Dataset of the Environmental Geological Survey on a Scale of 1∶50 000 in the Longmen Map Sheet, Hainan Province
-
摘要:
本数据集为2017年在海南省龙门市幅开展的1∶50 000环境地质调查的调查信息、水文地质钻孔、地下水采样及化学成分测试结果，包含机民井点221个，泉点21个，地表水点7个，水文地质钻孔10个，进尺808.77 m，地下水全分析采样点56个。调查点符合规范要求，钻探施工质量可靠，采样过程规范，测试均由符合资质要求的实验室完成，数据质量可靠。数据集可以真实反映该时段龙门市幅水文地质环境地质条件，并依托调查成果，为地方圈定1处地下水后备水源地，可有效缓解季节性缺水问题，为科学合理利用地下水资源提供依据。
Abstract:The dataset of the environmental geological survey on a scale of 1∶50 000 in the Longmen Map Sheet, Hainan Province in 2017 (also referred to as the Dataset) contains the survey information, data of hydrogeological boreholes, groundwater sampling information and the chemical component of the test results from the groundwater samples, which include 221 pumping (domestic) well points, 21 spring points, 7 surface water points, 10 hydrogeological boreholes, 808.77 m footage, and 56 groundwater full analysis sampling points. The data in the Dataset are credible since the survey points are consistent with applicable specifications, drilling quality is credible, the sampling conforms to relevant standards and the samples were tested in qualified labs. Therefore, the Dataset can faithfully reflect the hydrogeological and environmental geological conditions in the Longmen Map Sheet during the survey period. Furthermore, a backup groundwater source was delineated based on the survey results, making it possible to effectively alleviate the seasonal shortage of water and provide a basis for scientific and rational utilization of the groundwater resources.
-
-
表 1 数据库(集)元数据简表
条目 描述 数据库(集)名称 海南省龙门市幅1∶50 000环境地质调查数据集 数据库(集)作者 刘凤梅，中国地质调查局武汉地质调查中心
余绍文，中国地质调查局武汉地质调查中心
张彦鹏，中国地质调查局武汉地质调查中心数据时间范围 2017年1月—2017年12月 地理区域 海南省定安县 数据格式 .xlsx 数据量 425 KB 数据服务系统网址 http://dcc.cgs.gov.cn 基金项目 中国地质调查局地质调查项目“琼东南经济规划建设区1∶50 000环境地质调查”(DD20160259) 语种 中文 数据库(集)组成 该数据集是由14个Excel表格组成，表格名称分别为调查点基础数据表.xlsx、机民井调查表.xlsx、泉点野外调查表.xlsx、野外调查路线表.xlsx、野外地质综合调查表.xlsx、地层岩性界线调查点记录表.xlsx、野外构造点调查表.xlsx、地表水点综合调查表.xlsx、试坑渗水试验观测记录表.xlsx、试坑渗水试验综合成果表.xlsx、野外水样采集记录表.xlsx、水质分析综合成果表.xlsx、钻孔基本情况表.xlsx和钻孔地层描述表.xlsx
下载: 导出CSV
表 2 龙门市幅环境地质调查点基础数据集例表
字段名称 实例 统一编号 1101543471929577001 路线统一编号 L1 野外编号 D2001 调查点名称 − 经度 110154347 纬度 19295770 X坐标 19422534 Y坐标 2157150 地面高程 68 m 地理位置 海南省定安县龙门镇新安村 图幅编号 龙门市幅，E49E004010 调查点类型 机民井调查点，水样采集点，地质综合调查点，水质现场测试
