3D geological modeling and stratified skarn target prediction in the Jiama deposit, Tibet
-
摘要:
西藏甲玛矿区是冈底斯成矿带非常典型的多金属矿床，理论预测研究认为，在矿集区深部发育隐伏的斑岩-矽卡岩矿体，而基于矿区钻孔覆盖的勘查模型对外围区潜在靶区预测程度较低。以甲玛矿区45口钻孔岩心的密度、磁性、电阻率、极化率等物性资料为基础，分析了覆盖甲玛矿集区及外围的大地电磁测深三维数据体，基于GOCAD软件平台，通过离散光滑插值法与随机模拟算法，构建了甲玛矿区的地层岩性-地球物理三维可视一体化模型；结合大地电磁测深11条剖面的二维地质解译成果，精细刻划了3000 m以浅的三维矽卡岩体发育特征，并通过使用未参与建模的甲玛科学深钻JMKZ-1进行验证，结果显示三维地质模型具有较好的一致性；基于构建的矽卡岩成矿模型，结合甲玛矿区及邻区岩（矿）石电性参数特征分析和三维矽卡岩的电性结构，预测了甲玛矿区的层状矽卡岩靶区，为深部资源潜力评价及矿集区增储目标提供三维建模技术示范。
Abstract:The Jiama deposit in Tibet is a very typical polymetallic deposit in the Gangdise metallogenic belt.Through theoretical prediction and research, it is believed that concealed porphyry-skarn ore bodies are developed in the deep part of the ore-concentrated area.However, the exploration model based on the borehole coverage of the mining area has a low degree of prediction of the potential target in the peripheral area.Based on the density, magnetic properties, resistivity, and polarizability data of 45 borehole cores in the Jiama deposit, the three-dimensional magnetotelluric sounding data covering the Jiama deposit and its periphery were analyzed.Based on GOCAD software, the stratum lithology-geophysical three-dimensional visualization integrated model of the Jiama deposit was constructed through discrete smooth interpolation and stochastic simulation algorithms.Combined with the results of 2D geological interpretation of 11 magnetotelluric(MT) profiles, the development characteristics of 3D skarn bodies below 3000 m were finely depicted and verified with the Jiama Scientific Deep Drill JMKZ-1 which was not involved in the modeling.The results show a consistency agreement.Besides, based on the skarn metallogenic model, combined with the analysis of the electrical parameters of the Jiama deposit and adjacent areas, as well as the electrical characteristics of the three-dimensional skarn, the favorable target area of stratified skarn in Jiama deposit is predicted.The results can provide a demonstration of 3D modeling technology for the evaluation of deep resource potential and reserves increasing in the mining area.
-
-
表 1 甲玛矿区找矿模型
Table 1. Prospecting model of the Jiama mining area
控矿要素 特征描述 变量类型 定量描述 岩体 含矿岩体 成矿有利岩体影响范围 含矿性较好 地球物理探测 地球物理特征异常 电阻率异常区 电阻率异常值分析
下载: 导出CSV
表 2 甲玛矿区以往岩石物性标本磁性与电性参数统计[17]
Table 2. Statistics of magnetic and electrical parameters of previous rock samplesin the Jiama mining area
岩石名称 标本数 κ/(10-6× 4π·SI) Jr /(10-3A/m) ρ/(Ω·m) 变化范围 平均值 变化范围 平均值 变化范围 平均值 离散值 板岩 30 110~369 248 71~343 194 71~343 102 29.7 角岩 30 518~909 680 74~298 183 71~343 288 64.3 大理岩 30 22~163 91 63~232 155 71~343 1135 56.5 矽卡岩 30 507~969 680 114~535 269 71~343 650 80.8 铜矿体 30 66~361 104 137~321 168 71~343 411 32.6 斑岩 30 244~849 597 63~1361 350 71~343 393 51.3 灰岩 30 44~220 124 34~154 86 71~343 192 33.7
下载: 导出CSV
表 3 甲玛-驱龙矿区岩(矿)石电性参数
Table 3. Statistics of electrical parameters of rocks(ores)in the Jiama-Qulong mining area
岩性 样品数量 电阻率/(Ω·m) 大理岩 7 11888.64 蚀变大理石 5 3657.07 矽卡岩 6 9952.31 黑云母花岗闪长岩 4 1358.56 黄铁矿化炭质板岩 11 1252.41 钾化花岗斑岩 8 2584.71 凝灰岩(含浸染状黄铁矿) 2 3960.75 凝灰质砂岩(含黄铁矿) 1 22943.72 褐铁矿 3 2271.29 致密块状磁黄铁矿 2 0.45 铅多金属矿 6 4.59
下载: 导出CSV
-
[1] 陈建平, 吕鹏, 吴文, 等. 基于三维可视化技术的隐伏矿体预测[J]. 地学前缘, 2007, 14(5): 54-62. doi: 10.3321/j.issn:1005-2321.2007.05.006
[2] De Kemp E A, Monecke T, Sheshpart M. 3D GIS as a support for mineral discovery[J]. Geochemist. Explor. Environ. Anal., 2011, 11(2): 117-128. doi: 10.1144/1467-7873/09-IAGS-014
[3] Rossi M E, Deutsch C V. Mineral Resource Estimation[M]. Springer Science Business Media Dordrecht, 2014: 29-50.
