Devonian stratigraphic sequence in the Daguan area of Yunnan Province and its resource potentials of industrial quartz sand
-
摘要:
云南省大关县泥盆系蕴藏着丰富的石英砂资源，地层序列的研究不仅有助于深入分析石英砂形成的古地理环境及其变化特征，而且结合构造背景的研究，可研究石英砂形成分布规律，为硅产业的开发提供理论依据。为此，本文以野外地层剖面测量及页岩气调查井岩心编录为基础，结合古构造背景，研究了在直线距离50 km的滇东北大关县、盐津县泥盆系剖面特征，认为该区泥盆系具以下特点：（1）研究区位于晚古生代滇黔桂裂谷北部边缘地带，受边缘相带控制，沉积了坡松冲组、缩头山组两套高成熟度石英砂岩，是滇东北硅产业园的资源基础；（2）大关、盐津地区泥盆系总体上由下向上发育了坡松冲组、坡脚组、箐门组、缩头山组、红崖坡组、曲靖组、在结山组七个组，但受裂谷盆地隆、凹相间格局及同生断裂控制，七个组常发育不全，不同的地点，沉积序列常不一致，变化极其频繁；（4）泥盆系总体经历了两次海退→海进沉积过程，反映由陆架建设到碳酸盐台地的形成过程，同时，受裂谷盆地的影响，各组与建组剖面只是相似，具一定的变化特征；（4）总体上，缩头山组资源潜力优于坡松冲组。坡松冲组以盐津中和镇最具开发前景，缩头山组以大关县木杆镇及大关县黄荆坝最具前景。这些对泥盆系石英砂的开发具指导意义。
Abstract:The Devonian System in Daguan County of Yunnan Province is rich in quartz sand resources. The study of stratigraphic sequence in this area can not only contribute to the in-depth analysis of the paleogeographic environment and its variation characteristics of quartz sand formation, but also can reveal the formation and distribution rules of quartz sand with the help of tectonic background, and finally provide theoretical basis for the development of silicon industry. Therefore, based on the field stratigraphic profiling and core logging of shale gas wells, and combined with the paleotectonic background, this paper studied the Devonian profile characteristics in Daguan and Yanjin counties in northeast Yunnan Province with a straight-line distance of less than 50 kilometers. This area is located in the northern margin of Dianqiangui rift in Late Paleozonic, where controlled by the edge facies zone, two sets of high maturity quartz sandstone were deposited in Posongchong Formation and Suotoushan Formation. In general, seven Devonian formations were deposited, including Posongchong, Pojiao, Qingmen, Suotoushan, Hongyapo, Qujing, Zaijieshan from bottom to top in order, but these seven formations are often incomplete and vary very frequently at different locations. Controlled by the pattern of uplift and depression in the rift basin and syngenetic fractures, the sedimentary sequence is often inconsistent in different locations. The Devonian strata witnessed two regressive and transgressive depositional processes, reflecting the formation process from continental shelf construction to carbonate platform, and the strata of each formation are similar to those of stratotype section with certain variety characteristics. On the whole, the resource potential of Suotoushan Formation is better than that of Posongchong Formation. Zhonghe Town of Yanjin County is the most promising development prospect of industrial quartz sand for the Posongchong Formation, and Mugan Town and Huangjingba Town of Daguan County are the most promising prospects for the Suotoushan Formation, which are of guiding significance to the exploration of Devonian quartz sand.
-
Key words:
- Devonian /
- quartz sand /
- stratigraphic sequence /
- geological survey engineering /
- Daguan-Yanjin /
- Yunnan Province
-
-
图 1 云南省岩石地层区划及研究区位置图（据张远志修改, 1996）
Figure 1.
-
Jia Delong, Zhang Wanyi, Chen Conglin, Li Yongsheng, Wu Dongmei, Cui Minli, Zhang Cuiguang. 2019. Global resources status and China's development suggestions of high purity quartz[J]. Conservation and Utilization of Mineral Resources, 39(5): 111-117(in Chinese with English abstrct).
Jiang Wentao. 2016. Geological characteristics and selectivity of quartz sandstone in Yiliang County, Yunnan Province[J]. China Non-metallic Mining Industry Guide, (4): 10-13(in Chinese). http://en.cnki.com.cn/Article_en/CJFDTotal-LGFK201604004.htm
Li Meifeng. 2020. Geological Characteristics and Sedimentary Environment of Panjiazhai Sedimentary Silica Deposits, Yiliang County, Yunnan Province[D]. Chengdu: Chengdu University of Technology, 20-26 (in Chinese with English abstrct).
