221.9 271.5 326.8 360.4 356.5 224.0 342.6 266 345.3 332 Sr 104 40.1 115 95.3 104.5 33.6 92.4 71.7 54.5 33.2 44.4 59.1 12.8 34.6 14.2 8.8 Zr 299 315 292 268 201.4 161.4 170.5 177.7 185.2 111.9 178.0 196.6 75.5 104 96.0 104 Nb 10.8 10.5 9.17 13.2 17.77 13.39 19.78 16.31 12.36 10.08 13.93 13.57 13.93 3.04 13.34 10.5 In 0.083 0.058 0.061 0.069 0.12 0.12 0.10 0.11 0.10 0.12 0.11 0.07 0.14 0.046 0.10 0.11 Cs 6.3 13.7 8.63 16.3 31.14 23.46 15.57 18.13 19.37 16.03 21.40 11.05 9.68 6.64 8.43 14.7 Ba 568 638 421 531 494.0 173.6 591.7 516.5 538.4 285.3 391.2 401.6 23.0 54.5 25.3 35.7 Hf 10.2 11.4 10.5 8.83 7.16 6.18 5.60 5.62 9.79 4.82 7.79 9.54 3.30 3.71 3.37 3.54 Ta 1.11 1.22 0.82 1.33 1.40 0.86 1.68 1.42 1.50 1.23 1.47 1.06 2.15 0.48 1.46 1.43 W 1.99 1.15 0.92 1.28 2.86 2.39 1.02 0.68 3.81 3.30 2.63 1.43 2.16 2.29 3.11 1.79 Tl 0.48 0.70 0.51 0.78 1.23 1.29 0.97 1.32 1.76 1.61 1.81 1.01 1.81 1.28 1.51 1.47 Pb 40.8 38.0 24.2 32.1 30.9 25.0 31.3 34.1 34.7 42.6 46.0 28.2 32.2 44.4 32.0 33.0 Bi 0.69 0.86 0.52 0.56 0.15 0.27 0.48 0.65 0.78 0.65 1.30 0.30 0.85 7.52 1.07 1.49 Th 15.5 21.4 12.9 16.9 16.35 11.63 13.33 12.11 21.46 11.42 16.09 14.85 13.7 8.26 11.49 12.4 U 4.55 3.61 2.82 3.36 4.59 3.69 3.84 8.07 7.13 3.51 3.97 4.93 6.3 4.58 5.93 4.49 Sn 5.97 5.30 2.51 3.66 5.7 5.7 4.7 6.6 4.4 8.1 9.9 4.4 7.3 3.61 6.8 7.25 As 89.0 1.8 3.0 4.5 3.9 6.1 1.2 8.6 17.8 1.2 3.1 1.6 0.9 1.5 6.2 1.3 Sb 15.1 0.25 0.20 0.45 0.05 0.20 0.05 0.75 0.65 0.14 0.28 0.12 0.23 0.17 0.42 0.21 注:样品岩石地球化学分析由河北省区域地质矿产调查研究所实验室完成。其中ηγcT119件;ηγcT21 19件;ηγcT31 10件;ηγcT61 8件,文中仅对每个侵位单元列出4个,共12个样品的分析结果。铝饱和指数A/CNK=Al2O3/(CaO+Na2O+K2O)(摩尔分数比);A/NK=Al2O3/(Na2O+K2O) (摩尔分数比),比值单位为1。主量元素含量单位为%,稀土和微量元素含量为10-6。ηγcT21 —中细粒堇青黑云二长花岗岩;ηγcT21 —中粒(斑状)堇青黑云二长花岗岩;ηγcT31 —中粗粒(斑状)堇青黑云二长花岗岩;ηγcT61 —细粒堇青黑云二长花岗岩 表 2 六万山印支早期花岗岩单颗粒锆石U-Th-Pb同位素测定结果
Table 2. U-Th-Pb isotopic dating results for the single-grain zircon from Early Indosinian Liuwanshan granites
点
号Pb 232Th 238U 同位素比值 年龄/Ma /10-6 207Pb/206Pb 1δ 207Pb/235U 1δ 206Pb/238U 1δ 208Pb/232Th 1δ 207Pb/206Pb 1δ 207Pb/235U 1δ 206Pb/238U 1δ 208Pb/ 232Th 1δ D4054-Rz1 1.1 111 166 2939 0.0526 0.0017 0.306 0.010 0.04194 0.00053 0.01434 0.00079 322 75.9 271 8.1 265 3.3 288 16 2.1 259 435 2219 0.0564 0.0016 0.497 0.017 0.06349 0.00115 0.02375 0.00065 465 30.6 410 11.4 397 7.0 474 13 3.1 46 184 415 0.0576 0.0044 0.249 0.024 0.03977 0.00068 0.01177 0.00061 517 215 226 19.4 251 4.2 237 12 4.1 141 364 619 0.0530 0.0030 0.456 0.023 0.06243 0.00121 0.01872 0.00066 332 128 382 15.7 390 7.4 375 