[4] 陈建平, 于淼, 于萍萍, 等. 重点成矿带大中比例尺三维地质建模方法与实践[J]. 地质学报, 2014, 88(6): 1187-1195. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201406018.htm
[5] 张世辉, 陈建国. 山东焦家金矿三维地质地球物理建模与深部预测[C]//2018年中国地球科学联合学术年会论文集(四十三). 2018.
[6] Wang C, Wang G W, Liu J J, et al. 3D geochemical modeling for subsurface targets of Dashui Au deposit in Western Qinling(China)[J]. Journal of Geochemical Exploration, 2019, 203(8): 59-77. http://www.onacademic.com/detail/journal_1000042277160599_86aa.html
[7] 耿瑞瑞, 范洪海, 孙远强, 等. 基于GOCAD软件的沙子江铀矿床三维定量预测[J]. 矿床地质, 2020, 39(6): 1078-1090. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ202006008.htm
[8] 唐菊兴, 邓世林, 郑文宝, 等. 西藏墨竹工卡县甲玛铜多金属矿床勘查模型[J]. 矿床地质, 2011, 30(2): 179-196. doi: 10.3969/j.issn.0258-7106.2011.02.002
[9] 唐菊兴, 郑文宝, 陈毓川, 等. 西藏甲玛铜多金属矿床深部斑岩矿体找矿突破及其意义[J]. 吉林大学学报(地球科学版), 2013, 43(4): 1100-1108. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201304006.htm
[10] 冷秋锋. 西藏甲玛斑岩成矿系统地质特及矽卡岩型厚大富矿体控矿因素研究[D]. 成都理工大学硕士学位论文, 2013.
[11] 李波, 胡道功, 林广奇, 等. 西藏甲玛矿区侵入岩成岩成矿年龄[J]. 现代地质, 2016, 30(6): 1234-1242. doi: 10.3969/j.issn.1000-8527.2016.06.005
[12] 马士委. 藏南甲玛铜多金属矿床构造格架与成矿的关系[D]. 中国地质科学院博士学位论文, 2017.
[13] Tang J X, Yang H H, Song Y, et al. The copper polymetallic deposits and resource potential in the Tibet Plateau[J]. China Geology, 2021, 4(1): 1-16. http://www.sciencedirect.com/science/article/pii/S209651922100001X
[14] 郑文宝, 陈毓川, 唐菊兴, 等. 西藏墨竹工卡县甲玛矿区筒状矿体的发现及其地质意义[J]. 矿床地质, 2011, 30(2): 207-217. doi: 10.3969/j.issn.0258-7106.2011.02.004
[15] 宋磊, 汪雄武, 唐菊兴, 等. 从喷流成因到斑岩-矽卡岩成矿系统: 甲玛铜多金属矿床成功勘查的几点启示[J]. 矿床地质, 2011, 30(2): 220-228. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ201102006.htm
[16] 王立强, 陈伟, 林鑫, 等. 冈底斯成矿带斑岩-矽卡岩矿化之耦合关系——以邦铺矿床为例[J]. 矿物学报, 2013, (S2): 838-839. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB2013S2466.htm
[17] 屈挺, 贺日政, 鱼鹏亮, 等. 西藏甲玛矿区岩石物性统计及应用[J]. 物探与化探, 2021, 45(3): 1-8. https://www.cnki.com.cn/Article/CJFDTOTAL-WTYH202103014.htm
[18] 唐菊兴, 王登红, 汪雄武, 等. 西藏甲玛铜多金属矿矿床地质特征及其矿床模型[J]. 地球学报, 2010, 31(4): 495-506. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201004002.htm
[19] 曲晓明, 侯增谦, 黄卫. 冈底斯斑岩铜矿(化)带: 西藏第二条"玉龙"铜矿带?[J]. 矿床地质, 2001, (4): 355-366. doi: 10.3969/j.issn.0258-7106.2001.04.009
[20] 郑有业, 王保生, 樊子珲, 等. 西藏冈底斯东段构造演化及铜金多金属成矿潜力分析[J]. 地质科技情报, 2002, (2): 55-60. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200202013.htm
[21] 李光明, 刘波, 佘宏全, 等. 西藏冈底斯成矿带南缘喜马拉雅早期成矿作用——来自冲木达铜金矿床的Re-Os同位素年龄证据[J]. 地质通报, 2006, 35(12): 1481-1486. doi: 10.3969/j.issn.1671-2552.2006.12.018 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=2006012271&flag=1
[22] 宋扬, 唐菊兴, 曲晓明, 等. 西藏班公湖-怒江成矿带研究进展及一些新认识[J]. 地球科学进展, 2014, 29(7): 795-809. https://www.cnki.com.cn/Article/CJFDTOTAL-DXJZ201407006.htm
