摘要:
近年来岩溶地区呈高发态势的路面塌陷灾害不断威胁城市交通安全。用回填压实法治理塌陷时，埋入土工织物所形成的加筋垫层，能增强土体稳定性，防止二次塌陷。然而加筋治理方案中筋材的锚固长度分析及受力计算理论相对缺失，现存的加筋体设计方法也较少考虑塌陷发生后加筋治理铺设范围的选择，这些不足严重制约了土工合成材料在岩溶路基塌陷中的工程应用。针对这一现状，提出了一种岩溶路基塌陷后加筋治理的设计方法。该方法采用条分法对筋材上方土拱以下范围的填土进行受力分析，结合筋−土的作用特点，给出了塌陷区和稳定区加筋体拉力的计算公式，进而推导了加筋治理合理锚固长度的计算公式，并梳理了加筋体锚固长度设计流程；在此基础上，基于相关文献的模型试验结果及前人的计算方法对设计方法进行合理性验证，并进一步讨论塌陷宽度、加筋体最大挠度对加筋体拉力和合理锚固长度的影响。结果表明：（1）提出的加筋设计方法计算简洁，所得结果与试验结果更为吻合，由此建立的土工织物加筋垫层治理岩溶区城市路面塌陷的筋材拉力计算理论，对于工程实践具有一定的指导意义；（2）加筋体拉力在塌陷边缘处达到最大，塌陷宽度才是影响加筋体受力和合理锚固长度的主要因素，而加筋体最大挠度对合理锚固长度的影响较小。
Abstract:Karst areas are widely distributed in China, especially in South China. With the proposal of the Belt and Road Initiative, a large amount of infrastructure has to be built in the karst area. However, the diversity of structure and mechanical properties of karst make it difficult for us to construct roads on karst foundations. In recent years, the frequent occurrence of settlement and even collapse of the road surface caused by karst foundations under soil layers of roads has threatened the safety of urban transportation and the development of economy. Therefore, the treatment of karst collapse has become an urgent engineering problem. For the controlling of karst collapse under a complex urban road environment, the treatment of karst collapse by the method of backfilling and compacting is economical in construction and can be finished in short time, but collapses are prone to happen again after treatment. In this case, the treatment can be carried out with geosynthetics, namely filling the geotextile in the subsidence area during the backfilling and compacting process. This kind of treatment utilizes not only the reinforcement effect of geotextiles to achieve the self-stability of the entire reinforced soil system, but also utilizes the filtration performance of geotextiles to prevent the loss of soil particles backfilled, thus addressing both the symptoms and root causes of the collapse. However, the interface interaction between reinforcement and soil is so complex in this method that the corresponding design method of reinforcement is still not clear. In previous studies, the design method of reinforcement focuses on the prevention of collapse before its occurrence. In this kind of method, reinforcement materials are generally used with sufficient anchoring length for full paving. As for the design method of treatment after collapse, there are few studies on the range selection of paving reinforcement. In addition, the maximum tensile force of geotextile will affect its strength design and then impact the overall strength of the reinforced body. Therefore, the previous studies on anchoring length and the lack of theories on calculating reinforcement force have restricted the application of reinforcement in engineering practice.
In order to accurately calculate the maximum tensile force of the reinforcement and to study the anchoring length of the geotextile, a design method for reinforced treatment of karst roadbed collapse was proposed. Firstly, the simplified Bishop's strip method was used to analyze the soil force. According to the characteristics of tension action between reinforcement and soil, the calculation formula of the reinforcement force in subsidence areas and stability areas was deduced by assuming that the deformation of the reinforcement was catenary. Meanwhile, with the assumption that the anchoring force of the reinforced body was greater than the maximum tensile force to ensure the settlement stability of the subsidence area, a calculation formula for the reasonable anchoring length of the reinforcement was worked out and the relevant design procedure of the anchor length was sorted out. Additionally, based on the test results of existing models and the comparison with previous calculation methods, the calculation method of adding reinforcement tension and of the reasonable anchoring length was verified, on this basis of which the parameter design was conducted according to the relevant experimental results. It was assumed that the vertical stress in the stability area was roughly distributed in a decreasing exponential form. Finally, the effects of collapse width and maximum deflection of the reinforcement on the tensile force and on reasonable anchoring length were analyzed.