下载: 导出CSV
表 3 机民井调查表数据集例表
字段名称 实例 字段名称 实例 统一编号 1102513341928262801 浊度 − 野外编号 D2096 气味 无 天气 晴 透明度 透明 经度 110251334 HCO3− − 纬度 19282628 Ca2+ − 地面高程 110 m DO 7.48 地理位置 海南省定安县黄竹镇文星堆村 EC 231.3 μs/cm 图幅编号 龙门市幅，E49E004010 Eh 268.1 mV 井口高程 110 m 井与地表水距离 − 井口直径 3 700 mm 取水设备及型号 离心泵 井底直径 3 700 mm 是否做过抽水试验 否 地下水位埋深 1 m 成井日期 1986 井的类型 民井 可能污染源类型 农田 井深 10 m 可能污染源距井距离 4 m 井壁结构 石垒 主要用途 生活用水 井淘洗情况 每年 年水位变幅 1 开采方式 间歇开采 是否饮用 是 滤管位置 − 平面位置示意图 (BLOB) 取水层位 中更新统多文组(Qp2d) 剖面示意图 (BLOB) 地下水的类型 孔隙水 备注 含水层岩性特征 玄武岩风化残积层 项目名称 琼东南经济规划建设区1∶50 000环境地质调查—龙门市幅 取样情况 未取样 调查单位 武汉地质调查中心 开采量 20 m3/d 调查工作时间 2017-7-9 水温 29.03℃ 调查人 梁昌智 pH 7.19 记录人 龚皓 味 无 审核人 余绍文 色度 − 填表时间 2017-7-9 气温 29℃
下载: 导出CSV
表 4 泉点调查表数据集例表
字段名称 实例 字段名称 实例 统一编号 1102034371927216601 透明度 透明 野外编号 D1023 pH 6.35 经度 110203437 取样情况 未取样 纬度 19272166 Eh 217 mV 地面高程 93.9 m DO − 地理位置 海南省定安县龙门镇土地村 电导率 86 μs/cm 泉点名称 − HCO3− − 图幅编号 龙门市幅，E49E004010 Ca2+ − 泉水类型 下降泉 周围可能的污染源 泉点周边可见丢弃的洗衣袋、报纸等生活垃圾 含水层岩性 玄武岩 含水层特征 − 主要用途 灌溉、洗涤 剖面示意图 (BLOB) 补给来源 大气降水 平面位置示意图 (BLOB) 沉淀物及气体成分 − 备注 照片编号IMG1347-1353、IMG6569-6571 天气 晴 项目名称 琼东南经济规划建设区1∶50 000环境地质调查 气温 29℃ 照片编号 IMG1347-1353、IMG6569-6571 流量测定方法 三角堰法 调查单位 武汉地质调查中心 泉的流量 0.794 L/s 调查工作时间 2017-6-8 动态变化特征 随旱雨季变化明显 调查人 梁昌智、符策伟 泉水温度 25℃ 记录人 汪夏旭 色度 − 审核人 张彦鹏 味 无 填表时间 2017-6-8 气味 无
下载: 导出CSV
表 5 水样采集数据集例表
字段名称 实例 字段名称 实例 统一编号 1101531501926491801 EC 394.9 μS/cm 野外编号 D1006 pH 4.67 经度 110153150 色 无 纬度 19264918 嗅 无 X坐标 19422160 味 无 Y坐标 2151354 透明度 透明 地理位置 海南省琼海市龙门镇大船村 化学处理方式 阳离子加浓硝酸 地面高程 85 m 平面位置示意图 (BLOB) 图幅编号 龙门市幅，E49E004010 备注 − 样品编号 LM-FSH001 项目名称 琼东南经济规划建设区1∶50 000环境地质调查 采样时间 2017-9-18 调查单位 武汉地质调查中心 样品类型 地下水 采样人 张彦鹏 以往取样 无 记录人 张彦鹏 静止水位 10.69 m 审核人 余绍文 水温 26.43℃
下载: 导出CSV
表 6 水质分析综合成果表数据集例表
字段名称 实例 字段名称 实例 统一编号 1101531501926491801 Zn 0.06 样品编号 LM-FSH001 Cd 0.00 室内编号 D1006 Mn 0.78 测试编码 FSH001 Ni 0.02 水温 26.43 Co 0.02 pH 4.67 总Cr 0.00 铍 0.00 V 0.00 K+ 33.04 Sr 0.05 Na+ 32.71 Sb 0.00 Ca2+ 5.73 Fe 0.01 Mg2+ 3.23 Tl 0.00 Cl− 55.51 Ba 0.37 SO42− 22.93 B 0.00 NO3− 44.90 Br- 0.12 F− 0.34 As 0.00 PO43− n.a. Li 0.01 TDS 252.7 Al 0.36 Cu 0.00 取样时间 2017-9-18 Pb 0.00
下载: 导出CSV
表 7 钻孔基本情况数据集例表
