Characteristics and development potential of geothermal resources in northern Cangxian uplift
-
摘要:
研究目的 地热资源特征研究及开发潜力分析是开发区域地热资源的重要依据。
研究方法 本文将前人研究成果与最新钻井资料相结合，通过对沧县隆起北部地区地热地质背景、热储分布、地温场特征、水化学资源类型等主要因素进行剖析，建立了该区的地热成藏模式。
研究结果 沧县隆起北部地区是在渤海湾伸展型沉积盆地高大地热流值背景下，由北部燕山裸露区基岩接受的大气降水作为近源补给水源，进入基岩的冷水在深层循环过程中受到深部热源加热增温，沿断裂破碎带和不整合面向上运移富集，形成的以传导型传热机制为主的地热系统。
结论 本区地热资源特点为热储类型多、盖层地温梯度高、补给速度快、资源量巨大。主要表现为：区内分布馆陶组砂岩热储，奥陶系、蓟县系雾迷山组岩溶热储三套主力热水储集层；地温场分布主要受基底构造形态控制，基岩凸起区的平均地温梯度为45℃/km；地下水类型随着埋深的增加由HCO3-Na、HCO3·SO4-Na型水向成熟的Cl-Na型水过渡；本区内三套热储的可采地热资源量为1.67×1010GJ，折合标煤5.72×108t，年可开采地热资源量可满足供暖面积2亿m2，若在采灌平衡的条件下，沧县隆起北部地区年可采地热资源量为7.06×107GJ，折合标煤2.41×106t，可满足供暖面积0.85亿m2，具有良好的地热市场开发前景。
Abstract:This paper is the result of geothermal geological survey engineering.
Objective The characteristics and development potential of geothermal resources is an important basis for the development of regional geothermal resources.
Methods Combined the previous research results with the latest drilling data, the geothermal reservoir model is established based on the analysis of the main factors such as geothermal geological background, thermal reservoir distribution, geothermal field characteristics and hydrochemical resource types in the northern Cangxian uplift.
Results Under the background of high heat flow value in the extensional sedimentary basin of Bohai Bay, the atmospheric precipitation received by the bedrock in the exposed area of Yanshan Mountain in the north is used as the near source water supply. The cold water enters the bedrock, is heated by the deep heat source in the deep circulation process, and migrates and enriches along the fracture zone and unconformity surface, and forms the geothermal heat transfer mechanism dominated by conduction system.
Conclusions The geothermal resources in this area are characterized by many types thermal reservoirs, high geothermal gradient of caprock, rapid recharge rate and huge resources. It is mainly shown as follows: Three sets of main hot water reservoir, sandstone thermal reservoir of Guantao Formation, karst thermal reservoir of Ordovician and Jixian Wumishan Formation are distributed in the area; the distribution of geothermal field is mainly controlled by basement structure, and the average geothermal gradient in bedrock uplift area is 45 ℃/km; with the increase of groundwater depth, the groundwater type changes from HCO3-Na, HCO3·SO4-Na to mature Cl-Na; the recoverable geothermal resources in this area is 1.67×1010 GJ, equivalent to 5.72×108t of standard coal. The annual exploitable geothermal resources can meet the heating area of 2×108 m2, considering the balance of exploiting and irrigation, the annual exploitable resource of geothermal fluid in the northern part of Cangxian uplift is 7.06×107 GJ, equivalent to 2.41×106t of standard coal, which can meet the heating area of 8.5×107 m2, which has a good prospect of geothermal market development.
-
-
表 2 沧县隆起北部地区地热井数据统计表
Table 2. Statistical table of geothermal well data in northern Cangxian uplift
下载: 导出CSV
表 3 研究区地下水水化学测试结果(mg/L)
Table 3. Chemical compositions of groundwater from the study area(mg/L)
下载: 导出CSV
表 4 沧县隆起北部地区地热资源评价参数与计算结果汇总表
Table 4. Summary of evaluation parameters and calculation results of geothermal resources in Cangxian uplift
下载: 导出CSV
-
Armienta M A, Rodríguez R, Ceniceros N, CruzaA O, Aguayoa P, Moralesb Cienfuegosb E. 2014. Groundwater quality and geothermal energy. The case of Cerro Prieto Geothermal Field, México[J]. Renewable Energy, 63: 236-254. doi: 10.1016/j.renene.2013.09.018
Chu Hongxian, Mei Sai, Gao Xiaohui, Fang Zhonghua, Feng Jing. 2019. Analysis of formation and slope stability in Caofeidian Channel in Bohai Bay[J]. China Geology, 2(2): 189-197. doi: 10.31035/cg2018057
Duan Zhongfeng. 2007. The Numerical Modeling and Recharge Technique Analysis of The Wumishan Formation at Cangxian Uplift[D]. Jiaozuo: Henan Polytechnic University, 19-38(in Chinese with English abstract).
