Application of Geological Hazard Risk Assessment in Territorial Space Planning: A Case Study of Gaoxigou Village in Yulin City of Northern Shaanxi Province
-
摘要:
榆林市米脂县高西沟村位于黄土高原丘陵沟壑区，属于地质灾害多发区，因此，考虑地质灾害风险的国土空间规划具有极其重要的意义。笔者基于地质灾害调查数据，选取坡度、坡向、地质灾害发育密度等评价指标，采用信息量模型以斜坡单元进行危险性评价，在此基础上叠加承灾体易损性进行定量风险评价，划定地质灾害风险分区。利用ArcGIS将地质灾害风险区划与现状功能区叠加，将高西沟重构为4个国土空间分区：地质灾害中风险–生活居住区、地质灾害低风险–生态功能区、地质灾害低风险–农业生产区和沟谷区，并提出国土空间优化策略。
Abstract:Gaoxigou village of Mizhi county in Yulin city, is located in the hilly and gully region of the Loess plateau. It is a geological disaster prone area. Therefore, it is of great importance to consider the risk of geological disaster in territorial space planning. Based on geological disaster survey data, evaluation indexes such as slope, slope aspect and geological disaster development density were selected, the information quantity model was used to evaluate the risk with slope element, on this basis, the vulnerability of disaster bearing body was superimposed for quantitative risk assessment, and delineated risk zones of geological disasters. Using ArcGIS, the risk zoning of geological disasters and current functional areas were superimposed, and Gaoxigou was reconstructed into four territorial space zones: medium risk in geological hazards–living area, low risk in geological hazards–ecological functional area, low risk in geological hazards–agricultural production area, and ravine region, and put forward the territorial space optimization strategy.
-
-
表 1 信息量值对应危险性等级及灾点分布的对比表
Table 1. Comparison of information value corresponding to risk grade and disaster point distribution
危险性
等级信息
量值面积
（km2）面积所
占比例（%）崩塌
数（个）崩塌所
占比例（%）危险性中 2.401～6.015 0.850 20.89 20 76.9 危险性低 0～2.401 0.932 22.90 6 23.1 危险性极低 −2.171～0 2.133 52.40 0 0 沟谷区 0 0.155 3.81 0 0 总计 4.07 100 26 100
下载: 导出CSV
表 2 高西沟地质灾害风险评价结果表
Table 2. Risk assessment results of geological hazards in Gaoxigou
风险源
编号发生
概率P（L）到达
概率P（T:L）承灾体
时空概率P（T）财产易
损性V（prop）人员易
损性V（D）承灾体价值
E（万元）财产年损失
R（prop）（万元/a）单人年死亡
概率P（LoL）1号 10−4 1.0 0.625 0.5 0.2 60 0.0019 1.25×10−5 2号 10−3 1.0 0.625 0.6 0.3 30 0.0113 1.88×10−4 3号 10−4 1.0 0.625 0.5 0.3 100 0.0031 1.88×10−5 4号 10−3 1.0 0.625 0.6 0.3 20 0.0075 1.88×10−4 5号 10−3 1.0 0.625 0.6 0.3 50 0.0188 1.88×10−4 6号 10−3 1.0 0.625 0.7 0.3 15 0.0066 1.88×10−4 7号 10−4 1.0 0.625 0.5 0.2 40 0.0013 1.25×10−5 8号 10−3 1.0 0.625 0.7 0.3 60 0.0263 1.88×10−4 9号 10−3 1.0 0.625 0.6 0.5 80 0.0300 3.13×10−4 10号 10−4 1.0 0.625 0.5 0.3 90 0.0028 1.88×10−5 11号 10−4 1.0 0.625 0.3 0.2 30 0.0006 1.25×10−5 12号 10−3 1.0 0.625 0.6 0.5 80 0.0300 3.13×10−4 13号 10−4 1.0 0.625 0.4 0.2 85 0.0021 1.25×10−5 14号 10−4 1.0 0.625 0.5 0.2 90 0.0028 1.25×10−5 15号 10−3 1.0 0.625 0.6 0.5 80 0.0300 3.13×10−4 16号 10−4 1.0 0.625 0.5 0.2 50 0.0016 1.25×10−5 17号 10−4 1.0 0.625 0.5 0.2 16 0.0005 1.25×10−5 18号 10−3 1.0 0.625 0.6 0.3 18 0.0068 1.88×10−4 19号 10−4 1.0 0.625 0.5 0.3 40 0.0013 1.88×10−5 20号 10−4 1.0 0.625 0.5 0.2 30 0.0009 1.25×10−5 21号 10−4 1.0 0.625 0.5 0.2 15 0.0005 1.25×10−5 22号 10−4 1.0 0.625 0.5 0.2 38 0.0012 1.25×10−5 23号 10−3 1.0 0.625 0.6 0.3 40 0.0150 1.88×10−4 24号 10−3 1.0 0.625 0.7 0.3 80 0.0350 1.88×10−4 25号 10−4 1.0 0.625 0.5 0.2 15 0.0005 1.25×10−5 26号 10−4 1.0 0.625 0.5 0.2 85 0.0027 1.25×10−5
下载: 导出CSV
-
[1] 冯凡, 唐亚明, 潘学树, 等. 不同尺度下地质灾害风险评价方法探讨—以陕西吴堡县为例[J]. 中国地质灾害与防治学报, 2022, 33(2): 115-124
FENG Fan, TANG Yaming, PAN Xueshu. et al. An Attempt of Risk Assessment of Geological Hazards in Different Scales: A Case Study in Wubao County of Shaanxi Province[J]. The Chinese Journal of Geological Hazard and Control, 2022, 33(2): 115-124.