13 5.1 75 158 1135 0.0548 0.0026 0.301 0.015 0.03988 0.00044 0.01192 0.00066 467 105.5 267 11.3 252 2.7 240 13 6.1 130 157 4231 0.0497 0.0016 0.265 0.009 0.03896 0.00070 0.01393 0.00077 189 75.9 238 7.5 246 4.3 280 15 7.1 73 242 1057 0.0549 0.0027 0.307 0.015 0.04057 0.00052 0.01156 0.00055 469 114 272 11.8 256 3.2 232 11 8.1 75 154 1541 0.0471 0.0019 0.263 0.011 0.04032 0.00039 0.01355 0.00071 102 96.3 237 9.0 255 2.4 272 14 9.1 125 490 1253 0.0547 0.0023 0.303 0.013 0.04017 0.00043 0.01247 0.00040 467 94.4 269 10.0 254 2.6 251 8 10.1 320 404 994 0.0684 0.0022 1.151 0.052 0.11749 0.00393 0.03355 0.00140 880 66.7 778 24.5 716 22.7 667 27 11.1 70 160 1569 0.0534 0.0020 0.291 0.011 0.03963 0.00041 0.01169 0.00065 343 87.0 259 8.5 251 2.6 235 13 12.1 249 244 1379 0.0697 0.0020 1.019 0.034 0.10484 0.00180 0.03825 0.00138 920 63.9 713 17.1 643 10.5 759 27 13.1 141 121 4343 0.0568 0.0017 0.321 0.010 0.04060 0.00048 0.01691 0.00109 483 64.8 283 8.0 257 3.0 339 22 14.1 59 131 1356 0.0515 0.0024 0.279 0.013 0.03970 0.00041 0.01339 0.00078 265 107 249 10.0 251 2.5 269 16 15.1 99 176 916 0.0572 0.0022 0.629 0.039 0.07403 0.00308 0.02172 0.00128 502 85.2 495 24.1 460 18.5 434 25 16.1 78 129 1116 0.0618 0.0025 0.562 0.030 0.06275 0.00202 0.01601 0.00098 733 80.5 453 19.2 392 12.2 321 20 D2706-Rz1 1.1 42 0.0525 0.0028 0.248 0.015 0.03918 0.00050 0.01135 0.00090 316 137 225 11.8 248 3.1 228 18 2.1 64 193 981 0.0529 0.0025 0.384 0.021 0.05012 0.00120 0.01256 0.00066 324 107 330 15.7 315 7.3 252 13 3.1 54 122 1106 0.0555 0.0026 0.307 0.014 0.04047 0.00046 0.01610 0.00083 432 104 272 10.7 256 2.9 323 17 4.1 214 293 495 0.0709 0.0023 1.499 0.052 0.15255 0.00222 0.04467 0.00128 954 67.8 930 21.0 915 12.4 883 25 5.1 56 199 783 0.0531 0.0029 0.300 0.017 0.04110 0.00055 0.01356 0.00064 332 119 266 13.0 260 3.4 272 13 6.1 192 393 1240 0.0982 0.0039 1.156 0.065 0.07736 0.00258 0.02388 0.00151 1591 72.7 780 30.5 480 15.4 477 30 7.1 60 172 1231 0.0554 0.0024 0.302 0.013 0.03940 0.00045 0.01293 0.00071 428 96.3 268 10.3 249 2.8 260 14 8.1 54 258 549 0.0525 0.0036 0.213 0.019 0.03974 0.00059 0.01230 0.00060 317 87.8 196 16.0 251 3.7 247 12 9.1 168 269 1278 0.0758 0.0031 0.979 0.064 0.08211 0.00301 0.02837 0.00170 1100 83.3 693 32.7 509 17.9 566 33 10.1 80 218 1650 0.0504 0.0019 0.275 0.010 0.03940 0.00038 0.01270 0.00056 217 85.2 247 8.1 249 2.4 255 11 11.1 158 114 1854 0.0641 0.0014 0.849 0.020 0.09535 0.00098 0.02430 0.00116 746 47.1 624 10.9 587 5.8 485 23 12.1 54 115 748 0.0498 