LA-ICP-MS zircon U-Pb dating and geochemical characteristics of the volcanic rocks in Deren Formation, northern Liaoning Province
-
摘要:
通过对辽北平岗盆地中德仁组火山岩的岩石学、地球化学和年代学的研究，探讨了其岩石成因、形成时代、构造环境，以及华北克拉通东部岩石圈减薄时间和减薄机制。用LA-ICP-MS技术测定了平岗盆地中德仁组中部英安质角砾晶屑岩屑凝灰岩和上部流纹岩中的锆石U-Th-Pb同位素组成。获得前者的锆石206Pb/238U年龄为246.8±3.5Ma和169.6±4.6Ma，代表了2期岩浆活动的年龄，是平岗盆地基底早三叠世和中侏罗世岩浆活动的表现；后者的锆石206Pb/238U年龄为117.0±0.9Ma，表明流纹岩形成于早白垩世。德仁组火山岩富集大离子亲石元素K、Rb、Ba，亏损高场强元素Nb、Ta、Zr、Hf、Y、Yb；富集轻稀土元素，亏损重稀土元素，稀土元素配分曲线呈右倾型，表现出壳源特征。德仁组火山岩形成于活动大陆边缘火山弧环境，原始岩浆来源于盆地基底岩浆岩重熔。研究区在117~135Ma期间，发生了由正地形向负地形的重大转变，区域上发育伸展盆地和变质核杂岩，并在基底岩石重熔过程中受到地幔混染作用，表明研究区在早白垩世发生了岩石圈减薄，且减薄的起始时间早于117.0±0.9Ma，减薄机制为拆沉作用。
-
关键词:
- 平岗盆地 /
- 德仁组火山岩 /
- LA-ICP-MS锆石U-Pb测年 /
- 岩石圈减薄 /
- 英安质角砾晶屑岩屑凝灰岩 /
- 流纹岩
Abstract:This paper presents detailed petrologic, geochemical and geochronologic data of the volcanic rocks in Deren Formation of Pinggang Basin, northern Liaoning Province. The authors investigated their petrogenesis, formation age and tectonic settings and discussed the thinning time and mechanism of North China Craton. The LA-ICP-MS zircon U-Pb dating was conducted on dacitic breccia-crystal-lithic tuff in Deren Formation and the upper rhyolite. The former yielded 206Pb/238U ages of 246.8±3.5Ma and 169.6±4.6Ma which are supposed to represent two stages of magmatism, reflecting the Early Triassic and Middle Cretaceous magma activities in the basement of Pinggang Basin. The latter yielded 206Pb/238U age of 117.0±0.9Ma, which indicates that the rhyolites were formed in the Early Cretaceous. Volcanic rocks in Deren Formation are enriched in large ion lithophile elements (e.g., K, Rb, Ba) but are depleted in high field strength elements (e.g., Nb, Ta, Zr, Hf, Y, Yb). Besides, due to enrichment of LREEs and depletion of HREEs, the REE patterns exhibit right-inclined feature. These geochemical characteristics show that the source of the primitive magma was derived from the crust, and they were probably formed at the setting of volcanic arc along the active continental margins, resulting from remelting of the basement magma rocks. Major changes from positive to negative landform in the study area occurred during 117~135Ma. In combination with wide distribution of extensional basins and metamorphic core complexes, the authors hold that the magma might have been affected by mantle contamination during remelting of these basement rocks, and the thinning of lithosphere might have occurred during Early Cretaceous (earlier than 117±1.2Ma), which resulted in the delamination.
