Geochemical Characteristics and Ore−prospecting of Dashagou Area in East Kunlun, Xinjiang: Based on Stream Sediment Survey
-
摘要:
在1∶5万水系沉积物测量基础上，对东昆仑大沙沟一带成矿元素分布特征进行研究，获得了较为丰富的区域地球化学成果。通过对元素分布特征、元素相关性、地球化学参数特征等进行研究。结果表明，该区元素的富集与地层、构造、岩浆岩明显相关；Cu、Zn、Au、Ag、Sb、Hg富集成矿可能性较大，可作为区内主成矿元素及指示元素。本次工作共圈定37处综合异常，6处成矿远景区，5处找矿靶区，为下一步找矿工作提供了地球化学依据。
Abstract:Based on the 1∶50000 stream sediment survey, the distribution characteristics of ore-forming elements in Dashagou area, East Kunlun, and plentiful regional geochemical survey data was obtained. The author analyzed the characteristic of element distribution, geochemical features of stream sediment as well as the relationships between of elements, and found that the enrichment and depletion of elements relate to the formation, struture and magmatic rock, Cu, Zn, Au, Ag, Sb, Hg are more likely to be rich in integrated ore, which can be used as the main ore–forming element and indicator element in the area. A total of 37 composite anomalies and 6 potential ore–prospecting areas and 5 target area were delineated in this work, the results points out the direction for the prospecting work in the next stage.
-
Key words:
- stream sediment survey /
- geochemical characteristics /
- prospective area /
- Dashagou area /
- east Kunlun
-
-
表 1 研究区各地质单元异常下限统计表
Table 1. The threshold of anomaly of each geological unit in the study area
元素 北部 南部 元素 北部 南部 Ag 0.09 0.14 Hg 0.11 0.13 As 29.79 35.31 Li 49.58 55.2 Au 2 3.47 Mo 1.31 1.86 B 142.45 118.73 Ni 40.7 49.79 Be 1.94 2.35 Pb 24.52 29.02 Bi 0.27 0.38 Sb 3.7 7.18 Co 13.74 18.38 Sn 2.03 4.21 Cr 75.83 86.68 W 2.02 2.11 Cu 30.37 48.3 Zn 76.52 97.38 注：Au、Ag、Hg含量为10−9，其他元素含量为10−6。
下载: 导出CSV
表 2 元素特征值参数统计表
Table 2. Element eigenvalue parameter statistics table
北 部 南 部 元素 平均值（X1） 背景值（X2） 富集系数（K） 成矿有利度（Ma） 区域背景值 元素 平均值（X1） 背景值（X2） 富集系数（K） 成矿有利度（Ma） 区域背景值 Ag 0.04 0.04 0.74 0.33 0.058 Ag 0.10 0.09 1.52 0.64 0.06 As 15.14 14.75 1.12 0.26 13.163 As 18.95 16.48 0.90 0.26 18.37 Au 0.94 0.89 0.71 0.31 1.259 Au 2.01 1.67 1.34 0.69 1.25 B 59.08 45.49 1.43 1.00 31.746 B 77.73 75.72 1.90 0.69 39.77 Be 1.24 1.23 0.85 0.30 1.442 Be 1.88 1.88 1.04 0.29 1.8 Bi 0.17 0.16 0.80 0.28 0.207 Bi 0.29 0.28 1.12 0.39 0.25 Co 8.37 8.27 0.95 0.35 8.667 Co 14.01 13.92 1.25 0.31 11.15 Cr 39.49 37.66 0.78 0.40 48.502 Cr 65.07 64.06 1.41 0.40 45.54 Cu 20.26 19.90 0.99 0.33 20.112 Cu 44.55 43.91 1.53 0.58 28.71 Hg 0.05 0.04 1.10 0.59 0.036 Hg 0.09 0.07 0.00 0.00 40 Li 36.31 29.88 1.22 0.33 24.407 Li 45.31 44.82 1.26 0.32 35.66 Mo 0.81 0.76 0.85 0.26 0.897 Mo 1.39 1.27 1.64 0.79 0.77 Ni 23.64 21.96 0.95 0.32 23.169 Ni 42.01 41.04 1.53 0.42 26.77 Pb 16.22 14.01 0.82 0.23 17.016 Pb 20.05 19.60 1.06 0.33 18.43 Sb 1.45 1.37 1.23 0.32 1.112 Sb 3.57 2.60 2.03 1.06 1.28 Sn 0.92 0.75 0.37 0.23 2.038 Sn 2.68 2.60 1.31 0.52 1.99 W 1.18 1.06 0.88 0.36 1.208 W 1.62 1.53 1.24 0.34 1.24 Zn 49.54 48.41 1.01 0.37 48.009 Zn 89.96 89.61 1.13 0.32 79.51 注：Au、Ag、Hg含量为10−9，其他元素单位为10−6。
