Comprehensive Geological Environmental Survey in New Small Towns ― A Case Study of the Geological Dataset of Danyang City, Jiangsu in 2016
-
摘要:
成果的有效应用服务是城市地质调查工作的核心驱动力，城市地质数据集作为城市地质调查工作的核心成果，是决定城市地质调查研究成果应用服务有效性的关键。中国地质调查局部署开展丹阳小城镇地质环境综合调查试点，本次共完成遥感解译1 047 km2 (3期数据)，调查点767个，钻探115个，累计钻探进尺8 720 m (其中第四系孔915 m，水文孔2 366 m，工程孔5 439 m)，采集第四纪地质样品2 904组，地下水样品240组，原状土样1 108组，土壤样2 482组，地下水位统测点70 个，抽水试验18组等。查清了丹阳市水文地质、工程地质、地质灾害等分布规律，并围绕丹阳市规划建设对地质工作的实际需求，对各类调查原始数据进行了专项加工，建立了数据集，为丹阳市规划建设提供了良好的支撑服务。文章对数据来源、数据收集方法、处理技术等方面进行了整理和归纳，形成了小城镇地质调查应用服务地质数据集的构建方法，为今后小城镇地质调查和数据集处理及应用提供参考。
Abstract:Effective application of survey results in social service is a core driving force of urban geological survey. As the key result of urban geological survey, the urban geological dataset is critical to the effective application of geological survey results in service. The China Geological Survey (CGS) has deployed a pilot project for comprehensive survey of geological environment in small towns of Danyang. The workload of the comprehensive survey involves the interpretation of remote sensing images covering an area of 1 047 km2 (including data from three phases), 767 survey points, 115 boreholes, accumulated footage of 8 720 m (including 915 m for the Quaternary boreholes, 2 366 m for hydrological boreholes, and 5 439 m for engineering boreholes), 2 904 Quaternary geological samples, 240 groundwater samples, 1 108 undisturbed earth samples, 2 482 groups of soil samples, 70 points for simultaneous measurement of groundwater levels and 18 pumping tests. In this work, the distribution laws of the hydrogeology, engineering geology, and geologic disasters in Danyang City were ascertained. Furthermore, in view of the geological demand in the planning and construction of Danyang City, the original data obtained from various surveys were specially processed and a dataset was developed accordingly, thereby, providing strong support for the planning and construction of Danyang City. In this paper, the method of developing a geological survey dataset of small towns for the purposes of application and social service was established by collating and summarizing data sources, data collection methods and data processing techniques, in order to provide references for a geological survey in other small towns as well as the processing and application of the geological dataset in the future.
-
-
表 1 数据库(集)元数据简表
条 目 描述 数据库(集)名称 2016年江苏丹阳小城镇地质环境综合调查数据集 数据库(集)作者 葛伟亚，中国地质调查局南京地质调查中心
常晓军，中国地质调查局南京地质调查中心
贾军元，中国地质调查局南京地质调查中心
雷 廷，中国地质调查局南京地质调查中心数据时间范围 2014年4月—2016年10月 地理区域 江苏省丹阳市 数据格式 *.xls 数据量 6 676条 数据服务系统网址 http://dcc.cgs.gov.cn 基金项目 中国地质调查局地质调查项目“江苏镇江丹阳市小城镇水工环地质综合调查”(项目编码12120114023101)，丹阳市人民政府和南京地质调查中心合作项目“丹阳城镇地质环境综合调查” 语种 中文 数据库(集)组成 本数据集由图件、表格等组成，主要内容包括钻孔分布图1张，数据表18个，总记录数6 676条。数据表包括：调查点基础数据表、野外地质综合调查表、机民井调查表、野外水样采集记录表、水质分析综合成果表、地下水有机污染分析成果表、第四纪地质钻孔表、水文地质钻孔表、工程地质钻孔表、岩土工程样品测试表、抽水试验记录表、第四纪生物数据表、第四纪测年成果数据表、第四纪粒度参数数据表、原位测试记录表、工程地质标贯试验记录表、地下水观测井基本情况表、地下水位统测记录表
下载: 导出CSV
表 2 丹阳市地下水水化学类型统计表(舒卡列夫分类，单位：个）
当量＞25% HCO3 HCO3+SO4 HCO3+SO4+Cl HCO3+Cl SO4 SO4+Cl Cl Ca 17 3 0 0 0 0 0 Ca+Mg 29 3 1 1 0 0 0 Mg 0 0 0 0 0 0 0 Na+Ca 43 10 3 10 0 0 0 Na+Ca+Mg 37 8 1 8 0 0 0 Na+Mg 0 0 0 1 0 0 0 Na 0 0 0 0 0 0 0
下载: 导出CSV
表 3 土壤环境质量标准值(mg/kg)
级别 一级 二级 三级 土壤pH值 自然背景 <6.5 6.5～7.5 >7.5 >6.5 项目 数值 镉≤ 0.20 0.30 0.30 0.6 1.0 汞≤ 0.15 0.30 0.50 1.0 1.5 砷水田≤旱地≤ 1 515 3 040 2 530 2 025 3 040 铜农田等≤果园≤ 35— 50 150 100 200 100 200 400 400 铅≤ 35 250 300 350 500 铬水田≤旱地≤ 9 090 250 150 300 200 350 250 400 300 锌≤ 100 200 250 300 500 镍≤ 40 40 50 60 200 注：①重金属(铬主要是三价)和砷均按元素量计，适用于阳离子交换量>5 cmol(+)/kg的土壤，若≤5 cmol(+)/kg，其标准值为表内数值的半数。②水旱轮作地的土壤环境质量标准，砷采用水田值，铬采用旱地值。
