Study on Flotation - Centrifugal Gravity Separation Technology for Micro-fine Cassiterite Slime with High Sulfur and Mud From Bali Plant In Guangxi Province
-
摘要:
针对广西高峰矿业有限责任公司巴里选矿厂细泥系统高硫高泥微细粒锡石矿泥难分离、富集比低的特点,进行了微细粒锡石矿泥选矿工艺研究。通过流程方案分析,确定了采用浮选脱硫脱泥—浮选锡—离心重选的原则工艺流程。采用NY捕收剂(混合改性羟肟酸,黄药与少量起泡剂复配)进行脱硫脱泥浮选,ZY捕收剂(混合羟肟酸与脂肪酸类复配)浮选锡,Slon-160离心机进行精选,在最佳浮选药剂制度及技术参数条件下,最终获得锡精矿锡品位26.72%、回收率70.77%的试验指标,实现了高硫高泥微细粒锡石的高效回收,突破了巴里选矿厂细泥系统传统重选工艺回收率低、富集比低的技术瓶颈。
Abstract:It is difficult to separate and enrichment for micro-fine cassiterite slime with high sulfur and mud in the fine mud system of Bali plant, Guangxi Gaofeng Mining Co., Ltd. An experimental study of recovering tin was carried out. The principle of flotation desulphurization and desliming ─ tin flotation ─ centrifugal gravity separation was determined through the analysis of the flowsheet. Under the condition of the optimal reagent system and technical parameters, the ideal test indicators were obtained with tin grade 26.72% in the tin concentrates and the recovery rate 70.77% of tin in fine mud system. The highly effective recycling technology for micro-fine cassiterite with high sulfur and mud has been industrialized. It breaks through the technical bottleneck of low recovery and enrichment ratio in traditional gravity separation process of fine mud system in Bali plant.
-
Key words:
- cassiterite /
- desulphurization /
- desliming /
- flotation /
- centrifugal separation
-
-
表 1 试样多元素分析结果
Table 1. The multielement analysis of sample
/% 元素 Sn S Zn Pb Sb Fe As CaO MgO SiO2 含量 1.01 8.96 1.01 0.47 0.43 11.03 0.16 32.85 1.96 6.28 表 2 试样锡物相分析结果
Table 2. The tin phase analysis of the sample
/% 相别 氧化相 硫化相 其他相 合计 含量 0.902 0.069 0.039 1.010 分布率 89.31 6.83 3.86 100.00 表 3 试样矿物组成分析结果
Table 3. The mineral analysis of the sample
/% 矿物名称 锡石 黝锡矿 铁闪锌矿 脆硫锑铅矿 磁黄铁矿 含量 1.2 0.06 3.9 1.2 7.2 矿物名称 黄铁矿 毒砂 绢云母 石英、长石 方解石 含量 8.0 0.4 12 37~38 25 表 4 试样粒度分析结果
Table 4. The particle size analysis of the sample
粒级/mm 产率/% Sn品位/% Sn分布率/% 个别 累计 +0.074 14.56 0.08 1.12 1.12 -0.074+0.053 5.11 2.63 12.90 14.02 -0.053+0.041 8.22 1.98 15.62 29.64 -0.041+0.030 18.53 1.13 20.09 49.73 -0.030+0.019 10.62 1.22 12.43 62.16 -0.019+0.010 9.03 1.55 13.43 75.59 -0.010 33.93 0.75 24.41 100.00 合计 100.00 1.04 100.00 — 表 5 脱泥脱硫流程对比试验结果
Table 5. Comparison test of desulfurization and desliming process
/% 流程方案 产品名称 产率 S品位 Sn品位 S回收率 Sn回收率 水力旋流器脱泥+浮选脱硫 矿泥 38.46 9.89 1.18 42.50 43.59 硫产品 12.41 32.34 0.18 44.84 2.14 尾矿 49.13 2.31 1.15 12.66 54.27 合计 100.00 8.95 0.90 100.00 100.00 离心机脱泥+浮选脱硫 矿泥 29.84 10.89 0.96 35.91 28.57 硫产品 13.56 32.34 0.19 48.46 2.57 尾矿 56.60 2.50 1.22 15.64 68.86 合计 100.00 9.05 0.98 100.00 100.00 浮选脱硫脱泥 硫产品 33.18 24.80 0.66 89.14 21.04 尾矿 66.82 1.5 1.23 10.86 78.96 合计 100.00 9.23 1.04 100.00 100.00 表 6 NY-5用量试验结果
Table 6. Test results of NY-5 dosages
