Determination of the Magnetic Material Composition in Magnetite Ore and Processability Evaluation
-
摘要: 对磁铁矿样品分别用磁选管和手工内磁选法进行磁选，并对原矿样品和样品的磁性物中TFe、P、S、V2O5、TiO2、SiO2、Al2O3、CaO、MgO、Sn、Cu、Pb、Zn的含量进行测定。分析结果表明，采用手工内磁选和磁选管对磁铁矿进行磁选所得的结果一致，为了简便操作，本文均采用手工内磁选法选出磁性物。A矿区磁性铁(mFe)含量(22.42%)比B矿区mFe含量(22.59%)低，但A矿区样品的磁性物中TFe含量(磁铁精矿品位)大于66%，比B矿区样品的磁性物中TFe含量(小于57%)高，A矿区的磁铁矿选矿效果明显好于B矿区，说明对磁性物中TFe含量的测定能够更好地反映矿石的可选性。原矿样品中P、S的含量分别为0.328%、0.271%，而样品的磁性物中P、S的含量为0.021%、 < 0.005%，均达到铁矿石冶炼标准；原矿样品中V2O5、TiO2的含量分别为0.156%、1.37%，而样品的磁性物中V2O5、TiO2含量分别为0.823%、13.62%，达到了铁矿石冶炼标准。原矿样品的(CaO+MgO)/(SiO2+Al2O3)值为0.876，为自熔性矿石，而其磁性物的(CaO+MgO)/(SiO2+Al2O3)值为0.453，为酸性矿石。由此说明，单纯测定原矿样品中的各成分尚不能对磁铁矿的可选性进行科学性评价，只有进一步测定磁铁矿的磁性物中各成分的含量，才能够对磁铁矿进行可靠的评价。本文通过对磁铁矿中磁性物成分的测定，为磁铁矿的选冶性能提供了新的评价方法。Abstract: Magnetite samples were magnetically separated with a magnetic tube and artificial magnetic separation. The contents of TFe, P, S, V2O5, TiO2, SiO2, Al2O3, CaO, MgO, Sn, Cu, Pb and Zn in the magnetite samples were determined. The results of the two separation methods were consistent. Consequently, artificial magnetic separation in subsequent experiments was chosen in order to simplify the process. The average content of mFe in mining area A (22.42%) was lower than that in mining area B (22.59%), but the content of TFe in the magnetic material of mining area A magnetite samples (>66%) was higher than that in mining area B ( < 57%). The results indicate that the effect of mineral processing of mining area A is much better than that of mining area B since the content of TFe in magnetic material can better reflect processability. The contents of P and S were 0.328% and 0.271% in the magnetite ore samples, 0.021% and < 0.005% in the magnetic material, which met the requirements of the iron ore smelting standards as P<0.15% and S<0.15% in the magnetite. The contents of V2O5 and TiO2 were 0.156% and 1.37% in the magnetite ore samples, 0.823% and 13.62% in the magnetic material, which meet the requirements of the iron ore smelting standards as V2O5>0.15% and TiO2>3% in the magnetite. The magnetite with a(CaO+MgO)/(SiO2+Al2O3) ratio of 0.876 is the self-fluxing ore, but the magnetic material of this magnetite with a (CaO+MgO)/(SiO2+Al2O3) ratio of 0.453 is acid ore. This indicates that the evaluation of the magnetite does not depend on the contents of each component in the ore sample, but rather depends on the contents of each component in the magnetic material of the magnetite. Through the determination of magnetic materials in magnetite ore, a new evaluation method for magnetic separation and smelting has been determined.