-
-
表 1 德仁组火山岩主量、微量和稀土元素分析结果
Table 1. Major, trace and rare earth elements of the volcanic rocks in Deren Formation
编号 PM020-20-TY1 PM020-25-TY1 PM020-26-TY1 PM020-27-TY1 PM020-19-TY1 PM022-10-TY1 PM022-20-TY1 PM020-18-TY1 PM022-6-TY1 PM022-6-TY2 岩性 流纹岩 流纹岩 流纹岩 流纹岩 英安岩 桁面岩 桁安岩 桁安岩 玄武桁安岩 玄武桁安岩 SiO2 72.2 71.4 73.24 73.64 66.14 62.18 61.14 62.12 49.68 51.80 TiO2 0.22 0.23 0.22 0.12 0.65 0.82 0.99 0.79 1.76 1.36 Al2O3 13.55 14.45 13.60 13.70 17.00 17.00 15.80 17.05 16.97 19.62 Fe2O3 1.26 1.10 1.26 0.92 0.77 2.70 2.01 1.86 4.69 1.84 Fe0 1.83 1.77 1.42 1.51 3.47 2.51 3.15 3.44 5.63 4.89 MnO 0.07 0.07 0.1 0.06 0.08 0.12 0.12 0.12 0.11 0.13 MgO 0.26 0.36 0.3 0.2 1.29 2.63 2.58 1.42 4.90 3.88 CaO 0.34 0.56 0.5 0.36 2.00 1.33 2.40 4.08 2.92 2.05 Na2O 3.63 3.76 3.67 3.95 3.22 4.22 4.53 4.39 2.92 4.60 K2O 4.92 4.39 4.62 4.46 3.89 4.10 2.93 2.77 4.54 3.95 P2O3 0.05 0.05 0.03 0.09 0.16 0.23 0.34 0.22 1.00 0.88 总计 98.33 98.14 98.96 99.01 98.67 97.84 95.99 98.26 95.12 95.0 烧失量 0.79 1.05 0.61 0.81 1.21 2.16 3.29 0.94 3.87 4.13 K 40255 35919 37801 36492 31828 33546 23973 22664 37146 32319 Rb 124 102 171 163 139 106 54.6 93 126 88.3 Ba 620 923 358 246 861 1367 1054 634 2587 2174 Th 8.65 8.65 12.7 14.0 8.95 9.24 4.62 9.52 9.69 10.0 Ta 1.07 1.25 1.84 1.95 1.37 0.69 0.56 1.20 1.23 1.14 Nb 15.3 14.6 17.2 15.9 15.9 12.0 12.7 13.5 28.5 29.6 Zr 430 453 380 384 459 527 260 504 443 507 Hf 12.2 11.6 11.3 12.3 11.2 12.7 7.32 11.4 12.7 11.3 Sr 49.3 87.4 77.1 41.7 337 481 618 466 1014 1570 A/CNK 1.137 1.209 1.138 1.144 1.293 1.052 1.032 0.967 0.911 1.038 σ43 2.48 2.32 2.26 2.3 2.16 3.52 2.92 2.63 6.66 7.03 La 31.5 35.4 34.5 46.6 35.0 32.7 38.6 34.9 57.0 65.1 Ce 82.4 87.5 89.6 86.5 71.4 62.6 72.1 70.1 105 114 Pr 8.13 8.46 8.44 11.2 8.47 7.92 8.95 8.08 13.8 14.8 Nd 31.1 30.4 32.4 44.7 33.2 27.6 32.4 30.2 52.7 51.1 Sm 5.07 4.86 5.78 8.69 5.43 5.18 5.40 5.32 8.04 8.30 Eu 0.66 0.79 0.50 0.54 1.31 1.59 1.54 1.50 2.39 2.46 Gd 4.51 4.00 4.86 7.00 4.64 4.97 5.09 4.75 6.93 7.01 Tb 0.74 0.66 0.89 1.24 0.74 0.74 0.65 0.77 0.92 1.01 Dy 4.25 3.57 5.38 6.86 4.01 4.02 3.15 4.53 4.00 4.28 Ho 0.73 0.64 1.05 1.32 0.76 0.80 0.69 0.95 0.90 0.96 Er 2.46 1.97 2.99 4.04 2.16 2.16 1.72 2.72 2.34 2.42 Tm 0.40 0.32 0.58 0.67 0.35 0.31 0.25 0.41 0.32 0.28 Yb 2.75 2.01 3.59 4.17 2.08 1.81 1.56 2.55 2.19 2.09 Lu 0.41 0.34 0.52 