Li Zhongshui, Chen Junyuan, Liu Xiaolou, Li Jiaxin. 2019. Dividing the exploration types of silicon materials deposits: Discussion on the factors and methods of divding the exploration types[J]. China Non-metallic Minerals Industry, (1): 23-28, 45(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTotal-LGFK201901007.htm
Liu Baojun, Xu Xiaosong, Pan Xingnan. 1993. The Sedimentary Evolution and Mineralization of Ancient Continent in South China[M]. Beijing: Science Press, 56-58(in Chinese).
Luo Zhili. 1989. The determination and significance of Emei Taphrogenesis[J]. Sichuan Geological Journal, 9(1): 1-17(in Chinese with English abstrct).
Mao Zhichao, Du Yuansheng, Zhang Min. 2008. Devonian sedimentary environment and characteristics of sedimentary organic matter in central Guangxi[J]. Science in China series D: Earth Science, 38: 80-86(in Chinese).
Mei Mingxiang, Gao Jinhan, Li Donghai. 2003. Devonian Sequence stratigraphy and relative sea-level changes in Guizhou and Guangxi area, South China[J]. Acta Sedimentologica Sinica, 21(2): 297-306(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB200302016.htm
Mu Enzhi, Chen Xu, Ni Yunan. 1988. Silurian and Devonian systems in Qinzhou, Yulin, Guangxi[J]. Jounal of Stratigraphy, 12(4): 241-254(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DCXZ198804000.htm
Wang Ling, Dang Chenping, Li Caixia, Wang Yan, Wei Yuyan, Xia Jinzhuo, Pan Junliang. 2014. The technology of high-purity quartz in China: Status quo and prospect[J]. Earth Science Frontiers, 21(5): 267-273(in Chinese with English abstrct).
Wang Quanwei, Liang Bin, Yang Henshu. 2001. Devonian sedimentary evolution and mineralization on the West Yangtze continent[J]. Regional Geology of China, 20(4): 415-421(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD200104013.htm
Wang Zhongrong. 2014. Study on Purification of Quartz Sand in Yunnan[D]. Chengdu: Chengdu University of Technology, 30-38(in Chinese with English abstrct).
Wang Zizheng, Jiang Xinsheng, Zhou Bangguo, Pan Ningjin, Lu Shenglin. 2019. Sedimentary characteristics of member 1 of the Middle Devonian Suotoushan Formation in northeastern Yunnan Province and its ore-bearing potential[J]. Journal of Mineralogy and Petrology, 39(2): 90-98(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTotal-KWYS201902010.htm
Wei Qinlian, Zheng Rongcai, Zhou Gang. 2011. Clastic tempesite in Xiejiawan member of Ganxi Formation within Longmenshan area and its siginificance[J]. Geology in China, 38(5): 1282-1288(in Chinese with English abstrct). http://www.researchgate.net/publication/287697133_Clastic_tempestite_in_Xiejiawan_member_of_ganxi_formation_within_Longmenshan_area_and_its_signiflcance
Xia Bangdong, Liu Honglei, Wu Yungao. 1992. The Yunnan-Guizhou-Guangxi rift system[J]. Experimental Petroleum Geology, 14(1): 20-30(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD199201002.htm
Yang Shipu, Pan Jiang, Hou Hongfei. 1979. The Devonian system of China[J]. Acta Geologica Sinica, (3): 192-202(in Chinese with English abstrct).
Zhang Yuanzhi, Zhang Dinghui, Liu Shirong. 1996. Lithostratigraphy of Yunnan Province[M]. Wuhan: China University of Geosciences, 66-88(in Chinese).
Zheng Rongcai, Zhang Jinquan. 1989. The tectonic framework and the evolution of lithofacies and paleogeography of Devionian in eastern Yunnan and southwestern Guizhou[J]. Journal of Chengdu College of Geology, 16(4): 51-61(in Chinese with English abstrct). http://search.cnki.net/down/default.aspx?filename=CDLG198904008&dbcode=CJFD&year=1989&dflag=pdfdown
Zhou Bangguo, Wang Zizheng, Ji Panlong, Jiang Xinsheng, Chen Wenyang. 2018. Characteristics and sedimentary environments of quartz sandstones in the Middle Devonian Suotoushan Formation in northeastern Yunnan[J]. Sedimentary Geology and Tethyan Geology, 38(3): 25-31(in Chinese with English abstrct). http://en.cnki.com.cn/Article_en/CJFDTotal-TTSD201803003.htm
Zhu Lejiang. 2020. Geological Characteristics and Provenance Analysis of the Tianxing Quartz Sandstone Deposits in Daguan County, Yunnan[D]. Chengdu: Chengdu University of Technology, 26-28(in Chinese with English abstrct).
