基于天然辉钼矿制备的少层MoS<sub>2</sub>纳米片及其超电容性能研究

陈浩然; 齐慧强; 陈一人; 夏开胜; 李珍

doi:10.13779/j.cnki.issn1001-0076.2022.04.003

基于天然辉钼矿制备的少层MoS₂纳米片及其超电容性能研究

中国地质大学(武汉) 材料与化学学院, 湖北武汉 430074

基金项目:
国家自然科学基金面上项目（21975228）

详细信息

作者简介: 陈浩然(1998—)，男，湖南岳阳人，硕士研究生，主要从事储能材料研究。E-mail: 2910675253@qq.com; 夏开胜(1980—)，男，湖北浠水人，中国地质大学(武汉)教授、博士生导师，入选湖北省人才计划、地大学者“青年拔尖人才”计划。2005年毕业于中国地质大学(武汉)，获材料学硕士学位，2008年毕业于中国科学院上海硅酸盐研究所，获材料物理与化学博士学位，先后在华南理工大学、加拿大蒙克顿大学从事博士后研究。长期从事碳基储能材料、矿物材料的设计与应用研究，主持了国家自然科学基金面上项目、浙江省自然科学基金—青山湖联合基金项目、湖北省自然科学基金面上项目等10项，参与国家自然科学基金重点项目1项，发表SCI论文40余篇(ESI高被引论文2篇)，授权国家发明专利5件。担任湖北省线上线下混合式一流本科课程《材料物理》负责人，曾获湖北省技术发明二等奖、第五届朱训青年教师教育奖励基金

通讯作者: 夏开胜(1980—)，男，湖北浠水人，博士，教授，主要从事能源及矿物材料研究。E-mail: kaishengxia@cug.edu.cn

中图分类号: TD985;TB34;TM53

收稿日期: 2022-06-20

刊出日期: 2022-08-25

Preparation of Few-layer MoS₂ Nanosheets Based on Natural Molybdenite and Its Supercapacitor Properties

Faculty of Materials Science and Chemistry, China University of Geosciences, Wuhan 430074, China

More Information

Corresponding author: XIA Kaisheng, kaishengxia@cug.edu.cn

Received Date: 20 June 2022

Publish Date: 25 August 2022

摘要

摘要:
以天然辉钼矿为原料，采用Na⁺离子辅助液相剥离法制备了一种少层的MoS₂纳米片（F-MoS₂）。分析结果表明，剥离得到的F-MoS₂纳米片厚度约为1.1~1.5 nm，对应为2~3层MoS₂。电化学性能测试发现，F-MoS₂在0.25 A/g的电流密度下质量比容量可达到73.7 F/g，远高于未剥离的辉钼矿（9.2 F/g）和商品MoS₂（19.6 F/g），F-MoS₂显著提升的电容量主要归因于其充分暴露的活性表面。本研究证实了通过Na⁺离子辅助液相剥离法制备的F-MoS₂是一类非常有应用前景的储能材料。
- 天然辉钼矿 /
- 二硫化钼 /
- 超级电容器 /
- 液相剥离
Abstract:
A few-layer of MoS₂ nanosheets (F-MoS₂) was prepared from natural molybdenite by Na⁺ ion-assisted liquid phase peeling method. The results showed that the thickness of F-MoS₂ nanosheets obtained by peeling was about 1.1-1.5 nm, the number of layers corresponding to MoS₂ was 2-3 layers. It was confirmed by electrochemical performance tests that the specific capacitance of F-MoS₂ was 73.7 F/g at a current density of 0.25 A/g, which was much higher than that of unstripped molybdenite (9.2 F/g) and commercial MoS₂ (19.6 F/g), the significantly increased capacitance of F-MoS₂ was mainly attributed to its fully exposed active surface. This research confirms that F-MoS₂ obtained through Na⁺ ion-assisted liquid phase peeling method was a very promising class of energy storage materials.
- natural molybdenite /
- molybdenum disulfide /
- supercapacitors /
- liquid phase peeling

HTML全文

图 1 MoS₂的结构^[10](a)及三种晶体构型(b)

Figure 1.

下载: 全尺寸图片幻灯片

图 2 辉钼矿制备F-MoS₂分散液流程示意图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 原始辉钼矿的SEM照片

Figure 3.

下载: 全尺寸图片幻灯片

图 4 高纯辉钼矿精粉XRD谱图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 F-MoS₂及原始辉钼矿的XRD对比图

Figure 5.

下载: 全尺寸图片幻灯片

图 6 F-MoS₂的SEM照片(a, b)及TEM照片(c, d)

Figure 6.