0.67 0.36 0.33 0.27 0.43 0.32 0.32 Y 22.0 18.9 29.7 36.7 20.0 23.0 18.2 24.3 22.1 23.2 ΣREE 197 200 221 261 190 176 191 192 279 297 LREE/HREE 9.78 12.39 8.62 7.63 10.25 9.09 11.88 8.77 13.33 13.92 (La/Yb)N 7.72 11.87 6.48 7.53 11.35 12.18 16.69 9.23 17.54 21.00 δEu 0.41 0.53 0.28 0.21 0.78 0.95 0.89 0.89 0.96 0.96 La/Sm 6.21 7.28 5.97 5.36 6.45 6.31 7.15 6.56 7.09 7.84 Gd/Yb 1.64 1.99 1.35 1.68 2.23 2.75 3.26 1.86 3.16 3.35 Sm/Nd 0.16 0.16 0.18 0.19 0.16 0.19 0.17 0.18 0.15 0.16 注: 主量元素含量单位为%，微量和稀土元素含量为10-6
下载: 导出CSV
表 2 德仁组火山岩LA-ICP-MS锆石U-Th-Pb同位素分析结果
Table 2. LA-ICP-MS zircon U-Th-Pb age data from volcanic rocks in Deren Formation
点号 Pb/10-6 Th/10-6 U/10-6 Th/U 同位素比值 同位素年龄值/Ma 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ RZ30(英安质角砾晶屑岩屑凝灰岩)，206Pb/206U年龄加权平均值为246.8±3.5Ma(MSWD=2.9，n=12)和169.6±4.6Ma(MSWD=1.2, n=4) 1 63.0 697 1300 0.54 0.0534 0.0014 0.2897 0.0082 0.0396 0.0006 346 92 258 6 250 4 2 85.3 1124 1802 0.62 0.0540 0.0015 0.2847 0.0083 0.0384 0.0006 372 61 254 7 243 4 3 106 1606 1966 0.82 0.0505 0.0010 0.2819 0.0060 0.0406 0.0005 220 46 252 5 256 3 4 106 1639 2141 0.77 0.0518 0.0009 0.2717 0.0053 0.0381 0.0005 276 44 244 4 241 3 5 23.0 257 725 0.35 0.0465 0.0022 0.1702 0.0081 0.0268 0.0004 33 98 160 7 171 2 7 98.0 1023 2121 0.48 0.0518 0.0013 0.2698 0.0065 0.0379 0.0004 276 57 243 5 240 3 8 115 2162 2041 1.06 0.0538 0.0012 0.2879 0.0067 0.0391 0.0005 361 52 257 5 247 3 9 151 2158 2963 0.73 0.0526 0.0009 0.2825 0.0055 0.0390 0.0005 309 37 253 4 247 3 10 60.5 660 1260 0.52 0.0500 0.0013 0.2673 0.0076 0.0388 0.0005 195 27 240 6 245 3 11 56.8 742 1093 0.68 0.0544 0.0016 0.2988 0.0083 0.0403 0.0006 391 67 265 7 255 4 13 132 1974 2575 0.77 0.0535 0.0011 0.2919 0.0074 0.0394 0.0004 350 50 260 6 249 3 14 145 2947 2715 1.09 0.0510 0.0011 0.2746 0.0064 0.0390 0.0004 243 55 246 5 247 3 17 27.9 740 791 0.93 0.0525 0.0022 0.1871 0.0077 0.0263 0.0004 306 129 174 7 168 3 18 26.8 462 800 0.58 0.0523 0.0025 0.1946 0.0090 0.0272 0.0004 298 142 181 8 173 3 19 101 2021 1932 1.05 0.0546 0.0013 0.2844 0.0066 0.0380 0.0003 394 58 254 5 240 2 20 26.3 410 829 0.49 0.0561 0.0023 0.1985 0.0073 0.0262 0.0004 457 91 184 6 167 3 RZ33(流纹岩)，206Pb/238U年龄加权平均值为117.0±0.9Ma(MSWD=0.86, n=15) 1 40.7 1317 1813 0.73 0.0494 0.0018 0.1224 0.0048 0.0182 0.0004 169 85 117 4 116 2 2 19.7 899 