Study on the Availability of Wet Chemical Digestion of Geo-electrochemical Polyurethane Foam Samples
-
摘要: 灰化法和微波消解法作为地电化学泡塑样品的预处理方法适用于多数元素，但二者都存在局限性，如灰化法的高温加热过程会造成As、Hg等元素的损失影响测定结果，微波消解法则因用样量小（0.1 g），存在样品代表性和检出限方面的问题。湿法消解是一种传统的样品预处理方法，具有消解完全、元素损失量低、样品代表性好等优点，可以有效解决以上两种方法的不足。但因为加入高氯酸消解泡塑（有机物）样品过程中易爆炸和酸空白等问题，一直没有在泡塑样品的预处理中得到推广。本文选取内蒙古洛恪顿热液型铅锌多金属矿床一条地电化学勘查剖面，用20 mL硝酸+5 mL高氯酸和5 mL王水对泡塑样品（约0.5 g）进行预处理，氢化物发生原子荧光光谱法和高分辨电感耦合等离子体质谱法测定元素含量。结果表明：大多数元素的空白含量都比较低，地球化学剖面图上有良好的异常显示；湿法消解处理泡塑样品是可行的，分析泡塑样品主要使用这种预处理方法。
-
关键词:
- 地电化学 /
- 泡塑样品 /
- 湿法消解 /
- 氢化物发生-原子荧光光谱法 /
- 高分辨电感耦合等离子体质谱法
Abstract: As the pretreatment methods in analyzing geo-electrochemical polyurethane foam samples, ashing and microwave digestion methods are suitable for determination of most elements. Both methods have their disadvantages. The ashing method may cause volatilization loss of some elements (e.g. Hg, As) under high temperature, whereas issues about sample representation and detection limit exist in the microwave digestion method because of the small amount of sample (0.1 g). Wet chemical digestion is a traditional pretreatment method, which is widely used in the pretreatment of various geochemical samples and has the advantages of complete digestion, low element loss and good sample representation. However, because of the problems of explosion and acid blank during digestion of polyurethane foam (organic) samples, this method has not been used in pretreatment of geo-electrochemical foam samples. For this study a geo-electrochemical exploration line in Luokedun hydrothermal lead-zinc polymetallic deposit in Inner Mongolia was selected as the research subject. 20 mL of Nitric acid, 5 mL of perchloric acid, and 5 mL of aqua regia were used to digest 0.5 g foam samples. The contents of some related elements were determined by High-resolution Inductively Coupled Plasma-Mass Spectrometry (HR-ICP-MS) and Atomic Fluorescence Spectrometry (AFS). Results show that contents of the foam blank are relatively low for most elements, and the geochemical profiles show good anomalies. It is suggested that wet digestion is feasible in the analysis of geo-electrochemical polyurethane foam samples, and could be used widely in the future. -
-
表 1 样品分析重复测定监控结果
Table 1. Repeated measurement results of samples
元素 样品10 样品10重复测定
编号288001相对偏差
(%)样品25 样品25重复测定
编号288002相对偏差
(%)样品40 样品40重复测定
编号288003相对偏差
(%)Au 1.35 1.55 12.90 5.62 5.73 1.94 0.40 0.93 79.70 Ag 3.58 4.73 27.68 63.69 63.42 0.42 3.49 4.10 16.07 Al 38 40 5.13 85 88 3.47 188 215 13.40 As 64 59 8.13 80 77 3.82 134 134 0.00 Bi 5.88 5.53 6.13 7.04 6.68 5.25 18.81 19.63 4.27 Cd 12.72 13.77 7.93 4.42 4.38 0.91 23.01 26.61 14.51 Co 85 85 0.00 226 234 3.48 155 171 9.82 Cr 913 902 1.21 7496 7687 2.52 2083 2337 11.49 Cu 3358 3421 1.86 123925 126908 2.38 1688 2053 19.51 Fe 79 81 2.50 213 216 1.40 162 185 13.26 K 25.9 26.4 1.91 36.5 37.0 1.36 57.4 63.7 10.40 La 68 53 24.79 165 143 14.29 265 285 7.27 Mo 17.3 19.8 13.48 28.9 29.2 1.03 50.5 51.0 0.99 Ni 196 180 8.51 2196 2253 2.56 738 821 10.65 Pb 200 185 7.79 416 399 4.17 1612 1670 3.53 Sb 45 39 14.29 32 30 6.45 1065 1145 7.24 Se 23 25 8.33 23 24 4.26 50 43 15.05 Ti 5918 6234 5.20 7241 7532 3.94 9813 11069 12.03 U 26 25 3.92 45 43 4.55 79 82 3.73 Zn 3039 2991 1.59 6595 6680 1.28 5794 6446 10.65 注：K、Fe、Al含量的单位为μg，其余元素的单位为ng。
