摘要:
针对桂林市临桂区岩溶塌陷易发区域，采用FLAC3D模拟不同降雨速率下的强降雨入渗过程，探究不同直径土洞在强降雨作用下的致塌规律，结果表明：（1）强降雨条件下，不同直径土洞最大位移均出现在洞顶部。降雨速率相同，洞顶竖向位移增长速率随土洞直径的增加呈整体加快的特点；加快降雨速率，竖向位移增长明显，竖向位移与土洞大小呈正相关。（2）相同降雨速率下，土洞直径增大会引起土洞底部剪切破坏区域进一步扩展。上覆土层在强降雨初期主要受到潜蚀作用，加快降雨速率，土洞底部水位剧烈波动对上覆土体产生的水击气爆成为主导作用，剪切破坏速率加快，洞趾剪切应变明显增加，当土洞直径达到3 m时，水位波动愈加剧烈，加速上覆土层破坏。（3）降雨速率的变化对土洞塑性区拓展范围具有不同程度的影响，较大直径的土洞在加快降雨速率时塑性区拓展范围明显扩大，即土洞大小、降雨速率对上覆土层稳定性具有较大的影响。研究结果为定量研究强降雨与上覆土层塌陷的关系提供了依据，对有效、合理地预警岩溶塌陷具有一定的意义。
Abstract:Frequent heavy rainfall can lead to large-scale collapse of karst soil caves. Quaternary strata are widely distributed in the karst area of Lingui district, Guilin City, among which the subsidence area of the silty clay overlay with a one-dimensional structure formed by the Upper Pleistocene alluvial-pluvial layer Q3al-pl under the action of heavy rainfall is the largest in the collapse area of the entire study area. This subsidence area accounts for the largest proportion, posing a huge risk on security to the people. Heavy rainfall has aroused extensive attention and research on the collapse law of karst soil caves. Many scholars have revealed the mechanism of rainfall collapse, the effect laws of erosion, and water level fluctuations in the process of karst collapse from qualitative and quantitative perspectives. In order to better explore the collapse law of soil caves of different sizes with different rainfall rates, a generalized geological model was constructed for the study area, and the calculation models of karst soil caves of different sizes were established in the modeling software Rhino. Besides, the FLAC3D finite difference software was used to simulate the infiltration process of heavy rainfall with different rainfall rates. In this study, a karst calculation model—Mohr-Coulomb constitution and the parameters of physical and mechanical properties of the overlaying soil layer were firstly assigned. Then, the boundary conditions, the rainfall rate, the superimposed force field and the flow field were set to reproduce the cloud map of changes in stress, displacement and plastic zone during the evolution of karst soil caves in the process of heavy rainfall infiltration.
The numerical simulation results show that, (1) Under the condition of heavy rainfall, the maximum displacements of soil caves with different diameters all appear at the top of the cave. With the same rainfall rate, the larger the diameter of the soil cave is, the faster the growth rate of vertical displacement becomes. The increase of rainfall rate may result in obvious increase of vertical displacement, and the vertical displacement of the cave top is positively proportional to the size of the soil cave. (2) Given the same rainfall rate, the expansion of the soil cave diameter has caused the further expansion of the shear failure area at the bottom of the soil cave. The overlying soil layer is mainly subjected to subsurface erosion in the early stage of heavy rainfall. When the rainfall rate is accelerated, the water-hammer gas explosion of the overlying soil caused by the violent fluctuation of the water level at the bottom of the soil cave becomes the dominant effect. The shear failure rate is accelerated, and the shear strain at the toe of the cave increases significantly. When the diameter of the soil cave reaches 3 m, the water level fluctuates more and more violently, which accelerates the destruction of the overlying soil layer. (3) The change of rainfall rate poses, in different degrees, the influence on the development range of plastic zone in the soil cave. In the soil cave with a larger diameter, the development range of plastic zoon is significantly expanded with the accelerated rainfall rate. The size of the soil cave and the speed of rainfall have a great influence on the stability of the overlying soil layer. These results provide a basis for the quantitative study of the relationship between heavy rainfall and collapse of the overlying soil, which is crucial to effective and reasonable warning to karst collapse.