药剂及其用量/(g·t-1) 产品名称 产率/% S品位/% Sn品位/% S作业回收率/% Sn作业回收率/% NY-5 60+20+20 硫产品 30.78 25.29 0.75 86.20 22.04 尾矿 69.22 1.80 1.18 13.80 77.96 给矿 100.00 9.03 1.05 100.00 100.00 NY-5 80+20+20 硫产品 32.56 24.26 0.66 88.65 20.31 尾矿 67.44 1.5 1.25 11.35 79.69 给矿 100.00 8.91 1.06 100.00 100.00 NY-5 100+20+20 硫产品 36.85 21.59 0.85 89.49 30.88 尾矿 63.15 1.48 1.11 10.51 69.12 给矿 100.00 8.89 1.01 100.00 100.00 NY-5 80+20+20丁黄药80+20+20 硫产品 53.05 16.00 0.89 94.51 46.01 尾矿 46.95 1.05 1.18 5.49 53.99 给矿 100.00 8.98 1.03 100.00 100.00 表 7 捕收剂种类试验结果
Table 7. Test results of collector type
/% 捕收剂种类及其用量 产品名称 产率 Sn品位 Sn作业回收率 水杨羟肟酸 锡粗精矿 21.60 4.26 75.54 粗选1 500 g/t 尾矿 78.40 0.38 24.46 扫选300 g/t 合计 100.00 1.24 100.00 华联锌铟捕收剂 锡粗精矿 40.17 2.75 90.67 粗选500 g/t 尾矿 59.83 0.19 9.33 扫选200 g/t 合计 100.00 1.22 100.00 改性羟肟酸 锡粗精矿 14.42 5.23 61.14 粗选1 500 g/t 尾矿 85.58 0.56 38.86 扫选300 g/t 合计 100.00 1.23 100.00 ZY 锡粗精矿 20.96 5.45 90.03 粗选1 500 g/t 尾矿 79.04 0.16 9.97 扫选300 g/t 合计 100.00 1.27 100.00 表 8 闭路试验结果
Table 8. Result of closed-circuit flotation
/% 产品名称 产率 Sn品位 Sn作业回收率 硫产品 17.56 0.72 12.05 锡粗精矿 13.37 6.13 78.08 尾矿 69.07 0.15 9.87 给矿 100.00 1.05 100.00 表 9 锡粗精矿精选结果
Table 9. Cleaning result of tin roughconcentrate
/% 产品名称 产率 Sn品位 Sn作业回收率 Sn对给矿回收率 锡精矿 20.53 26.98 90.64 70.77 尾矿 79.47 0.72 9.36 7.31 合计 100.00 6.11 100.00 78.08 -
[1] 杨久流, 罗家坷, 王淀佐. 微细粒矿物的分选技术[J]. 国外金属矿选矿, 1995(5): 12-14. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK199505001.htm
YANG J L, LUO J K, WANG D Z. Benefication technology of microofine dessemineted minerals[J]. Metallic Ore Dressing Abroad, 1995(5): 12-14. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK199505001.htm
[2] 孙得成, 茹恩英, 朱咏兰, 等. 国外锡选矿概论[M]. 昆明: 冶金工业部昆明有色冶金设计研究院, 1981.
SUN D CH, RU E Y, ZHU Y L. Introduction to tin beneficiation abroad[M]. Kunming, Kunming nonferrous metallurgical design and research institute, 1981.
[3] 恒川昌美. 湿式重选技术的研究进展[J]. 国外金属矿选矿, 2006(5): 4-10. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK200605000.htm
HENG C C M. Research progress of wet gravity separation technology[J]. Metallic Ore Dressing Abroad, 2006(5): 4-10. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK200605000.htm
[4] 孙玉波. 用重选设备处理细粒和微细粒矿石的进展[J]. 矿山技术, 1988(3): 21-26.
SUN Y B. Progress in treatment of fine and micro-fine ores with gravity separation equipment[J]. Mining Technique, 1988(3): 21-26.
[5] 刘祚时, 胡川, 段骏. Falcon离心选矿机的分选特征和应用现状的研究[J]. 矿山机械, 2015(2): 81-86. https://www.cnki.com.cn/Article/CJFDTOTAL-KSJX201502023.htm
LIU Z S, HU C, DUAN J. Study on separation characteristics and application status of Falcon centrifugal concentrator[J]. Mining Machinery, 2015(2): 81-86. https://www.cnki.com.cn/Article/CJFDTOTAL-KSJX201502023.htm
[6] 王青芬, 张凤生. 射流离心选矿机工业试验研究[J]. 有色金属(选矿部分), 2010(2): 35-37. doi: 10.3969/j.issn.1671-9492.2010.02.009
WANG Q F, ZHANG F S. Study on industrial test of Jet centrifugal concentrator[J]. Non-ferrous metal (mineral processing section), 2010(2): 35-37. doi: 10.3969/j.issn.1671-9492.2010.02.009
[7] 吕晋芳, 童雄, 周永诚. 微细粒锡石浮选药剂研究概况[J]. 湿法冶金, 2010(2): 71-74. https://www.cnki.com.cn/Article/CJFDTOTAL-SFYJ201002001.htm
LYU J F, TONG X, ZHOU Y CH. Survey of research on flotation reagents for fine cassiterite[J]. Hydrometallurgy, 2010(2): 71-74. https://www.cnki.com.cn/Article/CJFDTOTAL-SFYJ201002001.htm
-