下载: 导出CSV
表 2 酸溶法处理内蒙古洛恪顿矿区电提取剖面样品测量数据统计结果
Table 2. Measurement data statistics of elements in samples from electric extraction profile of the Luokedun deposit in Inner Mongolia, pretreated with polyacid digestion
指标 Au Ag Al As Bi Cd Co Cr Cu Fe K La Mo Ni Pb Sb Se Ti U Zn 样品数 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 极大值 72.08 816.5 3.10 1.52 0.14 172.9 3.11 96.09 1588 3.24 0.87 4.64 0.73 69.9 12.12 8.01 0.38 222 1.72 84.54 极小值 1.44 6.39 0.28 0.27 0.04 25.25 0.60 5.17 2.67 0.42 0.19 0.52 0.14 1.44 1.59 0.20 0.18 38.1 0.11 14.63 平均值 7.51 42.17 0.85 0.65 0.06 55.92 0.99 15.06 52.6 0.90 0.34 1.57 0.26 6.22 2.98 1.15 0.25 70.3 0.44 31.87 中值 3.96 13.69 0.77 0.56 0.05 50.08 0.83 8.72 7.28 0.76 0.31 1.36 0.24 2.92 2.37 0.63 0.24 62.8 0.42 25.52 标准差 12.01 128.5 0.52 0.26 0.02 25.64 0.52 17.73 249.8 0.55 0.13 1.03 0.11 11.4 1.97 1.47 0.05 32.7 0.30 18.09 变异系数 1.60 3.05 0.61 0.40 0.34 0.46 0.52 1.18 4.75 0.61 0.38 0.66 0.42 1.83 0.66 1.28 0.19 0.47 0.68 0.57 泡塑空白 2.80 6.91 0.27 0.26 0.06 26.72 2.37 5.89 1.75 0.68 0.19 1.82 0.08 1.24 1.88 0.21 0.14 168 0.15 16.34 注：K、Fe、Al含量的单位为mg，Au、Ag、Cd含量的单位为ng，其余元素含量的单位为μg。
下载: 导出CSV
-
[1] 谢学锦, 王学求.深穿透地球化学新进展[J].地学前缘, 2003, 10(1):225-238. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200301041.htm
Xie X J, Wang X Q.Recent developments on deep-penetrating geochemistry[J].Earth Science Frontiers, 2003, 10(1):225-238. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200301041.htm
[2] Wang M Q, Wu H, Liao Y, et al.Pilot study of partial extraction geochemistry for base metal exploration in a thick loess-covered region[J].Journal of Geochemical Exploration, 2015, 148:231-240. doi: 10.1016/j.gexplo.2014.10.003
[3] Wang X Q, Zhang B M, Xin L, et al.Geochemical challenges of diverse regolith-covered terrains for mineral exploration in China[J].Ore Geology Reviews, 2016, 73:417-431. doi: 10.1016/j.oregeorev.2015.08.015
[4] Alekseev S G, Dukhanin A S, Veshev S A, et al.Some aspects of practical use of geo-electrochemical methods of exploration for deep-seated mineralization[J].Journal of Geochemical Exploration, 1996, 56(1):79-86. doi: 10.1016/0375-6742(95)00051-8
[5] 刘占元, 程志中, 孙彬彬.电提取技术中载体物质应用效果提高的途径[J].物探与化探, 2005, 29(5):401-403. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH200505005.htm
Liu Z Y, Cheng Z Z, Sun B B.The processing of the carrier material in the cathode receiver[J].Geophysical & Geochemical Exploration, 2005, 29(5):401-403. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH200505005.htm
[6] Luo X R, Hou B H, Wen M L, et al.CHIM-geo-electrochemical method in search of concealed mineralisation in China and Australia[J].Chinese Journal of Geochemistry, 2008, 27(2):198-202. doi: 10.1007/s11631-008-0198-8
[7] Hoover D B, Smith D B, Leinz R W.CHIM; an electro-geochemical partial extraction method; an historical overview[R]. U.S. Geological Survey, 1997:1-27.
