Determination of the Magnetic Material Composition in Ultra-low-grade Magnetite by ICP-OES and Washability Evaluation
-
摘要: 超贫磁铁矿是需要通过磁选富集后才能利用的铁矿石，磁性物是其磁选后的主要产品，磁性物中有益有害组分的含量是否满足规范要求是评价超贫磁铁矿可选性的前提，然而尚未引起足够的重视。本文采用电磁分选仪对超贫磁铁矿进行磁选，结合ICP-OES法对原矿和磁性物中有益有害组分（TFe、V2O5、TiO2、P、Cu、Pb、Zn）进行了测定。结果表明，对于含量明显低于规范要求的V2O5、Cu、Pb、Zn，磁选后其含量虽有变化，但不影响冶炼及综合评价的结果；对于TFe、TiO2、P，磁选后其含量发生明显变化，其中TFe由14.23%~16.60%提高至53.95%~69.86%，TiO2由4.43%~5.02%降至0.84%~1.83%，P由0.11%~0.30%降至0.027%~0.048%，已对冶炼及综合评价的结果产生了影响，依据磁性物中TFe、TiO2、P的含量更能切实反映超贫磁铁矿的可选性；所用超贫磁铁矿易于选别，通过单一弱磁选即可获得主要组分（TFe）及有害物质（P、Cu、Pb、Zn）满足炼铁用铁矿石工业要求的精矿；大部分TiO2随弱磁选进入尾矿，后期应注意对尾矿中的TiO2进行评价。该方法可快速获得超贫磁铁矿原矿及磁性物中有益有害组分的含量信息，既能从冶炼角度初步评价超贫磁铁矿的可选性，也可以确定后续综合利用研究的目标元素，对于超贫磁铁矿资源的合理开发利用具有重要的现实意义。
-
关键词:
- 超贫磁铁矿 /
- 磁性物 /
- 有益有害组分 /
- 可选性评价 /
- 电感耦合等离子体发射光谱法
Abstract: Ultra-low-grade magnetite could be used after magnetic separation, resulting in magnetic material being the major product. The content of useful and harmful components in magnetic materials are ideal for the washability evaluation of ultra-low-grade magnetite. However, they have received little attention so far. In this study, electromagnetic separation and Inductively Coupled Plasma-Optical Emission Spectrometry (ICP-OES) were used to determine the contents of useful and harmful compositions (TFe, V2O5, TiO2, P, Cu, Pb, Zn) in raw ore and magnetic material. When the component (V2O5, Cu, Pb, Zn) contents were far lower than the required contents of criterion, the contents of these elements after magnetic separation varied but did not affect the smelt and evaluation results. However, the contents of TFe, TiO2, and P changed obviously after magnetic separation. The TFe content increased from 14.23%-16.60% to 53.95%-69.86%, whereas the TiO2 content decreased from 4.43%-5.02% to 0.84%-1.83%. The P content decreased from 0.11%-0.30% to 0.027%-0.048%, which affected the smelt and evaluation results (in Table 2). The concentrations of TFe, TiO2, and P can be used to reflect the smelt selection of ultra-low-grade magnetite. The concentrate is easily obtained by low intensity magnetic separation and the content of TFe, P, Cu, Pb, Zn meets requirements. Attention should be paid to the evaluation of TiO2 in tailings since most TiO2 is concentrated in the tailings. In conclusion, this is a feasible method to evaluate the washability and define the objective elements of utilization by using electromagnetic separation and ICP-OES. This method can not only evaluate the smelt possibility of ultra-low-grade magnetite but can also determine the elements to be used, making it meaningful to the comprehensive utilization of ultra-low-grade magnetite. -
-
表 1 原矿中全铁及磁性铁的分析结果
Table 1. Analytical results of total iron and magnetic iron in raw ores
样品编号 全铁含量
(%)磁性铁含量
(%)磁性铁占有率
(%)1 14.74 11.63 78.92 2 14.38 10.87 75.61 3 14.23 10.57 74.28 4 16.09 12.64 78.54 5 16.60 13.14 79.14
下载: 导出CSV
表 2 原矿及磁性物中TFe、V2O5和TiO2的分析结果对比
Table 2. Comparison of analytical results of TFe, V2O5 and TiO2 in raw ore and magnetic substance
样品编号 TFe含量 (%) V2O5含量 (%) TiO2含量 (%) 原矿 磁性物 原矿 磁性物 原矿 磁性物 1 14.74 62.52 0.051 0.065 5.02 1.45 2 14.38 63.59 0.042 0.052 4.43 1.44 3 14.23 53.95 0.054 0.058 4.94 1.83 4 16.09 66.34 0.052 0.064 4.98 1.04 5 16.60 69.86 0.065 0.083 4.95 0.84
下载: 导出CSV
表 3 原矿及磁性物中P、Cu、Pb和Zn的分析结果对比
Table 3. Comparison of analytical results of P, Cu, Pb and Zn in raw ore and magnetic substance