766 1.17 0.0539 0.0031 0.1303 0.0066 0.0180 0.0004 369 131 124 6 115 2 3 21.9 926 875 1.06 0.0467 0.0024 0.1135 0.0056 0.0180 0.0003 32 119 109 5 115 2 4 61.9 1784 2628 0.68 0.0488 0.0015 0.1252 0.0038 0.0186 0.0002 139 72 120 3 119 1 8 51.0 2127 2087 1.02 0.0461 0.0015 0.1160 0.0041 0.0182 0.0003 400 -324 111 4 117 2 10 43.0 1574 1744 0.90 0.0544 0.0018 0.1378 0.0047 0.0184 0.0002 387 69 131 4 117 2 11 17.0 456 700 0.65 0.0679 0.0038 0.1706 0.0095 0.0185 0.0004 865 117 160 8 118 2 12 88.5 2421 3759 0.64 0.0506 0.0012 0.1288 0.0033 0.0184 0.0002 233 56 123 3 117 1 13 40.2 1330 1675 0.79 0.0499 0.0016 0.1231 0.0039 0.0179 0.0002 191 71 118 4 115 1 14 34.7 1104 1467 0.75 0.0542 0.0018 0.1346 0.0045 0.0182 0.0003 389 74 128 4 116 2 15 30.4 926 1246 0.74 0.0504 0.0022 0.1296 0.0059 0.0187 0.0003 213 102 124 5 119 2 16 34.1 914 1486 0.62 0.0504 0.0021 0.1256 0.0050 0.0182 0.0002 213 92 120 4 117 2 18 53.9 1620 2237 0.72 0.0484 0.0015 0.1229 0.0040 0.0184 0.0002 120 74 118 4 118 2 19 16.1 524 670 0.78 0.0541 0.0027 0.1325 0.0064 0.0183 0.0004 376 111 126 6 117 2 20 53.5 1548 2254 0.69 0.0564 0.0019 0.1402 0.0044 0.0182 0.0002 478 72 133 4 116 2
下载: 导出CSV
-
[1] Gao S, Lu T C, Zhong B R, et al.Chemical composition of the continental crust as revealed by studies in East China[J]. Geochim. Cosmochin Acta, 1998, 62:1989-1975. http://adsabs.harvard.edu/abs/1998GeCoA..62.1959G
[2] Gao S, Rudnick RL, Carlson R W, et al. Re-Os evidence for replacement of ancient mantle lithosphere beneath the North China Craton[J]. Earth and Planet. Sci. Lett., 2002, 198:307-322. doi: 10.1016/S0012-821X(02)00489-2
[3] 邓晋福, 莫宣学, 赵海玲, 等.中国东部岩石圈根/去根作用与大陆"活化"[J].现代地质, 1994, 8:349-356. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=xddz403.017&dbname=CJFD&dbcode=CJFQ
[4] 邓晋福, 赵海玲, 莫宣学.中国大陆根-柱构造——大陆动力学的钥匙[M].北京:地质出版社, 1996:91.
[5] 吴福元, 孙德有.中国东部中生代岩浆作用与岩石圈减薄[J].长春科技大学学报, 1999, 29(4):313-318. http://d.wanfangdata.com.cn/Thesis/Y1661487
[6] 吴福元, 孙德有, 张广良, 等.论燕山运动的深部地球动力学本质[J].高校地质学报, 2000, 6:379-388. doi: 10.3969/j.issn.1006-7493.2000.03.002
[7] Griffin W L, Zhang A, O, Reilly S Y, et al. Phanerozoic evolution of the lithosphere beneath the Sino-Korean craton[C]//Flower M F J, Chung S L, Lo C H, et al.Mantle Dynamics and Plate Interaction in East Asia. American Geophysical Union, 1998, 100:107-126.