0.0025 0.359 0.019 0.05263 0.00109 0.02004 0.00109 183 119 312 14.1 331 6.7 401 22 13.1 49 163 1040 0.0504 0.0023 0.275 0.013 0.03964 0.00045 0.01030 0.00068 213 107 247 10.0 251 2.8 207 14 14.1 48 155 1008 0.0495 0.0025 0.263 0.013 0.03861 0.00042 0.01135 0.00071 169 114 237 10.6 244 2.6 228 14 15.1 49 204 618 0.0534 0.0034 0.288 0.018 0.03937 0.00056 0.01172 0.00060 346 143 257 14.2 249 3.5 236 12 16.1 72 398 619 0.0499 0.0032 0.268 0.017 0.03918 0.00051 0.01130 0.00042 191 156 241 13.6 248 3.2 227 8 PM03-29-Rz1 1.1 43 0.0510 0.0027 0.274 0.014 0.03931 0.00493 0.01193 0.00061 243 122 246 11.4 249 3.1 240 12 2.1 172 325 5160 0.0503 0.0013 0.254 0.008 0.03645 0.00061 0.01238 0.00050 209 93.5 229 6.2 231 3.8 249 10 3.1 63 144 1569 0.0502 0.0020 0.264 0.010 0.03816 0.00039 0.01346 0.00088 206 86.1 238 8.2 241 2.5 270 18 4.1 40 173 597 0.0494 0.0033 0.266 0.017 0.03984 0.00053 0.01155 0.00063 165 152 240 13.9 252 3.3 232 13 5.1 46 166 796 0.0482 0.0027 0.263 0.015 0.04020 0.00049 0.01294 0.00068 109 126 237 11.7 254 3.1 260 14 6.1 239 183 1843 0.0668 0.0025 0.974 0.083 0.08952 0.00525 0.04468 0.00342 833 77.8 691 42.7 553 31.1 884 66 7.1 60 194 1093 0.0512 0.0022 0.280 0.012 0.03969 0.00045 0.01295 0.00063 256 98.1 251 9.3 251 2.8 260 13 8.1 94 254 1912 0.0484 0.0018 0.282 0.012 0.04186 0.00071 0.01498 0.00068 117 91.7 253 9.6 264 4.4 301 14 9.1 36 165 410 0.0566 0.0052 0.300 0.027 0.03956 0.00064 0.01309 0.00067 476 238 267 21.2 250 4.0 263 14 10.1 42 184 493 0.0498 0.0046 0.220 0.024 0.04033 0.00069 0.01395 0.00075 187 78.6 202 20.3 255 4.3 280 15 PM03-29-Rz1 11.1 56 222 799 0.0529 0.0029 0.280 0.015 0.03843 0.00047 0.01282 0.00055 324 124 251 12.0 243 2.9 257 11 12.1 40 108 772 0.0560 0.0030 0.302 0.015 0.03938 0.00046 0.01494 0.00102 450 119 268 12.0 249 2.9 300 20 13.1 99 601 751 0.0503 0.0029 0.245 0.016 0.03993 0.00054 0.01219 0.00041 208 89.1 222 13.3 252 3.4 245 8 14.1 82 197 1228 0.0483 0.0019 0.336 0.017 0.04919 0.00129 0.01746 0.00087 117 86.1 294 12.7 310 8.0 350 17 15.1 72 261 1180 0.0498 0.0023 0.266 0.011 0.03913 0.00046 0.01363 0.00054 187 110 239 9.0 247 2.9 274 11 16.1 354 810 852 0.0639 0.0022 0.709 0.032 0.07852 0.00217 0.03283 0.00089 739 74.1 544 18.9 487 13.0 653 18 D1218-Rz2 1.1 53 142 1141 0.0537 0.0022 0.363 0.017 0.04860 0.00096 0.01336 0.00062 367 94.4 315 12.3 306 5.9 268 12 2.1 79 187 1724 0.0521 0.0030 0.278 0.016 0.03927 0.00054 0.01283 0.00050 300 130 249 12.6 248 3.4 258 10 3.1 65 233 1068 0.0517 0.0020 0.277 0.010 0.03908 0.00041 