字段名称 实例 字段名称 实例 统一编号 1101609001925173301 含水层初见水位 0.15 m 野外编号 LMSK01 成井深度 101.5 m 经度 110160900 静止水位 3.16 m 纬度 19251733 质量等级 优 X坐标 19423242 含水层特征 砂岩 Y坐标 2148525 平面位置示意图 (BLOB) 地理位置 海南省定安县龙门镇角塘村 钻孔柱状图 (BLOB) 地面高程 91 m 备注 − 图幅编号 龙门市幅，E49E004010 项目名称 琼东南经济规划建设区1∶50 000环境地质调查 孔口高程 91 m 施工单位 广东省有色金属地质局水文地质队 钻机类型 XY-1A-4 调查日期 2017-10-31 钻孔类型 水文地质钻探 机长 郑连兵 开孔日期 2017-10-31 地质编录 陈国荣 终孔日期 2017-11-18 记录人 陈国荣 井斜 0 审核人 杨俊烁 开孔直径 168 mm 填表时间 2017-11-18 终孔直径 110 mm 钻孔ID − 终孔深度 101.5 m
下载: 导出CSV
表 8 钻孔地层描述表
字段名称 实例 统一编号 1101609001925173301 地质时代 K 地层编码 4 场地分层索引号 − 层底标高 84.5 m 层底深度 6.5 m 单层厚度 0.8 m 层底接触关系 − 层理构造 − 岩土名称 强风化砂岩 岩土颜色 上部浅紫红色，下部灰黄色 地层地质描述 细粒结构，层状构造，节理裂隙稍发育，沉积成因，由石英、长石组成，黏土胶结，粒径约0.05～1 mm，局部有水蚀痕迹，透水性一般 钻孔ID −
下载: 导出CSV
表 9 地下水水化学类型统计
类型 数量 比例 Ca-HCO3 5 50.00% Na-HCO3 6 Ca·Na-HCO3 15 Ca·Na-HCO3·SO4 4 7.70% Na·Ca-Cl 8 42.30% Na-Cl 10 Ca-Cl 4
下载: 导出CSV
Table 1. Metadata Table of Database (Dataset)
Items Description Database (dataset) name Dataset of the Environmental Geological survey on a scale of 1∶50 000 in the Longmen Map sheet, Hainan Province Database (dataset) authors Liu Fengmei, Wuhan Center, China Geological survey
Yu shaowen, Wuhan Center, China Geological survey
Zhang Yanpeng, Wuhan Center, China Geological surveyData acquisition time January – December in 2017 Geographic area Ding’an County, Hainan Province Data format .xlsx Data size 425 KB Data service system URL http://dcc.cgs.gov.cn Fund project China Geological survey project titled “Environmental Geological survey on a scale of 1∶50 000 in the Economic Planning and Construction Zone of southeast Hainan” (DD20160259) Language Chinese Database (dataset) composition The dataset consists of 14 data tables in Excel, namely “Basic data of survey points.xlsx”, Pumping (domestic) well survey.xlsx”, “Field survey of spring points.xlsx”, “Field survey routes.xlsx”, “Field comprehensive geological survey.xlsx”, “Survey point records of stratigraphic lithologic boundary.xlsx”, “Survey of field geological structural points.xlsx”, “Comprehensive survey of surface water points.xlsx”, “Observation records of permeability test in trial pits.xlsx”, “Comprehensive results of permeability test in trial pits.xlsx”, “Records of field water sampling.xlsx”, “Comprehensive results of water quality analysis.xlsx”, “Basic information of boreholes.xlsx” and “Description of strata revealed by boreholes.xlsx”.