[8] Menzies M A, Fanw, Zhang M. Paleaozoic and Cenozoic lithoprobes and the loss of 120 km of Archean lithosphere, Sino-Korean craton, China[C]//Prichard H M, Alabaster T, Harris N B, et al. Magmatic Processes and Plate Tectonics. Geological Sodety of London Special Publication, 1993, 76:71-81.
[9] Menzies M A, Xu Y. Geodynamics of the North China craton[C]//Flower M F J, Chung S L, Lo C H, et al.Mantle Dynamics and Plate Interaction in East Asia. American Geophysical Union, 1998, 100:155-164.
[10] Xu Y G. Thermo-tectonic destruction of the Archaean lithospheric, keel beneath the Sino-Korean Craton in China:Evidence, timing and mechanism[J]. Physics and Chemistry of the Earth, 2001, 26:747-757. http://www.irgrid.ac.cn/handle/1471x/340048?mode=full&submit_simple=Show+full+item+record
[11] 高山, 章成锋, 许文良, 等.拆沉作用于华北克拉通破坏[J].科学通报, 2009, 54:1962-1973. http://d.wanfangdata.com.cn/Thesis/Y2431623
[12] 吴福元, 徐义刚, 高山.华北岩石圈减薄与克拉通破坏研究的主要学术争论[J].岩石学报, 2008, 24(6):1145-1174. http://d.wanfangdata.com.cn/Periodical/ysxb98200806001
[13] 路凤香, 郑建平, 李伍平, 等.中国东部显生宙地幔演化的主要样式:"蘑菇云"模型[J].地学前缘, 2000, 7:97-107. doi: 10.3321/j.issn:1005-2321.2000.01.009
[14] 徐义刚, 李洪颜, 庞崇进, 等.论华北克拉通破坏的时限[J].科学通报, 2009, 54:1974-1989. http://d.wanfangdata.com.cn/Periodical/zgqydz200709017
[15] 郑建平, 余淳梅, 路凤香, 等.华北东部大陆地幔橄榄岩组成、年龄与岩石圈减薄[J].地学前缘, 2007, 14:87-97. doi: 10.3321/j.issn:1005-2321.2007.02.007
[16] 郑永飞, 吴福元.克拉通岩石圈的生长和再造[J].科学通报, 2009, 54:1945-1949. http://d.wanfangdata.com.cn/Periodical/ysxb98201305017
[17] 张宏福, 周新华, 范蔚茗, 等.华北东南部中生代岩石圈地幔性质、组成、富集过程及其形成机理[J].岩石学报, 2005, 21:443-454. http://d.wanfangdata.com.cn/Periodical/ysxb98200504024
[18] 张宏福.橄榄岩-熔体的相互作用:岩石圈地幔组成转变的重要方式[J].地学前缘, 2006, 13:2008-2026. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=dxqy200602006&dbname=CJFD&dbcode=CJFQ
[19] 张宏福.橄榄岩-熔体相互作用:克拉通型岩石圈地幔能够被破坏之关键[J].科学通报, 2009, 54:2008-2026. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=kxtb200914007&dbname=CJFD&dbcode=CJFQ
[20] 牛耀龄.玄武岩浆起源和演化的一些基本概念以及对中国东部中-新生代基性火山岩成因的新思路[J].高校地质学报, 2005, 11:9-46. doi: 10.3969/j.issn.1006-7493.2005.01.002
[21] 刘俊来, Davis G A, 纪沫, 等.地壳的拆离作用与华北克拉通破坏:晚中生代伸展构造约束[J].地学前缘, 2008, 15(3):72-81. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=dxqy200803005&dbname=CJFD&dbcode=CJFQ
[22] 林伟, 王清晨, 王军, 等.辽东半岛晚中生代伸展构造——华北克拉通破坏的地壳响应[J].中国科学(地球科学), 2011, 41(5):638-653. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=jdxk201105004&dbname=CJFD&dbcode=CJFQ