The results show that firstly, a design method of anchoring length of geotextile reinforced cushion for treating urban road collapses in karst areas has been established in this study. In order to ensure the reliability of the proposed design method of reinforcement, the methods of determining values involving the vertical stress distribution function P(x) of the tensile force reinforcement should be taken into account, one is the value determination by model tests or numerical means; another is the value estimation according to the classical earth arch theory. Meanwhile, when determining the anchoring length, it is necessary for us to introduce the corresponding factor of safety in combination with the actual situation to ensure the project quality. Secondly, the calculation results by the design method in this study are more consistent with the test results of other methods, which suggests that the proposed method not only increases the safety of preventing karst subgrade collapse, but also effectively improves the utilization effect of reinforcement. The result is of referential value for engineering practice. Moreover, the design method in this study also shows that both the anchoring length and the tensile force of reinforced body demanded by geotextile are big when the range of subgrade collapse is large. Thirdly, the collapse width is the main factor affecting the force of the reinforced body and the reasonable anchoring length. But the maximum deflection of the reinforced body has little effect on the reasonable anchoring length. Therefore, it is necessary to choose the anchoring length of the geosynthetics for the subgrade with a high standard required by the tendency to road deformation.
-
-
[1] 罗小杰, 沈建. 我国岩溶地面塌陷研究进展与展望[J]. 中国岩溶, 2018, 37(1):101-111.
LUO Xiaojie, SHEN Jian. Research progress and prospect of karst ground collapse in China[J]. Carsologica Sinica, 2018, 37(1):101-111.
[2] 吴亚楠. 泰安市城区−旧县水源地岩溶地面塌陷历程及影响因素分析[J]. 中国岩溶, 2020, 39(2):225-231.
WU Yanan. Analysis on development history and influencing factors of the karst collapse in Tai'an-Jiuxian water source area[J]. Carsologica Sinica, 2020, 39(2):225-231.
[3] 郑晓明, 金小刚, 陈标典, 刘鹏瑞, 杨戈欣, 李海涛, 杨涛. 湖北武汉岩溶塌陷成因机理与致塌模式[J]. 中国地质灾害与防治学报, 2019, 30(5):75-82.
ZHENG Xiaoming, JIN Xiaogang, CHEN Biaodian, LIU Pengrui, YANG Gexin, LI Haitao, YANG Tao. Mechanism and modes of karst collapse in Wuhan City, Hubei Province[J]. The Chinese Journal of Geological Hazard and Control, 2019, 30(5):75-82.
[4] 陈雨昂, 唐荣, 方建, 孔锋. 2014-2018年中国城市路面塌陷时空规律与原因分析[J]. 水利水电技术, 2020, 51(7): 108-116.
CHEN Yu'ang, TANG Rong, FANG Jian, KONG Feng. Analysis on spatio-temporal law and causation of urban road collapse in China from 2014 to 2018[J]. Water Resources and Hydropower Engineering: 2020, 51(7): 108-116.
[5] 胡聿涵, 白玉川, 徐海珏. 近10年中国城市道路塌陷原因及防治对策分析[J]. 公路, 2016(9):130-135.
HU Yuhan, BAI Yuchuan, XU Haijue. Analysis of reasons for urban road collapse and prevention and control countermeasures in recent decade of China[J]. Highway, 2016(9):130-135.
[6] 孙锡良, 陈亮晶, 欧健, 陈文东. 湖南宁乡煤炭坝镇富家村岩溶地面塌陷成因分析及防治建议[J]. 中国岩溶, 2018, 37(3):421-426.
SUN Xiliang, CHEN Liangjing, OU Jian, CHEN Wendong. Cause analyses and prevention suggestions for the karst collapse in the Fujia village of Hunan, China[J]. Carsologica Sinica, 2018, 37(3):421-426.
[7] 刘阳, 刘家才. 某海堤后方地面塌陷原因分析[J]. 水运工程, 2019(8):92-96. doi: 10.3969/j.issn.1002-4972.2019.08.018
LIU Yang, LIU Jiacai. Reason analysis of ground collapse in the rear of a seawall[J]. Port & Waterway Engineering, 2019(8):92-96. doi: 10.3969/j.issn.1002-4972.2019.08.018
[8] 吴迪, 吴建建, 徐超, 陈学军, 黄翔. 土工织物治理岩溶路基塌陷的模型试验研究[J]. 岩土力学, 2020, 41(Supp.2):143-153.
