CaCO<sub>3</sub>/硅灰石复合材料制备及其疏水性能研究

张俊; 王余莲; 谭瑞林; 王琪浩; 朱益斌; 刘珈伊; 时天骄; 林永瑾; 田伊笛; 苏德生; 袁志刚

doi:10.13779/j.cnki.issn1001-0076.2022.04.011

CaCO₃/硅灰石复合材料制备及其疏水性能研究

1.
沈阳理工大学, 材料科学与工程学院, 辽宁沈阳 110159

2.
辽宁省超高功率石墨电极材料专业技术创新中心, 辽宁丹东 118000

基金项目:
国家自然科学基金（51804200）：沈阳理工大学创新创业训练计划项目（202110144113）

详细信息

作者简介: 张俊(1997—), 男, 硕士研究生, 主要研究方向为矿物粉体表面改性研究, E-mail: zjw974977729@163.com

通讯作者: 王余莲(1986—)，女，博士，沈阳理工大学四级教授，硕士生导师，辽宁省“百千万人才工程”千人层次，省一流本科专业负责人，辽宁省颗粒学会理事；主要从事矿物材料制备与应用基础研究；主持国家级、省部级项目5项，千万元、百万元级别企业合作项目3项；发表学术论文40余篇；获国家授权发明专利4项，出版著作3部；获省级教学成果奖1项。
王余莲(1986—), 女, 博士, 副教授, 硕士生导师, 主要研究方向为矿物材料制备及其应用基础研究, E-mail: ylwang0908@163.com

中图分类号: TD985;TB332

收稿日期: 2022-07-19

刊出日期: 2022-08-25

Preparation and Hydrophobic Properties of CaCO₃/Wollastonite Composites

1.
School of Materials Science and Engineering, Shenyang Ligong University, Shenyang 110159, China

2.
Liaoning Province Ultra-high Power Graphite Electrode Material Professional Technology Innovation Center, Shenyang 110004, China

More Information

Corresponding author: WANG Yulian, ylwang0908@163.com

Received Date: 19 July 2022

Publish Date: 25 August 2022

摘要

摘要:
以天然硅灰石为原料，采用一步碳化法制得CaCO₃/硅灰石（W@C）复合材料，并对其表面进行有机改性。采用BET、XRD、SEM、FT-IR和TG-DSC等表征复合材料的比表面积以及改性前后产物的物相组成、形貌、基团和热稳定性。结果表明：当CaO添加量为25%、碳化温度为15℃、CO₂流速为0.08 m³/h、聚乙二醇用量为4.37 g/L时，可制得比表面积为15.28 m²/g的W@C复合材料，其比表面积比天然硅灰石提高了500%。W@C复合材料未改性时，接触角为19.37°，活化指数为0；采用1.5%硬脂酸钠改性W@C复合材料，接触角和活化指数分别增大至118.02°，99.9%，疏水性能显著提高。硬脂酸钠通过物理吸附包覆在W@C复合材料表面。
- 硅灰石 /
- CaCO₃/硅灰石复合材料 /
- 一步碳化法 /
- 有机改性
Abstract:
CaCO₃/wollastonite (W@C) composites were prepared from natural wollastonite through one-step carbonization method, and the surface was organically modified. BET、XRD、SEM、FT-IR and TG-DSC were used to characterize the specific surface area of the composites and the phase composition morphology, group and thermal stability of the products before and after modification. The results showed that the W@C composites with a specific surface area of 15.28 m²/g was obtained when the amount of CaO added was 25%, the carbonization temperature was 15℃, the CO₂ flow rate was 0.08 m³/h, and the amount of polyethylene glycol (PEG) content was 4.37 g/L. The specific surface area of the obtained product was 500% higher than that of natural wollastonite. When the W@C composite was not modified, the contact angle was 19.37° and the activation index was 0. When the W@C composite was modified with 1.5% sodium stearate, the contact angle and activation index increased to 118.02° and 99.9%, respectively, and the hydrophobicity was significantly improved. Sodium stearate was coated on the surface of the W@C composites by physical adsorption.
- wollastonite /
- CaCO₃/wollastonite composites /
- one-step carbonization /
- organically modified

HTML全文

图 1 CaO用量对CaCO₃/硅灰石复合材料比表面积影响的曲线

Figure 1.