样品编号 P含量 (%) Cu含量 (%) Pb含量 (%) Zn含量 (%) 原矿 磁性物 原矿 磁性物 原矿 磁性物 原矿 磁性物 1 0.19 0.036 0.019 0.037 0.0004 0.0016 0.0085 0.0051 2 0.11 0.027 0.0029 0.0056 0.0004 0.0016 0.010 0.0061 3 0.21 0.048 0.0056 0.010 0.0005 0.0014 0.0078 0.0042 4 0.15 0.032 0.020 0.036 0.0005 0.0018 0.010 0.0050 5 0.30 0.040 0.027 0.056 0.0003 0.0018 0.011 0.0063
下载: 导出CSV
-
[1] 谢承祥, 张晓华, 王少波, 等.承德市超贫 (钒钛) 磁铁矿特征[J].矿床地质, 2006, 25(增刊):487-490. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ200611003126.htm
Xie C X, Zhang X H, Wang S B, et al.Characteristics of the extremely poor vanado-titanomagnetite deposit in Chengde City, Hebei Province[J].Mineral Deposits, 2006, 25(Supplement):487-490. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ200611003126.htm
[2] 肖克炎, 娄德波, 阴江宁, 等.中国铁矿资源潜力定量分析[J].地质通报, 2011, 30(5):650-660. http://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD201105004.htm
Xiao K Y, Lou D B, Yin J N, et al.Quantified research on iron potential of China[J].Geological Bulletin of China, 2011, 30(5):650-660. http://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD201105004.htm
[3] 郝兴中, 祝德成, 王巧云, 等.山东省单县地区铁矿成矿规律探讨[J].地质论评, 2015, 61(增刊):818-819. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ201310009013.htm
Hao X Z, Zhu D C, Wang Q Y, et al.Iron ore metallogeic regularities in Shanxian, Shandong Province[J].Geological Review, 2015, 61(Supplement):818-819. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ201310009013.htm
[4] 周红春, 刘传权, 李中明, 等.河南嵩县南岭超贫磁铁矿的地质特征与找矿模式[J].现代地质, 2010, 24(1):89-97. http://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201001012.htm
Zhou H C, Liu C Q, Li Z M, et al.Geological characteristics and prospecting pattern of Nanling ultra poor magnetite in Songxian, Henan[J].Geoscience, 2010, 24(1):89-97. http://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201001012.htm
[5] 李亚娟.本溪大连洲铁矿工艺矿物学及选矿方法研究[D].沈阳:东北大学, 2011.
Li Y J.Process mineralogy and beneficiation process of Dalianzhou iron ore in Benxi[D].Shenyang:Northeastern University, 2011.
[6] Nie Y M, Lu X L, Dai Q H, et al.Mineral processing experiment research of low grade magnetite[J]. Advanced Materials Research, 2013, 641-642:448-451. doi: 10.4028/www.scientific.net/AMR.641-642
[7] Luo J H, Qiu K H, Qiu Y C, et al.Studies of mineralogical characteristics on vanadium titanium magnetite in Hongge area, Panzhihua, Sichuan, China[J]. Advanced Materials Research, 2013, 813:292-297. doi: 10.4028/www.scientific.net/AMR.813
[8] 刘长淼, 吴东印, 王守敬, 等.云南安益钛磁铁矿选铁试验研究[J].中国矿业, 2014, 23(2):119-121. http://www.cnki.com.cn/Article/CJFDTOTAL-ZGKA201402032.htm
Liu C M, Wu D Y, Wang S J, et al.Experimental of recovering titanic magnetite from Anyi mine in Yunnan Province[J].China Mining Magazine, 2014, 23(2):119-121. http://www.cnki.com.cn/Article/CJFDTOTAL-ZGKA201402032.htm
[9] 罗金华.红格钒钛磁铁矿主要元素在选矿中的分布[J].矿产综合利用, 2015(3):55-58. http://www.cnki.com.cn/Article/CJFDTOTAL-KCZL201503014.htm
Luo J H.Distribution of main elements of Hongge vanadium titano-magnetite in mineral processing[J].Multipurpose Utilization of Mineral Resources, 2015(3):55-58. http://www.cnki.com.cn/Article/CJFDTOTAL-KCZL201503014.htm
[10] 翟雪, 曹亦俊, 吴晓燕.安徽某含硫磁铁矿的工艺矿物学试验研究[J].矿冶, 2015, 24(4):84-88. http://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201504021.htm
Zhai X, Cao Y J, Wu X Y.Process mineralogy study on a sulfur-bearing magnetite ore in Anhui[J].Mining & Metallurgy, 2015, 24(4):84-88. http://www.cnki.com.cn/Article/CJFDTOTAL-KYZZ201504021.htm
[11] Liu D, Li J L, Wen S M, et al.Beneficiation experiment study on iron ore in Yunnan Province[J].Applied Mechanics & Materials, 2015, 737:813-816.