下载: 导出CSV
表 3 研究区变异系数及标准离差统计表
Table 3. Variable coefficient and standard deviationstatistical table in the study area
元素 北 部 南 部 Cv1 Cv2 Cv1/Cv2 S1 S2 S1/S2 Cv1 Cv2 Cv1/Cv2 S1 S2 S1/S2 Ag 0.56 0.45 1.24 0.02 0.02 1.29 0.68 0.42 1.60 0.07 0.04 1.76 As 0.63 0.23 2.72 9.52 3.42 2.79 0.59 0.29 2.02 11.26 4.83 2.33 Au 0.62 0.44 1.40 0.58 0.40 1.47 5.18 0.52 10.02 10.42 0.86 12.06 B 1.11 0.70 1.58 65.35 31.86 2.05 0.40 0.36 1.12 31.31 27.27 1.15 Be 0.36 0.35 1.04 0.45 0.43 1.05 0.29 0.28 1.04 0.55 0.52 1.05 Bi 0.36 0.35 1.02 0.06 0.06 1.03 0.42 0.35 1.23 0.12 0.10 1.26 Co 0.39 0.37 1.07 3.28 3.04 1.08 0.28 0.25 1.12 3.94 3.50 1.12 Cr 0.60 0.51 1.17 23.54 19.25 1.22 0.42 0.28 1.47 27.27 18.23 1.50 Cu 0.37 0.34 1.09 7.42 6.71 1.10 0.40 0.38 1.07 17.92 16.54 1.08 Hg 1.19 0.54 2.22 0.06 0.02 2.90 2.78 0.58 4.80 0.25 0.04 6.38 Li 1.24 0.27 4.68 45.16 7.95 5.68 0.28 0.26 1.11 12.85 11.43 1.12 Mo 0.50 0.30 1.66 0.40 0.23 1.76 0.82 0.48 1.71 1.14 0.60 1.88 Ni 0.55 0.34 1.61 13.02 7.52 1.73 0.47 0.27 1.72 19.67 11.19 1.76 Pb 2.10 0.28 7.51 34.00 3.91 8.69 0.36 0.31 1.16 7.18 6.05 1.19 Sb 0.95 0.26 3.68 1.38 0.35 3.90 1.23 0.52 2.36 4.38 1.35 3.23 Sn 0.93 0.61 1.51 0.85 0.46 1.84 0.46 0.40 1.16 1.23 1.03 1.20 W 0.62 0.40 1.53 0.73 0.43 1.69 0.75 0.27 2.73 1.21 0.42 2.88 Zn 0.40 0.36 1.09 19.71 17.61 1.12 0.29 0.28 1.02 26.08 25.47 1.02
下载: 导出CSV
表 4 旋转因子矩阵数据表
Table 4. Rotation factor matrix data table
变量 F1 F2 F3 F4 F5 F6 F7 F8 F9 Au 0.014 −0.034 0.018 −0.003 −0.011 0.999 0 −0.01 −0.025 Sn 0.149 −0.213 0.047 −0.055 −0.706 0.01 −0.02 −0.073 −0.489 Ag 0.044 −0.785 0.068 −0.001 −0.425 0.009 0.017 −0.053 −0.109 Cu 0.307 −0.599 0.197 −0.1 −0.046 0.029 0.086 0.035 −0.586 Pb 0.021 −0.077 −0.036 −0.87 −0.016 0.002 −0.046 −0.115 −0.075 Zn 0.379 −0.234 0.124 −0.168 −0.183 0.014 0.053 −0.029 −0.758 Ni 0.889 −0.19 0.098 −0.066 −0.126 0.011 0.025 −0.03 −0.3 W 0.068 −0.054 0.161 −0.043 −0.089 0.011 0.011 −0.909 −0.234 Mo 0.105 −0.888 0.145 −0.05 0.079 0.028 0.105 −0.044 −0.154 Cr 0.866 −0.02 0.041 −0.085 −0.176 0.008 0.011 −0.074 −0.396 Co 0.578 −0.16 0.167 −0.115 −0.162 0.011 0.065 −0.043 −0.687 Li 0.124 0.011 0.166 −0.78 −0.097 0.003 0.069 0.076 −0.196 Be 0.302 −0.076 0.121 −0.14 −0.215 0.012 0.001 −0.13 −0.828 B 0.172 −0.042 0.053 −0.081 −0.875 0.005 0.029 −0.051 −0.145 Ass 0.105 −0.141 0.794 −0.056 −0.012 0.004 −0.017 −0.283 −0.085 Sb 0.047 −0.108 0.827 −0.067 −0.078 0.018 0.024 0.06 −0.264 Bi 0.134 −0.099 0.202 −0.103 −0.144 0.015 −0.028 −0.26 −0.794 Hg 0.035 −0.114 0.004 −0.014 −0.015 0 0.988 −0.007 −0.028
下载: 导出CSV
-
[1] 崔晓亮,刘婷婷,王文恒,等. 东昆仑布青山地区水系沉积物测量地球化学特征及找矿方向[J]. 物探与化探,2011,35(5):573–578.
