湖北省蒲圻县(赤壁)幅1∶50 000环境地质调查数据集

张傲; 邵长生; 王岑; 杨艳林; 路韬

doi:10.12029/gc2019Z205

湖北省蒲圻县(赤壁)幅1∶50 000环境地质调查数据集

中国地质调查局武汉地质调查中心，湖北武汉 430205

基金项目: 中国地质调查局武汉市多要素城市地质调查（DD20190282）和中国地质调查局长江中游城市群咸宁—岳阳和南昌—怀化段高铁沿线1∶5万环境地质调查（DD20160248）联合资助

详细信息

作者简介: 张傲，男，1988年生，博士，工程师，研究方向为城市地质调查；E-mail：zhangaocug@163.com

收稿日期: 2019-10-25

修回日期: 2019-11-13

刊出日期: 2019-12-25

Dataset of the Environmental Geological Survey on a Scale of 1∶50 000 in the Puqi County (Present Chibi City) Map Sheet, Hubei Province

Wuhan Center, China Geological Survey, Wuhan 430205, China

Fund Project: Jointly funded by two projects titled “Multi-element Urban Geological Survey of Wuhan City” (DD20190282) and “Environmental Geological Survey on a Scale of 1∶50 000 in the City Clusters of the Middle Reaches of Yangtze River Along Xianning – Yueyang and Nanchang – Huaihua High-speed Railway” (DD20160248) initiated by China Geological Survey.

More Information

Author Bio: ZHANG Ao, male, born in 1988, engineer with doctorate degree, engages in urban geological survey; E-mail: zhangaocug@163.com .

Received Date: 25 October 2019

Revised Date: 13 November 2019

Publish Date: 25 December 2019

摘要

摘要:
依托自然资源部中国地质调查局部署的“长江中游城市群咸宁—岳阳和南昌—怀化段高铁沿线1∶50 000环境地质调查”项目, 开展了蒲圻县幅1∶50 000环境地质调查。本数据集采取水文地质调查、岩溶地面塌陷调查、水文地质钻探、水质测试分析等方法而形成。数据集包含73个泉水调查点、7个矿泉水测试分析结果、1个岩溶地面塌陷点、7个岩溶洞穴点、10个水文钻孔等5方面数据。其中泉水调查成果包括泉点的分布位置、野外水质检测指标、泉水成因等; 矿泉水分析结果为针对区内泉点及水文钻孔所取水样进行室内测试, 达到矿泉水标准的测试结果; 岩溶地面塌陷数据主要包括岩溶地面塌陷的位置、塌陷坑特征、地质背景、塌陷后状态等信息; 岩溶洞穴调查成果包括洞穴点的位置、洞穴发育特征、开发利用情况等信息; 钻孔基本情况数据为钻孔位置信息、孔径、孔深等信息。数据集为赤壁市城镇规划建设, 土地安全利用, 优质地质资源开发提供重要的地质数据源支撑。
- 环境地质调查工程 /
- 地下水 /
- 矿泉水 /
- 岩溶地面塌陷 /
- 地质灾害 /
- 赤壁市 /
- 湖北省
Abstract:
The environmental geological survey on a scale of 1∶50 000 in the Puqi Map Sheet (also referred to as the Survey) was carried out by relying on the project titled Environmental Geological Survey on a Scale of 1∶50 000 in the City Clusters of the Middle Reaches of the Yangtze River Along Xianning – Yueyang and Nanchang – Huaihua High-speed Railway initiated by the China Geological Survey. The dataset obtained through the Survey (also referred to as the Dataset) was developed by methods such as the hydrogeological survey, karst collapse survey, hydrogeological drilling and water-quality testing and analysis. It consists of the data of 73 spring survey points, test and analystical results of mineral water from 7 water samples and the data from 1 karst collapse point, 7 karst cave points and 10 hydrological boreholes. The detailed contents of these data are as follows: the results of the spring water survey include locations of spring survey points, water quality indices to be tested in the field and the genesis of spring water. The analytical results of mineral water are the ones reaching the requirements of mineral water according to the indoor testing of water samples taken from spring points and hydrological boreholes in the Puqi County Map Sheet. The data of karst collapses mainly include location of karst collapses, features of collapse pits, geological background and the state after collapse. The survey results of karst caves include the location, development features and development and utilization of the caves. The data of boreholes contain the location, diameter and depth of the boreholes. The Dataset will provide an important geological source for the planning and construction of towns, safe utilization of land and the development of high-quality geological resources in Chibi City.
- environmental geological survey engineering /
- groundwater /
- mineral water /
- karst collapse /
- geologic disaster /
- Chibi City /
- Hubei Province

HTML全文

图 1 蒲圻县（赤壁）幅地理交通位置图

下载: 全尺寸图片幻灯片

图 2 地下水调查点分布图

下载: 全尺寸图片幻灯片

Figure 1.