0.01177 0.00040 272 88.9 248 8.0 247 2.6 236 8 4.1 108 153 1601 0.0503 0.0023 0.263 0.012 0.03807 0.00039 0.01266 0.00053 209 110 237 9.3 241 2.4 254 11 5.1 95 142 516 0.0575 0.0039 0.417 0.031 0.05220 0.00142 0.01904 0.00066 509 150 354 22.1 328 8.7 381 13 6.1 60 261 692 0.0517 0.0021 0.292 0.012 0.04084 0.00052 0.01156 0.00058 333 95.4 260 9.6 258 3.2 232 12 7.1 34 153 339 0.0527 0.0030 0.276 0.016 0.03866 0.00058 0.01074 0.00037 322 125 248 12.3 245 3.6 216 8 8.1 125 201 874 0.0589 0.0024 0.309 0.013 0.03836 0.00048 0.01122 0.00053 565 86.1 273 9.8 243 3.0 225 11 9.1 64 249 882 0.0537 0.0017 0.321 0.012 0.04316 0.00080 0.01344 0.00062 367 74.1 283 8.9 272 4.9 270 12 10.1 58 164 705 0.0531 0.0020 0.281 0.010 0.03849 0.00037 0.01114 0.00037 332 87.0 252 8.2 243 2.3 224 7 11.1 62 140 1292 0.0576 0.0023 0.347 0.014 0.04357 0.00048 0.01440 0.00054 517 88.9 302 10.6 275 3.0 289 11 12.1 65 285 866 0.0495 0.0031 0.265 0.016 0.03958 0.00056 0.01131 0.00050 172 144 239 12.7 250 3.5 227 10 13.1 45 155 964 0.0540 0.0019 0.299 0.010 0.04007 0.00041 0.01085 0.00041 369 77.8 266 8.1 253 2.6 218 8 14.1 146 419 353 0.0555 0.0031 0.302 0.017 0.03980 0.00051 0.01195 0.00043 435 126 268 13.0 252 3.2 240 9 15.1 127 698 957 0.0544 0.0022 0.291 0.012 0.03886 0.00041 0.01139 0.00046 387 90.7 260 9.2 246 2.6 229 9 16.1 195 579 123 0.0547 0.0020 0.299 0.011 0.03954 0.00043 0.01211 0.00035 398 78.7 266 8.9 250 2.7 243 7 -
[1] 汪绍年.桂东南地区过铝花岗岩中堇青石研究[J].广西地质, 1990, 3(3):15-26. http://www.cnki.com.cn/Article/CJFDTOTAL-GXDZ199003001.htm
[2] 彭松柏, 金振民, 付建明. 大容山-十万大山花岗岩带中超高温麻粒岩包体的发现及其地质意义[R]. 全国岩石学与地球动力学研讨会, 2006.
[3] 罗修泉.广西大容山-十万大山花岗岩岩基地质年代表[J].岩石矿物学杂志, 1988, 11(1):31-42.
[4] 祁昌实, 邓希光, 李武显.桂东南大容山-十万大山S型花岗岩带的成因:地球化学及Sr-Nd-Hf同位素制约[J].岩石学报, 2007, 23(2): 403-412. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200702020.htm
[5] 覃小峰, 王宗起, 曹洁, 等.桂南钦防构造带西南段印支早期花岗岩的成因:年代学和地球化学约束[J].吉林大学学报 (地球科学版), 2013, 43(5):1472-1488. http://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201305014.htm
[6] 广西壮族自治区地质矿产局.广西壮族自治区区域地质志[M].北京:地质出版社, 1985:652-732.
[7] 邓希光, 陈志刚, 李献华, 等.桂东南地区大容山-十万大山花岗岩带SHRIMP锆石U-Pb定年[J].地质论评, 2004, 50(4):426-432. http://www.cnki.com.cn/Article/CJFDTOTAL-DZLP200404016.htm
[8] 汪绍年.大容山-十万大山岩带陆壳转生型花岗岩中包体初步研究[J].广西地质, 1987, (1):29-36. http://www.cnki.com.cn/Article/CJFDTOTAL-GXDZ198701003.htm
[9] 汪绍年.广西大容山-十万大山岩带中花岗岩类特征及成因[J].岩石学报, 1991, 5(2):73-80. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB199102010.htm
[10] 覃小峰, 李江, 李容森, 等.云开地块北缘博白-岑溪造山带的形成和演化[M].北京:北京大地出版社, 2008.