下载: 全尺寸图片幻灯片

图 7 F-MoS₂在洗涤前(a)后(b)的AFM照片

Figure 7.

下载: 全尺寸图片幻灯片

图 8 天然辉钼矿、F-MoS₂和商品MoS₂电极材料的CV曲线：5 mV/s(a)，50 mV/s(b)

Figure 8.

下载: 全尺寸图片幻灯片

图 9 (a) F-MoS₂在不同电流密度下的充放电曲线；(b) 天然辉钼矿、F-MoS₂及商品MoS₂电极在0.25 A/g下的充放电曲线；(c) 各样品的倍率性能曲线；(d) 各样品的EIS曲线

Figure 9.

下载: 全尺寸图片幻灯片

表 1 高纯辉钼矿精粉化学成分分析 /%

Table 1. Chemical composition analysis of high purity molybdenite delicate powder

成分	Mo	S	SiO₂	Fe₂O₃	MgO	CuO	Al₂O₃	Zn
含量	50.20	28.48	8.12	4.07	2.69	1.21	1.02	0.41

成分	K	Pb	Bi	Ti	Ni	As	Mn	W
含量	0.41	0.29	0.16	0.10	0.09	0.08	0.07	0.04

下载: 导出CSV

参考文献(29)

[1]	国际钼协会发布: 2021年全球钼产量和消费量[J]. 中国钼业, 2022, 46(2): 24. International molybdenum association: Global molybdenum production and consumption in 2021[J]. China molybdenum industry, 2022, 46(2): 24.
[2]	黄凡, 王登红, 陈毓川, 等. 中国内生钼矿床辉钼矿的微量元素特征研究[J]. 矿床地质, 2014, 33(6): 1193-1212. doi: 10.3969/j.issn.0258-7106.2014.06.004 HUANG F, WANG D H, CHEN Y C, et al. Characteristics of trace elements of molybdenite from endogenous molybdenum deposits in China[J]. Mineral deposits, 2014, 33(6): 1193-1212. doi: 10.3969/j.issn.0258-7106.2014.06.004
[3]	高源, 于新刚. 辉钼矿深加工技术及产业分析[J]. 中国资源综合利用, 2014, 32(11): 41-43. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWZS201411018.htm GAO Y, YU X G. Molybdenite deep processing technology and industry analysis[J]. Comprehensive utilization of resources in China, 2014, 32(11): 41-43. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWZS201411018.htm
[4]	徐双, 余春荣. 辉钼精矿提取冶金技术研究进展[J]. 中国钼业, 2019, 43(3): 17-23. doi: 10.13384/j.cnki.cmi.1006-2602.2019.03.004 XU S, YU C R. Research progress in extraction and metallurgy of molybdenite concentrate[J]. China molybdenum industry, 2019, 43(3): 17-23. doi: 10.13384/j.cnki.cmi.1006-2602.2019.03.004
[5]	闻振乾. 辉钼矿电氧化分解过程的研究[D]. 长沙: 中南大学, 2009. WEN Z G. Study on electrooxidation and decomposition process of molybdenite[D]. Changsha: Central South University, 2009.
[6]	张文钲. 纳米级二硫化钼的研发现状[J]. 中国钼业, 2000(5): 25-28. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY200005009.htm ZHANG W Z. Development status of nano-scale molybdenum disulfide[J]. China molybdenum industry, 2000(5): 25-28. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY200005009.htm
[7]	刘旭恒, 陈星宇, 赵中伟, 等. 辉钼矿的造锍熔炼与吹炼[J]. 中国有色金属学报, 2014, 24(6): 1616-1622. doi: 10.19476/j.ysxb.1004.0609.2014.06.028 LIU X H, CHEN X Y, ZHAO Z W, et al. Matte smelting and blowing of molybdenite[J]. The Chinese journal of nonferrous metals, 2014, 24(6): 1616-1622. doi: 10.19476/j.ysxb.1004.0609.2014.06.028
[8]	杨久流. 制备优质辉钼矿精矿的提纯技术[J]. 国外金属矿选矿, 2000(8): 22-24+27. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK200008003.htm YANG J L. Purification technology for preparation of high quality molybdenite concentrate[J]. Metal ore dressing abroad, 2000(8): 22-24+27. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXK200008003.htm
[9]	FEDUSCHAK T, AKIMOV A, MOROZOV M, et al. Synthesis and characterization of mechanically activated bulky molybdenum sulphide catalysts[J]. Comptes Rendus Chimie, 2016, 19(10): 1315-1325.
[10]	RADISAVLJEVIC B, RADENOVIC A, BRIVIO J, et al. Single-layer MoS₂ transistors[J]. Nature Nanotechnology, 2011, 6(3): 147-150.
[11]	THEERTHAGIRI J, SENTHIL R A, SENTHILKUMAR B, et al. Recent advances in MoS₂ nanostructured materials for energy and environmental applications-A review[J]. Journal of Solid State Chemistry, 2017, 252: 43-71.
[12]	WANG T, CHEN S, PANG H, et al. MoS₂-based nanocomposites for electrochemical energy storage[J]. Advanced Science, 2017, 4(2): 1600289.