-
Key words:
- magnetite /
- artificial magnetic separation /
- magnetic material /
- iron /
- component analysis /
- processability evalution
-
-
表 1 磁铁矿样品TFe及磁性物含量分析结果比对
Table 1. Comparison of analytical results of TFe in samples
样品编号 磁选管法wB/% 手工内磁选法 wB/% 磁性物
含量磁性物
中TFe样品
mFe磁性物
含量磁性物
中TFe样品
mFeA矿区ZK1905-1 23.50 66.07 15.53 23.62 66.27 15.65 A矿区ZK1905-2 27.43 67.16 18.42 27.38 67.46 18.47 A矿区ZK1905-3 25.07 68.52 17.18 25.24 68.87 17.38 A矿区ZK1905-4 28.89 66.88 19.32 28.92 67.53 19.53 A矿区ZK1905-5 39.84 66.90 26.65 39.61 66.63 26.39 A矿区ZK1905-6 45.54 67.28 30.64 45.89 67.72 31.08 A矿区ZK1905-7 43.05 67.83 29.20 43.31 67.36 29.17 B矿区ZK705-1 35.63 56.34 20.07 35.78 56.27 20.13 B矿区ZK705-2 36.35 52.34 19.03 36.57 52.28 19.12 B矿区ZK705-3 44.51 51.45 22.90 44.68 51.29 22.92 B矿区ZK705-4 47.56 52.65 25.04 47.72 52.47 25.04 B矿区ZK705-5 46.32 56.87 26.34 46.48 56.67 26.34 B矿区ZK705-6 47.97 46.13 22.13 48.23 46.00 22.19 注：样品中mFe含量为根据磁性物含量及磁性物中TFe含量计算得出的结果。
下载: 导出CSV
表 2 磁铁矿中P和S分析结果
Table 2. Comparison of analytical results of P and S in samples
样品编号 w(P)/% w(S)/% 原矿样品 样品的磁性物 原矿样品 样品的磁性物 磁铁矿1# 0.328 0.021 0.271 < 0.005 磁铁矿2# 0.428 0.183 0.256 0.415
下载: 导出CSV
表 3 磁铁矿中V2O5、TiO2分析结果比对
Table 3. Comparison of analytical results of V2O5 and TiO2 in samples
样品编号 w(V2O5)/% w(TiO2)/% 原矿样品 样品的磁性物 原矿样品 样品的磁性物 磁铁矿3# 0.156 0.823 1.37 13.62 磁铁矿4# 0.137 0.009 1.26 0.007
下载: 导出CSV
表 4 磁铁矿中SiO2、Al2O3、CaO、MgO分析结果比对
Table 4. Comparison of analytical results of SiO2,Al2O3,CaO and MgO in samples
元素 wB/% 原矿样品 样品的磁性物 SiO2 15.87 4.08 Al2O3 1.56 1.01 CaO 5.04 1.02 MgO 10.23 1.65
下载: 导出CSV
表 5 磁铁矿中Sn、Cu、Pb、Zn分析结果比对
Table 5. Comparison of analytical results of Sn,Cu,Pb and Zn in samples
元素 wB/% 原矿样品 样品的磁性物 Sn 0.132 0.062 Cu 0.193 0.083 Pb 0.137 0.078 Zn 0.403 0.071
下载: 导出CSV
-
[1] 李厚民,王瑞江,肖克炎,张晓华,刘亚玲,孙莉.中国超贫磁铁矿资源的特征、利用现状及勘查开发建议——以河北和辽宁的超贫磁铁矿资源为例[J].地质通报,2009,28(1): 85-90. http://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD200901012.htm
[2] 孙炳泉.超贫铁矿资源化利用技术现状及发展趋势[J].金属矿山,2009,6(1): 9-12. http://www.cnki.com.cn/Article/CJFDTOTAL-JSKS200901004.htm
[3] 王世军.承德超贫磁铁矿的开发与评价[J].资源与产业,2004,6(5): 16-18. http://www.cnki.com.cn/Article/CJFDTOTAL-ZIYU200405003.htm
[4] DZ/T 0200—2002,铁、锰、铬矿地质勘查规范[S].
[5] 祁向雷.超贫磁铁矿勘查技术规程(暂行)[M].北京:地质出版社,2005.
[6] GB/T 18711—2002,选煤用磁铁矿粉试验方法[S].
[7] 张皓,李勇.磁性物含量测定中常见问题及解决方法[J].选煤技术,2008(5): 32-33. http://www.cnki.com.cn/Article/CJFDTOTAL-XMJS200805010.htm
[8] 赵鹏.相态分析与地质找矿(第二版)[M].北京:地质出版社,2008: 351-352.
[9] 曲亮亮,周平.云南罗茨铁矿降硫降磷选矿试验研究[J].矿产保护与利用,2010(6): 33-36. http://www.cnki.com.cn/Article/CJFDTOTAL-KCBH201006008.htm
[10] 谢美芳,文书明,郑海雷,陈宇.钒钛磁铁矿精矿提铁降硫工艺试验研究[J].金属矿山,2010,7(4): 44-46. http://www.cnki.com.cn/Article/CJFDTOTAL-JSKS201007014.htm
[11] 岩石矿物分析编委会.岩石矿物分析(第四版 第二分册)[M].北京:地质出版社,2011: 738-739.
[12] GB/T 6730,铁矿石化学分析方法[S].
-