-
Key words:
- heavy rainfall /
- karst collapse /
- FLAC3D /
- numerical simulation /
- soil cave
-
-
表 1 土体基本物理、力学参数
Table 1. Basic physical and mechanical parameters of soil
覆盖层类型 密度/g·cm−3 孔隙率 剪切模量/kpa 体积模量/kpa 内摩擦角/° 粘聚力/kPa 渗透系数/cm·s−1 粉质黏土 1.72 0.47 1.354
1064.22
1068.8 25.3 3.22
10−4
下载: 导出CSV
表 2 模拟方案设计
Table 2. Simulation scheme design
方案 土洞直
径/m降雨强
度/mm·d−1集雨面
积/m2降雨历
时/h降雨速
率/m3·s−11 0.5 200 50 2 1.39
10−31.0 1.5 2.0 2.5 3.0 2 0.5 2.5 1.11
10−31.0 1.5 2.0 2.5 3.0 3 0.5 4 6.94
10−41.0 1.5 2.0 2.5 3.0
下载: 导出CSV
-
[1] CHEN Xuejun. GIS-based evaluation of danger in karst collapse[J]. Journal of China University of Geosciences, 2001(2):132-136.
[2] 陈学军, 杨越, 白汉营, 宋宇, 陈李洁. 基于ANP-模糊聚类分析法的岩溶塌陷研究[J]. 工程地质学报, 2017, 27(5):1213-1219. doi: 10.13544/j.cnki.jeg.2017.05.005
CHEN Xuejun, YANG Yue, BAI Hanying, SONG Yu, CHEN Lijie. Use of analytic network process and fuzzy clustering analysis method in karst collapse[J]. Journal of Engineering Geology, 2017, 27(5):1213-1219. doi: 10.13544/j.cnki.jeg.2017.05.005
[3] 陈学军, 陈植华, 贾晓青. 桂林市西城区岩溶塌陷灾害危险性评价[M]. 武汉: 中国地质大学出版社, 2004: 69-71.
CHEN Xuejun, CHEN Zhihua, JIA Xiaoqing. Risk assessment of karst collapse disaster in Xicheng district, Guilin City[M]. Wuhan: China University of Geosciences Press, 2004: 69-71.
[4] 雷明堂, 蒋小珍, 李瑜. 岩溶塌陷模型试验: 以武昌为例[J]. 地质灾害与环境保护, 1993, 4(2):39-44.
LEI Mingtang, JIANG Xiaozhen, LI Yu. Karst collapse model test: Taking Wuchang as an example[J]. Geological Hazards and Environmental Protection, 1993, 4(2):39-44.
[5] 戴建玲, 雷明堂, 蒋小珍, 罗伟权. 极端气候与岩溶塌陷[J]. 中国矿业, 2020, 29(S2):402-404. doi: 10.12075/j.issn.1004-4051.2020.S2.082
DAI Jianling, LEI Mingtang, JIANG Xiaozhen, LUO Weiquan. Extreme climate and sinkhole[J]. China Mining Magazine, 2020, 29(S2):402-404. doi: 10.12075/j.issn.1004-4051.2020.S2.082
[6] Jiang Xiaozhen, Lei Mingtang, Gao Yongli. Formation mechanism of large sinkhole collapses in Laibin, Guangxi, China[J]. Environment Earth Sciences, 2017, 76(24):810-823.
[7] 靳红华, 王林峰, 杨培丰, 宋男男. 降雨与岩溶渗漏联合作用下岩溶塌陷稳定性分析[J]. 人民长江, 2019, 50(9):105-112. doi: 10.16232/j.cnki.1001-4179.2019.09.018
JIN Honghua, WANG Linfeng, YANG Peifeng, SONG Nannan. Stability analysis of karst collapse considering joint effect of rainfall infiltration and groundwater leakage[J]. Yangtze River, 2019, 50(9):105-112. doi: 10.16232/j.cnki.1001-4179.2019.09.018
[8] Xiao Xiaoxuan, Li Zhaofeng, Cai Guoqing, Yang He. Effects of declining water levels on water-air interactions in cover collapse sinkhole[J]. Bulletin of Engineering Geology Environment, 2021, 80(3):2545-2556. doi: 10.1007/s10064-020-02089-y
[9] XIAO Xiaoxuan, XU Mo, DING Qingzhong, KANG Xiaobing, XIA Qiang, DU Feng. Experimental study investigating deformation behavior in land overlying a karst cave caused by groundwater level changes[J]. Environment Earth Sciences, 2018, 77(3):64-77. doi: 10.1007/s12665-017-7102-y
[10] Xiao Xiaoxuan, Gutiérrez Francisco, Guerrero Jesús. The impact of groundwater drawdown and vacuum pressure on sinkhole development. Physical laboratory models[J]. Engineering Geology, 2020, 279:1-10. doi: 10.1016/j.enggeo.2020.105894
[11] 贾龙, 蒙彦, 管振德. 岩溶土洞演化及其数值模拟分析[J]. 中国岩溶, 2014, 33(3):294-298. doi: 10.11932/zgyr20140305
JIA Long, MENG Yan, GUAN Zhende. Evolution and numerical simulation of a karst soil cave[J]. Carsologica Sinica, 2014, 33(3):294-298. doi: 10.11932/zgyr20140305
[12] 苏添金, 洪儒宝, 简文彬. 覆盖型岩溶土洞致灾过程的数值模拟与预测[J]. 自然灾害学报, 2018, 27(5):179-187. doi: 10.13577/j.jnd.2018.0520
SU Tianjin, HONG Rubao, JIAN Wenbin. Numerical simulation and prediction of covered karst collapse[J]. Journal of Natural Disasters, 2018, 27(5):179-187. doi: 10.13577/j.jnd.2018.0520
[13] 陈育民, 许鼎平. FLAC3D基础工程与实例[M]. 中国水利水电出版社, 2013.