下载: 全尺寸图片幻灯片

Figure 2.

下载: 全尺寸图片幻灯片

表 1 数据库(集)元数据简表

条目	描述
数据库(集)名称	湖北蒲圻县(赤壁)幅1∶50 000环境地质调查数据集
数据库(集)作者	张傲，中国地质调查局武汉地质调查中心邵长生，中国地质调查局武汉地质调查中心王岑，中国地质调查局武汉地质调查中心杨艳林，中国地质调查局武汉地质调查中心路韬，中国地质调查局武汉地质调查中心
数据时间范围	2017.1—2017.12
地理区域	湖北省咸宁市赤壁
数据格式	*.xlsx
数据量	76 KB
数据服务系统网址	http://dcc.cgs.gov.cn
基金项目	武汉市多要素城市地质调查(DD20190282)和长江中游城市群咸宁−岳阳和南昌−怀化段高铁沿线1∶50 000环境地质调查(DD20160248)联合资助
语种	中文
数据库(集)组成	泉水调查表.xlsx、矿泉水测试分析表.xlsx、岩溶地面塌陷调查表.xlsx、岩溶洞穴调查表.xlsx、钻孔基本情况表.xlsx

下载: 导出CSV

表 2 泉水调查表

序号	数据项名称	数据类型	实例
1	野外编号	字符串	Q120
2	地理位置	字符串	赤壁市凤凰山镇公安泉村八组
3	图幅编号	字符串	蒲圻县幅(H49E014024)
4	泉水类型	字符串	下降泉
5	含水层岩性	字符串	S2f2泥质粉砂岩夹砂岩
6	主要用途	字符串	未利用
7	补给来源	字符串	碎屑岩裂隙水
8	天气	字符串	多云转晴
9	气温/℃	浮点型	33
10	流量测定方法	字符串	流速仪
11	泉的流量/(L/s)	浮点型	0.16
12	动态变化特征	字符串	据访问，该泉流量随季节变化，长年有水，雨后流量增大，枯季减少
13	泉水温度/℃	浮点型	18
14	色度	字符串	无
15	味	字符串	无
16	气味	字符串	无
17	透明度	字符串	透明
18	pH	浮点型	7.06
19	取样情况	字符串	无
20	Eh/mV	浮点型	257
21	DO/(mg/L)	浮点型	6.12
22	电导率/(μs/cm)	浮点型	267.1
23	周围可能的污染源	字符串	周围未见明显污染源
24	含水层特征	字符串	地质：为志留系坟头组泥质粉砂岩。地貌：位于低岗地与堆积阶地过渡地带。含水层：点西侧为志留系坟头组碎屑岩裂隙含水岩组，富水性中等，据调查，该泉原供应生产队几十人同时使用
25	备注	字符串	据访问，该泉原来流量较大，流量可达0.3 L/S。因废弃多年无人使用，致使先流量很小。点位于王洪山背斜北翼
26	调查工作时间	字符串	2017-06-03