[2] 冯旭, 王凯, 毛其智, 等. 国土空间规划体系下的乡村空间规划方法—基于规划与治理的一体化视角[J]. 城市规划, 2022, 46(11): 21-31
FENG Xu, WANG Kai, MAO Qizhi, et al. Rural spatial planning methods in the territorial planning: from an integrated perspective of planning and governance[J]. City Planning Review, 2022, 46(11): 21-31.
[3] 姬永涛, 王鲜, 郝业, 等. 基于斜坡单元的陕西省城镇地质灾害风险调查评价-以西安市蒋村街道为例[J]. 灾害学, 2022, 37(4): 000-000
JI Yongtao, WANG Xian, HAO Ye, et al. Investigation and Evaluation of Urban Geological Hazard Risk Based on Slope Unit in Shaanxi Province: A Case Study of Jiangcun Sub-district in Xi’an City[J]. Journal of Catastrophology, 2022, 37(4): 000-000.
[4] 李畅. 基于生态环境保护的乡村发展规划策略[J]. 林业调查规划, 2022, 47(4): 170-174
LI Chang. Rural development planning strategy based on ecological environment protection[J]. Forest Inventory and Planning, 2022, 47(4): 170-174.
[5] 李冠宇, 李鹏, 郭敏, 等. 基于聚类分析法的地质灾害风险评价-以韩城市为例[J]. 科学技术与工程, 2021, 21(25): 10629-10638
LI Guanyu, LI Peng, GUO Min, et al. Application of Cluster Analysis Method in Geological Hazard Risk Assessment: A Case Study of Hancheng City[J]. Science Technology and Engineering, 2021, 21(25): 10629-10638.
[6] 卢全中, 彭建兵, 赵发锁. 地质灾害风险评估(价)研究综述[J]. 灾害学, 2003, 18(4): 59-63
LU Quanzhong, PENG Jianbing, ZHAO Fasuo. A Review of Geological Hazard Risk Assessment[J]. Journal of Catastrophology, 2003, 18(4): 59-63.
[7] 马云飞, 邹芳, 徐海燕. 基于地质灾害风险评价的衡东县国土空间管制研究[J]. 地理信息世界, 2020, 27(6): 14-20
MA Yunfei, ZOU Fang, XU Haiyan, et al. Land Space Control of Hengdong County Based on Geological Hazard Risk Assessment[J]. Geomatics World, 2020, 27(6): 14-20.
[8] 齐信, 唐川, 陈州丰, 等. 地质灾害风险评价研究[J]. 自然灾害学报, 2012, 21(5): 33-40
QI Xin, TANG Chuan, CHEN Zhoufeng, et al. Research of Geohazards Risk Assessment[J]. Journal of Natural Disasters, 2012, 21(5): 33-40.
[9] 邱维蓉, 吴帮玉, 潘学树, 唐亚明. 几种聚类优化的机器学习方法在灵台县滑坡易发性评价中的应用[J]. 西北地质, 2020, 53(1): 223-233
QIU Weirong, WU Bangyu, PAN Xueshu, TANG Yaming. Application of Several Cluster-optimization-based Machine Learning Methods in Evaluation of Landslide Susceptibility in Lingtai County[J]. Northwestern Geology, 2020, 53(1): 223-233.
[10] 唐亚明, 冯卫, 毕银强, 毕俊擘. 基于风险评价的黄土滑坡分类及特征[J]. 地质通报, 2015, 34(11): 2092-2099
Tang Ya-ming, Feng Wei, Bi Yin-qiang, Bi Jun-bo. The classification and features of loess landslide based on risk assessment [J]. Geological Bulletin of China, 2015, 34(11): 2092-2099.
[11] 唐亚明, 张茂省, 薛强. 一种大比例尺的滑坡风险区划方法-以延安市区黄土滑坡风险评价为例[J]. 地质通报, 2011, 30(1): 166-172
Tang Ya-ming, Zhang Mao-sheng, Xue Qiang. Landslide risk assessment methods and flow on a large scale-A case study of loess landslide risk assessment in Yan’an urban district, Shaanxi, China [J]. Geological Bulletin of China, 2011, 30(1): 166-172.