下载: 全尺寸图片幻灯片

图 2 天然硅灰石与CaCO₃/硅灰石复合材料的XRD图谱

Figure 2.

下载: 全尺寸图片幻灯片

图 3 碳化温度对CaCO₃/硅灰石复合材料比表面积影响的曲线

Figure 3.

下载: 全尺寸图片幻灯片

图 4 CO₂流速对CaCO₃/硅灰石复合材料比表面积影响的曲线

Figure 4.

下载: 全尺寸图片幻灯片

图 5 PEG对CaCO₃/硅灰石复合材料比表面积影响的曲线

Figure 5.

下载: 全尺寸图片幻灯片

图 6 CaCO₃/硅灰石复合材料包覆前后的SEM图

Figure 6.

下载: 全尺寸图片幻灯片

图 7 CaCO₃/硅灰石复合材料面扫描区域及元素分布

Figure 7.

下载: 全尺寸图片幻灯片

图 8 CaCO₃/硅灰石复合材料的SEM-EDS图

Figure 8.

下载: 全尺寸图片幻灯片

图 9 改性前CaCO₃/硅灰石复合材料的接触角

Figure 9.

下载: 全尺寸图片幻灯片

图 10 硬脂酸钠用量对改性后CaCO₃/硅灰石复合材料接触角及活化指数的影响曲线

Figure 10.

下载: 全尺寸图片幻灯片

图 11 改性前后CaCO₃/硅灰石复合材料的XRD谱

Figure 11.

下载: 全尺寸图片幻灯片

图 12 改性前后CaCO₃/硅灰石复合材料的红外光谱

Figure 12.

下载: 全尺寸图片幻灯片

图 13 改性前后CaCO₃/硅灰石复合材料的TG-DSC曲线

Figure 13.

下载: 全尺寸图片幻灯片

图 14 硬脂酸钠改性CaCO₃/硅灰石复合材料前后的SEM图像

Figure 14.

下载: 全尺寸图片幻灯片

表 1 CaCO₃/硅灰石复合材料点扫描区域的元素含量

Table 1. Elemental contents in point scanning region of CaCO₃/wollastonite composites

Element Quality score/% Atomic ratio/%

C 17.47 26.40

O 52.37 59.42

Si 2.65 1.71

Ca 27.51 12.46

下载: 导出CSV

表 2 改性剂种类对改性后CaCO₃/硅灰石复合材料接触角及活化指数的影响

Table 2. Effects of modifier types on contact angle and activation index of modified CaCO₃/wollastonite composites

Types of modifiers Contact angle/(°) Activation index/%

-- 19.37 0

KH-550 23.28 0

KH-570 31.17 0.21

YZSX 112.76 99.70

YZSN 118.02 99.90

下载: 导出CSV

参考文献(33)