下载: 导出CSV

表 3 矿泉水测试分析表

序号	数据项名称	数据类型	实例	序号	数据项名称	数据类型	实例
1	送样号	字符串	Q02	23	Mg²⁺/(mg/L)	浮点型	4.14
2	分析号	字符串	C172070002	24	NH⁴⁺/(mg/L)	浮点型	0
3	HBO₂/(mg/L)	浮点型	0.012	25	Fe³⁺/(mg/L)	浮点型	0.046
4	Cu/(mg/L)	浮点型	0.001 0	26	Fe²⁺/(mg/L)	浮点型	0
5	Pb/(mg/L)	浮点型	0.000 30	27	Cl⁻/(mg/L)	浮点型	1.67
6	Zn/(mg/L)	浮点型	0.001 1	28	SO₄²⁻/(mg/L)	浮点型	19.3
7	Ni/(mg/L)	浮点型	0.007 8	29	HCO³⁻/(mg/L)	浮点型	266
8	Co/(mg/L)	浮点型	0.001 4	30	CO₃²⁻/(mg/L)	浮点型	0
9	Cd/(mg/L)	浮点型	<0.000 1	31	NO₃⁻/(mg/L)	浮点型	11.4
10	Li/(mg/L)	浮点型	0.003 0	32	NO₂⁻/(mg/L)	浮点型	0
11	Mo/(mg/L)	浮点型	0.000 20	33	F⁻/(mg/L)	浮点型	0.19
12	As/(mg/L)	浮点型	0.003 0	34	PO₄³⁻/(mg/L)	浮点型	0.022
13	Hg/(mg/L)	浮点型	0.000 10	35	pH	浮点型	7.6
14	Sr/(mg/L)	浮点型	0.36	36	H₂SiO₃/(mg/L)	浮点型	11.8
15	Ba/(mg/L)	浮点型	0.016	37	Mn/(mg/L)	浮点型	0.004 1
16	V/(mg/L)	浮点型	0.001 7	38	Br⁻/(mg/L)	浮点型	0.009 0
17	Se/(mg/L)	浮点型	0.000 30	39	耗氧量/(mg/L)	浮点型	0.64
18	Ag/(mg/L)	浮点型	0.000 20	40	游离CO₂/(mg/L)	浮点型	3.30
19	I⁻/(mg/L)	浮点型	0.001 0	41	可溶性SiO₂/(mg/L)	浮点型	9.10
20	K⁺/(mg/L)	浮点型	0.37	42	Cr⁶⁺/(mg/L)	浮点型	0
21	Na⁺/(mg/L)	浮点型	0.90	43	Al³⁺/(mg/L)	浮点型	0.068
22	Ca²⁺/(mg/L)	浮点型	91.4

下载: 导出CSV

表 4 岩溶地面塌陷调查表

序号	数据项名称	数据类型	实例
1	野外编号	字符串	TX446
2	图幅编号	字符串	蒲圻县幅(H49E014024)
3	天气	字符串	晴
4	地理位置	字符串	湖北省赤壁市赤马港镇砂子岭村八组
5	塌陷前兆	字符串	地面裂缝
6	诱发因素	字符串	道路施工，抽水，地面堆载
7	塌陷坑深度	浮点型	3
8	塌陷坑剖面形态	字符串	坛状
9	塌陷坑平面形态	字符串	椭圆形
10	下伏基岩是否可见	字符串	否
11	水位埋深/m	浮点型	4.88
12	塌陷坑长轴方向	浮点型	10
13	有无洞穴存在	字符串	无
14	江河水位高程/m	浮点型	29.9
15	塌陷坑长轴半径/m	浮点型	57.5
16	塌陷坑短轴半径/m	浮点型	35
17	洞穴类型	字符串	土洞
18	地貌类型	字符串	丘陵平原
19	土地利用类型	字符串	旱地
20	附近最近出现的塌坑或湖	字符串	无
21	土层结构	字符串	单层结构Qp棕红色网纹状粉质黏土，密集坚硬
22	土层厚度/m	浮点型	5
23	基岩层位	字符串	三叠系下统嘉陵江组Tj
24	基岩岩性	字符串	白云质灰岩、灰岩
25	是否已处理	字符串	是
26	处理方案	字符串	1号塌陷坑于2010年采用跨越式基础应急措施，目前为平地建成河北大道路面，塌陷区未见明显变形，处理措施效果较好；2号塌陷坑于2012年采用填土夯实措施，现已建成地下停车场至今未再发生过塌陷现象
27	群体分布情况	字符串	距1号塌坑SE方向86 m处菜地发生2号塌坑
28	调查日期	字符串	2017-06-19

