Three–dimensional Analysis of Seismic Stability and Failure Process of Lijie Landslide in Gansu Province, China
-
摘要:
针对甘肃省舟曲县立节镇北山滑坡在地震情况下的稳定性及失稳后可能威胁的范围问题，笔者使用显式有限元及动力学大变形方法分析了该滑坡在地震情况下的稳定性及失稳后的破坏过程。首先基于滑坡纵剖面建立二维平面应变模型分析滑坡稳定性及破坏过程，之后使用航测点云数据建立三维滑坡模型进行计算分析。地震条件下三维计算确定的滑坡安全系数结果低于1.0，较二维计算结果低7.7%；三维情况计算出的滑动距离达1.73 km，高于二维情况17%，说明滑坡灾害问题使用二维小变形方法得出结果偏于危险。笔者采用显式有限元、三维及大变形计算方法分析更符合实际，可为滑坡灾害的工程防治提供科学理论依据。
Abstract:The seismic stability and failure process of Lijie landslide is analyzed using the explicit finite element method with dynamic and large deformation modes. Firstly, the Lijie landslide seismic stability is analyzed with two–dimensional plane strain assumption. Then, a three–dimensional mountain model is established via the point cloud data, and three–dimensional landslide failure process analysis is processed to determine the maximum sliding distance and failure range of the landslide. The results obtained by the explicit finite element, three–dimensional and large deformation method in this paper is more accurate than that of the two–dimensional and small deformation method. This study will propose the theoretical guidance for earthquake resistance and the prevention of earthquake–induced landslide disaster.
-
-
表 1 甘肃地区典型地震及诱发滑坡统计表
Table 1. Typical earthquakes and landslides in Gansu
时间 震中 震级（M） 烈度 滑坡灾害特点 1654 甘肃天水 8 XI 密集滑坡群 1718 甘肃通渭 7½ X 密集滑坡群，
遇难人数占总数2/31927 甘肃古浪 8 XI 密集滑坡群 2013 甘肃岷县 6.6 Ⅷ 成片及密集分布
下载: 导出CSV
表 2 计算参数取值表
Table 2. The parameter value list
Gmax （MPa） Poisson's ratio ν γref a Dmax c（kPa） φ （°） 40.0 0.25 0.10 0.5 0.200 30 20.0
下载: 导出CSV
表 3 输入地震波特征信息表
Table 3. Characteristics of the input earthquake motions
地震加速度时程 Northridge（美国） Kocaeli（土耳其） 记录站点 CDMG（24278） Yarimca（KOERI330） 发生时间 1994年1月17日 1999年8月17日 地震动显着持时（秒） 9.06 15.62 峰值加速度（g） 0.56830 0.349
下载: 导出CSV
表 4 滑坡滑动距离计算结果列表
Table 4. Calculation result of slide distance
模型 滑坡状态 安全系数 变形/滑动距离（m） 二维 临界滑动状态 --- 5.36 失稳滑动 1.05 1767.54 三维 临界滑动状态失稳滑动 ---0.96 38.262052.46
下载: 导出CSV
-
刘畅, 张平松, 杨为民, 等. 税湾地震黄土滑坡的岩土动力特性及其稳定性评价[J]. 西北地质, 2020, 53(04): 176-185 doi: 10.19751/j.cnki.61-1149/p.2020.04.016
Liu Chang, ZHANG Pingsong, YANG Weimin, et al. Geotechnical dynamic characteristics and stability evaluation of Shuiwan earthquake loess landslide[J]. Northwestern Geology, 2020, 53(04): 176-185. doi: 10.19751/j.cnki.61-1149/p.2020.04.016
谢定义. 土动力学[M]. 北京: 高等教育出版社, 2011
XIE Dingyi. Soil dynamics[M]. Beijing: Higher Education Press, 2011.
王兰民, 蒲小武, 陈金昌. 黄土高原地震诱发滑坡分布特征与灾害风险[J]. 城市与减灾. 2019, 3: 33-40
WANG Lanmin, PU Xiaowu, CHEN Jinchang. Distribution feature and disaster risk of earthquake-induced landslides in Loess Plateau[J]. Cities and Disaster Reduction. 2019, 3: 33-40.
王兰民, 吴志坚. 岷县漳县6.6级地震震害特征及其启示[J]. 地震工程学报, 2013, 35(3): 401-412 doi: 10.3969/j.issn.1000-0844.2013.03.0401
WANG Lanmin, WU Zhijian. Earthquake damage characteristics of the Minxian-Zhangxian Ms6.6 earthquake and its lessons[J]. Chinese Earthquake Engineering Journal, 2013, 35(3): 401-412. doi: 10.3969/j.issn.1000-0844.2013.03.0401
王振华, 马宗源, 党发宁. 等效线性和非线性方法土层地震反应分析对比[J]. 西安理工大学学报, 2013, 29(04): 421-427. doi: 10.19322/j.cnki.issn.1006-4710.2013.04.008
殷跃平. 汶川八级地震地质灾害研究[J]. 工程地质学报, 2008, 1(04): 433-444 doi: 10.3969/j.issn.1004-9665.2008.04.001
YIN Yueping. Features of landslides triggered by the Wenchuan earthquake[J]. Journal of Engineering Geology, 2008, 1(04): 433-444. doi: 10.3969/j.issn.1004-9665.2008.04.001
中华人民共和国国家治理监督检验检疫总局, 中国国家标准化管理委员会. 《中国地震动参数区划图》(GB18306-2015)[S]. 北京: 中国标准出版社, 2016.
Griffiths DV, Lane PA. Slope stability analysis by finite elements[J]. Géotechnique, 1999; 49(3): 387-403. doi: 10.1680/geot.1999.49.3.387
Hardin B O, Drnevich V P. Shear Modulus and Damping in Soils: Design Equations and Curves[J]. Journal of the Soil Mechanics and Foundation Engineering Division, ASCE, 1972, 98(7): 667–692. doi: 10.1061/JSFEAQ.0001760
MA Zongyuan, LIAO Hongjian, DANG Faning, CHENG Yuxiang. Seismic slope stability and failure process analysis using explicit finite element method[J]. Bulletin of Engineering Geology and the Environment, 2021, 80: 1287–1301. doi: 10.1007/s10064-020-01989-3
MA Zongyuan, DANG Faning, LIAO Hongjian, CHENG Yuxiang. Seismic stability and failure process analysis of earth-filled dam[J]. Arabian Journal of Geosciences, 2020, 13(827): 1-12.
Newmark N M. Effect of earthquake on dam and embankment[J]. Geotechnique, 1965, 15(2): 139-160. doi: 10.1680/geot.1965.15.2.139
Shukha R, Operstein V, Frydman S. Stability charts for pseudo-static slope stability analysis[J]. Soil dynamics and earthquake engineering. 2006; 26(9): 813-823.
Travasarou T, Bray JD. Pseudostatic Coefficient for Use in Simplified Seismic Slope Stability Evaluation. Journal of geotechnical and geoenvironmental engineering. 2009; 135(9): 1336-1340.
-