[1]	陶勇. 硅灰石表面改性研究现状与应用进展[J]. 中国非金属矿工业导刊, 2008(6): 9-12+18. doi: 10.3969/j.issn.1007-9386.2008.06.002 TAO Y. Current status of the surface modification of wollastonite and its application progress[J]. Chinese Journal of nonmetallic Minerals Industry, 2008(6): 9-12+18. doi: 10.3969/j.issn.1007-9386.2008.06.002
[2]	王泽红, 周鸭羊, 宁国栋, 等. 高长径比硅灰石制备及机理研究[J]. 矿产保护与利用, 2015(1): 49-53. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=1a1d5e65-2b6a-4578-8c67-bfc82e55c582 WANG Z H, ZHOU Y Y, NING G D. Study on the preparation of high aspect ratio wollatonite and its mechanism[J]. Conservation and utilization of mineral resources, 2015(1): 49-53. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=1a1d5e65-2b6a-4578-8c67-bfc82e55c582
[3]	苑金生. 硅灰石的开发利用及其市场动向[J]. 中国非金属矿工导刊, 2007(6): 56-57. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK200706018.htm YUAN J S. Development and utilization of wollastonite and its market trends[J]. China Non-Metallic Mineral Industry Guide, 2007(6): 56-57. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK200706018.htm
[4]	欧阳友和. 我国硅灰石矿产资源及勘查开发现状和发展建议[J]. 山东国土资源, 2020, 36(12): 26-31. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI202012004.htm OUYANG Y H. Exploration and development condition and development suggestions of wollastonite mineral resources in China[J]. Shandong Land and Resources, 2020, 36(12): 26-31. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI202012004.htm
[5]	汪先三. 硅灰石开发利用及发展趋势[J]. 中国非金属矿工业导刊, 2016(1): 13-15. doi: 10.3969/j.issn.1007-9386.2016.01.004 WANG X S. Study on exploitation and development trend of wollastonite[J]. Guide to China's non-metallic mining industry, 2016(1): 13-15. doi: 10.3969/j.issn.1007-9386.2016.01.004
[6]	李忠水. 吉林省重要非金属矿产资源地质特征及勘查新进展[J]. 中国非金属矿工业导刊, 2018(4): 31-34+60. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK201804012.htm LI Z S. Geological characteristics and new advances in prospecting of important non-metallic mineral resources in Jilin Province[J]. Guide to China's non-metallic mining industry, 2018(4): 31-34+60. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK201804012.htm
[7]	董全, 张文军. 硅灰石的特性与开发应用[J]. 辽宁工程技术大学报, 2005(S2): 33-35. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKY2005S2012.htm DONG Q, ZHANG W J. Properties and developing applications of wollastonite[J]. Journal of Liaoning Technical University, 2005(S2): 33-35. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKY2005S2012.htm
[8]	宋世坤, 彭鹤松, 李永安, 等. 硅烷改性剂对硅灰石填充ABS复合材料的性能影响[J]. 山东工业技术, 2017(21): 244-245. https://www.cnki.com.cn/Article/CJFDTOTAL-SDGJ201721221.htm SONG S K, PENG H S, Li Y A, et al. Effect of silane modifier on the properties of wollastonite filled ABS composites[J]. Shandong Industrial Technology, 2017(21): 244-245. https://www.cnki.com.cn/Article/CJFDTOTAL-SDGJ201721221.htm
[9]	王鉴, 马震, 孟庆明, 等. 硅灰石的表面改性及应用[J]. 当代化工, 2016, 45(10): 2296-2298. https://www.cnki.com.cn/Article/CJFDTOTAL-SYHH201610006.htm WANG J, MA Z, MENG Q M, et al. Research on modification and application of wollastonite[J]. Contemporary Chemical Industry, 2016, 45(10): 2296-2298. https://www.cnki.com.cn/Article/CJFDTOTAL-SYHH201610006.htm
[10]	田海山, 刘立新, 孙志明, 等. 西藏班戈湖水菱镁的矿热分解特性[J]. 硅酸盐学报, 2017, 45(2): 317-322. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB201702022.htm TIAN H S, LIU L X, SUN Z M, et al. Thermal decomposition characteristics of hydromagnesite from Bangor Lake in Tibet[J]. J. Chin. Ceram. Soc, 2017, 45(2): 317-322. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB201702022.htm