[23] 段秋梁, 谭未一, 杨长春, 等.华北东部晚中生代伸展构造作用[J].地球物理学进展, 2007, 22(2):403-410. http://d.wanfangdata.com.cn/Periodical/dqwlxjz200702010
[24] 申亮, 刘俊来, 胡玲, 等.辽东半岛大营子拆离断层系及其区域构造意义[J].中国科学(D辑), 2011, 41(4):437-451. http://d.wanfangdata.com.cn/Conference/7241306
[25] 张兴洲, 杨宝俊, 吴福元, 等.中国兴蒙-吉黑地区岩石圈结构基本特征[J].中国地质, 2006, 33(4):816-823. http://d.wanfangdata.com.cn/Periodical/zgdizhi200604011
[26] Liu Y S, Hu Z C, Gao S, et al. In situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257(1/2):34-43. https://www.sciencedirect.com/science/article/pii/S0009254108003501
[27] Liu Y S, Gao S, Hu Z C. et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen:U-Pb dating, Hf isotopes and trace elements in zircons of mantle xenoluths[J]. Journal of Petrology, 2010, 51(1/2):537-571. http://www.oalib.com/references/15778808
[28] Liu Y S, Hu Z C, Zong K Q. et al. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LAICP-MS[J]. Chinese Science Bulletin, 2010, 55(15):1535-1546. doi: 10.1007/s11434-010-3052-4
[29] Ludwig K R.User's manual for Isoplot 3.0:A geochronological toolkit for Microsoft Excel[M]. Berkeley Geochronology Center Special Publication, 2003:1-20. http://d.wanfangdata.com.cn/NSTLQK/10.1016-j.immuni.2011.10.010/
[30] Sun S S, McDonough W F. Chemical and isotopic systematics of oceanic basalts:implications for mantle composition and processes[C]//Saunders A D, Norry M J. Magmatism in Ocean Basins. London:Geological Society of Special Publication, 1989, 42(1):313-345.
[31] Boynton WV. Geovhemistry of the Rare Earth Elements:Meterorite Studies[C]//Henderson P. Rare Earth Elements Geochemistry, 1984:63-114.
[32] Maniar P D, Piccoli P M.从微量元素方面来对花岗岩构造背景进行判别[J]. Mineralium Deposita, 1990, 25(1):221-232.
[33] 张宏, 柳小明, 李之彤, 等.辽西阜新-义县盆地及附近地区早白垩世地壳大规模较薄及成因探讨[J].地质论评, 2005, 51(4):360-372. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=dzlp200504002&dbname=CJFD&dbcode=CJFQ
[34] 刘俊来, 纪沫, 申亮, 等.辽东半岛早白垩世伸展构造组合、形成时代及区域构造内涵[J].中国科学(D辑), 2011, 41(5):618-637. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=jdxk201105003&dbname=CJFD&dbcode=CJFQ
[35] 林强, 葛文春, 曹林, 等.大兴安岭中生代双峰式火山岩的地球化学特征[J].地球化学, 2003, 32(3):208-222. http://d.wanfangdata.com.cn/Periodical/dqhx200303002
[36] 许文良, 孙德有, 周燕.满洲里-绥芬河地学断面岩浆作用与地壳结构[M].北京:地质出版社, 1994:94.
[37] 刘锦, 刘正宏, 李世超, 等.华北北缘东段开原地区三叠世侵入岩年代学及岩石地球化学研究[J].岩石学报, 2016, 30(9):2739-56. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ysxb201609010&dbname=CJFD&dbcode=CJFQ
[38] 陈国能, 洛尼.格拉佩斯著; 彭卓伦, 张献河, 胡文烨译, 花岗岩成因:原地重熔与地壳演化[M].武汉:中国地质大学出版社, 2009:6.
-