下载: 导出CSV
表 4 原始资料数据
序号 数据表名称 记录数 1 调查点基础数据表 1 449 2 野外地质综合调查表 436 3 机民井调查表 397 4 野外水样采集记录表 251 5 水质分析综合成果表 204 6 地下水有机污染分析成果表 37 7 第四纪地质钻孔表 11 8 水文地质钻孔表 19 9 工程地质钻孔表 89 10 岩土工程样品测试表 1 396 11 抽水试验记录表 11 12 第四纪生物数据表 819 13 第四纪测年成果数据表 19 14 第四纪粒度参数数据表 311 15 原位测试记录表 65 16 工程地质标贯试验记录表 810 17 地下水观测井基本情况表 31 18 地下水位统测记录表 321
下载: 导出CSV
Table 1. Metadata Table of Database (Dataset)
Items Description Database(dataset) name Dataset of Comprehensive Geological Environmental Survey of Small Towns in Danyang City, Jiangsu in 2016 Database(dataset) authors Ge Weiya, Nanjing Center, China Geological Survey
Chang Xiaojun, Nanjing Center, China Geological Survey
Jia Junyuan, Nanjing Center, China Geological Survey
Lei Ting, Nanjing Center, China Geological SurveyData acquisition time Apr. 2014–Oct. 2016 Geographic area Danyang City, Jiangsu Province Data format *.xls Data size 6 676 entries Data service system URL http://dcc.cgs.gov.cn Fund project China Geological Survey project titled “Comprehensive Survey of Hydrogeology, Engineering Geology, and Environment Geology of Small Towns in Danyang City of Zhenjiang in Jiangsu Province” (Project No. 12120114023101), and a project tilted “Comprehensive Geological Environmental Survey of Towns in Danyang City” cooperatively initiated by the People’s Government of Danyang City and Nanjing Center, China Geological Survey Language Chinese Database(dataset) composition The dataset consists of maps and data tables, mainly including one borehole distribution map, 18 data tables and 6 676 record entries. The names of the data tables are: basic information of survey points, field comprehensive geological survey, pumping & domestic well survey, records of field water sampling, comprehensive analytical results of water samples, analytical results of groundwater organic pollution, Quaternary geological boreholes, engineering geological boreholes, records of geotechnical sample testing, records of pumping tests, Quaternary organisms, Quaternary dating results, Quaternary grain-size parameters, records of in-situ tests, standard penetration test records of geotechnical engineering, basic information of groundwater observational borehole wells, and records of simultaneous measurement of groundwater levels.
下载: 导出CSV
Table 2. Statistics of Groundwater Hydrochemical Types in Danyang City (Schukarev classification, unit: number)
equivalent>25% HCO3 HCO3+SO4 HCO3 +SO4 +Cl HCO3+Cl SO4 SO4+Cl Cl Ca 17 3 0 0 0 0 0 Ca+Mg 29 3 1 1 0 0 0 Mg 0 0 0 0 0 0 0 Na+Ca 43 10 3 10 0 0 0 Na+Ca+Mg 37 8 1 8 0 0 0 Na+ Mg 0 0 0 1 0 0 0 Na 0 0 0 0 0 0 0
下载: 导出CSV
Table 3. Standard Values for Environmental Quality of Soils (mg/kg)
Grade Grade I Grade II Grade III pH value of soil Natural background <6.5 6.5–7.5 >7.5 >6.5 Item Value Cd ≤ 0.20 0.30 0.30 0.6 1.0 Hg ≤ 0.15 0.30 0.50 1.0 1.5 As Paddy field ≤Dry land ≤ 1 515 3 040 2 530 2 025 3 040 Cu Farmland etc. ≤Orchard ≤ 35— 50 150 100 200 100 200 400 400 Pb ≤ 35 250 300 350 500 Cr Paddy field ≤Dry land ≤ 9 090 250 150 300 200 350 250 400 300 Zn ≤ 100 200 250 300 500 Ni ≤ 40 40 50 60 200 Notes: ① Heavy metals (Cr mainly refers to Cr3+) and As are calculated according to their element contents, suitable for the soils where cation exchange capacity > 5cmol (+)/kg. For the soils where cation exchange capacity ≤ 5cmol(+)/kg, the standard values shall be half of the values in the table. ② As for the environmental quality standard of the soils of land for the purpose of wet and dry crop rotation, the value for paddy fields and the value for dry land shall be respectively adopted for As and Cr.