[13]	XIA D, GONG F, PEI X, et al. Molybdenum and tungsten disulfides-based nanocomposite films for energy storage and conversion: A review[J]. Chemical Engineering Journal, 2018, 348: 908-928.
[14]	ZHANG G, LIU H, QU J, et al. Two-dimensional layered MoS₂: rational design, properties and electrochemical applications[J]. Energy & Environmental Science, 2016, 9(4): 1190-1209.
[15]	王国栋, 蒋丽娟, 李来平, 等. 二硫化钼润滑剂应用研究进展[J]. 中国钼业, 2013, 37(5): 10-14. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY201305005.htm WANG G D, JIANG L J, LI L P, et al. Progress in application of molybdenum disulfide lubricant[J]. China molybdenum industry, 2013, 37(5): 10-14. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY201305005.htm
[16]	张文钲. 发掘中的二硫化钼新用途[J]. 中国钼业, 1997(Z1): 126-128. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY7Z1.031.htm WHANG W Z. New uses of molybdenum disulfide in excavation[J]. China molybdenum industry, 1997(Z1): 126-128. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY7Z1.031.htm
[17]	张文钲. 二硫化钼润滑剂研究进展[J]. 中国钼业, 2006(5): 3-7. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY200605002.htm ZHANG W Z. Research progress of molybdenum disulfide Lubricant[J]. China molybdenum industry, 2006(5): 3-7. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGMY200605002.htm
[18]	MAK K F, MCGill K L, PARK J, et al. The valley Hall effect in MoS₂ transistors[J]. Science, 2014, 344(6191): 1489-1492.
[19]	LOPEZ-SANCHEZ O, LEMBKE D, KAYCI M, et al. Ultrasensitive photodetectors based on monolayer MoS₂[J]. Nature Nanotechnology, 2013, 8(7): 497-501.
[20]	LEE J, MAK K F, SHAN J. Electrical control of the valley Hall effect in bilayer MoS₂ transistors[J]. Nature Nanotechnology, 2016, 11(5): 421-425.
[21]	YAN Y, XIA B Y, XU Z C, et al. Recent development of molybdenum sulfides as advanced electrocatalysts for hydrogen evolution reaction[J]. ACS Catalysis, 2014, 4(6): 1693-1705.
[22]	WANG T, CHEN S, PANG H, et al. MoS₂-based nanocomposites for electrochemical energy storage[J]. Advanced Science, 2017, 4(2): 1600289. http://www.ncbi.nlm.nih.gov/pmc/articles/PMC5323880/pdf/ADVS-4-na.pdf
[23]	XIA D, GONG F, PEI X, et al. Molybdenum and tungsten disulfides-based nanocomposite films for energy storage and conversion: a review[J]. Chemical Engineering Journal, 2018, 348: 908-928.
[24]	ZHANG G, LIU H, QU J, et al. Two-dimensional layered MoS₂: rational design, properties and electrochemical applications[J]. Energy & Environmental Science, 2016, 9(4): 1190-1209.
[25]	BELLO I T, OLADIPO O, ADEDOKUN O, et al. Recent advances on the preparation and electrochemical analysis of MoS₂-based materials for supercapacitor applications: a mini-review[J]. Materials Today Communications, 2020, 25: 101664.
[26]	GENG X, ZHANG Y, HAN Y, et al. Two-dimensional water-coupled metallic MoS₂ with nanochannels for ultrafast supercapacitors[J]. Nano Letters, 2017, 17(3): 1825-1832.
[27]	WANG D, XIAO Y, LUO X, et al. Swollen ammoniated MoS₂ with 1T/2H hybrid phases for high-rate electrochemical energy storage[J]. ACS Sustainable Chemistry & Engineering, 2017, 5(3): 2509-2515.
[28]	LI J, GAO D, WANG J, et al. Ball-milling MoS₂/carbon black hybrid material for catalyzing hydrogen evolution reaction in acidic medium[J]. Journal of Energy Chemistry, 2015, 24(5): 608-613.
[29]	BANG G S, NAM K W, KIM J Y, et al. Effective liquid-phase exfoliation and sodium ion battery application of MoS₂ nanosheets[J]. ACS Appl Mater Interfaces, 2014, 6(10): 7084-7089.