WU Di, WU Jianjian, XU Chao, CHEN Xuejun, HUANG Xiang. Model test of geotextiles in controlling the collapse of karst roadbed[J]. Rock and Soil Mechanics, 2020, 41(Supp.2):143-153.
[9] 贺炜, 李昆, 王芳洪. 防岩溶塌陷加筋垫层大比例模型试验及设计理论研究[J]. 岩石力学与工程学报, 2016, 35(5):980-988.
HE Wei, LI Kun, WANG Fanghong. Large-scale experimental study of multi-layered reinforcement to prevent underneath sinkhole in karst terrain and the design method[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 35(5):980-988.
[10] Vinh Le, Jie Huang, Sazzad Bin-Shafique, A T Papagiannakis. Model tests of subsidence of the reinforced soil over voids[C]//Ground Improvement and Geosynthetics, Shanghai, ASCE, 2014 (238): 312-321.
[11] Jie Huang,Vinh Le, Sazzad Bin-Shafique, A T Papagiannakis. Experimental and numerical study of geosynthetic reinforced soil over a channel[J]. Geotextiles & Geomembranes, 2015, 43(5):382-392.
[12] 万梁龙, 陈福全, 邹维列. 岩溶塌陷影响下加筋路基承载机理研究[J]. 长江科学院院报, 2017, 34(2):56-62.
WAN Lianglong, CHEN Fuquan, ZOU Weilie. Mechanisms of load transfer in geosynthetic-reinforced embankments subjected to localised karst collapse[J]. Journal of Yangtze River Scientific Research Institute, 2017, 34(2):56-62.
[13] 黄杰, 王钊, 肖衡林. 空穴加筋的设计方法及讨论[J]. 长江科学院院报, 2002(5):24-26 , 30. doi: 10.3969/j.issn.1001-5485.2002.05.007
HUANG Jie, WANG Zhao, XIAO Henglin. Design method of reinforcement over voids and discussion[J]. Journal of Yangtze River Scientific Research Institute, 2002(5):24-26 , 30. doi: 10.3969/j.issn.1001-5485.2002.05.007
[14] 丁烈梅, 郭超祥. 水平向加筋体抗沉陷作用机理分析及设计方法[J]. 土木工程与管理学报, 2016, 33(3):57-60, 67. doi: 10.3969/j.issn.2095-0985.2016.03.010
DING Liemei, GUO Chaoxiang. Mechanical performance and design method of horizontal reinforcement subjected to subsidence[J]. Journal of Civil Engineering and Management, 2016, 33(3):57-60, 67. doi: 10.3969/j.issn.2095-0985.2016.03.010
[15] 王非, 缪林昌. 落水洞上覆路堤土工加筋设计新方法[J]. 东南大学学报(自然科学版), 2009, 39(6):1217-1221. doi: 10.3969/j.issn.1001-0505.2009.06.025
WANG Fei, MIAO Linchang. New design method of geosynthetic-reinforced embankment over sinkhole[J]. Journal of Southeast University (Natural Science Edition), 2009, 39(6):1217-1221. doi: 10.3969/j.issn.1001-0505.2009.06.025
[16] 刘飞成, 张建经, 曾鹏毅. 一种桩网路堤荷载传递机制的简化分析方法[J]. 岩石力学与工程学报, 2018, 37(Supp.1):3747-3755.
LIU Feicheng, ZHANG Jianjing, ZENG Pengyi. A simplified method to analyze load transfer mechanisms of geosynthetic-reinforced and pile-supported embankment[J]. Chinese Journal of Rock Mechanics and Engineering, 2018, 37(Supp.1):3747-3755.
[17] Han J, Gabr M A. Numerical analysis of geosynthetic-reinforced and pile-supported earth platforms over soft soil[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2002, 128(1):44-53. doi: 10.1061/(ASCE)1090-0241(2002)128:1(44)
[18] 周亦涛, 陈福全. 抗条形沉陷的土工合成材料加筋体设计[J]. 中国科技论文, 2019, 14(4):441-446. doi: 10.3969/j.issn.2095-2783.2019.04.016
ZHOU Yitao, CHEN Fuquan. Design of reinforcement of geosynthetics for resisting strip settlement[J]. China Science Paper, 2019, 14(4):441-446. doi: 10.3969/j.issn.2095-2783.2019.04.016
[19] 付宏渊, 殷苗苗, 贺炜. 防治公路岩溶塌陷的土工合成材料设计理论研究[J]. 岩土力学, 2011, 32(10):2983-2988. doi: 10.3969/j.issn.1000-7598.2011.10.015
FU Hongyuan, YIN Miaomiao, HE Wei. Study of design theory of geosynthetics for treating road sinkhole collapse hazard in karst terrain[J]. Rock and Soil Mechanics, 2011, 32(10):2983-2988. doi: 10.3969/j.issn.1000-7598.2011.10.015
[20] 赵洪元, 蔺港, 杨胜波. 公路路堤抗溶洞塌陷水平加筋体受力机理及设计方法研究[J]. 中外公路, 2015, 35(4):35-38.