[12] 万成伟, 宋代军. 可持续的乡村振兴规划建设模式—基于海峡两岸的案例比较[J]. 城市规划, 2022, 46(6): 90-102
WAN Chengwei, SONG Daijun. Sustainable planning and construction mode of rural revitalization: based on the comparative study of cases between ZHEJIANG and TAIWAN provinces[J]. City Planning Review, 2022, 46(6): 90-102.
[13] 王颖, 王志一, 纪轶群. 北京地质灾害风险评价研究[J]. 首都师范大学学报(自然科学版), 2022, 43(3): 54-61
WANG Ying, WANG Zhiyi, JI Yiqun. Risk Assessment of Geological Hazards in Beijing[J]. Journal of Capital Normal University(Natural Science Edition), 2022, 43(3): 54-61.
[14] 吴树仁, 石菊松, 张春山, 等. 滑坡风险评估理论与技术[M]. 北京: 科学出版社, 2012
WU Shuren, SHI Jusong, ZHANG Chunshan, et al. Theory and Technique of Landslide Risk Assessment[M]. Beijing: Science Press, 2012.
[15] 解明礼, 巨能攀, 刘蕴琨, 等. 崩塌滑坡地质灾害风险排序方法研究[J]. 水文地质工程地质, 2021, 48(5): 184-192
XIE Mingli, JU Nengpan, LIU Yunkun, et al. A Study of the Risk Ranking Method of Landslides and Collapses[J]. Hydrogeology & Engineering Geology, 2021, 48(5): 184-192.
[16] 许创智, 岳连雄, 赵文川, 等. 陕西省榆林市米脂县地质灾害详细调查报告[R]. 西安: 中国人民武装警察部队黄金第五支队, 2016
XU Chuangzhi, YUE Lianxiong, ZHAO Wenchuan, et al. Detailed Investigation Report of Geological Disaster in Mizhi County, Yulin City, Shaanxi Province[R]. Xi’an: the Fifth Gold Detachment of Chinese People’s Armed Police Force, 2016.
[17] 徐继维, 张茂省, 范文. 地质灾害风险评估综述[J]. 灾害学, 2015, 30(4): 130-134
XU Jiwei, ZHANG Maosheng, FAN Wen. A Review of Geological Hazard Risk Assessment[J]. Journal of Catastrophology, 2015, 30(4): 130-134.
[18] 杨柳, 牟鑫亮, 李晨, 等. 延安市宝塔区地质灾害风险评价[J]. 山地学报, 2020, 38(5): 679-690
YANG Liu, MOU Xinliang, LI Chen, et al. Geological Hazard Risk Assessment of Baota District in Yan’an City[J]. Mountain Research, 2020, 38(5): 679-690.
[19] 杨淞月, 翁茂芝, 田华. 等. 湖北省鹤峰县城区滑坡地质灾害风险评价[J]. 安全与环境工程, 2021, 28(1): 144-155
YANG Songyue, WENG Maozhi, TIAN Hua, et al. Landslide Risk Evaluation in the Rrban Area in Hefeng County, Hubei Province[J]. Safety and Environmental Engineering, 2021, 28(1): 144-155.
[20] 张茂省, 唐亚明. 地质灾害风险调查的方法与实践[J]. 地质通报, 2008, 27(8): 1205-1216
ZHANG Maosheng, TANG Yaming. Risk Investigation Method and Practice of Geohazards [J]. Geological Bulletin of China, 2008, , 27(8): 1205-1216.
[21] 张茂省, 薛强, 贾俊, 等. 山区城镇地质灾害调查与风险评价方法及实践[J]. 西北地质, 2019, 52(2): 125-135
ZHANG Maosheng, XUE Qiang, JIA Jun, et al. Methods and Practices for the Investigation and Risk Assessment of Geo-hazards in Mountainous Towns[J]. Northwestern Geology, 2019, 52(2): 125-135.
[22] 周超, 常鸣, 徐璐, 等. 贵州省典型城镇矿山地质灾害风险[J]. 武汉大学学报·信息科学版, 2020, 45(11): 1782-1791
ZHOU Chao, CHANG Ming, XU Lu, et al. Geological Hazard Risk of Mines in Typical Towns of Guizhou Province[J]. Geomatics and Information Science of Wuhan University, 2020, 45(11): 1782-1791.
[23] AGS. Landslide Risk Management Practice Note[S]. Australian Geomechanics Society, 2008, In press.
[24] Fell R, Ho K K S, Lacasse S, et al. A framework for landslide risk assessment and management[A]. Hungr O, Fell R, Couture R, et al. Landslide Risk Management[C]. The International Conference on Landslide Risk Management, Vancouver, Canada, 2005.
-