CUI Xiaoliang, LIU Tingting, WANG Wenheng, et al Geochemical characteristics and ore search prospects of Buqingshan area in Qinghai Province based on stream sediment survey[J], Geophysical & Geochemical Exploration, 2011, 35(5): 573-578.
[2] 董庆吉,陈建平,唐宇. R型因子分析在矿床成矿预测中的应用——以山东黄埠岭金矿为例[J]. 地质与勘探,2008,44(4):64–68.
DONG Qingji, CHEN Jianping, TANG Yu, Application of R-Factor analysis in Mineralization prognosis: By an example of Huangbuling gold deposit, Shandong Province[J]. Geology and Prospecting, 2008.44(4): 64-68.
[3] 杜保峰,杨长青,柴建玉. 等, 水系沉积物测量在西藏春哲地区找矿效果[J]. 中国地质,2018,45(3):604–616.
DU Baofeng, YANG Changqing, CAI Jianyu, et al. The effect of stream sediment survey for prospecting in Chuanzhearea, Tibet, [J], Geology in China, 2018, 45(3): 604-616.
[4] 郝立波,李巍,陆继龙. 确定岩性复杂区的地球化学背景与异常的方法[J]. 地质通报,2007,26(12):1531–1535. doi: 10.3969/j.issn.1671-2552.2007.12.004
HAO Libo, LI Wei, LU Jilong. Method for determining the geochemical background and anomalles in areas with complex lithology[J]. Geological Bulletin of China, 2007, 26(12): 1531-1535. doi: 10.3969/j.issn.1671-2552.2007.12.004
[5] 何艳红,栗健强,程佳孝,等. 内蒙古温根地区水系沉积物地区化学特征及找矿预测[J]. 西北地质,2015,48(2):216–223.
HE Yanhong, LI Jianqiang, CHENG Jiaxiao. et al . Geochemical Characteristics and Prospecting Direction of Stream Sediment in Wengen Area of Inner Mongolia[J]. Northwestern Geology, 2015, 48(2): 216-223.
[6] 蒋敬业, 程建萍, 祁士华, 等. 应用地球化学[M]. 武汉: 中国地质大学出版社, 2006
JIANG Jingye, CHENG Jianping, QI Shihua, et al applied geochemistry[M]. Wuhan: China University of Geosciences Press, 2006
[7] 李玉芹,沈恒丽,王学贞. 都兰地区水系沉积物测量地球化学特征及找矿预测[J]. 矿物学报,2011,31(3):615–620. doi: 10.16461/j.cnki.1000-4734.2011.03.043
LI Yuqin, SHEN Hengli, WANG Xuezhen. Geochemical Characteristic of Stream Sediment Survey and Metallogenic Prognosis of Dulanarea, Qinghai Province, China[J], Acta Mineralogica Sinica, 2011, 31(3): 615-620. doi: 10.16461/j.cnki.1000-4734.2011.03.043
[8] 李文明, 刘拓, 孙吉明, 等. 新疆北山白山地区地球化学特征及找矿远景预测[J]. 西北地质, 2021, 54(4): 42−48.
LI Wenming, LIU Tuo, SUN Jiming, et al. Geochemical Characteristics and Prospecting Prognosis in Baishan Area of Xinjiang Beishan[J]. Northwestern Geology, 2021, 54(4): 42−48.
[9] 李天虎, 彭桥梁, 王伟, 等. 新疆温宿县盐场地区水系沉积物地球化学特征及找矿效果[J]. 西北地质, 2022, 55(1): 78−92.
LI Tianhu, PENG Qiaoliang, WANG Wei, et al. Geochemical Characteristics and Ore Prospecting of Stream Sediment in Yanchang Area of Wensu, Xinjiang[J]. Northwestern Geology, 2022, 55(1): 78−92.
[10] 宋贺民,张辉,顾松松,等. 新疆哈拉奇地区水系沉积物地球化学特征及找矿方向[J]. 地质通报,2014,33(1):71–78. doi: 10.3969/j.issn.1671-2552.2014.01.010
SONG Hemin, ZHANG Hui, GU Songsong, et al. Stream sediment geochemical characteristics and prospecting direction in Karaqi area of Xinjiang[J]Geological Bulletin of China, 2014, 33(1): 71-78. doi: 10.3969/j.issn.1671-2552.2014.01.010
[11] 宋建中,张雪冰,魏良民,等. 内蒙古额济纳旗道噶地区土壤地球化学特征及找矿方向[J]. 西北地质,2014,47(3):8–13.