下载: 导出CSV
Table 2. Real Example of “Basic data of survey points.xlsx” in the Dataset
Field name Real Example Unified No. 1101543471929577001 Unified No. of route L1 Field No. D2001 Survey point name Longitude 110154347 Latitude 19295770 Coordinate X 19422534 Coordinate Y 2157150 Ground elevation 68 m Geographical location Xin’an Village, Longmen Town, Ding’an County, Hainan Province Map Sheet No. Longmen Map Sheet, No.: E49E004010 Survey point type Pumping (domestic) well survey point, water sampling point, comprehensive geological survey point, water-quality on-site testing
下载: 导出CSV
Table 3. Real Example of “Pumping (domestic) well survey.xlsx” in the Dataset
Field name Real Example Field name Real Example Unified No. 1102513341928262801 Turbidity − Field No. D2096 Odor Odorless Weather Sunny Transparency Transparent Longitude 110251334 HCO3− − Latitude 19282628 Ca2+ − Ground elevation 110 m DO 7.48 Geographical location Wenxingdui Village, Huangzhu Town, Ding’an County, Hainan Province EC 231.3 μS/cm Map sheet No. Longmen Map Sheet, No.: E49E004010 Eh 268.1 mV Wellhead elevation 110 m Distance from wellhead to surface water − Wellhead diameter 3 700 mm Device and model for water intaking Centrifugal pump Well bottom diameter 3 700 mm Pumping test No Burial depth of groundwater level 1 m Date of well completion 1986 Well type Domestic well Possible type of pollution source Farmland Well depth 10 m Distance from well to the possible pollution source 4 m Well wall structure Built with stones Main purposes For daily usage Elutriation type of well Yearly Annual change amplitude of water level 1 Exploitation method Intermittent exploitation Whether for drinking use Yes Location of screen pipe − Planimetric location sketch (BLOB) Water-intaking stratum Duowen Formation of Middle Pleistocene (Qp2d) Profile sketch (BLOB) Groundwater Type Pore water Remarks Lithologic feature of aquifer Basalt-weathered eluvium Project title Environmental Geological Survey on a scale of 1∶50 000 in the Economic Planning and Construction Zone in Southeast Hainan ― Longmen Map Sheet Sampling No sample taken Undertaken by Wuhan Center, China Geological Survey Exploitation volume 20 m3/d Date of survey July 9, 2017 Water temperature 29.03°C Surveyed by Liang Changzhi pH 7.19 Recorded by Gong Hao Taste Tasteless Checked by Yu Shaowen Chroma − Filled on (date) July 9, 2017 Atmospheric temperature 29°C
下载: 导出CSV
Table 4. Real Example of “Field survey of spring points.xlsx” in the Dataset
Field name Real Example Field name Real Example Unified No. 1102034371927216601 Transparency Transparent Field No. D1023 pH 6.35 Longitude 110203437 Sampling No sample taken Latitude 19272166 Eh 217 mV Ground elevation 93.9 m DO − Geographical location Tudi Village, Longmen Town, Ding’an County, Hainan Province EC 86 μS/cm Spring point Name − HCO3− − Map sheet No. Longmen Map Sheet, No.: E49E004010 Ca2+ − Spring type Gravity spring Possible pollution sources beside the spring point Domestic waste discarded visible around the spring point, such as laundry bags and newspaper Lithology of aquifer Basalt Aquifer feature − Main purposes For irrigation and washing Profile sketch (BLOB) Source of recharge Meteoric precipitation Sketch of planimetric position (BLOB) Composition of sediments and gases − Remarks Picture numbers: IMG1347-1353 and IMG6569-6571 Weather Sunny Project title Environmental Geological Survey on a scale of 1∶50 000 in Economic Planning and Construction Zone of Southeast Hainan Atmospheric temperature 29 Picture numbers IMG1347-1353 and IMG6569-6571 Method for measuring