[23] 李宝龙, 彭勃, 秦广洲, 等. 班-怒结合带西段革吉地区帕阿岩基的成因: 元素地球化学、锆石U-Pb年代学及Hf同位素约束[J]. 岩石学报, 2019, 35(3): 687-704. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201903005.htm
[24] 何紫兰, 朱鹏飞, 马恒, 等. 基于多源数据融合的相山火山盆地三维地质建模[J]. 地质与勘探, 2018, 54(2): 404-414. doi: 10.3969/j.issn.0495-5331.2018.02.020
[25] 高乐, 卢宇彤, 虞鹏鹏, 等. 成矿区三维可视化与立体定量预测——以钦-杭成矿带庞西垌地区下园垌铅锌矿区为例[J]. 岩石学报, 2017, 33(3): 767-778. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201703008.htm
[26] 孙岳, 王功文, 方同辉, 等. 新疆红海块状硫化物矿床三维地质建模及勘探应用[J]. 地质与勘探, 2013, 49(1): 179-184. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKT201301020.htm
[27] 杨志华, 兰恒星, 张永双. 基于GIS-GOCAD耦合技术的三维地质建模[J]. 地理与地理信息科学, 2012, 28(5): 16-20. https://www.cnki.com.cn/Article/CJFDTOTAL-DLGT201205005.htm
[28] Lu R Q, Liu Y D, Xu X W, et al. Three-Dimensional Model of the Lithospheric Structure Under the Eastern Tibetan Plateau: Implications for the Active Tectonics and Seismic Hazards[J]. Tectonics, 2019, 38(3/4): 1292-1307. http://onlinelibrary.wiley.com/doi/10.1029/2018TC005239
[29] Lemon A M, Jones N L. Building solid models from boreholes and user-defined cross-sections[J]. Computers & Geosciences, 2003, 29(5): 547-555. http://www.researchgate.net/profile/Norman_Jones4/publication/222672922_Building_solid_models_from_boreholes_and_user-defined_cross-sections/links/0912f5097d0642fb3f000000
[30] 屈红刚, 潘懋, 王勇. 基于含拓扑剖面的三维地质建模[J]. 北京大学学报(自然科学版), 2006, 42(6): 717-723. doi: 10.3321/j.issn:0479-8023.2006.06.004
[31] Kaufmann O, Martin T. 3D geological modelling from boreholes, cross-sections and geological maps, application over former natural gas storages in coal mines[J]. Computers & Geosciences, 2008, 34(3): 278-290.
[32] Wu Q, Xu H, Zou X K. An effective method for 3Dgeological modeling with multi-source data integration[J]. Computers & Geosciences, 2005, 31(1): 35-43. http://www.sciencedirect.com/science/article/pii/S0098300404001505
[33] 吴胜和. 储层表征与建模[M]. 北京: 石油工业出版社, 2013.
[34] 杜光树, 姚鹏, 潘凤雏, 等. 喷流成因矽卡岩与成矿——以西藏甲马铜多金属矿床为例[M]. 成都: 四川科学技术出版社, 1998: 82-113.
[35] Hou Z Q, Yang Z M, Qu X M, et al. The Miocene Gangdese porphyry copper belt generated during post-collisional extension in the Tibetan Orogen[J]. Ore Geology Reviews, 2009, 36(1/3): 25-51. http://gizmo.geotop.uqam.ca/Hou_et_al_OGR_2009.pdf
[36] 唐菊兴, 陈毓川, 多吉, 等. 西藏冈底斯成矿带东段主要矿床类型、成矿规律和找矿评价[J]. 矿物学报, 2009, 29(S1): 476-478. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB2009S1249.htm
[37] 应立娟, 唐菊兴, 王登红, 等. 西藏甲玛超大型铜矿石榴子石特征及成因意义[J]. 地质学报, 2012, 86(11): 1735-1747. doi: 10.3969/j.issn.0001-5717.2012.11.003
[38] 林彬, 唐菊兴, 唐攀, 等. 斑岩成矿系统多中心复合成矿作用模型——以西藏甲玛超大型矿床为例[J]. 矿床地质, 2019, 38(6): 1204-1222. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ201906002.htm
① 唐菊兴, 王立强. 青藏高原首个固体矿产勘查领域3000米科学深钻胜利竣工. 中国地质调查局, 2020.
-