贾德龙, 张万益, 陈从林, 李永胜, 吴冬梅, 崔敏利, 张崔光. 2019. 高纯石英全球资源现状及我国发展建议[J]. 矿产保护与利用, 39(5): 111-117. https://www.cnki.com.cn/Article/CJFDTOTAL-KCBH201905014.htm
姜文涛. 2016. 云南省彝良县石英砂岩地质特征及可选性研究[J]. 中国非工业矿工业导刊, (4): 10-13. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK201602004.htm
李美烽. 2020. 云南彝良县潘家寨沉积型硅石矿矿床地质特征及沉积环境分析[D]. 成都: 成都理工大学, 20-26.
李忠水, 陈军元, 刘小楼, 李嘉欣. 2019. 硅质原料矿床勘查类型划分——划分因素及划分方法探讨[J]. 中国非金属矿工业导刊, (1): 23-28, 45. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK201901007.htm
刘宝珺, 许效松, 潘杏南. 1993. 中国南方古大陆沉积地壳演化与成矿[M]. 北京: 科学出版社, 56-58.
罗志立. 1989. 峨眉地裂运动的厘定及其意义[J]. 四川地质学报, 9(1): 1-17. https://www.cnki.com.cn/Article/CJFDTOTAL-SCDB198901000.htm
毛治超, 杜远生, 张敏. 2008. 广西桂中地区泥盆系沉积环境及沉积有机质特征[J]. 中国科学(D辑): 地球科学, 38: 80-86. doi: 10.3321/j.issn:1006-9267.2008.z2.011
梅冥相, 高金汉, 李东海. 2003. 黔桂地区泥盆系层序地层格架及相对海平面变化[J]. 沉积学报, 21(2): 297-306. doi: 10.3969/j.issn.1000-0550.2003.02.017
穆恩之, 陈旭, 倪寓南. 1988. 广西钦州、玉林地区的志留系和泥盆系[J]. 地层学杂志, 12(4): 241-254. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ198804000.htm
汪灵, 党陈萍, 李彩侠, 王艳, 魏玉燕, 夏瑾卓, 潘俊良. 2014. 中国高纯石英技术现状及发展前景[J]. 地学前缘, 21(5): 267-273. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201405026.htm
王全伟, 梁斌, 杨恒书. 2001. 西扬子大陆区泥盆系沉积演化与成矿[J]. 中国区域地质, 20(4): 415-421. doi: 10.3969/j.issn.1671-2552.2001.04.014
王中荣. 2014. 云南彝良县石英砂提纯工艺研究[D]. 成都: 成都理工大学, 30-38.
王子正, 江新胜, 周邦国, 潘宁槿, 陆生林. 2019. 滇东北地区中泥盆统缩头山组一段沉积特征及其含矿性[J]. 矿物岩石, 39(2): 90-98. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201902010.htm
魏钦廉, 郑荣才, 周刚. 2011. 龙门山甘溪组谢家湾段风暴岩沉积特征及其意义[J]. 中国地质, 38(5): 1282-1288. doi: 10.3969/j.issn.1000-3657.2011.05.015
夏邦栋, 刘洪磊, 吴运高. 1992. 滇黔桂裂谷[J]. 石油实验地质, 14(1): 20-30. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD199201002.htm
杨式溥, 潘江, 侯鸿飞. 1979. 中国的泥盆系[J]. 地质学报, (3): 192-202. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE197903002.htm
张远志, 张定辉, 刘世荣. 1996. 云南省岩石地层[M]. 武汉: 中国地质大学出版社, 66-88.
郑荣才, 张锦泉. 1989. 滇东-黔西南泥盆纪构造格局与岩相古地理演化[J]. 成都地质学院学报, 16(4): 51-61. https://www.cnki.com.cn/Article/CJFDTOTAL-CDLG198904008.htm
周邦国, 王子正, 冀盘龙, 江新胜, 陈文杨. 2018. 滇东北中泥盆统缩头山组石英砂岩特征及其沉积环境[J]. 沉积与特提斯地质, 38(3): 25-31. doi: 10.3969/j.issn.1009-3850.2018.03.003
祝乐江. 2020. 云南大关天星石英砂矿床地质特征及物源分析[D]. 成都: 成都理工大学, 26-28.
-