water flowTriangular weir Undertaken by Wuhan Center, China Geological Survey Water flow 0.794 L/s Date of survey June 8, 2017 Dynamic change feature Vary greatly between wet and dry seasons Surveyed by Liang Changzhi, Fu Cewei Water temperature 25℃ Recorded by Wang Xiaxu Chroma − Checked by Zhang Yanpeng Taste Tasteless Filled on (date) June 8, 2017 Odor Odorless
下载: 导出CSV
Table 5. Real Example of “Records of field water sampling.xlsx” in the Dataset
Field name Real Example Field name Real Example Unified No. 1101531501926491801 EC 394.9 μS/cm Field No. D1006 pH 4.67 Longitude 110153150 Color Colorless Latitude 19264918 Odor Odorless Coordinate X 19422160 Taste Tasteless Coordinate Y 2151354 Transparency Transparent Geographical location Dachuan Village, Longmen Town, Qionghai City, Hainan Province Chemical treatment means Cation and concentrated nitric acid Ground elevation 85 m Sketch of planimetric location (BLOB) Map sheet No. Longmen Map Sheet, No.: E49E004010 Remarks Sample No. LM-FSH001 Project title Environmental Geological Survey on a Scale of 1∶50 000 in the Economic Planning and Construction Zone of Southeast Hainan Sampling date September 18, 2017 Undertaken by Wuhan Center, China Geological Survey Sample type Groundwater Sampled by Zhang Yanpeng Previous sampling No Recorded by Zhang Yanpeng Static water level 10.69 m Checked by Yu Shaowen Water temperature 26.43℃
下载: 导出CSV
Table 6. Real Example of “Comprehensive results of water quality analysis.xlsx” in the Dataset
Field name Real Example Field name Real Example Unified No. 1101531501926491801 Zn 0.06 Sample No. LM-FSH001 Cd 0.00 Indoor No. D1006 Mn 0.78 Testing code FSH001 Ni 0.02 Water temperature 26.43 Co 0.02 pH 4.67 Total Cr 0.00 Be 0.00 V 0.00 K+ 33.04 Sr 0.05 Na+ 32.71 Sb 0.00 Ca2+ 5.73 Fe 0.01 Mg2+ 3.23 Tl 0.00 Cl− 55.51 Ba 0.37 SO42− 22.93 B 0.00 NO3− 44.90 Br- 0.12 F− 0.34 As 0.00 PO43− n.a. Li 0.01 TDS 252.7 Al 0.36 Cu 0.00 Sampling date Septemper 18, 2017 Pb 0.00
下载: 导出CSV
Table 7. An Example of “Basic information of boreholes.xlsx” in the Dataset
Field name Real Example Field name Real Example Unified No. 1101609001925173301 Initial water level of aquifer 0.15 m Field No. LMSK01 Well depth 101.5 m Longitude 110160900 Static water level 3.16 m Latitude 19251733 Quality grade Excellent Coordinate X 19423242 Aquifer feature Sandstone Coordinate Y 2148525 Sketch of planimetric location (BLOB) Geographical location Jiaotang Village, Longmen Town, Ding’an County, Hainan Province Borehole histogram (BLOB) Ground elevation 91 m Remarks - Map sheet No. Longmen Map Sheet, No.: E49E004010 Project name Environmental Geological Survey on a Scale of 1∶50 000 in the Economic Planning and Construction Zone of Southeast Hainan Borehole head elevation 91 m Constructed by Hydrogeological Team from the Guangdong Geological Bureau of Nonferrous Metals Drilling rig type XY-1A-4 Date of survey October 31, 2017 Borehole type Hydrogeological drilling Drilling foreman Zheng Lianbing Start date of drilling October 31, 2017 Person in charge of geological logging Chen Guorong End date of drilling November 18, 2017 Recorded by Chen Guorong Well deviation 0 Checked by Yang Junshuo Open hole diameter 168 mm Filled on (date) November 18, 2017 Final hole diameter 110 mm Borehole ID - Final hole depth 101.5 m