Gao Zhiyun. 1995. The Preliminary researeh on sedimentary phases and reservoir of Wumishan Formation in Cangxian Uplift[J]. Journal of Northwest University (Natural Science Edition), 25(4): 348-352(in Chinese with English abstract).
Giggenbach W F. 1988. Geothermal solute equilibria. derivation of Na-K-Mg-Ca geoindicators. Geochimica et Cosmochimica Acta[J]. 52(12): 2749-2765.
Hong Zenglin, Zhang Yinlong, Zhou Yang. 2019. Research on the modes of occurrence and application of geothermal resources in the middle and deep layers of the piedmont area in southern Guanzhong Basin[J]. Geology in China, 46(5): 1224-1235(in Chinese with English abstract).
Jiang Guosheng. 2014. The Research on the Main Factors of Controlling the Development of Ordovician Geothermal Reservoirs in Tianjin[D]. Beijing: China University of Geosciences(Beijing) (in Chinese with English abstract).
Li Sanzhong, Suo Yanhui, Dai Liming, Liu Liping, Jin Chong, Liu Xin, Hao Tianyao, Zhou Lihong, Liu Baohua, Zhou Juntai, Jiao Qian. 2010. Development of the Bohai Bay Basin and destruction of the North China Craton[J]. Earth Science Frontiers, 17(4): 64-89.
Li Shengtao, Yue Dongdong, Feng Zhaolong, Song Jian, Liu Donglin, Song Zhibin, He Guolei, Long Hui, Hao Wenjie, Zhang Qiuxia. 2022. Sinoprobe and parameters study on deep karst geothermal reservoir in the Donglihu Area, Tianjin[J]. Geology in China, 49(6): 1732-1746(in Chinese with English abstract).
Lin Wenjing, Liu Zhiming, Wang Wanli, Wang Guiling. 2013. The assessment of geothermal resources potential of China[J]. Geology in China, 40(1): 312-320(in Chinese with English abstract). doi: 10.3969/j.issn.1000-3657.2013.01.021
Liu Chiyang. 1986. The determination of the Cangxian-Tianjin Palaeo-Synclinorium and its geological evidence[J]. Oil & Gas Geology, 7(4): 333-343(in Chinese with English abstract).
Liu Kai, Wang Shanshan, Sun Ying, Cui Wenjun, Zhu Deli. 2017. Characteristics and regionalization of geothermal resources in Beijing[J]. Geology in China, 44(6): 1128-1139(in Chinese with English abstract).
Liu Qiongying, He Lijuan. 2019. Tectono-thermal modeling of the Bohai Bay Basin since the Cenozoic[J]. Chinese Journal of Geophysics, 62(1): 219-235(in Chinese with English abstract).
Lu Qingwei, Wang Qiang, Zhan Jian, Guo Wei, Li Wen, Wang Xiyu. 2018. Middle Pleistocene stratigraphic hiatus on the Cangxian Uplift, the west coast of Bohai Bay[J]. Journal of Palaeogeography, 20(4): 665-679(in Chinese with English abstract).
Mao Xiaoping, Wang Xinwei, Li Kewen, Guo Shaobin. 2018. Sources of heat and control factors in geothermal field[J]. Earth Science, 43(11): 4256-4266(in Chinese with English abstract).
Pirlo M C. 2004. Hydrogeochemistry and geothermometry of thermal groundwaters from the Birdsville Track Ridge, Great Artesian Basin, South Australia[J]. Geothermics, 33: 743-774. doi: 10.1016/j.geothermics.2004.07.001
Qi Peng, Ren Jianye, Lu Gangchen, Lu Shuangshuang, Tong Dianjun, Zhang Junxia. 2010. Cenozoic Episodic subsidence in the middle and north part of Huanghua Depression, Bohai Bay Basin[J]. Earth Science——Journal of China University of Geosciences, 35(6): 1041-1052(in Chinese with English abstract). doi: 10.3799/dqkx.2010.118
Ruan Chuanxia, Shen Jian, Li Liliang, Liu Rongguang, Mou Shuangxi. 2017. Researches on the reinjection of Dongli Lake bedrock reservoir in Binhai New Area, Tianjin[J]. Geological Bulletin of China, 36(8): 1439-1449(in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2017.08.013
Tianjin Geothermal Exploration and Development Design Institute. 2003. General Survey Report of Geothermal Resources in Panzhuang-Lutai, Tianjin[R]. Tianjin Geothermal Exploration and Development Design Institute(in Chinese).