下载: 导出CSV

表 5 岩溶洞穴调查表

序号	数据项名称	数据类型	实例
1	野外编号	字符串	DX422
2	图幅编号	字符串	蒲圻县幅(H49E014024)
3	地理位置	字符串	湖北省赤壁市赤马港办事处砂子岭社区九组
4	天气	字符串	晴
5	温度/℃	浮点型	27
6	洞口高/m	浮点型	7.2
7	洞口宽/m	浮点型	4.3
8	洞口形状	字符串	拱形
9	洞口朝向/°	字符串	西北向290°
10	样品及数量	字符串	简分析2组(J21)
11	地貌类型	浮点型	岩溶丘陵
12	洞穴利用	浮点型	未利用
13	地貌位置	字符串	低丘中底部
14	地层及岩性	字符串	三叠系下统嘉陵江中段(T₁j²)灰岩，产状：170°∠65°
15	构造部位	字符串	位于B8蒲圻向斜南翼
16	水文地质	字符串	为碳酸盐岩类岩溶裂隙水，具备良好的地下水运移通道，洞穴内部地表形成水流，顶部有多出渗水点，有水滴落，下大雨水量增大，干旱时水量减少。流速法测得流量Q=193.34 L/S
17	工程地质	字符串	洞口走向110°，基岩裸露，出露地层岩性为三叠系下统嘉陵江组中段(T₂j)灰色灰岩，薄层—中厚层状，溶蚀而光滑，小溶沟溶槽发育，岩层产状179°∠69°，方解石脉发育，较坚硬
18	洞穴描述	字符串	溶穴走向110°，近水平方向延伸，约30 m向左发育(100°)，长逾50 m，洞内宽3～6 m，高5～7 m，石针乳，石灰华发育，水底见砂石冲出物(卵石、细砂)。推测为地下河出口
19	备注	字符串	本次实测：流速法，Q=192.57 L/S；水温T=16.9℃，pH=7.2，Eh=253.0 mV，Ec=446.01 μs/cm，DO=9.01
20	调查日期	字符串	2017-06-14

下载: 导出CSV

表 6 钻孔基本情况表

序号	数据项名称	数据类型	实例
1	野外编号	字符串	SZK2
2	地理位置	字符串	湖北省赤壁市中伙铺镇中伙村十六组
3	图幅编号	字符串	蒲圻县幅(H49E014033)
4	孔口高程/m	浮点型	44
5	钻机类型	字符串	XY-2
6	钻孔类型	字符串	水文钻孔
7	开孔日期	字符串	2017-11-28
8	终孔日期	字符串	2017-12-17
9	井斜/°	浮点型	0.5
10	开孔直径/mm	浮点型	219
11	终孔直径/mm	浮点型	130
12	终孔深度/m	浮点型	152
13	含水层初见水位/m		0.6
14	成井深度/m	浮点型	152
15	静止水位/m	浮点型	0.98
16	含水层特征	字符串	地质：钻孔揭露土层9.00 m为第四系黏土(Qh)，9～152.00 m为P₁q灰色灰岩。地貌：孔位位于岗地底部，地形起伏较小。含水层：主要含水段为9～152.00 m，其中孔深21.6～26.1 m，29.1～30.40 m为溶洞，含岩溶水，中等富水性
17	调查日期	字符串	2017-12-17

下载: 导出CSV

Table 1. Metadata Table of Database (Dataset)

Items	Description
Database (dataset) name	Dataset of the Environmental Geological Survey on a Scale of 1∶50 000 in the Puqi County (Present Chibi City) Map Sheet, Hubei Province
Database (dataset) authors	Zhao Ao, Wuhan Center, China Geological Survey Shao Changsheng, Wuhan Center, China Geological Survey Wang Cen, Wuhan Center, China Geological Survey Yang Yanlin, Wuhan Center, China Geological Survey Lu Tao, Wuhan Center, China Geological Survey
Data acquisition time	January—December in 2017
Geographic area	Chibi City, Xianning, Hubei Province
Data format	*.xlsx
Data size	76 KB
Data service system URL	http://dcc.cgs.gov.cn
Fund project	Jointly funded by two projects titled “Multi-element Urban Geological Survey of Wuhan City” (DD20190282) and “Environmental Geological Survey on a Scale of 1∶50 000 in the City Clusters of the Middle Reaches of the Yangtze River Along Xianning – Yueyang and Nanchang – Huaihua High-speed Railway” (DD20160248).
Language	Chinese
Database (dataset) composition	Spring water survey.xlsx, Mineral water testing and analysis.xlsx, Karst collapse survey.xlsx, Karst cave survey.xlsx, and Basic information of boreholes.xlsx

