Determination of Hf, Ti and Zr in Zirconium-Titanium Placer by Inductively Coupled Plasma-Atomic Emission Spectrometry
-
摘要: 锆钛砂矿是一种极难消解的矿物,除氢氟酸外,几乎不溶于所有的酸,由于矿物中铪、钛、锆含量高,而铪、钛、锆又易水解形成难溶的偏铪酸、偏钛酸、偏锆酸析出,样品前处理给定量分析带来很大困难。传统的化学法繁琐费时,且只能进行锆(铪)合量的分析。本文建立了电感耦合等离子体发射光谱法(ICP-AES)测定锆钛砂矿样品中铪、钛、锆的方法。通过筛选四种溶矿方法,确定在刚玉坩埚中用过氧化钠于700℃时熔融样品,硝酸-EDTA浸取盐分前处理矿物,利用EDTA的强络合性质可使铪、钛、锆形成稳定的可溶络合物,制备出有代表性的样品溶液;在ICP-AES分析中,采用Re作为内标和大的高频功率消除了基体效应的影响。方法的精密度(RSD,n=11)低于1.3%,Hf、Ti、Zr的检出限分别为0.97 μg/g、0.86 μg/g、0.33 μg/g。实际样品的测定值与化学分析方法和X射线荧光光谱法的测定结果基本吻合。。本方法采用刚玉坩埚熔矿,提高了样品处理数量,降低了分析成本,适用于难熔锆钛砂矿样品的快速定量分析。Abstract: Zirconium titanium placer is an ore which is extremely difficult to be digested. It is almost insoluble in all kind of acid except HF. Moreover, Hf, Ti and Zr in the ore tends to hydrolyze to form insoluble partial hafnium acid, metatitanic acid and zirconium hydroxide which increases the difficulty for their qualitative determination. The traditional chemical method can only yield total amounts of Zr and Hf and involve a complex time-consuming chemical procedure. After comparing four different methods to melt the sample, it was found that extracting salt with HNO3-EDTA and melting the sample with Na2O2 at 700℃ was a simple, highly efficient and practical method for sample digestion. Based on this melting method, an Inductively Coupled Plasma-Atomic Emission Spectrometry (ICP-AES) method was set up for Hf, Ti and Zr detection in zirconium titanium placer. Re was used as an internal standard and high frequency power was applied to eliminate the matrix effect. The RSD (n=11) was less than 1.3% and the detection limits for Hf, Ti and Zr were 0.97, 0.86 and 0.33 μg/g, respectively. The results were much more precise and accurate than the traditional chemical method and X-ray Fluorescence Spectrometry. The method of melting the sample in a corundum crucible increased the number of samples and reduced the cost, which is beneficial for the fast determination of insoluble Zr-Ti placer samples.
-
Key words:
- zirconium-titanium placer /
- Hf /
- Ti /
- Zr /
- alkaline fusion /
- Inductively Coupled Plasma-Atomic Emission Spectrometry
-
-
表 1 仪器工作参数
Table 1. Working parameters of the ICP-AES instrument
工作参数 设定条件 垂直观测高度 15 mm 蠕动泵泵速 50 r/min 冷却气流量 一般 辅助气流量 1.0 L/min 重复测量次数 3 发射功率 1250 W 载气压强 0.22 MPa 冲洗时间 30 s 短波积分时间 20 s 长波积分时间 10 s 表 2 元素的分析谱线、校准系列
Table 2. Spectral line and calibration curve of the element
元素 分析谱线
λ/nm背景校正 ρ/(μg·mL-1) 相关系数 标准1 标准2 标准3 标准4 标准5 Hf 339.980 右 0.1 1 5 10 20 0.9993 Ti 351.084 右 10 50 100 200 500 0.9999 Zr 327.305 左 1 10 50 100 200 0.9998 Re 221.426 左、右 10 10 10 10 10 - 表 3 精密度和准确度试验
Table 3. Precision and accuracy tests of the method
样品 w(Hf)/% w(Ti)/% w(Zr)/% 本法 其他
方法RSD/% 本法 其他
方法RSD/% 本法 其他
方法RSD/% 样品1 0.0400 0.041 0.5 13.63 13.71 0.2 2.073 1.99 0.2 样品2 0.0292 0.029 0.6 9.335 9.182 0.4 1.438 1.44 0.2 样品3 0.0724 0.073 0.9 18.24 18.01 0.2 3.674 3.66 0.7 样品4 0.0332 0.034 1.2 13.05 12.84 0.1 1.677 1.68 0.3 样品5 0.0546 0.055 1.1 16.98 17.03 0.2 2.686 2.70 0.3 -
[1] 迟洪纪,李秀章,郑作平.山东省滨海砂矿成矿规律及远景区划[J].山东地质, 2001, 17(5): 24-31. http://www.cnki.com.cn/Article/CJFDTOTAL-SDDI200105004.htm
[2] Boiko N I.Titanium-zirconium placers of the Stavropol Region[J].Lithology and Mineral Resources, 2004, 39(6): 523-529. doi: 10.1023/B:LIMI.0000046955.64505.3d
[3] Levchenko E N. Specific features of the mineral compo-sition of titanium zirconium placers in Russia[J].Lithology and Mineral Resources, 2006, 41(2): 117-136. doi: 10.1134/S0024490206020039
[4] Patyk-Kara N G, Gorelikova N V, Bardeeva E G.History of the formation of the Tsentral'noe titanium-zirconium sand deposit in the European part of Russia[J].Lithology and Mineral Resources, 2004, 39(6): 509-522. doi: 10.1023/B:LIMI.0000046954.64161.5c
[5] 岩石矿物分析编委会.岩石矿物分析(第四版第三分册)[M].北京:地质出版社,2011: 426-445.
[6] 裘立奋.现代难熔金属和稀散金属分析[M].北京:化学工业出版社,2007: 8-88.
[7] 陈德平,陈泽明,王新豫.国内外锆矿及金属锆材料元素分析标准方法的比较[J].检验检疫科学,2006, 16(5): 63-65. http://www.cnki.com.cn/Article/CJFDTOTAL-XDSJ200605027.htm
[8] GB/T 17416.1-2010,锆矿石化学分析方法;第1部分:锆铪合量的测定[S].
[9] GB/T 17416.2-2010,锆矿石化学分析方法;第2部分:锆量和铪量的测定[S].
[10] 刘江斌,赵峰,余宇,党亮,张旺强,陈月源.X射线荧光光谱法同时测定地质样品中铌钽锆铪铈镓钪铀等稀有元素[J].岩矿测试,2010, 29(1): 74-76. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201001023.htm
-