[8] 孙彬彬, 刘占元, 周国华.地电化学方法技术研究现状及发展趋势[J].物探与化探, 2015, 39(1):16-21. doi: 10.11720/wtyht.2015.1.03
Sun B B, Liu Z Y, Zhou G H.Research status and development trends for geo-electrochemical methods[J].Geophysical & Geochemical Exploration, 2015, 39(1):16-21. doi: 10.11720/wtyht.2015.1.03
[9] 满荣浩, 罗先熔, 易超.地电化学法在鄂尔多斯盆地东胜地区寻找隐伏铀矿中的应用[J].矿物岩石地球化学通报, 2015, 34(5):1007-1013. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201505022.htm
Man R H, Luo X R, Yi C.Application of the geo-electrochemical method on prospecting for concealed uranium deposits in the Dongsheng area of the Ordos Basin[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2015, 34(5):1007-1013. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201505022.htm
[10] 刘攀峰, 文美兰, 张佳莉.地电化学集成技术在云南西邑铅锌矿区的找矿应用[J].物探与化探, 2016, 40(4):655-660. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201604003.htm
Liu P F, Wen M L, Zhang J L.The application of geo-electrochemical integrated technology to the prospecting in the Xiyi Pb-Zn deposit, Yunnan Province[J].Geophysical and Geochemical Exploration, 2016, 40(4):655-660. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201604003.htm
[11] 聂凤莲, 艾晓军, 逮艳军.地电化学(泡塑)样品中金的预处理[J].黄金科学技术, 2007, 15(6):52-55. http://youxian.cnki.com.cn/yxdetail.aspx?filename=YKCS2017092700M&dbname=CAPJ2015
Nie F L, Ai X J, Dai Y J.Pretreatment of Au geoelectrical chemical samples (foam)[J].Gold Science and Technology, 2007, 15(6):52-55. http://youxian.cnki.com.cn/yxdetail.aspx?filename=YKCS2017092700M&dbname=CAPJ2015
[12] 施意华, 杨仲平, 黄俭惠, 等.ICP-MS测定电吸附找矿泡塑样品中微量元素[J].光谱学与光谱分析, 2009, 29(6):1687-1690. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN200906066.htm
Shi Y H, Yang Z P, Huang J H, et al.Determination of trace elements in electrical absorption prospecting polyform sample by inductively coupled plasma mass spectrometry[J].Spectroscopy and Spectral Analysis, 2009, 29(6):1687-1690. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN200906066.htm
[13] 张勤, 白金峰, 王烨.地壳全元素配套分析方案及分析质量监控系统[J].地学前缘, 2012, 19(3):33-42. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201203004.htm
Zhang Q, Bai J F, Wang Y.Analytical scheme and quality monitoring system for China geochemical baselines[J].Earth Science Frontiers, 2012, 19(3):33-42. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201203004.htm
[14] 刘亚轩, 李晓静, 白金峰, 等.植物样品中无机元素分析的样品前处理方法和测定技术[J].岩矿测试, 2013, 32(5):681-693. http://www.ykcs.ac.cn/article/id/be7f4a99-23f3-461f-bea1-ac90d0835111
Liu Y X, Li X J, Bai J F, et al.Review on sample pretreatment methods and determination techniques for inorganic elements in plant samples[J].Rock and Mineral Analysis, 2013, 32(5):681-693. http://www.ykcs.ac.cn/article/id/be7f4a99-23f3-461f-bea1-ac90d0835111
[15] 严洪泽, 孙彬彬, 徐进力, 等.灰化法与微波消解法处理地电化学泡塑样品的分析效果对比研究[J].岩矿测试, 2016, 35(3):59-66. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.03.010
Yan H Z, Sun B B, Xu J L, et al.Comparison of ashing and microwave digestion in analyzing geo-electrochemical polyurethane foam samples[J].Rock and Mineral Analysis, 2016, 35(3):59-66. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.03.010
[16] Bednar A J, Jones W T, Chappell M A, et al.A modified acid digestion procedure for extraction of tungsten from soil[J].Talanta, 2010, 80(3):1257-1263. doi: 10.1016/j.talanta.2009.09.017
[17] 胡艳巧, 程文翠, 支云川, 等.四酸溶矿-电感耦合等离子体发射光谱法测定铬铁矿中多种元素[J].分析试验室, 2016, 35(11):1312-1316. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201611017.htm
Hu Y Q, Cheng W C, Zhi Y C, et al.Simultaneous determination of 11 elements in chromites by inductively coupled plasma-atomic emission spectrometry with HCl-HNO3-HF-HClO4 digestion method[J].Chinese Journal of Analysis Laboratory, 2016, 35(11):1312-1316. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201611017.htm
[18] 马生凤, 温宏利, 马新荣, 等.四酸溶样-电感耦合等离子体原子发射光谱法测定铁、铜、锌、铅等硫化物矿石中22个元素[J].矿物岩石地球化学通报, 2011, 30(1):65-72. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201101010.htm
Ma S F, Wen H L, Ma X R, et al.Determination of 22 elements in iron, copper, zinc, and lead sulphide ores by ICP-AES with four acids digestion[J].Bulletin of Minera-logy, Petrology and Geochemistry, 2011, 30(1):65-72. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201101010.htm
[19] 李晓辉, 王亮. 内蒙古自治区东乌珠穆沁旗洛恪顿铅锌多金属矿详查年度总结报告[R]. 赤峰: 内蒙古赤峰地质矿产勘查开发院, 2013.