下载: 导出CSV

Table 2. Structure of “Spring water survey.xlsx” in the Dataset

No.	Data item name	Data type	Real example
1	Field No.	string	Q120
2	Geographic location	string	Group 8, Gonganquan Village, Fenghuangshan Town, Chibi City
3	Map sheet No.	string	Puqi Map Sheet (H49E014024)
4	Spring type	string	Gravity spring
5	Aquifer lithology	string	S2f2 muddy siltstone interbedded with sandstone
6	Main purpose	string	Not used
7	Source of recharge	string	Fissure water in clastic rocks
8	Weather	string	Clouds early/clearing late
9	Atmospheric temperature, ℃	float	33
10	Method of measuring flow	string	Flow meter
11	Spring flow (L/s)	float	0.16
12	Dynamic change features	string	According to visits, water flow varies with seasons and it increases after rain while decreases in the dry season; water flows all year round
13	Spring water temperature, ℃	float	18
14	Chroma	string	Colorless
15	Taste	string	Tasteless
16	Odor	string	Odorless
17	Transparency	string	Transparent
18	pH value	float	7.06
19	Sampling	string	No sample taken
20	Eh/mV	float	257
21	DO (mg/L)	float	6.12
22	EC (us/cm)	float	267.1
23	Possible pollution source nearby	string	No pollution source visible nearby
24	Aquifer feature	string	Geology: hybrid siltstone of the Silurian Fentou Formation. Landform: located in the transitional zone between low downland and accumulation terrace. Aquifer: fissured water-bearing formation of clastic rocks of the Silurian Fentou Formation in the western part of the survey point, with medium water richness. This spring was concurrently consumed by dozens of people in the previous production team according to investigations.
25	Remarks	string	According to visits, the water flow of this spring was up to 0.3 L/S before and then becomes very small after being discarded and unused for many years. It is located in the north wing of the anticline of the Wanghong Mount.
26	Date of survey	string	June 3, 2017

下载: 导出CSV

Table 3. Structure of “Mineral water testing and analysis.xlsx” in the Dataset

No.	Data item name	Data type	Real example	No.	Data item name	Data type	Real example
1	No. of testing samples	string	Q02	23	Mg²⁺/(mg/L)	float	4.14
2	Analysis No.	string	C172070002	24	NH⁴⁺/(mg/L)	float	0
3	HBO₂/(mg/L)	float	0.012	25	Fe³⁺/(mg/L)	float	0.046
4	Cu/(mg/L)	float	0.0010	26	Fe²⁺/(mg/L)	float	0
5	Pb/(mg/L)	float	0.00030	27	Cl^-/(mg/L)	float	1.67
6	Zn/(mg/L)	float	0.0011	28	SO₄^2-/(mg/L)	float	19.3
7	Ni/(mg/L)	float	0.0078	29	HCO^3-/(mg/L)	float	266
8	Co/(mg/L)	float	0.0014	30	CO₃^2-/(mg/L)	float	0
9	Cd/(mg/L)	float	<0.0001	31	NO₃^-/(mg/L)	float	11.4
10	Li/(mg/L)	float	0.0030	32	NO₂^-/(mg/L)	float	0
11	Mo/(mg/L)	float	0.00020	33	F^-/(mg/L)	float	0.19
12	As/(mg/L)	float	0.0030	34	PO₄^3-/(mg/L)	float	0.022
13	Hg/(mg/L)	float	0.00010	35	pH	float	7.6
14	Sr/(mg/L)	float	0.36	36	H₂SiO₃/(mg/L)	float	11.8
15	Ba/(mg/L)	float	0.016	37	Mn/(mg/L)	float	0.0041
16	V/(mg/L)	float	0.0017	38	Br^-/(mg/L)	float	0.0090
17	Se/(mg/L)	float	0.00030	39	DO/(mg/L)	float	0.64
18	Ag/(mg/L)	float	0.00020	40	Free CO₂/(mg/L)	float	3.30
19	I^-/(mg/L)	float	0.0010	41	Soluble SiO₂/(mg/L)	float	9.10
20	K⁺/(mg/L)	float	0.37	42	Cr⁶⁺/(mg/L)	float	0
21	Na⁺/(mg/L)	float	0.90	43	Al³⁺/(mg/L)	float	0.068
22	Ca²⁺/(mg/L)	float	91.4