下载: 导出CSV
Table 8. An Example of “Description of strata revealed by boreholes.xlsx” in the Dataset
Field name Example Unified No. 1101609001925173301 Geological age K Stratum code 4 Index of site-based layer − Elevation of stratum bottom 84.5 m Depth of stratum bottom 6.5 m Thickness of a single layer 0.8 m Contact relation at stratum bottom − Bedding structure − Name of rock or soil Strongly weathered sandstone Color of rock or soil Lightly purplish-red in the upper part and grayish-yellow in the lower part Stratigraphic geological description Fine-grained and laminar structure, joints and fissures slightly developed, sedimentogenesis, composed of quartz and feldspar, cemented by clay, particle size: about 0.05–1 mm, signs of water erosion locally visible, water permeability: medium Borehole ID −
下载: 导出CSV
Table 9. Summary Table of the groundwater hydrochemical types in the survey area
Groundwater hydrochemical type Number of samples Percentage Ca-HCO3 5 50.00% Na-HCO3 6 Ca·Na-HCO3 15 Ca·Na -HCO3·SO4 4 7.70% Na·Ca-Cl 8 42.30% Na-Cl 10 Ca-Cl 4
下载: 导出CSV
-
[1] 环境保护部. 2009. 水质采样样品的保存和管理技术规定: HJ 493−2009[S]. 北京.
[2] 环境保护部. 2009. 水质采样技术指导: HJ 494−2009[S]. 北京.
[3] 李成柱, 马洪云, 吴耀国. 2018. 关中盆地地下水无机指标数据集(2015年度)[J]. 中国地质, 45(S2): 23−29. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi2018z2004
[4] 马洪云, 李成柱, 张俊. 2018. 鄂尔多斯盆地地下水无机指标数据集(2014—2015年度)[J]. 中国地质, (S1): 27−30.
[5] 中华人民共和国国土资源部. 2014. 水文水井地质钻探规程: DZ/T 0148−2014[S]. 北京.
[6] 中华人民共和国国土资源部. 2015. 水文地质调查规范(1∶50 000): DZ/T 0282−2015[S]. 北京: 中国标准出版社.
[7] 中华人民共和国卫生部. 2006. 生活饮用水标准检验方法水样的采集和保存: GB/T 5750.2−2006[S]. 北京.
[1] Li Chengzhu, Ma Hongyun, Wu Yaoguo. 2018. An Inorganic Index Dataset of Groundwater in the Guanzhong Basin (2015)[J]. Geology in China, 45(S2): 31−38. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi2018z2004
[2] Ma Hongyun, Li Chengzhu, Zhang Jun. 2018. Inorganic Indicator Dataset for Groundwater in Ordos Basin (2014—2015)[J]. Geology in China, 45(S1): 35−40.
[3] Ministry of Environmental Protection of the People’s Republic of China. 2009. Water Quality Sampling - Technical Regulation of Preservation and Handling of Water Samples: HJ 493−2009[S]. Beijing: China Environmental Science Press (in Chinese).
[4] Ministry of Environmental Protection of the People’s Republic of China. 2009. Water Quality - Guidance on Sampling Techniques: HJ 494−2009[S]. Beijing: China Environmental Science Press (in Chinese).
[5] Ministry of Health of the People’s Republic of China. 2006. Standard examination methods for drinking water - Collection and preservation of water samples: GB/T 5750.2−2006[S]. Beijing: Standards Press of China (in Chinese)
[6] Ministry of Land and Resources of the People’s Republic of China. 2014. Specification for Hydrological Well Drilling: DZ/T 0148−2014 [S]. Beijing: Standards Press of China (in Chinese).
[7] Ministry of Land and Resources of the People’s Republic of China. 2015. Specification for Hydrogeological Survey (1∶50 000): DZ/T 0282−2015[S]. Beijing: Standards Press of China (in Chinese).
-