[11] 潘桂棠, 肖庆辉, 陆松年, 等.中国大地构造单元划分[J].中国地质, 2009, 36(1):1-28. http://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200901004.htm
[12] Yuan H L, Gao S, Liu X M. Accurate U-Pb age and trace element determinations of zircon by laser ablation-inductively coupled plas ma mass spectrometry[J]. Geostand Geoanaly Res., 2004, 28(3): 353-370. doi: 10.1111/ggr.2004.28.issue-3
[13] Anderson T. Correction of common lead in U-Pb analyses that do not report 204Pb[J]. Chem. Geol., 2002, 192:59-79. doi: 10.1016/S0009-2541(02)00195-X
[14] Ludwig K R. Users manual for Isoplot 3.00:A geochronological toolkit for Microsoft Excel[J]. Berkeley Geochron. Cent. Spec. Pub., 2003, 4: 25-32.
[15] 邱家骥.应用岩浆岩岩石学[M].武汉:中国地质大学出版社, 1991: 114-154.
[16] Sun S S, McDonough W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publication, 1989, 42: 313-345. doi: 10.1144/GSL.SP.1989.042.01.19
[17] 赵振华.关于微量元素构造环境判别图解使用的有关问题[J].大地构造与成矿学, 2007, 31(1):92-103. http://www.cnki.com.cn/Article/CJFDTOTAL-DGYK200701012.htm
[18] 李厚民, 沈远超, 毛景文, 等.石英、黄铁矿及其包裹体的稀土元素特征——以胶东焦家式金矿为例[J].岩石学报, 2003, 19(2): 267-274. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200302007.htm
[19] 杨帆, 肖荣阁, 李娜.内蒙古宝音图钼矿床花岗岩稀土元素地球化学特征及花岗岩成因[J].现代地质, 2013, 27(4):831-840. http://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201304011.htm
[20] 杨超群.华南不同成因花岗岩类的稀土元素地球化学特征[J].矿物岩石地球化学通报, 1986, 5(1):8-10. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH198601004.htm
[21] 亨德森P.稀土元素地球化学[M].北京:地质出版社, 1989: 20-188.
[22] Li X H, Li W X, Li Z X. On the genetic classification and tectonic implications of the Early Yanshanian granitoids in the Nanling Range South China[J]. Chinese Science Bulletin, 2007, 52(14): 1873-1885. doi: 10.1007/s11434-007-0259-0
[23] 王敏芳, 郭晓南, 覃莹.广西云开地区六万大山花岗岩体LAICP-MS锆石U-Pb年代学初探[J].矿物学报, 2013, S2:615. http://www.cnki.com.cn/Article/CJFDTOTAL-KWXB2013S2345.htm
[24] 陈海泓, 肖文交.多岛海型造山作用:以华南印支期造山带为例[J].地学前缘, 1998, 5(增刊):95-102. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY8S1.010.htm
[25] 王岳军, 范蔚茗, 席先武, 等.湖南印支期过铝质花岗岩的形成:岩浆地侵与地壳加厚热效应的数值模拟[J].中国科学 (D辑), 2002, 32(6):491-499. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK200206005.htm
[26] 许冬, 邹婷婷, 田静轩, 等.广西十万山盆地花岗岩类岩石学及地球化学初步研究[J].华南地质与矿产, 2004, 3: 43-49. http://www.cnki.com.cn/Article/CJFDTOTAL-HNKC200403007.htm
[27] 汪绍年.大容山-十万大山岩带花岗质岩石特征及其成因和演化[J].广西地质, 1984, 1(1):58-66.
[28] 汪洋, 邓晋褔.广西南部三叠纪强过铝质火成岩岩石化学特征的动力学意义[J].地质地球化学, 2003, 31(4):35-42. http://www.cnki.com.cn/Article/CJFDTOTAL-DZDQ200304006.htm
[29] 方晴浩, 冯君储, 何令仪.广西大容山S-型花岗岩套[J].岩石学报, 1987, 3:23-33. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB198703003.htm
[30] Barbarin B. Granitoids:Main petrogenetic classifications in relation to origin and tectonic setting[J]. Geol. J. Petrol., 1990, 42(12): 2279-3202. http://onlinelibrary.wiley.com/doi/10.1002/gj.3350250306/full
[31] Barbarin B. A review of the relationships between granitoid types, their origins and their geodynamic environments[J]. Lithos, 1999, 46:605-626. doi: 10.1016/S0024-4937(98)00085-1
[32] Pearce J A, Harris N B W, Tindle A G. Trace Element Discrimination Diagrams for the Tectonic Interpretation of Granitic Rocks[J]. Journal of Petrology, 1984, 25:956-983. doi: 10.1093/petrology/25.4.956
-
