钛铁矿和辉石浮选分离试验研究及抑制剂作用机理

高虎林; 刘建; 罗德强; 董文超; 于云龙; 郝佳美; 秦晓艳

doi:10.13779/j.cnki.issn1001-0076.2022.01.009

钛铁矿和辉石浮选分离试验研究及抑制剂作用机理

1.
昆明理工大学国土资源工程学院, 云南昆明 650093

2.
攀钢集团矿业有限公司设计研究院, 四川攀枝花 617063

基金项目:
省部共建复杂有色金属清洁利用国家重点实验室基金项目(CNMRCUTS2003)

详细信息

作者简介: 高虎林(1998-), 男, 贵州毕节人, 硕士研究生, 主要从事量子化学, 界面化学研究, E-mail: 1970789098@qq.com

通讯作者: 刘建(1984-), 男, 四川广元人, 博士, 教授, 主要从事浮选表界面化学研究, E-mail: vacation2008@126.com

中图分类号: TD923⁺.14;TD952.7

收稿日期: 2021-12-23

刊出日期: 2022-02-25

Experimental Study on Flotation Separation of Ilmenite and Pyroxene and Action Mechanism of Depressants

1.
Faculty of Land Resource Engineering, Kunming University of Science and Technology, Kunming 650093, China

2.
Pangang Group Mining Company Design Research Institute, Panzhihua 617063, China

More Information

Corresponding author: LIU Jian, vacation2008@126.com

Received Date: 23 December 2021

Publish Date: 25 February 2022

摘要

摘要:
以MOH为捕收剂, 水玻璃、草酸、LD-C(一种有机高分子抑制剂)为抑制剂, 对钛铁矿和辉石进行单矿物浮选试验研究, 并通过浮选溶液化学分析、Zeta电位测试和红外光谱测试, 研究了LD-C与钛铁矿和辉石的作用机理。试验结果表明: LD-C对辉石的选择性抑制效果明显优于水玻璃和草酸, 在弱酸性环境(pH=5~6)、捕收剂MOH用量为160 mg/L、抑制剂LD-C用量为2 mg/L的条件下, 钛铁矿回收率为80%, 辉石回收率为9%。LD-C与钛铁矿作用后, 对捕收剂在钛铁矿表面吸附的影响较小。LD-C与辉石作用后会阻碍捕收剂MOH在辉石表面的吸附, 这主要是由于辉石在矿浆中会溶解暴露出钙镁活性位点, 使得LD-C在辉石表面发生强烈的化学吸附, 从而阻碍了捕收剂的吸附。
- 钛铁矿 /
- 辉石 /
- 浮选分离 /
- 抑制剂
Abstract:
Using MOH as collector, sodium silicate, oxalic acid and LD-C (carboxymethyl cellulose) as depressants, single mineral flotation of ilmenite and pyroxene was carried out. In addition, the interaction mechanism of LD-C with ilmenite and pyroxene was studied by solution chemistry of flotation, zeta potential test and infrared spectroscopic test. The test results show that the selective depression effect of LD-C on pyroxene was significantly better than that of sodium silicate and oxalic acid. Under weak acidic conditions, and the dosage of collector MOH was 160 mg/L, depressant LD-C was 2 mg/L, the recovery of ilmenite can reach 80% and that of pyroxene was 9%. The interaction of LD-C on pyroxene can hinder the subsequent adsorption of MOH while that on ilmenite has little effect on the adsorption of MOH. This due to the fact that the active sites of Ca and Mg exposed on the pyroxene surface during flotation can make LD-C adsorb on pyroxene strongly, which hindering the adsorption of collector.
- ilmenite /
- pyroxene /
- flotation separation /
- depressants

HTML全文

图 1 钛铁矿和辉石晶体结构示意图：(a)钛铁矿；(b)辉石

Figure 1.

下载: 全尺寸图片幻灯片

图 2 钛铁矿和辉石的X射线衍射图：(a)钛铁矿；(b)辉石

Figure 2.

下载: 全尺寸图片幻灯片

图 3 捕收剂用量对钛铁矿和辉石可浮性的影响(柴油用量: 10mg/L; pH: 5~6)

Figure 3.

下载: 全尺寸图片幻灯片

图 4 水玻璃用量与矿物可浮性的关系(捕收剂用量: 160 mg/L; 柴油用量: 10 mg/L; pH: 5~6)

Figure 4.

下载: 全尺寸图片幻灯片

图 5 草酸用量与矿物可浮性的关系(捕收剂用量: 160 mg/L; 柴油10 mg/L; pH: 5~6)

Figure 5.