[11]	毋伟, 陈建峰, 屈一新, 等. 硅烷偶联剂的种类与结构对二氧化硅表面聚合物接枝改性的影响[J]. 硅酸盐学报, 2004(5): 570-575. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB200405007.htm WU W, CHEN J F, QU Y X, et al. Influence of the kinds and structure of silane coupling agent on polyme grafting modification of the ultrafine silicon dioxide surface[J]. J. Chin. Ceram. Soc, 2004(5): 570-575. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB200405007.htm
[12]	崔嵬, 任天宇, 陈婉婷, 等. 机械研磨制备硅灰石-SiO₂复合颗粒及其表征[J]. 非金属矿, 2016, 39(5): 14-16+48. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK201605005.htm CUI W, REN T Y, CHEN W T, et al. Preparation and characterization of wollastonite-SiO₂ composite particles by mechanical grinding method[J]. Non-metallic Minerals, 2016, 39(5): 14-16+48. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK201605005.htm
[13]	林浩, 管俊芳, 杨文, 等. 硅灰石资源及加工应用现状分析[J]. 中国非金属矿工业导刊, 2009(2): 24-26+45. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK200902008.htm LIN H, GUAN J F, YANG W, et al. Analysis of wollastonite production application[J]. China Nonmetallic Mining Industry Guide, 2009(2): 24-26+45. https://www.cnki.com.cn/Article/CJFDTOTAL-LGFK200902008.htm
[14]	李酽. 硅灰石的研究与应用进展[J]. 化工矿物与加工, 2004(4): 1-4. https://www.cnki.com.cn/Article/CJFDTOTAL-HGKJ200404000.htm LI Y. Development in utilization and research of wollastonite[J]. Industrial Minerals and Processing, 2004(4): 1-4. https://www.cnki.com.cn/Article/CJFDTOTAL-HGKJ200404000.htm
[15]	WANG C, ZHENG S, WANG H. Evaluation of mechanical properties of polyamide 6(PA6) filled with wollastonite and inorganic modified wollastonite[J]. Applied Mechanics and Materials, 2012, 217-219: 522-525.
[16]	吴静晰, 梁化强, 欧雪梅, 等. TiO₂包覆硅灰石及其填充PA1010复合材料的性能研究[J]. 合肥工业大学学报(自然科学版), 2012, 35(11): 1519-1522. https://www.cnki.com.cn/Article/CJFDTOTAL-HEFE201211018.htm WU J X, LIANG H Q, OU X M, et al. Study on the property of TiO₂ coated wollastonite and PA1010 composite filled by it[J]. Journal of Hefei University of Technology, 2012, 35(11): 1519-1522. https://www.cnki.com.cn/Article/CJFDTOTAL-HEFE201211018.htm
[17]	陈婉婷. 硅灰石表面包覆二氧化硅复合颗粒制备与表征[D]. 鞍山: 辽宁科技大学, 2015. CHEN W T. Preparation of amorphous silica/wollastonite composite particles and its representation[D]. Anshan: Liaoning University of Science and Technology, 2015.
[18]	WANG C, WANG D, YANG R, et al. Preparation and electrical properties of wollastonite coated with antimony-doped tin oxide nanoparticles[J]. Powder Technology, 2019, 342: 397-403.
[19]	侯小芳, 张永华, 丁华, 等. 机械化学法制备的环保型硅灰石@TiO₂复合颗粒[J]. 颗粒学, 2017(40): 105-112. HOU X F, ZHANG Y H, DING H, et al. Environmentally friendly wollastonite@TiO₂ composite particles prepared by a mechano-chemical method[J]. Particuology, 2017(40): 105-112.
[20]	赵宇龙, 沈上越, 苏芳, 等. 硬脂酸改性硅灰石机理的红外光谱研究[J]. 矿产保护与利用, 2003(2): 17-20. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=358af470-44c8-4db8-892d-b7678f309a18 ZHAO Y L, SHEN S Y, SU FANG, et al. The infrared spectrum study on modified mechanism by stearic acid for wollastonite[J]. Conservation and Utilization of Mineral Resources, 2003(2): 17-20. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=358af470-44c8-4db8-892d-b7678f309a18
[21]	杜高翔, 郑水林, 李杨, 等. 超细水镁石的硅烷偶联剂表面改性[J]. 硅酸盐学报, 2005(5): 659-664. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB200505024.htm DU G X, ZHENG S L, LI Y, et al. Surface modification of ultra-fine brucite powder by silane coupling agent[J]. J. Chin. Ceram. Soc, 2005(5): 659-664. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB200505024.htm
[22]	MEHIEDDINE BOUATROUS, FERHAT BOUZERARA, ARVIND K. BHAKTA, et al. A modified wet chemical synthesis of wollastonite ceramic nanopowders and their characterizations[J]. Ceramics International, 2020, 46(8): 12618-12625.