Li X H, Wang L.Detailed Survey Annual Summary Report of Luokedun Pb-Zn Polymetallic Deposit in Dong Ujimqin Banner, Inner Mongolia[R].Chifeng:Chifeng Mineral Resources Exploration and Development Institute of Inner Mongolia, 2013.
[20] 徐立权, 陈志勇, 陈郑辉, 等.内蒙古东乌旗朝不楞铁矿区中粗粒花岗岩SHRIMP定年及其意义[J].矿床地质, 2010, 29(2):317-322. http://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ201002014.htm
Xu L Q, Chen Z Y, Chen Z H, et al.SHRIMP dating of medium-coarse-grained granite in Chaobuleng iron deposit, Dong Ujimqin Banner, Inner Mongolia[J].Mineral Deposits, 2010, 29(2):317-322. http://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ201002014.htm
[21] 孙彬彬, 刘占元, 周国华.固体载体型元素提取器研制[J].物探与化探, 2011, 35(3):375-378. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201103021.htm
Sun B B, Liu Z Y, Zhou G H.The development of the solid carrier elements extractor[J].Geophysical & Geochemical Exploration, 2011, 35(3):375-378. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201103021.htm
[22] 钱建平, 黄德阳, 谢彪武, 等.西藏谢通门县斯弄多铅锌矿区矿床地质特征和构造地球化学找矿研究[J].大地构造与成矿学, 2013, 37(1):29-41. http://www.cnki.com.cn/Article/CJFDTOTAL-DGYK201301007.htm
Qian J P, Huang D Y, Xie B W, et al.Study on geology and tectono-geochemistry of the Silongduo lead-zinc deposit in Xietongmen country, Tibet[J].Geotectonica et Metallogenia, 2013, 37(1):29-41. http://www.cnki.com.cn/Article/CJFDTOTAL-DGYK201301007.htm
[23] 胡剑辉, 吉蕴生, 曾志钢, 等.新疆萨热克铜矿床地球化学异常评价研究[J].矿产勘查, 2014, 5(2):281-292. http://www.cnki.com.cn/Article/CJFDTOTAL-YSJS201402021.htm
Hu J H, Ji Y S, Zeng Z G, et al.Evaluation of geochemical anomalies of the Sareke copper deposit in Xinjiang[J].Mineral Exploration, 2014, 5(2):281-292. http://www.cnki.com.cn/Article/CJFDTOTAL-YSJS201402021.htm
[24] 赵斌, 陈志兵, 董丽.氢化物发生-原子荧光光谱法测定植物样品中汞硒砷[J].岩矿测试, 2010, 29(3):319-321. http://www.ykcs.ac.cn/article/id/ykcs_20100327
Zhao B, Chen Z B, Dong L.Determination of Hg, Se and As in plant samples by hydride generation-atomic fluorescence spectrometry[J].Rock and Mineral Analysis, 2010, 29(3):319-321. http://www.ykcs.ac.cn/article/id/ykcs_20100327
[25] 程志中, 王学求, 胡忠贤, 等.森林沼泽区富含有机质样品中金的存在形式及对分析的影响[J].物探与化探, 2004, 28(3):206-208. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH200403005.htm
Cheng Z Z, Wang X Q, Hu Z X, et al.Modes of occurrence of gold in samples rich in organic matter from forest-swamp areas and their influence upon analysis[J].Geophysical & Geochemical Exploration, 2004, 28(3):206-208. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH200403005.htm
[26] 贺攀红, 杨珍, 荣耀, 等.氢化物发生-电感耦合等离子体发射光谱法测定铀矿地质样品中痕量硒[J].岩矿测试, 2016, 35(2):139-144. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.02.005
He P H, Yang Z, Rong Y, et al.Determination of trace selenium in uranium-bearing geological samples by hydride generation-inductively coupled plasma-optimal emission spectrometry[J].Rock and Mineral Analysis, 2016, 35(2):139-144. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.02.005
[27] 李自强, 李小英, 钟琦, 等.电感耦合等离子体质谱法测定土壤重金属普查样品中铬铜镉铅的关键环节研究[J].岩矿测试, 2016, 35(1):37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007
Li Z Q, Li X Y, Zhong Q, et al.Determination of Cr, Cu, Cd and Pb in soil samples by inductively coupled plasma-mass spectrometry for an investigation of heavy metal pollution[J].Rock and Mineral Analysis, 2016, 35(1):37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007
[28] 孙彬彬, 张学君, 周国华, 等.地电化学泡塑载体分析质量监控预研究[J].物探与化探, 2016, 40(3):557-560. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201603018.htm
Sun B B, Zhang X J, Zhou G H, et al.Pre-research on analytical quality monitoring for geo-electrochemical foam carrier[J].Geophysical & Geochemical Exploration, 2016, 40(3):557-560. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201603018.htm
-