下载: 全尺寸图片幻灯片

图 6 LD-C用量与矿物可浮性的关系(捕收剂用量: 160mg/L; 柴油用量：10mg/L；pH: 5~6)

Figure 6.

下载: 全尺寸图片幻灯片

图 7 钛铁矿浮选溶液浓度对数图

Figure 7.

下载: 全尺寸图片幻灯片

图 8 钛铁矿、钛铁矿+LD-C、钛铁矿+LD-C+MOH在不同pH下的Zeta电位(MOH用量：160 mg/L；LD-C用量：20 mg/L)

Figure 8.

下载: 全尺寸图片幻灯片

图 9 辉石、辉石+LD-C、辉石+LD-C+MOH在不同pH下的Zeta电位(MOH用量：160 mg/L；LD-C用量：20 mg/L)

Figure 9.

下载: 全尺寸图片幻灯片

图 10 LD-C与钛铁矿作用的红外光谱

Figure 10.

下载: 全尺寸图片幻灯片

图 11 LD-C与辉石作用的红外光谱

Figure 11.

下载: 全尺寸图片幻灯片

参考文献(22)

[1]	李政, 陈从喜. 全球钛资源行业发展现状[J]. 地球学报, 2021(2): 245-250. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB202102016.htm LI Z, CHEN C X. Development status of global titanium resources industry [J]. Acta Geoscientica Sinica, 2021(2): 245-250. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB202102016.htm
[2]	许国栋, 王桂生. 钛金属和钛产业的发展[J]. 稀有金属, 2009(6): 903-912. doi: 10.3969/j.issn.0258-7076.2009.06.028 XU G D, WANG G S. Development of titanium and its industry [J]. Chinese Journal of Rare Metals, 2009(6): 903-912. doi: 10.3969/j.issn.0258-7076.2009.06.028
[3]	陈攀, 翟计划, 王洪彬, 等. 微细粒钛铁矿浮选捕收剂改性试验研究[J]. 稀有金属, 2018(2): 205-212. https://www.cnki.com.cn/Article/CJFDTOTAL-ZXJS201802013.htm CHEN P, ZHAI J H, WANG H B, et al. Experimental study on modification of collector for fine grained ilmenite [J]. Chinese Journal of Rare Metals, 2018(2): 205-212. https://www.cnki.com.cn/Article/CJFDTOTAL-ZXJS201802013.htm
[4]	刘伟军. 红格矿区钛铁矿与含硅脉石矿物浮选分离机理与工艺研究[D]. 绵阳: 西南科技大学, 2016. LIU W J. Flotation separation mechanism and technology of ilmenite and silicon gangue minerals of hongge [D]. Mianyang: Southwest University of Science and Technology, 2016.
[5]	刘向春, 高峰, 邓军平, 等. ABO₃型钛铁矿结构化合物的容差因子[J]. 无机材料学报, 2008(5): 881-885. doi: 10.3321/j.issn:1000-324X.2008.05.004 LIU X C, GAO F, DENG J P, et al. Tolerance factor of ABO₃-type ilmenite compound [J]. Journal of Inorganic Materials, 2008(5): 881-885. doi: 10.3321/j.issn:1000-324X.2008.05.004
[6]	赵文迪, 章晓林, 景满, 等. 钛铁矿选别工艺进展[J]. 有色金属(选矿部分), 2020(2): 50-56. doi: 10.3969/j.issn.1671-9492.2020.02.009 ZHAO W D, ZHANG X L, JING M, et al. Progress of ilmenite separation process [J]. Nonferrous Metals(Mineral Processing Section), 2020(2): 50-56. doi: 10.3969/j.issn.1671-9492.2020.02.009
[7]	YUAN Z T, DU Y S, MENG Q Y, et al. Adsorption differences of carboxymethyl cellulose depressant on ilmenite and titanaugite[J]. Minerals Engineering, 2021(166): 106887.
[8]	GUILLOT L M, MARTINEZ A F, AGUDO E R, et al. Carbonation of calcium-magnesium pyroxenes: physical-chemical controls and effects of reaction-driven fracturing[J]. Geochimica et Cosmochimica Acta, 2021(304): 258-280.
[9]	陈列锰, 宋谢炎, 聂晓勇, 等. 甘肃金川Ⅱ号岩体辉石化学特征及其地质意义[J]. 矿物岩石, 2008(1): 88-96. doi: 10.3969/j.issn.1001-6872.2008.01.013 CHEN L M, SONG X Y, NIE X Y, et al. Mineral chemistry and geological significance of pyroxene in section Ⅱ of Jinchuan pluton, Gansu Province [J]. Journal of Mineralogy and Petrology, 2008(1): 88-96. doi: 10.3969/j.issn.1001-6872.2008.01.013
[10]	马龙秋, 杜雨生, 孟庆有, 等. 钛铁矿浮选药剂及其作用机理研究进展[J]. 金属矿山, 2018(3): 7-12. https://www.cnki.com.cn/Article/CJFDTOTAL-JSKS201803002.htm MA L C, DU Y S, MENG Q Y, et al. Research progress on flotation reagents of ilmenite and their interaction mechanisms [J]. Metal Mine, 2018(3): 7-12. https://www.cnki.com.cn/Article/CJFDTOTAL-JSKS201803002.htm