下载: 导出CSV
Table 4. Original Data
No. Data table name Number of record entries 1 Basic information of survey points 1 449 2 Field comprehensive geological survey 436 3 Pumping and domestic well survey 397 4 Records of field water sampling 251 5 Comprehensive results of water quality analysis 204 6 Analytical results of groundwater organic pollution 37 7 Quaternary geological boreholes 11 8 Hydrogeological boreholes 19 9 Engineering geological boreholes 89 10 Records of geotechnical sample testing 1 396 11 Records of pumping tests 11 12 Quaternary organisms 819 13 Quaternary dating results 19 14 Quaternary grain-size parameters 311 15 Records of in-situ tests 65 16 Standard penetration test record of geotechnical engineering 810 17 Basic information of groundwater observational borehole wells 31 18 Records of simultaneous measurement of groundwater levels 321
下载: 导出CSV
-
[1] 常晓军, 葛伟亚, 周丹坤, 贾军元, 雷廷. 2019. 基于Voxler平台的城市地质调查数据的三维可视化[J]. 城市地质, 14(2): 6−11. doi: 10.3969/j.issn.1007-1903.2019.02.002
[2] 姜月华, 周权平, 李云, 苏晶文, 张泰丽, 贾军元, 葛伟亚, 杨辉, 刘林, 杨国强, 金阳. 2019. 江苏丹阳千年" 沸井”的地质成因与形成机理[J]. 地质学报, 93(7): 1778−1791. doi: 10.3969/j.issn.0001-5717.2019.07.016
[3] 骆祖江, 杜菁菁. 2018. 基于热平衡分析的地埋管地源热泵换热方案模拟优化[J]. 农业工程学报, 34(13): 246−254. doi: 10.11975/j.issn.1002-6819.2018.13.030
[4] 徐晓, 骆祖江, 常晓军. 2017. 江苏丹阳市滨江新城浅层地温能开发利用适宜性分区研究[J]. 中国煤炭地质, 29(5): 45−52. doi: 10.3969/j.issn.1674-1803.2017.05.09
[5] 于丹丹, 骆祖江. 2015. 基于线热源理论的岩土体现场热响应试验研究[J]. 工程勘察, (12): 48−51. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gckc201512010
[6] 张庆, 雷廷, 贾军元, 田福金, 杨洋. 2018. 丹阳地区重金属污染对土体力学性质影响研究[J]. 工程地质学报, 26(S1): 612−617.
[1] Chang Xiaojun, Ge Weiya, Zhou Dankun, Jia Junyuan, Lei Ting. 2019. 3D visualization of urban geological survey data based on Voxler platform[J]. Urban Geology, 14(2): 6−11 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/csdz201902002
[2] Jiang Yuehua, Zhou Quanping, Li Yun, Su Jingwen, Zhang Taili, Jia Junyuan, Ge Weiya, Yang Hui, Liu Lin, Yang Guoqiang, Jin Yang. 2019. Geological origin and formation mechanism of the millennium " boiling well” in Danyang, Jiangsu Province[J]. Acta Geologica Sinica, 93(7): 1778−1791 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dizhixb201907016
[3] Luo Zujiang, Du Jingjing. 2018. Heat exchange scheme simulation optimization for ground source heat pump system with buried pipes by thermal equilibrium analysis[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 34(13): 246−254 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/nygcxb201813030
[4] Xu Xiao, Luo Zujiang, Chang Xiaojun. 2017. Study on shallow geothermal energy exploitation and utilization suitability zoning in Binjiang New Residential Quarter, Danyang City, Jiangsu Province[J]. Coal Geology of China, 29(5): 45−52 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgmtdz201705009
[5] Yu Dandan, Luo Zujiang. 2015. Study on geotechnical field thermal response test based on lineal heat source theory[J]. Geotechnical Investigation & Surveying, (12): 48−51 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/gckc201512010
[6] Zhang Qing, Lei Ting, Jia Junyuan, Tian Fujin, Yang Yang. 2018. A study on the impacts of heavy metal pollution on soil properties in Danyang Region[J]. Journal of Engineering Geology, 26(S1): 617−617 (in Chinese with English abstract).
-