Wang Di, Wang Xinwei, Mao Xiang, Wu Minghui, Liu Huiying, Zhang Xuan, Wang Tinghao. 2020. Characteristics of geothermal geology of the Wucheng uplift geothermal field[J]. Earth Science Frontiers, 27(3): 269-280(in Chinese with English abstract).
Wang Guiling, Wang Wanli, Zhang Wei, Ma Feng, Liu Feng. 2020. The status quo and prospect of geothermal resources exploration and development in Beijing-Tianjin-Hebei region in China[J]. China Geology, 3(1): 173-181. doi: 10.31035/cg2020013
Wang Guiling, Zhang Wei, Lin Wenjing, Liu Feng, Zhu Xi, Liu Yanguang, Li Jun. 2017. Research on formation mode and development potential of geothermal resources in Beijing-Tianjin-Hebei region[J]. Geology in China, 44(6): 1074-1085(in Chinese with English abstract).
Wang Xinwei, Wang Tinghao, Zhang Xuan, Mao Xiang, Luo Lu, Wang Di, Wu Minghui. 2019. Genetic mechanism of Xiwenzhuang geothermal field in Taiyuan Basin[J]. Earth Science, 44(3): 1042-1056(in Chinese with English abstract).
Yang Huifeng, Cao Wengeng, Zhi Chuanshun, Li Zeyan, Bao Xilin, Ren Yu, Liu Futian, Fan Cunliang, Wang Shufang, Wang Yabin. 2021. Evolution of groundwater level in the North China Plain in the past 40 years and suggestions on its overexploitation treatment[J]. Geology in China, 48(4): 1142-1155(in Chinese with English abstract).
Yue Baojing, Liu Jinqing, Liu Jian, Liao Jing, Zhang Junqiang. 2020. Grain size distribution of sediment of core YRD-1101 in the western margin of the modern Bohai Sea since the latest Pleistocene and its environmental change[J]. Geology in China, 47(3): 853-867(in Chinese with English abstract).
Zhang Baiming, Lin Li, Zhao Sumin. 2006. Analyses on mechanism or geothermal origin in Tianjin area[J]. Hydrogeology and Engineering Geology, 33(2): 104-107(in Chinese with English abstract). doi: 10.3969/j.issn.1000-3665.2006.02.025
Zhang Baojian, Zhao Tian, Li Yanyan. 2019. The hydrochemical characteristics and its significance of geothermal water in both sides of large fault: Taking northern section of the Liaokao fault in north China as an example[J]. China Geology, 4: 512-521. doi: 10.31035/cg2018132
Zhang Wei, Wang Guiling, Liu Feng, Xing Linxiao, Li Man. 2019. Characteristics of geothermal resources in sedimentary basins[J]. Geology in China, 46(2): 255-268(in Chinese with English abstract).
Zhao Sumin, Gao Baozhu, Li Xuemei, Li Huijuan, Hu Yan. 2007. Haracter and water-temperature conductivity of the Cangdong Fault(Tianjin Segment)[J]. Geological Survey and Research, 30(2): 121-127(in Chinese with English abstract).
段忠丰. 2007. 沧县隆起雾迷山组热储层数值模拟及回灌分析[D]. 焦作: 河南理工大学, 19-38.
高知云. 1995. 沧县隆起雾迷山组沉积相与储层初探[J]. 西北大学学报(自然科学版), 25(4): 348-352.
洪增林, 张银龙, 周阳. 2019. 关中盆地南部山前中深层地热资源赋存特征及应用[J]. 中国地质, 46(5): 1224-1235. http://geochina.cgs.gov.cn/geochina/article/abstract/20190522?st=search
江国胜. 2014. 天津市奥陶系热储层发育主控因素研究[D]. 北京: 中国地质大学(北京).