[11]	邓传宏, 马军二, 张国范, 等. 水玻璃在钛铁矿浮选中的作用[J]. 中国有色金属学报, 2010(3): 551-556. https://www.cnki.com.cn/Article/CJFDTOTAL-ZYXZ201003028.htm DENG C H, MA J E, ZHANG G F, et al. Effect of water glass on floatation of ilmenite [J]. The Chinese Journal of Nonferrous Metals, 2010(3): 551-556. https://www.cnki.com.cn/Article/CJFDTOTAL-ZYXZ201003028.htm
[12]	LIU X, HUANG G Y, LI C X, et al. Depressive effect of oxalic acid on titanaugite during ilmenite flotation [J]. Minerals Engineering, 2015(79): 62-67.
[13]	朱建光, 陈树民, 姚晓海, 等. 用新型捕收剂MOH浮选微细粒钛铁矿[J]. 有色金属(选矿部分), 2007(6): 42-45. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXK200706011.htm ZHU J G, CHEN S M, YAO X H, et al. Flotation of micro-fine ilmenite using new type collector-MOH [J]. Nonferrous Metals(Mineral Processing Section), 2007(6): 42-45. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXK200706011.htm
[14]	朱阳戈. 微细粒钛铁矿浮选理论与技术研究[D]. 长沙: 中南大学, 2012. ZHU Y G. Research on theory and technology of micro-fine ilmenite flotation [D]. Changsha: Central South University, 2012.
[15]	徐翔, 章晓林, 许炳梁, 等. 钛铁矿浮选中的抑制剂研究[J]. 矿冶, 2010(4): 21-23. https://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201004007.htm XU X, ZHANG X L, XU B L, et al. Reserch on depressants in ilmenite flotation. [J]. Mining and Metallurgy, 2010(4): 21-23. https://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201004007.htm
[16]	申帅平. 微细粒级钛铁矿分选特性研究[D]. 沈阳: 东北大学, 2014. SHEN S P. Research on separation characteristics of micro-fine ilmenite [D]. Shenyang: Northeastern University, 2014.
[17]	YANG Y H, XU L H, TIAN J, et al. Selective flotation of ilmenite from olivine using the acidified water glass as depressant [J]. International Journal of Mineral Processing, 2016(157): 73-79.
[18]	魏志聪, 徐翔, 方建军, 等. 钛铁矿和钛辉石对羧甲基纤维素的吸附机理研究[J]. 矿冶, 2011(1): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201101001.htm WEI Z C, XU X, FANG J J, et al. Study on the adsorption mechanism of carboxymethyl cellulose on ilmenite and titanaugite [J]. Mining and Metallurgy, 2011(1): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201101001.htm
[19]	张其东. 辉钼矿与滑石可浮性差异调控基础研究[D]. 沈阳: 东北大学, 2016. ZHANG Q D. Fundamental study on regulation and control floatability difference of molybdenite and talc [D]. Shenyang: Northeastern University, 2016.
[20]	潘高产, 卢毅屏. CMC和古尔胶对滑石浮选的抑制作用研究[J]. 有色金属(选矿部分), 2013(2): 74-78. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXK201302020.htm PAN G C, LU Y P. Study on the inhibition effect of CMC and guar gum in the talc flotation [J]. Nonferrous Metals(Mineral Processing Section), 2013(2): 74-78. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXK201302020.htm
[21]	DU Y S, MENG Q Y, YUAN Z T, et al. Study on the flotation behavior and mechanism of ilmenite and titanaugite with sodium oleate [J]. Minerals Engineering, 2020, 152: 106366.
[22]	ZHU Y G, ZHANG G F, FENG Q M, et al. Effect of surface dissolution on flotation separation of fine ilmenite from titanaugite [J]. Transactions of Nonferrous Metals Society of China, 2011, 21(5): 1149-1154.