[21] 朱斌, 陈若曦, 陈云敏, 陈仁朋. Trapdoor 位移相关土压力及抗沉陷加筋设计新方法[J]. 岩土工程学报, 2009, 31(12):1895-1901. doi: 10.3321/j.issn:1000-4548.2009.12.014
ZHU Bin, CHEN Ruoxi, CHEN Yunmin, CHEN Renpeng. Trapdoor deflection-related earth pressure and new design method of reinforcements to resist local subsidence[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(12):1895-1901. doi: 10.3321/j.issn:1000-4548.2009.12.014
[22] 贺炜, 付宏渊. 岩溶区路堤下塌陷防治的水平加筋设计方法研究[J]. 岩土工程学报, 2011, 33(Supp.1):365-370.
HE Wei, FU Hongyuan. Design of horizontal reinforcement as prevention of sinkhole hazards for roadbed engineering in karst areas[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(Supp.1):365-370.
[23] 张东卿, 薛元, 罗强, 刘菀茹, 郑永飞. 水平加筋体加固岩溶路基受力机理及设计方法[J]. 西南交通大学学报, 2019, 54(2):336-342. doi: 10.3969/j.issn.0258-2724.20170784
ZHANG Dongqing, XUE Yuan, LUO Qiang, LIU Wanru, ZHENG Yongfei. Load mechanisms and design method for karst subgrade reinforced by horizontal geosynthetic reinforcement[J]. Journal of Southwest Jiaotong University, 2019, 54(2):336-342. doi: 10.3969/j.issn.0258-2724.20170784
[24] 陈福全, 赖丰文. 抗土洞塌陷的低填方加筋路基荷载传递机制及设计方法[J]. 岩土工程学报, 2018, 40(7):1180-1189.
CHEN Fuquan, LAI Fengwen. Load transfer mechanisms and design method of low geosynthetic-reinforced embankments subjected to localized sinkholes[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(7):1180-1189.
[25] 陈福全, 万梁龙. 岩溶塌陷影响下加筋路基加筋体设计方法[J]. 中南大学学报(自然科学版), 2018, 49(1):208-216. doi: 10.11817/j.issn.1672-7207.2018.01.027
CHEN Fuquan, WAN Lianglong. Design method for geosynthetics as reinforcement to prevent embankments from collapsing due to localised sinkholes[J]. Journal of Central South University (Science and Technology), 2018, 49(1):208-216. doi: 10.11817/j.issn.1672-7207.2018.01.027
[26] Huckert A, Briancon L, Villard P, Garcin P. Load transfer mechanisms in geotextile-reinforced embankments overlying voids: Experimental and analytical approaches[J]. Geotextiles and Geomembranes, 2016, 44(3):442-456. doi: 10.1016/j.geotexmem.2015.06.005
[27] Abusharar S W, Zheng J J, Chen B G, Yin J H. A simplified method for analysis of a piled embankment reinforced with geosynthetics[J]. Geotextiles and Geomembranes, 2009, 27(1):39-52. doi: 10.1016/j.geotexmem.2008.05.002
[28] Lu W H, Miao L C. A simplified 2D evaluation method of the arcing effect for geosynthetic-reinforced and pile-supported embankments[J]. Computers and Geotechnics, 2015, 65(65):97-103.
[29] Helwett W J, Randolph M F. Analysis of piled embankment[J]. Ground Engineering, 1988, 21(3):12-18.
[30] Giroud J P, Bonaparte R, Beech J F. Design of soil layer-geosynthetic systems overlying voids[J]. Geotextiles & Geomembranes, 1990, 9(1):11-50.
[31] British Standard Institution. BS-8006 Code of Practice for Strengthened/Reinforced Soils and Other Fills[S]. 2010.
-