下载: 导出CSV

Table 4. Structure of “Karst collapse survey.xlsx” in the Dataset

No.	Data item name	Data type	Example
1	Field No.	string	TX446
2	Map sheet No.	string	Puqi Map Sheet (H49E014024)
3	Weather	string	Sunny
4	Geographical location	string	Group 8, Shaziling Village, Chimagang Town, Chibi City, Hubei Province
5	Precursor of collapse	string	Ground fissures
6	Inducing factors	string	Road construction, water pumping and stacking on the ground
7	Depth of collapse pit	float	3
8	Profile morphology of collapse pit	string	Jar-shaped
9	Plane morphology of collapse pit	string	Ellipse
10	Whether underlying bedrock is visible	string	No
11	Burial depth of water level/m	float	4.88
12	Direction of long axis of collapse pit	float	10
13	Caves	string	No
14	Elevation of river level/m	float	29.9
15	Radius of long axis of collapse pit/m	float	57.5
16	the radius of the short axis of collapse pit/m	float	35
17	Cave type	string	Soil cave
18	Landform type	string	Hills and plain
19	Type of land utilization	string	Dry land
20	Collapse pits or lakes occurring nearby recently	string	No
21	Soil layer structure	string	Single-layer structure: Qp brownish red reticulate silty clay, dense and hard
22	Soil layer thickness/m	float	5
23	Bedrock horizon	string	Lower-Triassic Jialing River Formation Tj
24	Bedrock lithology	string	Dolomitic limestone, limestone
25	Whether the collapse has been treated	string	Yes
26	Treatment plan	string	The #1 collapse pit was treated with a spanning fundamental emergency measure in 2010. It is flat and has been built into a part of Hebei Road now with no marked deformation visible, indicating a good treatment effect. The #2 collapse pit was filled with soil and compacted in 2012. It has been converted into an underground parking lot now and no collapse has ever happened so far.
27	Distribution of collapse bit cluster	string	The #2 collapse pit occurred in the vegetable plot which is 86 m SE from the # 1 collapse pit.
28	Date of survey	string	June 19, 2017

下载: 导出CSV

Table 5. Structure of “Karst cave survey.xlsx” in the Dataset

No.	Data item name	Data type	Example
1	Field No.	string	DX422
2	Map sheet No.	string	Puqi Map Sheet (H49E014024)
3	Geographical location	string	Group 9, Shaziling Community, Chimagang Office, Chibi City, Hubei Province
4	Weather	string	Sunny
5	Temperature (℃)	float	27
6	Cave opening elevation (m)	float	7.2
7	Cave opening width (m)	float	4.3
8	Cave opening shape	string	Arch
9	Cave opening direction (°)	string	290°, Northwest
10	Samples and their qualities	string	2 for simple chemical analysis (J21)
11	Landform type	float	Karst hills
12	Cave utilization	float	Not used
13	Landform location	string	Medium – bottom part of low hills
14	Stratam and lithology	string	Limestone of the Middle Member of Lower-Triassic Jialing River Formation (T₁j²), attitude: 170°∠65°
15	Tectonic position	string	Located in the south wing of Puqi Syncline B8
16	Hydrogeology	string	The groundwater is fissure water in a carbonate-type karst with developed transportation channels. Inside the cave, water flows on the surface and water leaks and drops in some places of the ceiling. Water yield increases during cases of heavy rain and decreases in the dry season. The water flow is Q=193.34 L/S measured by the flow velocity method.
17	Engineering geology	string	The strike of the cave opening is 110° and the bedrock is exposed. The lithology of outcrops is characterized by thin-medium laminated, corroded and smooth gray limestone of the Middle Member of Lower-Triassic Jialing River Formation (T₂j), with the occurrence of 179°∠69° and small karrens and water-eroded grooves developed. Hard calcite veins are developed.
18	Cave description	string	The karst cave, with a strike of 110° and length of more than 50 m, extends nearly horizontally and one part with a length of about 30 m developed leftwards (100°). It is 3–6 m in width and 5–7 m in height inside, with lithostyle-shaped stalactites and travertines developed. Materials made of sand and stone washed out by water are visible in the water bottom (such as pebble and fine sand). It is inferred that the cave is located at an outlet of a subsurface river.
19	Remarks	string	Parameter values measured in this Survey: Q=192.57 L/S determined by flow velocity method; water temperature T=16.9°C, pH=7.2, Eh=253.0 mv, Ec=446.01 μs/cm and DO=9.01
20	Date of survey	string	June 14, 2017