SONG Jianzhong, ZHANG Xuebing, WEI Liangmin, et al . Geochemical Characteristics of Soils and Exploration Directions of Daoga Area, Ejinaqi County, Inner Mongolia[J]. Northwestern Geology, 2014, 47(3): 8-13
[12] 孙江华, 刘峰, 陈利民. 等. 新疆昆仑山东段木孜塔格-阿尔喀山1: 20万地球化学图说明书[R]. 新疆维吾尔自治区地质调查院, 2003.
[13] 孙社良,冯增会,黄孝波,等. 新疆汉水泉地区水系沉积物测量地球化学特征及找矿方向[J]. 物探与化探,2018,42(6):1116–1117.
SUN Sheliang, FENG Zenghui, HUANG Xiaobo, et al Geochemical characteristics and ore-search prospects of Hanshuiquan area in Xinjiang based on stream sediment survey [J] Geophysical & Geochemical Exploration, 2018, 42(6): 1116-1117.
[14] 王崇云. 地球化学找矿基础[M]. 北京: 地质出版社, 1987: 15–60
WANG Chongyun. The basis of Geochemical prospects[M]. Beijing: Geological Publishing House, 1987: 15–60
[15] 夏祥标,郑来林. 普迟亚地区水系沉积物测量地球化学特征及找矿方向[J]. 物探与化探,2009,33(6):626–634.
XIA Xiangbiao, ZHENG Lailin. Geochemical characteristics and ore-search prospects of Puchiya area in Tibet based on stream sediment survey[J], Geophysical & Geochemical Exploration, 2009, 33(6): 626-634.
[16] 肖霞,倪师军,白涛,等. 西藏妥坝地区水系沉积物地球化学特征及找矿靶区[J]. 矿物岩石地球化学通报,2016,35(3):570–575.
XIAO Xia, NI Shijun, BAI Tao, et al. Geochemical Characteristics of Stream Sediments and Prospecting Targets in the Tuoba Area of Tibet, China. Bulletin of Mineralogy, Petrology and Geochemistry, 2016, 35(3): 570-575
[17] 谢学锦. 区域地质调查野外工作方法: 区域化探[M]. 北京: 地质出版社, 1979
XIE Xuejin. Field work method of regional geological survey: Regional geochemical[M]. Beijing: Geological Publishing House, 1979.
[18] 薛琮一,王嘉伟,杨征,等. 新疆和田布雅煤矿一带水系沉积物测量地球化学特征及找矿方向[J]. 西北地质,2020,58(4):66–72.
XUE Congyi, WANG Jiawei, YANG Zheng, et al. A Review of Geochemical Characteristics and Prospecting Direction of Stream Sediment of Buya Coal Mine in Hetian, Xinjiang[J]. Northwestern Geology, 2020, 58(4): 66-72.
[19] 姚玉增,巩恩普,梁俊红,等. R型因子分析在处理混杂原生晕样品中的应用——以河北丰宁银矿为例[J]. 地质与勘探,2005,41(2):51–55.
YAO Yuzeng, GONG Enpu, LIANG Junhong, et al Application of R-Factor analysis in Handing mixed samples of primary halo-A case study of Fengning silver deposit[J]. Geology and Prospecting, 2005.41(2): 51-55.
[20] 张辉善,张杰,史俊波,等. 青海格尔木红石山地区水系沉积物测量异常特征及优选找矿靶区[J]. 物探与化探,2010,35(6):768–772.
ZHANG Huishan, ZHANG Jie, SHI Junbo, et al. Anomaly characteristics of stream sediment survey in Hongshishan area of Golmud, Qinghai Province, and the optimization of prospecting target areas. [J] Geophysical & Geochemical Exploration, 2010, 35(6): 768-772.
[21] 赵娟, 马正婷, 柴云, 等. 青海省冷湖行委俄博梁地区稀有稀土元素地球化学特征及找矿潜力分析[J]. 西北地质, 2021, 54(4): 82−87.
ZHAO Juan, MA Zhengting, CHAI Yun, et al. Geochemical Characteristics and Prospecting Potential of Rare Rare-earth Element in Eboliang Area, Lenghu, Qinghai Province[J]. Northwestern Geology, 2021, 54(4): 82-87.
[22] 赵禹, 赵寒森, 刘拓, 等. 西北地区土地质量地球化学调查进展与主要成果[J]. 西北地质, 2022, 55(3): 140−154.
ZHAO Yu, ZHAO Hansen, LIU Tuo, et al. Progresses and Main Achievements of Geochemical Survey of Land Quality in Northwest China[J]. Northwestern Geology, 2022, 55(3): 140−154.
-