CHEN Yumin , XU Dingping. FLAC3D foundation engineering and examples[M]. China Water Resources and Hydropower Press, 2013.
[14] 彭文斌. FLAC3D实用教程[M]. 机械工业出版社, 2020.
PENG Wenbin. FLAC3D practical tutorial[M]. China Machine Press, 2020.
[15] 唐灵明. 强降雨作用下覆盖型岩溶塌陷模型试验研究[D]. 桂林: 桂林理工大学, 2021.
TANG Lingming. Experimental study on covering karst collapse model under heavy rainfall[D]. Guilin: Guilin University of Technology, 2021.
[16] 王文全, 张立翔. 计算流固耦合动力学及其应用[M]. 中国水利水电出版社, 2015: 58-67.
WANG Wenquan, ZHANG Lixiang. Computational fluid structure coupling dynamics and its application[M]. China Water Resources and Hydropower Press, 2015: 58-67.
[17] 高江平, 胡海波, 孙世界, 王泽普. 太沙基地基极限承载力的三剪应力统一强度理论解[J]. 西安建筑科技大学学报(自然科学版), 2019, 51(2):186-191. doi: 10.15986/j.1006-7930.2019.02.005
GAO Jiangping, HU Haibo, SUN Shijie, WANG Zepu. Three-shear stress unified strength theoretical solution of Terzaghi ultimate bearing capacity of foundation[J]. Journal of Xi'an University of Architecture & Technology(Natural Science Edition), 2019, 51(2):186-191. doi: 10.15986/j.1006-7930.2019.02.005
[18] 张鑫. 覆盖型岩溶塌陷模型试验与数值模拟研究[D]. 合肥: 合肥工业大学, 2017.
ZHANG Xin. Model test and numericaI simulation of overburden karst collapse [D]. Hefei: Hefei University of Technology, 2017.
[19] 邢宇健. 岩溶区地下水位动态变化诱发地表塌陷的机理研究[D]. 北京: 北京交通大学, 2018.
XING Yujian. Study on the mechanism of overburden collapse induced by groundwater fluctuation in karst area[D]. Beijing: Beijing Jiaotong University, 2018.
[20] 肖先煊. 覆盖型岩溶区水气相互驱动盖层变形演化及塌陷机理研究[D]. 成都: 成都理工大学, 2018.
XIAO Xianxuan. Deformation behavior evolution and collapse mechanism of karst covers under water-air interaction in karst area[D]. Chengdu: Chengdu University of Technology, 2018.
[21] 王滨, 贺可强, 孙建敏. 岩溶塌陷临界土洞高度的确定:以唐山市体育场岩溶塌陷为例[J]. 工程地质学报, 2005, 13(3):320-324. doi: 10.3969/j.issn.1004-9665.2005.03.007
WANG Bin, HE Keqiang, SUN Jianmin. Determination of critical height of soil holes of karst collapse: Karst collapse case from Tangshan palaestra[J]. Journal of Engineering Geology, 2005, 13(3):320-324. doi: 10.3969/j.issn.1004-9665.2005.03.007
[22] 王滨, 贺可强. 岩溶塌陷临界土洞的极限平衡高度公式[J]. 岩土力学, 2006, 27(3):458-462. doi: 10.3969/j.issn.1000-7598.2006.03.024
WANG Bin, HE Keqiang. Study on limit equilibrium height expression of critical soil cave of karst collapse[J]. Rock and Soil Mechanics, 2006, 27(3):458-462. doi: 10.3969/j.issn.1000-7598.2006.03.024
-