李三忠, 索艳慧, 戴黎明, 刘丽萍, 金宠, 刘鑫, 郝天珧, 周立宏, 刘保华, 周均太, 焦倩. 2010. 渤海湾盆地形成与华北克拉通破坏[J]. 地学前缘, 17(4): 64-89. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201004009.htm
李胜涛, 岳冬冬, 冯昭龙, 宋健, 刘东林, 宋志彬, 和国磊, 龙慧, 郝文杰, 张秋霞. 2022. 天津东丽湖深部岩溶热储探测与储层参数研究[J]. 中国地质, 49(6): 1732-1746. http://geochina.cgs.gov.cn/geochina/article/abstract/20220603?st=search
蔺文静, 刘志明, 王婉丽, 王贵玲. 2013. 中国地热资源及其潜力评估[J]. 中国地质, 40(1): 312-320. http://geochina.cgs.gov.cn/geochina/article/abstract/20130121?st=search
刘池洋. 1986. 古沧县-天津复向斜和其确定的依据[J]. 石油与天然气地质, 7(4): 333-343. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT198604004.htm
刘凯, 王珊珊, 孙颖, 崔文君, 朱德莉. 2017. 北京地区地热资源特征与区划研究[J]. 中国地质, 44(6): 1128-1139. http://geochina.cgs.gov.cn/geochina/article/abstract/20170608?st=search
刘琼颖, 何丽娟. 2019. 渤海湾盆地新生代以来构造-热演化模拟研究[J]. 地球物理学报, 62(1): 219-235. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201901016.htm
鲁庆伟, 王强, 詹健, 郭维, 李稳, 王西玉. 2018. 渤海湾西岸沧县隆起中更新世地层间断[J]. 古地理学报, 20(4): 665-679. https://www.cnki.com.cn/Article/CJFDTOTAL-GDLX201804011.htm
毛小平, 汪新伟, 李克文, 郭少斌. 2018. 地热田热量来源及形成主控因素[J]. 地球科学, 43(11): 4256-4266. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201811040.htm
祁鹏, 任建业, 卢刚臣, 史双双, 佟殿君, 张俊霞. 2010. 渤海湾盆地黄骅坳陷中北区新生代幕式沉降过程[J]. 地球科学——中国地质大学学报, 35(6): 1041-1052. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201006016.htm
阮传侠, 沈健, 李立亮, 刘荣光, 牟双喜. 2017. 天津市滨海新区东丽湖地区基岩热储回灌研究[J]. 地质通报, 36(8): 1439-1449. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD201708013.htm
天津地热勘查开发设计院. 2003. 天津市潘庄-芦台地热资源普查报告[R]. 天津地热勘查开发设计院.
汪新伟, 王婷灏, 张瑄, 毛翔, 罗璐, 王迪, 武明辉. 2019. 太原盆地西温庄地热田的成因机制[J]. 地球科学, 44(3): 1042-1056. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201903030.htm
王迪, 汪新伟, 毛翔, 武明辉, 刘慧盈, 张瑄, 王婷灏. 2020. 河北武城凸起地热田地热地质特征[J]. 地学前缘, 27(3): 269-280. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY202003026.htm
王贵玲, 张薇, 蔺文静, 刘峰, 朱喜, 刘彦广, 李郡. 2017. 京津冀地区地热资源成藏模式与潜力研究[J]. 中国地质, 44(6): 1074-1085. http://geochina.cgs.gov.cn/geochina/article/abstract/20170603?st=search
杨会峰, 曹文庚, 支传顺, 李泽岩, 包锡麟, 任宇, 柳富田, 范存良, 王树芳, 王亚斌. 2021. 近40年来华北平原地下水位演变研究及其超采治理建议[J]. 中国地质, 48(4): 1142-1155. http://geochina.cgs.gov.cn/geochina/article/abstract/20210411?st=search
岳保静, 刘金庆, 刘健, 廖晶, 张军强. 2020. 渤海西缘YRD-1101孔晚更新世以来沉积物粒度特征及其环境变迁[J]. 中国地质, 47(3): 853-867. http://geochina.cgs.gov.cn/geochina/article/abstract/20200321?st=search
张百鸣, 林黎, 赵苏民. 2006. 天津地区地热形成机理分析[J]. 水文地质工程地质, 33(2): 104-107. https://www.cnki.com.cn/Article/CJFDTOTAL-SWDG200602027.htm
张薇, 王贵玲, 刘峰, 邢林啸, 李曼. 2019. 中国沉积盆地型地热资源特征[J]. 中国地质, 46(2): 255-268. http://geochina.cgs.gov.cn/geochina/article/abstract/20190204?st=search
赵苏民, 高宝珠, 黎雪梅, 李慧娟, 胡燕. 2007. 沧东断裂(天津段)特征及导水导热性质分析[J]. 地质调查与研究, 30(2): 121-127. https://www.cnki.com.cn/Article/CJFDTOTAL-QHWJ200702008.htm
-