下载: 导出CSV

Table 6. Structure of “Basic information of boreholes.xlsx”

No.	Data item name	Data type	Example
1	Field No.	string	SZK2
2	Geographic location	string	Group 16, Zhonghuo Village, Zhonghuopu Town, Chibi City, Hubei Province
3	Map sheet No.	string	Puqi Map Sheet (H49E014033)
4	Borehole head elevation/m	float	44
5	Drilling rig type	string	XY-2
6	Borehole type	string	Hydrological borehole
7	Start date of drilling	string	November 28, 2017
8	End date of drilling	string	December 17, 2017
9	Well deviation/°	float	0.5
10	Open hole diameter/mm	float	219
11	Final hole diameter/mm	float	130
12	Hole hole depth/m	float	152
13	Initial water level of aquifer/m		0.6
14	Well depth/m	float	152
15	Static water level/m	float	0.98
16	Aquifer features	string	Geology: it is revealed by the borehole that the soil layer at the depth of 9.00 m is Quaternary clay (Qh) and the rock layer at the depth of 9–152.00 m is gray limestone of P₁q. Landform: located in the bottom of downland, with topography rising and falling slightly. Aquifer: main water-bearing segment is located at the depth of 9–152.00 m, with the borehole at the depth of 21.6–26.1 m and karst caves at the depth of 29.1–30.40 m; the aquifer bears karst water, with medium water richness.
17	Date of survey	string	December 17, 2017

下载: 导出CSV

参考文献(12)

[1]	付立新. 2012. 湖北省赤壁市城区生活饮用水水质监测分析[J]. 环境卫生学杂志, 10(2): 221−224. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gwyx-wsx201205007
[2]	龚磊, 王新峰, 宋绵, 李红燕, 肖则佑, 胡啟锋, 王进, 吴琳伟, 王磊, 缪赛. 2019. 赣南兴国和宁都脱贫攻坚1∶50 000水文地质调查数据集[J]. 中国地质, 46(S1): 11−17.
[3]	马洪云, 李成柱, 张俊. 2018. 鄂尔多斯盆地地下水无机指标数据集(2014−2015)[J]. 中国地质, 45(S1): 27−31.
[4]	中华人民共和国国家质量监督检验检疫总局. 2008. 饮用天然矿泉水: GB 8537−2008 [S]. 北京: 中国标准出版社.
[5]	中华人民共和国国土资源部. 2014. 水文水井地质钻探规程: DZT 0148−2014 [S]. 北京: 中国标准出版社.
[6]	中华人民共和国国土资源部. 2015. 水文地质调查规范(1∶50 000): DZT 0282−2015 [S]. 北京: 地质出版社.
[1]	General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China. 2008. Drinking Natural Mineral Water: GB 8537−2008[S]. Beijing: Standards Press of China (in Chinese).
[2]	Ministry of Land and Resources of the People’s Republic of China. 2014. The specification for hydrogeological well drilling: DZ/T 0148−2014 [S]. Beijing: Standards Press of China (in Chinese).
[3]	Ministry of Land and Resources of the People’s Republic of China. 2015. Specification for hydrogeological survey(1∶50 000): DZ/T 0282−2015[S]. Beijing: Geological Publishing House (in Chinese).
[4]	Fu Lixin. 2012. Monitoring Analysis on the Quality of Drinking Water in Urban Areas of Chibi City[J]. Journal of Environmental Hygiene, 10(2): 221−224 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gwyx-wsx201205007
[5]	Gong Lei, Wang Xinfeng, Song Mian, Li Hongyan, Xiao Zeyou, Hu Qifeng, Wang Jin, Wu Linwei, Wang Lei, Miu Sai. 2019. 1∶50 000 Hydrogeological Survey Dataset for Poverty Alleviation in Xingguo and Ningdu Counties, South Jiangxi[J]. Geoloy in China, 46(S1): 15−23.
[6]	Ma Hongyun, Li Chengzhu, Zhang Jun. 2018. Inorganic indicator dataset for groundwater in Ordos Basin (2014—2015)[J]. Geology in China, 45(S1): 35−40.