[12] Chokshi Y, Limaye M A, Dutta S K, et al.Mineralogical studies of low-grade iron ore from Jharkhand-Orissa Region, India[J].Transactions of the Indian Institute of Metals, 2016, 69(1):151-155. doi: 10.1007/s12666-015-0740-4
[13] 张洋, 郑诗礼, 王晓辉, 等.ICP-AES法对铬铁矿中的多种元素进行定性与定量分析[J].光谱学与光谱分析, 2010, 30(1):251-254. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN201001067.htm
Zhang Y, Zheng S L, Wang X H, et al.Qualitative and quantitative analysis of various elements in chromite ore by ICP-AES[J].Spectroscopy and Spectral Analysis, 2010, 30(1):251-254. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN201001067.htm
[14] 马生凤, 温宏利, 马新荣, 等.四酸溶样-电感耦合等离子体原子发射光谱法测定铁、铜、锌、铅等硫化物矿石中22个元素[J].矿物岩石地球化学通报, 2011, 30(1):65-72. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201101010.htm
Ma S F, Wen H L, Ma X R, et al.Determination of 22 elements in iron, copper, zinc, and lead sulphide ores by ICP-AES with four acids digestion[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2011, 30(1):65-72. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201101010.htm
[15] 孙喜顺, 王彦茹, 阎雪.电感耦合等离子体原子发射光谱法测定钒钛铁精矿中的钒钛铝镁锰[J].冶金分析, 2011, 31(8):79-82.
Sun X S, Wang Y R, Yan X.Determination of vanadium, titanium, aluminium, magnesium and manganese in vanadium-titanium-iron concentrate by inductively coupled plasma atomic emission spectrometry[J].Metallurgical Analysis, 2011, 31(8):79-82.
[16] 胡艳巧, 程文翠, 支云川, 等.四酸溶矿-电感耦合等离子体发射光谱法测定铬铁矿中多种元素[J].分析试验室, 2016, 35(11):1312-1316. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201611017.htm
Hu Y Q, Cheng W C, Zhi Y C, et al.Simultaneous determination of 11 elements in chromites by inductively coupled plasma-atomic emission spectrometry with HCl-HNO3-HF-HClO4 digestion method[J].Chinese Journal of Analysis Laboratory, 2016, 35(11):1312-1316. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201611017.htm
[17] 黄瑞成, 肖洁, 魏灵巧, 等.新型磁选装置的研制及其应用于分离超贫磁铁矿中的磁性铁[J].岩矿测试, 2015, 34(2):213-217. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150210&flag=1
Huang R C, Xiao J, Wei L Q, et al.Development of a new magnetic separation device and its application in separation of magnetic iron in ultra-low-grade magnetite[J]. Rock and Mineral Analysis, 2015, 34(2):213-217. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150210&flag=1
[18] 吕宪俊, 邱俊, 陈平, 等.新疆某低品位铁矿石工艺矿物学研究[J].金属矿山, 2009(6):99-116. http://www.cnki.com.cn/Article/CJFDTOTAL-JSKS200906034.htm
Lü X J, Qiu J, Chen P, et al.Investigation on the process mineralogy of a low grade iron ore from Xinjiang[J].Metal Mine, 2009(6):99-116. http://www.cnki.com.cn/Article/CJFDTOTAL-JSKS200906034.htm
[19] 班俊生, 任金鑫, 刘桂珍, 等.磁铁矿中磁性物成分的测定及可选性评价[J].岩矿测试, 2013, 32(3):469-473. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20130321&flag=1
Ban J S, Ren J X, Liu G Z, et al.Determination of the magnetic material composition in magnetite ore and processability evaluation[J].Rock and Mineral Analysis, 2013, 32(3):469-473. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20130321&flag=1
[20] 王斌.安徽某高硫磁铁矿选矿试验[J].现代矿业, 2014, 30(9):56-59. http://www.cnki.com.cn/Article/CJFDTOTAL-KYKB201409021.htm
Wang B.Benificiation experiment on a high-sulphur magnetite ore in Anhui[J].Modern Mining, 2014, 30(9):56-59. http://www.cnki.com.cn/Article/CJFDTOTAL-KYKB201409021.htm
[21] 靳建平, 李英, 吴天骄, 等.陕西某含硫磁铁矿选矿试验[J].现代矿业, 2016, 32(1):91-93. http://www.cnki.com.cn/Article/CJFDTOTAL-KYKB201601033.htm
Jin J P, Li Y, Wu T J, et al.Benificiation experiment on a sulphur-bearing magnetite ore in Shanxi[J].Modern Mining, 2016, 32(1):91-93. http://www.cnki.com.cn/Article/CJFDTOTAL-KYKB201601033.htm
-