[23]	张文治, 章文贡, 汤永艳, 等. 硅灰石的偶联活化改性研究[J]. 塑料, 2005(1): 69-72+5. https://www.cnki.com.cn/Article/CJFDTOTAL-SULA200501016.htm ZHANG W Y, ZHANG W G, TANG Y Y, et al. Coupling activation modification of wollastonite powder[J]. Plastics, 2005(1): 69-72+5. https://www.cnki.com.cn/Article/CJFDTOTAL-SULA200501016.htm
[24]	付鹏, 崔喆, 于艺博, 等. 硅灰石填充改性尼龙1212复合材料的制备[J]. 高分子材料科学与工程, 2014, 30(4): 154-157. https://www.cnki.com.cn/Article/CJFDTOTAL-GFZC201404032.htm FU P, CUI Z, YU Y B, et al. Preparation of nylon 1212/wollastonite composites[J]. Polymer Materials Science and Engineering, 2014, 30(4): 154-157. https://www.cnki.com.cn/Article/CJFDTOTAL-GFZC201404032.htm
[25]	冉霞, 刘粲, 何勤军, 等. KH-570/硬脂酸复合改性硅灰石及填充聚丙烯研究[J]. 非金属矿, 2021, 44(2): 34-37. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202102010.htm RAN X, LIU C, HE Q J, et al. Study on KH-570/stearic acid composite modification wollastonite and filled polypropylene[J]. Nonmetallic minerals, 2021, 44(2): 34-37. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202102010.htm
[26]	SERGEY V, PANIN, HUANG Q T, VLADISLAV O ALEXNKO, et al. Design of wear-resistant UHMWPE-based composites loaded with wollastonite microfibers treated with Various Silane Coupling Agents[J]. Applied Sciences, 2020, 10(13).
[27]	杨勇, 王奥兰, 毋伟, 等. 硅灰石-三氧化二锑复合颗粒的制备及在PA6中的应用研究[J]. 高校化学工程学报, 2014, 28(6): 1302-1308. https://www.cnki.com.cn/Article/CJFDTOTAL-GXHX201406019.htm YANG Y, WANG A L, WU W et al. The preparation of wollastonite-antimony trioxide composite particles and its application in PA6[J]. Journal of Chemical Engineering in Colleges and Universities, 2014, 28(6): 1302-1308. https://www.cnki.com.cn/Article/CJFDTOTAL-GXHX201406019.htm
[28]	徐昊, 杨云川, 王余莲, 等. 硅灰石表面有机改性及性能表征[J]. 矿产保护与利用, 2020, 40(4): 117-123. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=dfdbec74-cbd1-48bd-a68f-7eeeb9b09586 XU H, YANG Y C, WANG YL, et al. Surface organic modification and characterization of wollastonite[J]. Conservation and Utilization of Mineral Resources, 2020, 40(4): 117-123. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=dfdbec74-cbd1-48bd-a68f-7eeeb9b09586
[29]	陈晓龙, 于福家, 丛国龙, 等. 硅灰石表面改性及其在天然橡胶中的应用[J]. 非金属矿, 2020, 43(5): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202005003.htm CHEN X L, YU F J, CONG G L, et al. Wollastonite surface modification and its application in natural rubber[J]. Nonmetallic Minerals, 2020, 43(5): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202005003.htm
[30]	郝增恒. 纳米碳酸钙包覆微米硅灰石复合材料的研究及其在聚丙烯中的应用[D]. 重庆: 重庆大学, 2004: 17-47. HAO Z H. Study of the composite particle of wollastonite coated by nano-CaCO₃ and application of it in PP[D]. Chongqing: Chongqing University, 2004: 17-47.
[31]	郝增恒, 卢健, 盖国胜, 等. 纳米碳酸钙包覆微米硅灰石复合矿物颗粒研究[J]. 非金属矿, 2003(6): 19-20. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK200306007.htm HAO Z H, LU J, GAI G S, et al. Study of the composite particle of micron wollastonite composite mineral particle coated by nano-CaCO₃[J]. Nonmetallic Minerals, 2003(6): 19-20. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK200306007.htm
[32]	单传省. 纳米SiO₂/硅灰石复合粒子的制备及其在聚丙烯(PP)中的应用研究[D]. 成都: 成都理工大学, 2012. SHAN C S. Preparation of nano-SiO₂/wollastonite composite particles and application in polypropylene (PP)[D]. Chengdu: Chengdu University of Technology, 2012.
[33]	王余莲, 印万忠, 李闯, 等. 碱式碳酸镁的表面有机改性及性能表征[J]. 硅酸盐学报, 2020, 48(1): 120-127. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB202001018.htm WANG Y L, YIN W Z, LI C, et al. Surface organic modification and characterization of hydromagnesite[J]. J. Chin. Ceram. Soc, 2020, 48(1): 120-127. https://www.cnki.com.cn/Article/CJFDTOTAL-GXYB202001018.htm
